High-Lift Pallet Trucks
Manual High-Lift Pallet Truck
National Distributor, Local Service
Adjustable stabilisers
Overload/Pressure relief valve
Self-lubricating brushes
Sealed hydraulic system
Single nylon rollers
Quicklift below 250kg
WARRIOR HIGH-LIFT PALLET TRUCKS are designed for use with
open-bottomed pallets, and are intended to ease the physical strain of
lifting tasks. With a higher lift height than standard pallet trucks, high-lift
trucks elevate loads to optimal working heights for your team, well-suited
for use as a work bench or at the end of production lines.
MODEL CAPACITY
(KG)
WR10540 1000 1170 x 540 85 800 Ø 180 x 50 Ø 75 x 50 75
WR10680 1000 1170 x 685 85 800 Ø 180 x 50 Ø 75 x 50 75
FORK DIMENSIONS
(MM)
LOWERED FORK
HEIGHT (MM)
RAISED FORK HEIGHT
(MM)
STEERING WHEEL
DIMENSIONS (MM)
HEAVY
DUTY
LOAD ROLLER
DIMENSIONS (MM)
NET WEIGHT
(KG)
Electric High-Lift Pallet Truck
Adjustable stabilisers
Overload/Pressure relief valve
Self-lubricating brushes
Sealed hydraulic system
Single nylon rollers
0.8kW lifting motor
12V/6Ah sealed gel battery and built-in charger
Elevate your workplace safety and uplift your team with a
WARRIOR ELECTRIC HIGH-LIFT PALLET TRUCK, engineered
to reduce strain injury and provide a high-lift solution where
standard pallet trucks will not suffice.
MODEL CAPACITY
(KG)
WRACX-10E 1000 1170 x 540 85 800 Ø 180 x 50 Ø 75 x 50 12V/60AH 75
WRACX-10EW 1000 1170 x 680 85 800 Ø 180 x 50 Ø 75 x 50 12V/60AH 75
FORK DIMENSIONS
(MM)
LOWERED FORK
HEIGHT (MM)
RAISED FORK HEIGHT
(MM)
STEERING WHEEL
DIMENSIONS (MM)
LOAD ROLLER
DIMENSIONS (MM)
BATTERY NET WEIGHT
(KG)
T: 01384 423330 E: [email protected]8
