1
19
OPEN
LOCK
OPEN
LOCK
OPEN
LOCK
CBL10
Hot Blending Lid
(optional)
3
4
5
6
5
7
8
9
2
20
One Gallon Blender
and Spigot Container
CB15SF
Unit Information
3 Limited Motor Warranty
15.0 Amps.
1,700-18,000 RPM’s (no load)
25
26
17
13
12
12
16
14
10
15
11
18
28
27
29
30
21
22
23
®
NSF
013304
NSF Seal
502977
Blending Assembly
Graphic by: Sandra A. Montysko Revised June 18, 2019 Approved 6/18/19 Page 1 of 5
31
24
503433
Container with Blending Assembly and Spigot
32
POWER
ON/OFF
STOP
LOW MED HIGH
35
HEAVY DUTY
BLENDER
PULSE
37
36
38
33
Blender Unit Components
34
Used with 035520 Motors
CB15SF
39
40
41
53
48
54
55
45
49
50
43
44
51
52
033485
Brush Cap
(2 required)
027381
Brush & Spring Assembly
(2 required)
47
42
46
Page 2 of 5 Revised June 18, 2019
Catalog Model
CB15SF
CB15N CB15G CB15SF
(after 9/22/2016)
(after 12/3/2015)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
www.waringcommercialproducts.com
Illustration# Part# Description
1 024000 Hot Blending Outer Lid
2 026496 Gasket
3 023998 Hot Blending Baffle Cup
4 002972 Cap Nut
5 027581 Flat Washer
6 027683 Blade
7 018389 "O" Ring
8 027582 Bearing Cap
9 018390 Small "V" Ring
10 023934 Bearing Holder
11 004946 Washer
12 018386 Bearing
13 023926 Spacer
(2 required)
(2 required)
Fax 860-496-9017
14 023907 Spring Washer
15 023927 Retaining Ring
16 023906 Large "V" Ring
17 023933 Drive Shaft
18 025817 Key
19 028530 Cover Insert
20 028226 Outer Lid
21 034026 "O" Ring
22 033965 Spigot Assembly
23 034320 Spigot Rubber Insert
24 034016 Spigot Plug
25 008791 Latch Wire
(3 required)
26 502773 Bracket Assembly (spot welded to container 3 required)
27 503434 Container-Adapter Assembly
28 502977 Blending Assembly
(complete)
29 004949 Gasket for container base
30 025571 Container Support
(container base)
31 012008 Lock Nut
Revised June 18, 2019 Page 3 of 5
Catalog Model
CB15SF
CB15N CB15G CB15SF
(after 9/22/2016)
(after 12/3/2015)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
www.waringcommercialproducts.com
Fax 860-496-9017
Illustration# Part# Description
32 503328 Coupling with Magnet Ring
33 025871 Jar Pad
34 028025 Top Housing
35 030893 Control Panel
36 029888 Rear Control Panel
37 026497 Screw
38 030453 Control Panel Baffle
39 002984 Washer
003344 Washer (on units after 12/3/2015)
002984 Washer (4 required)
40 016691 Bolt (4 required on units after 9/22/2016)
019098 Screw (4 required on units after 12/3/2015)
016691 Bolt (4 required)
41 035520 Leili Motor (on units after 7/13/2017)
029875 Motor (on units after 9/22/2016)
503472 Motor Modified Groschopp (on units after 12/3/2015 use 036445)
029875 Motor
(4 required)
(4 required on units after 9/22/2016)
42 026318 Baffle (on units after 9/22/2016)
035355 Baffle (on units after 12/3/2015)
026318 Baffle
43 026500 Screw
(6 required)
44 018791 Screen
45 013731 Cable Tie
46 503329 Cord Set
47 018811 Strain Relief
48 026317 Bottom Housing
49 002984 Washer
(4 required)
50 026412 Screw (4 required)
51 002943 Ground Washer
52 027278 Ground Screw
53 026296 Foot
(4 required)
54 018314 Washer (4 required)
55 026493 Screw (4 required)
Page 4 of 5 Revised June 18, 2019
Catalog Model
CB15SF
CB15N CB15G CB15SF
(after 9/22/2016)
(after 12/3/2015)
Waring Factory Service Center
314 Ella T. Grasso Ave.
Torrington, CT 06790
Tele. 1-800-269-6640
Groschopp Motor
Parts No Longer Used
(on units between 4/14/2016 & 9/29/2016)
019098
Screw
035576
Brush Cap
(2 required)
035575
Brush & Spring Assembly
(2 required)
www.waringcommercialproducts.com
Fax 860-496-9017
035355
003344
Washer
Baffle
503472
Motor
(use 036445)
030405
Screw
030187
Hall Effect Sensor
036445
CB15 Groschopp Motor Replacement Kit
Used with 029875 Motors
033485
Brush Cap
(2 required)
027381
Brush & Spring Assembly
(2 required)
Wiring Diagram
Motor
Brown
Hall Effect Sensor
Black
002984
Washers
035520
Leili Motor
016691
Bolts
3
2
ACNACL
030453
Control Panel Baffle
026318
Motor Baffle
Green
Black
Red
1
M+M-
Green/Yellow
Blue
Blue
Revised June 18,2019 Page 5 of 5
