Walker WP4084FHD Operating Instructions Manual

COLOUR TELEVISION WITH REMOTE CONTROL

OPERATING INSTRUCTIONS

WP4084FHD

English - 1 -

Contents

Features ................................................................. 2

Accessories ............................................................ 2

Introduction ............................................................. 2

Preparation ............................................................. 2

Safety Precautions ................................................. 3

Power Source ..................................................... 3

Power Cord ......................................................... 3

Moisture and Water ............................................ 3

Cleaning.............................................................. 3

Ventilation ........................................................... 3

Heat and Flames ................................................ 3

Lightning ............................................................. 3

Replacement Parts ............................................. 3

Servicing ............................................................. 3

Waste Disposal ................................................... 3

Information for Users in European Union

Countries ............................................................ 3

Disconnecting the Device ................................... 3

Headphone Volume ............................................ 3

Installation........................................................... 4

LCD Screen ........................................................ 4

Warning .............................................................. 4

Overview of the Remote Control ............................ 5

LCD TV and Operating Buttons .............................. 6

Viewing the Connections- Back Connectors .......... 6

Viewing the Connections - Side Connectors .......... 8

Aerial Connection ................................................... 8

Power Connection .................................................. 8

Connecting the LCD TV to a PC ............................. 9

Connecting to a DVD Player................................... 9

Using Side AV Connectors ..................................... 9

Using Other Connectors ......................................... 9

Connecting Other Equipment via Scart ................ 10

Inserting Batteries in the Remote Control

Handset ................................................................ 10

Switching the TV On/Off ....................................... 10

To Switch the TV On ......................................... 10

To Switch the TV Off ......................................... 10

First Time Installation............................................ 10

Input Selection ...................................................... 10

Basic Operations ...................................................11

Operation with the Buttons on the TV ................11

Operation with the Remote Control ...................11

Menu System.........................................................11

Picture Menu......................................................11

Sound Menu ..................................................... 12

Feature Menu ................................................... 13

Install Menu ...................................................... 14

Source Menu .................................................... 16

PC Mode Menu System........................................ 16

PC Position Menu ............................................. 16

Displaying TV Information .................................... 17

Mute Function ....................................................... 17

PIP (Picture-in-Picture) and PAP (Picture-and

-Picture) Modes .................................................... 17

Picture Mode Selection......................................... 17

Freezing Picture ................................................... 17

Zoom Modes......................................................... 17

Teletext ................................................................. 18

Tips ....................................................................... 19

Appendix A: PC Input Typical Display Modes ....... 20

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types) ........................ 20

Appendix C: Supported DVI Resolutions.............. 21

Appendix D: PIP/PAP Mode Combinations .......... 21

Specications ....................................................... 22

Important Instruction ............................................. 23

English - 2 -

Features

• Remote controlled colour LCD TV.

• HDMI connectors for digital video and audio. This
connection is also designed to accept high denition

signals.

• 200 programmes from VHF, UHF.

• OSD menu system.

• Two scart sockets for external devices (such as
video, video games, audio set, etc.).

• Stereo sound system. (German + Nicam)

• Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward manual tuning.

• Sleep timer.

• Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• PIP / PAP / PAT functions.

• AVL (Automatic Volume Limiting).

• When no valid signal is detected, after 5 minutes the

TV switches itself automatically to standby mode.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, ME, 2000, XP, Vista.

• Audio line out.

• Game Mode (optional).

Accessories

EXIT

/

GUIDE

WIDE

ABC

DEF

GHI

JKL MNO

PQR

STU

VWX

YZ

M

P<P

TV

DTV

i

I-II

INFO

- -

V P

+ +

-/--

PP

0

1

2

3

4

5

6

7

8

9

PC

OK

Remote

Controller

Batteries: 2 X AAA

Instruction Book

Introduction

Thank you for choosing this product. This manual will
guide you for the proper operation of your TV.

Before operating the TV, please read this

manual thoroughly.

Please do keep this manual in a safe place for
future references.

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top

of the set.

Use this device in moderate climates.

10 cm

10 cm

10 cm

English - 3 -

Safety Precautions

Please read the following recommended safety
precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220-240

V AC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the
power cord by the plug. Do not unplug the appliance
by pulling from the power cord and never touch the
power cord with wet hands as this could cause a short

circuit or electric shock. Never make a knot in the cord

or tie it with other cords. The power cords should be
placed in such a way that they are not likely to be

stepped on. A damaged power cord can cause re or

give you an electric shock. When it is damaged and

needs to be replaced, it should be done by qualied

personnel.

