Waring FP40C User Manual
FP40C
Operation Manual for Waring
FP40 and FP40C Food Processors
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed including these:
1. Read all instructions.
2. Blades are sharp. Handle carefully.
3. Your Waring food processor is a piece of kitchen equipment and like all other kitchen equipment,
extreme care must be used when operating it. Although training requirements are minimal, only
responsible and prudent individuals should be allowed to operate this food processor.
4. To avoid injury, never place cutting blade or disc on base without first having put the bowl properly
in place.
5. Keep hands as well as spatulas and other utensils away from moving blades or discs while processing
food to prevent the possibility of severe personal injury or damage to the food processor. A plastic
scraper may be used, but must be used only when the food processor is not running.
6. To protect against risk of electrical shock, do not put base in water or other liquid.
7. Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.
To unplug, grasp plug and pull from electrical outlet. Never pull cord.
8. Avoid contacting moving parts. Never feed food by hand when slicing or shredding.
Always use food pusher.
9. Make sure motor has completely stopped before removing the lid.
10. Do not operate any appliance with a damaged cord or plug, or after appliance has been dropped or
damaged in any manner. Return appliance to the nearest authorized service facility for examination,
repair or adjustment.
11. The use of attachments not recommended or sold by Waring may cause fire, electric shock or injury.
12. Do not use outdoors.
13. Do not let cord hang over edge of table or counter, or touch hot surfaces.
14. This product is UL listed for commercial use. Use it only for food preparation as described in
this book.
15. Do not attempt to defeat the cover interlock mechanism.
16. Be certain cover is securely locked in place before operating appliance.
17. If the machine malfunctions for any reason, discard any food being processed at that time.
SAVE THESE INSTRUCTIONS
2
GROUNDING INSTRUCTIONS
GROUNDING INSTRUCTIONS
• For your protection, this appliance is equipped with a 3-conductor cordset.
• 120 volt units are supplied with a molded 3-prong grounding-type plug, and should be used in
combination with a properly connected grounding-type outlet as shown in Figure A.
If a grounding-type outlet is not available, an adapter, shown in Figure B, may be obtained to
enable a 2-slot wall outlet to be used with a 3-prong plug.
Referring to Figure C, the adapter must be grounded by attaching its grounding lug under the
screw of the outlet cover plate.
CAUTION: Before using an adapter, it must be determined that the outlet cover plate screw is
properly grounded. If in doubt, consult a licensed electrician.
Never use an adapter unless you are sure it is properly grounded.
NOTE: USE OF AN ADAPTER IS NOT PERMITTED IN CANADA.
• 240 Volt units are supplied without a plug, and an appropriate one must be installed by user in
accordance with local electrical codes observing the following cordset conductor color coding:
GREEN/YELLOW: EARTH GROUND BLUE: NEUTRAL BROWN: LIVE
For your protection, this appliance is equipped with a 3-conductor cordset.
120 volt units are supplied with a molded 3-prong grounding-type plug (NEMA5-15P), and should be used
in combination with a properly connected grounding-type outlet as shown in Figure A.
If a grounding-type outlet is not available, an adapter, shown in Figure B, may be installed to allow a
3-prong plug to be used in a 2-slot wall outlet.
Ground the adapter by attaching its grounding lug under the screw of the outlet cover plate (see figure c).
CAUTION: Before using an adapter, it must be determined that the outlet cover plate screw is
properly grounded. If in doubt, consult a licensed electrician. Never use an adapter unless you are
sure it is properly grounded.
NOTE: USE OF AN ADAPTER IS NOT PERMITTED IN CANADA. 220-240 volt “GS Safety
Approved” units are supplied with a molded European grounding-type plug (CEE 7/7).
220-240 volt standard units are supplied without a plug, and an appropriate one must be installed by user
in accordance with local electrical codes:
NOTE: USER-INSTALLED CORDSET PLUGS ARE NOT PERMITTED IN EUROPE.
3
INTRODUCTION
The Waring®FP40 and FP40C commercial food processors are the most versatile food processors in their
class. These professional machines benefit from Waring’s forty years of commercial food service experience
as well as thirty years of food processing experience by the same technical, engineering, manufacturing and
development team that has made Cuisinart the best known name in food processors.
These machines are both NSF and Commercial UL listed. The accessories are also NSF listed.
