Waring CB15V Part List

OPEN
LOCK
OPEN
OPEN
LOCK
CBL10
Hot Blending Lid
(optional)
3
1
2
19
One Gallon Variable Speed Blender
CB15V
20
21
4
5
6
5
13
22
7
8 9
10
18
23
11
Unit Information
12
12
14
15
16
3 Limited Motor Warranty
15.0 Amps.
1,700-18,500 RPM’s (no load)
®
NSF
24
25
013304
NSF Seal
17
27
502235
Container with Blending Assembly
704587
502977
Blending Assembly
Graphic by: Sandra A. Montysko Revised July 19, 2018 Approved 7/19/18 Page 1 of 5
Container Complete with Lid
26
STANDBY
START/STOP
PULSE
T
28
29
HEAVY DUTY VARIABLE
SPEED BLENDER
030201
Control Panel Assembly
STANDBY
START/STOP
PULSE
T
HEAVY DUTY
VARIABLE
SPEED BLENDER
31
Blender Unit Components
CB15V
30
35
36
37
33
49
46
50
51
41
32
34
40
38
39
44
45
42
47
48
43
Page 2 of 5 Revised July 19, 2018
Catalog# Model
(after 9/27/2016)
CB15V
Convert Back
to CB15V
CB15VG CB15V CB15VS
(after 2/25/2016)
(after 10/7/2010)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790 Tele. 1-800-269-6640
www.waringcommercialproducts.com
Fax 860-496-9017
Illustration# Part# Description
1 024000 Hot Blending Outer Lid
2 026496 Hot Blending Outer Lid Gasket
3 023998 Hot Blending Baffle Cup
4 002972 Cap Nut
5 027581 Flat Washer
6 027683 Blade
7 018389 "O" Ring
8 027582 Bearing Cap
9 018390 Small "V" Ring
10 023934 Bearing Holder
11 004946 Washer
12 018386 Bearing
(2 required)
(2 required)
13 023926 Spacer
14 023907 Spring Washer
15 023927 Retaining Ring
16 023906 Large "V" Ring
17 023933 Drive Shaft
18 025817 Key
19 028530 Cover Insert
20 028226 Outer Lid
21 008791 Latch Wire
(3 required)
22 502773 Bracket Assembly (spot welded to container 3 required)
23 023909 Double Handle Container
24 502977 Blending Assembly
25 004949 Container Support Gasket
26 025571 Container Support
27 012008 Lock Nut
28 503328 Coupling
29 025871 Jar Pad
30 028025 Top Housing
(changed after 9/17/2010)
Revised July 19, 2018 Page 3 of 5
Catalog# Model
(after 9/27/2016)
CB15V
Convert Back
to CB15V
CB15VG CB15V CB15VS
(after 2/25/2016)
(after 10/7/2010)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790 Tele. 1-800-269-6640
www.waringcommercialproducts.com
Fax 860-496-9017
Illustration# Part# Description
31 503527 Control Panel Assembly Relabled (on units after 5/25/2018) 030201 Control Panel Assembly
32 029888 Control Panel Rear
33 026497 Screw
34 030453 Control Panel Baffle
35 002984 Washer (4 required on units after 9/27/2016) 003344 Washer (4 required on units after 2/25/2016)
002984 Washer (4 required)
36 016691 Bolt (4 required on units after 9/27/2016) 019098 Screw (4 required on units after 2/25/2016) 016691 Blot (4 required)
37 035520 Leili Motor (changed after 11/8/2017) 029875 ECM Motor with MTP & Sensor (on units after 9/27/2016)
503472 Groscopp Motor Modified (on units after 2/25/2016 use 036445) 029875 ECM Motor with MTP & Sensor (on units after 8/8/2013) 503323 Motor with Sensor 029875 ECM Motor with MTP & No Sensor
(4 required)
(on units after 9/27/2016)
(on units after 9/12/2012)
38 026318 Baffle (on units after 9/27/2016)
035355 Baffle (on units after 2/25/2016) 026318 Baffle
39 018791 Screen
40 026500 Screw
(6 required)
41 013731 Cable Tie (2 required on units after 3/14/2013) 013731 Cable Tie (5 required)
42 018811 Strain Relief
43 503329 Cord Set
44 002943 Ground Washer
45 027278 Ground Screw
46 026317 Bottom Housing
47 002984 Washer
(4 required)
48 026412 Screw (4 required)
49 026296 Foot (4 required)
50 018314 Washer (4 required)
51 026493 Screw (4 required)
Page 4 of 5 Revised July 19, 2018
Catalog# Model
(after 9/27/2016)
CB15V
Convert Back
to CB15V
CB15VG CB15V CB15VS
(after 2/25/2016)
(after 10/7/2010)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790 Tele. 1-800-269-6640
Groschopp Motor Parts No Longer Used
019098
Screw
035576
Brush Cap
(2 required)
035575
Brush & Spring Assembly
(2 required)
(on units after 2/25/2016 thru 9/27/2016)
003344
Washer
503472
Motor
(use 036445)
030405
Screw
030187
Hall Effect Sensor
CB15 Groschopp Motor Replacement Kit
036445
www.waringcommercialproducts.com
Fax 860-496-9017
035355
Baffle
Brush & Spring Assembly
027381
(2 required used with ECM motors)
033485
Brush Cap
(2 required used with ECM motors)
Motor
Black
002984
Washers
035520
Leili Motor
Hall Effect Sensor
016691
Bolts
3
2
030453
Control Panel Baffle
026318
Motor Baffle
Green
Black
Red
1
Wiring Diagram
Green/Yellow
Brown
Blue
Red
ACNACL
M+M-
Revised July 19, 2018 Page 5 of 5