Moisture and Water

Do not use this device in a humid

and damp place (avoid the bathroom,
the sink in the kitchen, and near the

washing machine). Do not expose this

device to rain or water, as this may be
dangerous and do not place objects
filled with liquids, such as flower
vases, on top. Avoid from dripping

or splashing.

If any solid object or liquid falls into the cabinet, unplug
the TV and have it checked by qualied personnel

before operating it any further.

Cleaning

Before cleaning, unplug the TV set

from the wall outlet. Do not use
liquid or aerosol cleaners. Use soft
and dry cloth.

Ventilation

The slots and openings on the TV
set are intended for ventilation and to ensure reliable

operation. To prevent overheating, these openings

must not be blocked or covered in anyway.

Heat and Flames

The set should not be placed near
to open flames and sources of
intense heat such as an electric

heater. Ensure that no open ame
sources, such as lighted candles,

are p l a c ed on top of the TV.
Batteries should not be exposed to excessive heat

such as sunshine, re or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specied by the manufacturer or have the
same specications as the original one. Unauthorized
substitutions may result in re, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualied

personnel. Do not remove the cover
yourself as this may result in an
electric shock.

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and
should principally be recycled. Packaging materials,
such as foil bag, must be kept away from children.

• Batteries, including those which are heavy metal­free, should not be disposed of with household

waste. Please dispose of used battery in an
environment friendly manner. Find out about the
legal regulations which apply in your area.

• Cold cathode fluorescent lamp in LCD PANEL

contains a small amount of mercury; please follow
the local laws or regulations for disposal.

Information for Users in European Union
Countries

This symbol on the product or on its
packaging means that your electrical
and electr o n i c device sh o u l d be
disposed at the end of its service
life separately from your household
wastes. There are separate collection
systems for recycling in EU.

For more information, please contact the local

authority or the dealer where you purchased the
product.

Disconnecting the Device

The mains plug is used to disconnect TV set from
the mains and therefore it must remain readily
operable.

Headphone Volume

Excessive sound pressure from
earphones and headphones can cause
hearing loss.

English - 4 -

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the installation
instructions when mounted to the wall (if the option
is available).

LCD Screen

The LCD panel is a very high technology product with

about a million thin lm transistors, giving you ne
picture details. Occasionally, a few non-active pixels
may appear on the screen as a xed blue, green or

red point. Please note that this does not affect the
performance of your product.

Warning

Do not leave your TV in standby or operating mode
when you leave your house.

English - 5 -

Overview of the Remote Control

EXIT

/

GUIDE

WIDE

ABC

DEF

GHI

JKL MNO

PQR

STU

VWX

YZ

1

2

3

4

5

6

7

8

9

10

11

12
13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

M

P<P

TV

DTV

i

I-II

INFO

- -

V P

+ +

-/--

PP

0

1

2

3

4

5

6

7

8

9

PC

OK

Standby1.

Yellow (Feature menu)2.

Blue (Install menu)3.

Previous programme4.

Cursor up5.

Cursor right6.

Cursor down7.

TV mode / (No function)8.

Mono/Stereo - Dual I-II 9.

Programme up/down10.

Numeric buttons11.

(No function)12.

Hold (in TXT mode) / PIP position13.

Update (in TXT mode) / PAP mode 14.

Index page / Guide (No function)15.

Reveal (in TXT mode) / Switch from TV to 16.

PC

Green (Picture menu)17.

Red / (Sound menu)18.

Menu on/off19.

Ok / Conrm20.

Cursor Left21.

AV / Source22.

Info23.

Volume up/down24.

Mute25.

Personal preferences26.

Time27.

Teletext 28.

Mix (in TXT mode) / PIP mode29.

Expand (in TXT mode) / Image size30.

English - 6 -

LCD TV and Operating Buttons

Standby button1.

TV/AV button2.

Programme Up/Down buttons3.

Volume Up/Down buttons4.

Note: Press

“ ” / “ ”

buttons at the same time to view
main menu.

Viewing the Connections- Back Connectors

12

S/PDIF Digital Out1. outputs digital audio signals of the currently watched source.
Use a digital optic cable to transfer audio signals to a device that has S/PDIF input.

Subwoofer Out2. is for connecting an external, active subwoofer to the set to give a much deeper bass

effect.
Use an appropriate RCA cable to connect the set to a subwoofer unit.

Audio Line Outs3. output audio signals to an external device such as an optional sound system.

To connect the external speakers to your TV, use AUDIO LINE OUTS of the TV with an audio cable.

SCART 24. inputs or outputs for external devices.

SCART 15. inputs or outputs for external devices.