This instruction book describes two models. One model, the FP40, comes with a work bowl (also known as
a batch bowl) and a cutter blade (or S-Blade) to CHOP, GRIND, PURÉE, MIX or KNEAD in the batch
bowl. WHAT MAKES THIS MACHINE UNIQUE IS THAT THE BATCH BOWL ALSO ALLOWS
YOU TO PROCESS IN THE BOWL, which means you can SHRED, GRATE, SLICE, or JULIENNE
in the bowl WITHOUT NEED OF A CONTINUOUS FEED CHUTE! The FP40 is shipped from our
factory with a starter kit that includes a
The second model, the FP40C, comes with the same attachments as the FP40 but also INCLUDES a
CONTINUOUS FEED CHUTE to do large volume processing such as shredding, grating, slicing
and julienne.
Many additional processing accessories are available for both models. More will be added.
Size, Power and Convenience
The full one-and-one-half horsepower motor of this food processor is more powerful than other food
processors of comparable 4.0 quart size.
The wide feed tube is convenient for large volume processing of large foods; the drive shaft is of stainless
steel for durability; the housing, work bowl, chute, covers and pushers are all made from durable
polycarbonate for heavy use conditions and easy cleanup. The clear bowl and processing covers are
convenient for viewing food processing results, and extremely heavy duty for standing up to daily use.
3
⁄16" shredding disc and a 1⁄8" slicing disc.
Use it well and use it often. Waring’s food processors will be an aid to making good food and plenty of it!
4
CONTENTS
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Grounding Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
The Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembly of Batch Bowl Parts, FP40 & FP40C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Disassembly of Batch Bowl Parts, FP40 & FP40C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Assembly of Continuous Feed Chute Parts, FP40C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disassembly of Continuous Feed Chute Parts, FP40C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operating the Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Food Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Food Pusher Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Use Instructions for S-Blade (Cutter Blade) in the Batch Bowl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Use Instructions for Accessory Discs in the Continuous Feed Chute. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Accessory Disc Selection and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Slicing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Slicing Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Waved Slicing Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Pulping/Grating/Shredding Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Grating Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Julienne Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Julienne Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Safety Reset Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Processing Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5
THE PARTS
The Waring®FP40 and FP40C food processors are compact, easy-to-use appliances. Completely assembled,
the FP40 is only 21" high (53.3cm) and stores conveniently when not in use. For more compact
storage, the cover can be stored upside down with the feed tube in the bowl. When stored this way, the unit
is only 151⁄2" high (39.4 cm).
The Waring FP40 and FP40C food processors both consist of the following standard parts and accessories:
1. Solid Polycarbonate Motor Base with vertical stainless steel shaft
2. Two Control Levers
a. ON
b. PULSE/OFF
3. Safety Interlock Tower
Prevents machine from operating until cover is in place
4. Clear Work Bowl with 8" diameter (20.3cm)
Dry capacity of 4 quarts
Wet capacity of 3.8 quarts
5. Clear Work Bowl Cover
a. Large-Feed Kidney-Shaped Feed Tube for maximum use of cutting surface
61⁄8" (15.5 cm) x 3" (7.6 cm) wide
b. Large Pusher with full size and reduced size feed options
c. Small Pusher within the large pusher for smaller vegetables and pepperoni, etc.
Note: This combination pusher allows use of the entire feed tube for
large foods and provides controlled processing for small diameter foods
such as carrots, celery and pepperoni.
Sharp and durable S-Blade (Cutter Blade) to chop, grind, purée, mix and knead
6.
7. 3 mm, 1⁄8" Slicing Disc
8. 5 mm, 3⁄16" Shredding Disc
9. Safety Reset Switch
The FP40C comes with these additional components:
10. Continuous Feed Chute
11. Clear Cover for Feed Chute
12. Slinger
6
BATCH
BOWL
CONTINUOUS
FEED
5c
5c
5b
5b
5a
5a
11
5
12
6
3
1
2a
FP40 is batch bowl model
2b
7
8
4
3
9
2a
FP40C is combination model with
batch bowl and continuous parts
2b
10
1
7
ASSEMBLY of BATCH BOWL PARTS
(FP40 & FP40C)
We will use the terms Work Bowl, Batch Bowl and Cutter Bowl interchangeably throughout this
instruction book. They mean the same thing.
• Clean and sanitize the motor base, and wash, rinse, and sanitize the bowl, cover, food pusher, food pusher
insert and processing tools prior to initial use.
• Place the base on a counter or table near a 3-prong electrical outlet. Position it so you look at the front of
the unit and can see the control paddles. Be certain that the cord is unplugged and the OFF switch paddle
has been pressed. Do not plug in the cord until the processor is completely assembled.
