wanscam HW0036 User Manual

IP Camera

HW0036

Wanscam

Shenzhen Wanscam Technology Co., Ltd

Packaging list:

Note:Some camera models don’t have separate antenna(fixed)

Installation procedures:

Note:For the first time use IP Camera,please refer to the procedures

Connect Hardwares

Install the Search Tool

Login the IP Camera in Lan

Login the IP Camera On PC

Client

Access By Mobile

Wireless Settings

End

Begin

above

Connect the Camera with Internet cable and power accordingly as above

2.Install the Search Tool

Open the CD,Install the following software:

1. Open the File “JW & HW series”-”Browser View”:

Click “OCX setup”—“Next”—“Install”—“Finish”

2. Open the File “JW & HW series”-”Browser View”:

Copy “Search Tool ” to desktop and run it

3. E-View7 App Installation

APP Download

Please Download and install the E-view7 APP before you set up the
IP Camera. Search on Google Play store or APP Store for “E-view7”

One Key Setting Function (cell phone must be connected to the WiFi. ）

Step1.Connect the camera with power adaptor (you do not need to connect
the Ethernet cable).

Step2.Launch the APP, tap on “+” to access the “Add Camera” function, then
click on “One Key Setting”, and the screen shown below will appear:

1

Step3.Enter the correct WiFi password, then click on “Start configuration”, like

shown in the screen below:

2 3

Step4. Wait for 60 seconds, then choose the respective device and enter the
password. If done, click on save to connect to the WiFi.

Three methods to add IP camera

Method 1:Input the P2P ID, User name, Password of your camera manually.

Then click “Save”

Method 2:Scan the QR code:Click the “Scan QR code” button,at the bottom of

the camera, there is a label of QR Code, then scan the QR code with your
smart phone,it will show the ID, input the user name and password, then click
“Save ”

Method 3:Click “Search”, then you will get the local camera list in your phone.

Choose the camera which you want to view, input the user name and
password, then click “Save”

Then the video will be showed,refer to picture 7
Click the “!” In the red circle,the camera settings are available,refer to picture 8

7 8

Open the WiFi settings,showed as Picture 9
choose the correct SSID,and input the password,like picture 10

9 10

After wifi connection, the camera will be rebooting,
You will find the camera online after 3-5 minutes
The video will be showed wirelessly,refer to Picture 11and 12

11 12

4. Login IP Camera In LAN

After hardwares connection properly, run the search tool, the Camera IP Address will

be showed automatically.（Before viewing camera on IE, you must set One Key
Setting）

Note:If the Search Tool shows subnet mask does not match,please click

Double click the camera IP address in the search tool.
A Sign-in interface will be showed on your default browser, like the below:

Note: username is “admin”;password is none

(Please change the account info for safety after login)

The login screen will be showed after the correct user name and password input

Note: If the OCX installed before,then login directly

A. Click “OCX” to download and Install it.
B. Refresh the webpage and login again,the camera video will be displayed as
below

Live video

.

5.Device imformation Setting
