WallboxOK UP User And Installation Manual

UP WALLBOX

USER MANUAL

INSTALLATION MANUAL

View this manual online

www.wallboxok.com/man

2

EV Portable bears the CE mark. The corresponding
Declarations of Conformity are located at WallboxOK.

This product meets the requirements of the ROHS
Directive (2011/65/CE). The corresponding Declarations
of Conformity are located at WallboxOK

.

Disposal Information

The above symbol, crossed-out trash container, indicates that electric
appliances and electronic devices including accessories (EEE), the electrical
and electronic equipment of the electric charging station, as well as its
accessories, are to be disposed of separately from general household
trash. You can find more information about this directly on the product, in
the operating manual or on the packaging. The materials are recyclable
according to their labeling. The reuse, the recycling of materials and other
forms of reuse of used equipment contribute considerably to protect our
planet.

3

1 INDEX

1 INDEX ..................................................................................................................................... 3

2 IMPORTANT INFORMATION .................................................................................................. 4

2.1 SAFETY INTRUCTIONS .................................................................................................... 4

2.2 ENTENDED USE .............................................................................................................. 5

2.3 ABOUT THIS MANUAL ................................................................................................... 5

3 OVERVIEW. ............................................................................................................................ 6

3.1 VERSIONS....................................................................................................................... 6

4 USING THE CHARGING STATION. .......................................................................................... 7

4.1 ELECTRIC CHARGING BOX WITH CABLE ........................................................................ 7

4.2 CHARGE AMPS SELECTION ............................................................................................ 8

4.3 A CCESS TO THE CHARGER MENU ................................................................................. 8

5 TROUBLESHOOTING. ............................................................................................................. 9

6 INSTALLATION. .................................................................................................................... 10

6.1 GENERAL CRITERIA FOR THE SITE ................................................................................ 10

6.2 INDICACIONES PARA LA CONEXIÓN ELÉCTRICA GENERALIDADES .............................. 10

6.3 PLACE EVSE .................................................................................................................. 11

6.4 CABLE INSERTION ........................................................................................................ 11

Dear Customer,

WallboxOk Team wants to thank you for buying one of our Electric Vehicle Charging Box. Our passion in
design and innovation makes our charging points leaders in technology and design.

Do not hesitate to contact us at [e-mail] if you have any suggestion.

We hope you enjoy your product

Best regard,

The Wallbox Ok Team

4

2 IMPORTANT INFORMATION

2.1 SAFETY INTRUCTIONS

Warning!

Not observing the safety instructions can result in risk of death, injuries and damage to the
device! WALLBOXOK assumes no liability for claims resulting from this!

• Electrical hazard / fire hazard!

Never use damaged worn or dirty charging plugs. first time tuning on the electrical
charging station must be carried out exclusively by competent and qualified technical
personnel, fully responsible for compliance with the installation regulations and
existing standards.

• Electrical hazard / fire hazard!

Never use damaged, worn or dirty charging connectors.

• The owner must ensure that the charging station is only ever operated in perfect

condition:

- The charging station must be checked regularly for faulty sockets and

connectors and damage to the housing (visual inspection).

- A damaged charging station must be switched off immediately and replaced.

- Repair work to the charging station is forbidden and may only be performed by

the manufacturer (replacement of the charging station)!

- Do not carry out any unauthorized conversion work or modifications to the

charging station!

- Do not remove any notices on the device, such as safety symbols, warning

notices, rating plates, nameplates or cable markings!

• The charging station does not have its own power switch! The RCD circuit breaker and

the line circuit breaker of the building installation serve as main connectors.

• No extension cables are permitted for connecting an electric vehicle to the power

supply device for electric vehicles.

Only electrical vehicles or their chargers may be connected. No connection of other
loads is permitted (electric tools etc.)!

• Read the information and instructions for your vehicle carefully before youλ charge

the vehicle using the charging station.

• Ventilation: A number of vehicles require an external ventilation system in the interior

areas due to the possible creation of toxic or explosive gases during the charging
procedure.

• Unplug the charging cable by pulling on the connector, never on the cable.
