OPERATING
INSTRUCTIONS

CORDLESS IMPACT
DRIVER

model Id-3000l

1. The appliance is not intended for use by young children or infirmed persons unless they have been
adequately trained by a responsible adult to ensure that they can use the appliance safely and
without supervision.

2. Young children should be supervised to ensure that they do not play with the appliance.

3. Consider work area environment. Do not expose tools to rain. Do not use tool in damp or wet
locations. Keep work area well lit. Do not use tools in the presence of flammable liquids or gasses.

4. When using the charger, to guard against electric shock, avoid contact with live terminals.

5. Keep children away. Do not let visitors touch the tool or extension cord. All visitors should be kept
away from the work area.

6. Store idle tools. When not in use, tools should be stored in a dry secure place, out of reach of
children.

7. Do not force the tool. It will do the job better and more safely at the rate for which it was intended.

8. Stay alert. Watch what you are doing and use common sense. Do not operate too when you are
tired.

9. Check damaged parts. Before further use of the tool, a guard or other damaged parts should be
carefully checked to determine that it will operate properly and perform its intended function.

10. Check for alignment of moving parts, jamming of moving parts, breakage of parts, mounting and
any other condition that may affect its operation.

11. A guard or other part that is damaged should be properly repaired or replaced by an authorised
service centre unless otherwise indicated in the instruction manual. Have defective switches
replaced by an authorised service centre. Do not use tool if switch does not turn it on.

12. To ensure the designed operational integrity of the power tool, do not remove installed cover or
screws.

13. Do not touch movable parts or accessories until the power source has been disconnected.

14. Do not wipe plastic parts with solvent. Solvents such as gasoline, thinner, benzine, carbon
tetrachloride, alcohol, ammonia and oil containing chloic annex may damage and crack plastic
parts. Wipe plastic parts with a soft cloth lightly dampened with soap and water.

15. Dress properly when operating the machine. Do not wear loose clothing or jewellery. Contain long
hair. Keep you hair, clothing, and gloves away from moving parts.

16. Use safety equipment. Always wear eye protection, non-skid safety shoes, hard hat and hearing
protection.

17. Do not overreach. Proper footing and balance enables better control of the tool in unexpected
situations.

18. Use clamps of other practical ways to secure and support the work piece to a stable platform.

19. Use only accessories that are recommended by the manufacturer for your model.

General Operational Precautions

1. Caution: To reduce risk of injury, change only specific type rechargeable batteries. Other types of
batteries may burst causing personal injury and damage.

2. Before using battery charger, read all instructions and cautionary markings on the batteries and
chargers.

3. Do not expose charger to rain or snow.

4. To reduce the risk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting charger.

5. Use of an attachment not recommended or sold by the battery charger manufacturer may result in
fire, electric shock or injury to persons.

6. Make sure cord is located so that it will not be stepped on, tripped on, tripped over or otherwise
subjected to damage or stress.

7. Do not operate charger with damaged cord or pug. Replace them immediately.

8. Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any
way – take it to a qualified repair centre.

9. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or
cleaning. Turning off controls will not reduce this risk.

10. Do not disassemble charger or battery cartridge, take it to a qualified service centre when a repair
is required. Incorrect reassembling may result in electric shock or fire.

1. Do not charge battery cartridge when temperature is below 10°c (50°F) or above 40°C (104°F).

2. Do not attempt to use a set-up transformer, an engine generator or DC power receptacle.

3. Do not allow anything to cover or clog the charger vents.

4. Always cover the battery terminals with the battery cover when the battery cartridge is not used.

5. Do not short the battery cartridge: Do not touch the terminals with any conductive material. Avoid
storing battery cartridge in a container with other metal objects such as nails, coins etc. Do not
expose battery cartridge to water or rain. A battery short can cause large current flow, overheating,
possible burns and even a breakdown.

6. Do not store the machine and battery cartridge in locations where the temperature may reach or
exceed 50°C (122°F).

7. Do not incinerate the battery cartridge even if it is severely damaged or completely worn out. The
battery cartridges can explode in a fire.

8. Be careful not to drop, shake or strike battery.

9. Do not charge inside a bot or container of any kind. The battery must be placed in a well-ventilated
area during charging.

10. For maximum battery lifetime, the lithium-ion battery is designed with a protection feature to stop
battery damage. In the cases described below, when using this product, even if you are operating
the switch, the motor may stop. This is not a malfunction but the results of the protection feature:

• When the battery power remaining runs out, the motor stops.

• If the tool is overloaded, the motor may stop. In this case, release the switch and eliminate the

cause of the overload. After that you can use it again.

• If the battery is overheated due to work overload, the battery power may stop. In this case stop

using the battery and let the battery cool. After that you can use again.

Important Safety Instructions for Charger & Battery Cartridge

Additional Safety Rules for Charger & Battery Cartridge

Model No ID-3000L

Voltage 14.4V DC

No Load Speed 0-2000RPM

Max Torque 2000kg/cm

Impacts Per Minute 3000

Tool weight
(with battery)

1.53kg
(battery 0.53kg)

Capacity 6mm/10mm

Charging Time 1 Hour – Auto Cut-off

Specifications