English - 7 -

Connect the SCART cable between SCART sockets on TV and SCART socket on your external
device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART sockets, the TV will automatically switch to
AV mode. If both sockets are employed at the same time, SCART 1 will override SCART 2 unless
manually selected.
Note: You should connect the decoder to EXT-1, if you are planning to watch a scrambled channel.
The decoder might not function properly if you do not connect the decoder to the Scart 1 (Ext-1) socket
Note: Picture state can be affected by scart cable quality.

Component Video Inputs (YPbPr)6. are used for connecting component video.
You can connect the component video and audio sockets with a device that has component output.
Connect the component video cables between the COMPONENT VIDEO INPUTS on on the TV and

the component video outputs of your device. While connecting, be sure that the letters on your TV, “Y”,

“Pb”, “Pr” correspond with your device’s connectors.

PC/YPbPr Audio Inputs7. are used for connecting audio signals of a PC or a device that connects to the

TV via YPbPr.
Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output of your PC to
enable PC audio.
Connect the audio cable between AUDIO INPUTS on the TV and audio outputs of your device to
enable component audio.

S/PDIF Coaxial Out8. outputs digital audio signals of the currently watched source.
Use an SPDIF coaxial cable to trasfer audio signals to a device that has S/PDIF input.

RF Input9. connects to an antenna or a cable.

Note that if you use a decoder or a media recorder, you should connect the aerial cable through the
device to the television with an appropriate antenna cable, as shown in the illustrationin the following

pages.

PC Input10. is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.

HDMI 2: 11. HDMI Input

HDMI 1: 12. HDMI Input

HDMI Inputs are for connecting a device that has an HDMI socket. Your LCD Television is capable of

displaying High Denition pictures from devices such as a High Denition Satellite Receiver or DVD

Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets
can accept either 720p or 1080i signals. No sound connection is needed for an HDMI to HDMI connection.

English - 8 -

Viewing the Connections - Side Connectors

Headphone jack is used for connecting an external headphone to the 1.
system. Connect to the HEADPHONE jack to listen to the TV from

headphones (optional).

Video Input is used for connecting video signals of external devices.Connect 2.

the video cable between the VIDEO IN socket on the TV and the VIDEO
OUT jack on your device.

Audio Inputs are used for connecting audio signals of external devices. 3.

Connect the audio cable between the AUDIO INPUTS on the TV and the
AUDIO OUTPUT jacks on your device. Note: If you connect a device to the
TV via the VIDEO INPUT, you should also connect your device with an audio
cable to the AUDIO INPUTS of the TV to enable audio.

Aerial Connection

• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the

mains.

• Plug the power cable to the mains socket outlet.

English - 9 -

Connecting the LCD TV to a PC

For displaying your computer’s screen image on

your LCD TV, you can connect your computer to the

TV set.

• Power off both computer and display before making

any connections.

• Use 15-pin D-sub display cable to connect a PC to

the LCD TV.

• When the connection is made, switch to PC source.

See “Input selection” section.

• Set the resolution that suits your viewing requirements.

Resolution information can be found in the appendix
parts.

PC audio cable

(not supplied)

to AUDIO INPUTS

on the TV

PC RGB cable
(not supplied)
to PC input

Audio
Inputs

PC Input

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer
to your DVD player’s instruction book for additional
information. Power off both the TV and the device
before making any connections.

Note: Cables shown in the illustration are not
supplied.

• If your DVD player has an HDMI socket, you can

connect via HDMI. When you connect to DVD player

as illustrated below, switch to HDMI source. See,

“Input Selection” section.

• Mo s t DVD playe r s are conne c t ed th r o ugh
COMPONENT SOCKETS. Use a component video
cable to connect video input. For enabling audio,

use a component audio cable as illustrated below.

When the connection is made, switch to YPbPr
source. See, “Input selection” section.

• You may also connect through the SCART 1 or

SCART 2. Use a SCART cable as shown below.

Note: These three methods of connection perform the
same function but in different levels of quality. It is not

necessary to connect by all three methods.

HDMI

inputs

Scart sockets

Component

video

inputs

Component

audio

inputs

DVD Player

REAR VIEW

Using Side AV Connectors

You can connect a range of optional equipment to your

LCD TV. Possible connections are shown below. Note

that cables shown in the illustration are not supplied.

• For connecting a camcorder, connect to the VIDEO
IN socket and the AUDIO SOCKETS. Do not connect
the camcoder to VIDEO IN socket at the same time

since it can cause noise in the picture. For selecting

the related source, see the section “Input selection”

in the following parts.

• To listen the TV sound from headphones, connect
to the HEADPHONE jack of theTV.

