SCA-DUAL
SCP-120
FEATURES & BENEFITS
Operates electrically- and mechanically-held
contactors for pilot duty applications
ADVANCED ROOF & GUTTER CONTROL
PREMIUM SNOW MELT CONTROL
Voltage: 100 - 277 Vac; 50/60 Hz
Features weather-resistant NEMA 4X enclosure
C-UL-US Listed
Adjustable hold-on timer continues heater
operation up to 8 hours after snow and ice
accumulation stop to ensure complete melting
Maximum 2 sensor capability
Automatic and manual override operator controls
Use with the GTR-SS and/or AIR-SS
Minimize
Operating Costs
Automatic and
manual-override
operator controls
Handles resistive loads up to 30 amps
Easy to Operate
0101
SCA-DUAL
SCP-120
About the Advanced Roof & Gutter Control
The SCA-DUAL provides for advanced control of snow melting and roof and gutter deicing systems to minimize
operating costs. It operates electrically- and mechanically-held contactors for pilot duty applications. With automatic
and manual override operator controls, the SCA-DUAL includes an adjustable hold-on timer to continue heater
operation up to 8 hours after snow and ice accumulation stop to ensure complete melting.
Featuring a weather-resistant NEMA 4X enclosure, this unit handles resistive loads up to 30 amps and operates at
100 - 277 Vac and 50/60 Hz. C-UL-US Listed, the SCA-DUAL has a maximum 2 sensor capability and can be used
with the GTR-SS and/or AIR-SS sensors.
ADVANCED ROOF & GUTTER CONTROL
PRODUCTS
SCP-120
Advanced Snow
Melt Control
GTR-SS
Gutter-Mounted
Ice Sensor
RCO - Remote
Control Override
AIR-SS- Aerial
Mounted Sensor
02
ADVANCED ROOF & GUTTER CONTROL
SCA-DUAL
Specifications
Specifications
SCA-DUAL Advanced Snow Melt Control
Area of use Nonhazardous locations
Approvals 109R Type 873 Temperature Regulating Equipment
Enclosure Protection NEMA 4X
Material Polycarbonate
Mounting Wall mount
Dimensions 5 1/2" (L) x 8 1/8" (W) x 4 3/8" (H) / 140mm (L) x 207mm (W) x 112mm (H)
Supply voltage 100 – 277 VAC; 50/60 Hz
Load 7 amp maximum inductive
30 amp maximum resistive
Contact type 2 Form A
Weight 3 Pounds (not including sensors)
Maximum ratings Voltage: 120 VAC
Current: 30 amps
Heater Hold-On timer 0 to 8 hours; actuated by snow stopping or toggle switch
System test Switch toggles heater contact on and o.
If temperature exceeds optional high limit thermistor
(45°F), heater shuts o to reduce costs and prevent damage.
Status indicator SUPPLY (green): Power on
HEAT (yellow): Heating cycle in progress
SNOW (yellow): Sensor(s) detect snow
Snow/Ice Sensors
Sensor type Up to 6 sensors
Circuit type NEC Class 2
Lead length Up to 500' (152m) using 18 AWG 3-wire jacketed cable,
Up to 2,000' (609m) using 12 AWG 3-wire jacketed cable
RLY-Series
Model RLY-4PL
Enclosure NEMA 1
Dimensions 10” x 8” x 4” (254mm x 203mm x 102mm)
Contains 2 relays for a total of 4 poles
Controls 4 circuits at 120 VAC or 277 VAC or 2 circuits at 208 VAC or 240 VAC
Model RLY-8PL
Enclosure NEMA 1
Dimensions 12” x 10” x 4” (305mm x 254mm x 102mm)
Contains 4 relays for a total of 8 poles
Controls 8 circuits at 120 VAC or 277 VAC or 4 circuits at 208 VAC or 240 VAC
Model RLY-12PL
Enclosure NEMA 1
Dimensions 16” x 12” x 4” (406mm x 305mm x 102mm)
Contains 6 relays for a total of 12 poles
Controls 12 circuits at 120 VAC or 277 VAC or 6 circuits at 208 VAC or 240 VAC
NOTE: Relays do NOT contain circuit breaker devices
ORDERING
ORDERING
Accessories
AIR-SS Aerial Mounted Snow Sensor
GTR-SS Gutter Mounted Ice Snesor
SMP Snow Melting Plaque
LIMITED WARRANTY
WarmlyYours’ two year limited warranty covering defects in workmanship and materials applies.
Contact Warmly Yours at (800) 875-5285 or go to www.WarmlyYours.com for complete information
For more information, operating and
For more information, operating and
technical manuals, please refer to
technical manuals, please refer to
www.warmlyyours.com.
www.warmlyyours.com.
*Product specifications
*Product specifications
are subject to change.
are subject to change.