• Pick up the transparent work bowl, holding it in both hands with the handles at the 4 and 10 o’clock position.
• Place the bowl on the base, fitting its central tube over the motor shaft on the base and placing its handles
at the 4 and 10 o’clock positions.
• Press the bowl down so the lower rim fits around the circular platform. Turn the bowl counterclockwise
as far as it will go. It will lock into position with the tabs on the sides of the platform.
Read this if Assembling the Batch Bowl Parts to use S-Blade (Cutter Blade).
• Do not put any food in the bowl before assembling the S-Blade to the shaft.
• Pick up the metal blade, being careful to grasp the plastic hub. Do not touch the metal blades, as they are
very sharp.
• Place the S-Blade over the tip of the motor shaft, lining up the inside of the hub with the shaft. Press it
down firmly, rotating the center hub until the blade assembly is fully seated. It should easily drop into
place. Be sure it is pushed down as far as it will go. If it is not all the way down, it may become damaged.
Push only on the center section (plastic part); never touch the cutting blade as it is extremely sharp.
• Check to be sure the blade is all the way down by turning it back and forth while lightly pushing it down.
If properly installed and fully seated, the lower blade will be positioned just above the inside bottom of
the bowl.
• If processing food with the S-Blade, now is the time to add the food or liquid to the work bowl.
Read this if Assembling Batch Bowl Parts to use Accessory Discs in Batch Bowl.
• Do not put any food in the bowl before placing the accessory disc onto the shaft.
• Select the appropriate accessory disc: Grating disc, shredding disc, slicing disc, waved slicing disc, pulping
disc, or julienne/French fry disc.
• Each of these discs had a disc stem. The disc stem fits over the double flat in the food processor’s stainless
steel motor shaft. The stem will also fit inside either the clear plastic tube inside the bowl or the
continuous feed chute and slinger.
• After selecting the appropriate disc, pick up the disc, either using the finger holes on the disc surface,
or holding the disc firmly between both hands. Be careful not to grab the blades or scrape your hands
on the shredding / grating nodules.
• Carefully guide the center disc hub over the metal shaft so the double slots in the hub line up with the pin
in the shaft. Put the disc on top of the shaft and rotate until it drops down and into place. Be sure it is
pushed down as far as it will go. Push on the outside rim only; never touch the cutting blades. It should
easily drop into place, but if not, then gently rock back and forth until you feel the disc drop into place.
• The FP40 and FP40C food processors have a locking mechanism that will secure the discs in place while
the machine is running. T
hold it securely in place.
• When it is time to remove the accessor
the disc straight up. The r
Note: Do not put any food in the bowl before placing the accessory disc onto the shaft.
wo locking pins on the shaft mesh with slots in the hub of the accessory disc and
otation moves the pin out of the slot in the disc’
y disc, r
otate the disc counter
clockwise as far as you can, and pick
s center hub.
8
Batch Bowl Assembly continued…….
• Place the cover on the bowl, with the feed tube on the left, slightly toward the front. The locking tabs on
the cover should be at the left of the locking tabs on the front rim of the work bowl.
• Rotate the cover counterclockwise to lock it into place. When the cover is rotated into place, the safety
interlock tab on the back rim of the cover will deactivate the safety interlock mechanism located in the
safety interlock tower.
• The cover must be in place correctly, with the cover’s safety interlock tab firmly engaged with the
tower’s magnetic safety interlock mechanism, for the food processor to operate. This is an important
safety feature.
NEVER ATTEMPT TO START THE FOOD PROCESSOR
WITHOUT THE COVER LOCKED INTO POSITION.
Two Pushers for Feed Tube
Pick up the large food pusher and the small food pusher. The large
pusher is for processing larger vegetables. The smaller
pusher nests in the larger pusher and can be used for smaller
vegetables, guiding long thin vegetables for more precise cuts
or for jobs like slicing pepperoni.
Large Pusher
Insert the small food pusher into the large food pusher opening.
When it is fully inserted, rotate the small pusher clockwise to lock it
into place. Now you are ready to insert the large pusher into the feed
tube opening. Drop the pusher into the feed tube gently.
Small Pusher
To use the small pusher, rotate it counterclockwise to disengage the
locking feature. Now you can lift the small pusher up and out of the
large pusher. When using the small pusher, the large pusher now
becomes the feed tube for the small pusher.
9
Loading...