Camcorder

Headphone

Using Other Connectors

You can connect a range of optional equipment to your

LCD TV. Possible connections are shown below. Note

that cables shown in the illustration are not supplied.

• To connect external speakers, use an audio cable.
Do not reverse the AUDIO LEFT and AUDIO RIGHT
jacks. Turn on the LCD TV and external speaker set

after all connections are made. Refer to your speaker
set’s manual for further queries.

• For connecting a to a device that has SPDIF support,

use an appropriate SPDIF cable to enable sound
connection.

External Speakers

A device that

supports

SPDIF signal.

English - 10 -

Connecting Other Equipment via
Scart

Most devices support SCART connection. You can

connect a; DVD recorder, a VCR or a decoder to your
LCD TV by using the SCART sockets. Note that cables

shown in the illustration are not supplied.

Power off both the TV and the devices before making
any connections.

For more information, refer to your device’s own

instruction book.

Scart sockets

Decoder

DVD Recorder

Video Recorder

Inserting Batteries in the Remote
Control Handset

• Remove the battery cover located on the back of

the handset by gently pulling backwards from the
indicated part.

• Insert two AAA/R3 or equivalent type batteries
inside. Place the batteries in the right directions and
replace the battery cover.

+

Note: Remove the battery from remote control
handset when it is not to be used for a long period.
Otherwise it can be damaged due to any leakage of
batteries.

Remote range is approximately 7m/23ft.

Switching the TV On/Off

To Switch the TV On

• Connect the power cord to the 220-240V AC, 50

Hz.

• Press STANDBY switch. Then the standby LED

lights up.

• To switch on the TV from standby mode either:

• Press the “

” button, P+ / P- or a numeric button

on the remote control.

• Press the -P/CH or P/CH+ button on the TV. The TV
will then switch on.

Note: If you switch on your TV via PROGRAMME
UP/DOWN buttons on the remote control or on the
TV set, the programme that you were watching last
will be reselected.

By either method the TV will switch on.

To Switch the TV Off

• Press the “ ” button on the remote control or
press the STANDBY switch, so the TV will switch

to standby mode.

• To power down the TV completely, unplug the
power cord from the mains socket.

First Time Installation

When the TV is switched on for the rst time, the

following menu screen will be displayed.

S e l e c t y o u r C o u n t r y , L a n g u a g e
and TXT language by using “ ” o r

“ ” and “ ” or “ ” buttons.

Press OK or RED button to continue.

To cancel, press the BLUE button.

For more information on this process, see “Install

Menu” section.

Note: Do not turn off the TV while initializing rst time

installation.

Input Selection

Once you have connected external systems to your

TV, you can switch to different input sources.

• Press “

” button on your remote control for directly

changing sources.

or,

• Select “Source” option from the main menu

by using “

” or “ ” button. Use then “ ” or
“ ” button to highlight an input and press “ ” button
to select.

Note: You can mark desired source options by
pressing the OK button. Therefore, when

“ ” button

is pressed, only the marked source options will be
available (except for the TV source).

English - 11 -

Basic Operations

You can operate your TV using both the remote
control and onset buttons.

Operation with the Buttons on the TV

Volume Setting

• Press “ ” button to decrease volume or “
” button to increase volume, so a volume level scale

(slider) will be displayed on the screen.

Programme Selection

• Press “P/CH +” button to select the next programme or
“P/CH -” button to select the previous programme.

Viewing Main Menu

• Press “ ” / “ ” buttons at the same time
to view main menu. In the Main menu select sub­menu using “P/CH -” or “P/CH +” buttons and enter

the sub-menu using “

” or “ ” buttons.

To learn the usage of the menus, refer to the menu

system sections.

AV Mode

• Press the “TV/AV” button in the control panel on the
TV to switch between AV modes.

Operation with the Remote Control

• The remote control of your TV is designed to control

all the functions of the model you selected. The
functions will be described in accordance with the
menu system of your TV.

• Functions of the menu system are described in the

following sections.

Volume Setting

• Press “V +” button to increase the volume. Press “V

-” button to decrease the volume. A volume level

scale (slider) will be displayed on the screen.

Programme Selection (Previous or Next
Programme)

• Press “P -” bu tton to sele c t th e pr eviou s
programme.

• Press “P +” button to select the next programme.

Programme Selection (Direct Access)

• Press numeric buttons on the remote control to

select programmes between 0 and 9. The TV
will switch to the selected programme. To select

programmes between 10-199, press the numeric

buttons consecutively. The limit of the delay time
is 3 seconds.

• Press directly the programme number to reselect

single digit programmes.

Menu System

Picture Menu

Mode

For your viewing requirements, you can set the related

mode option.

Press “

” or “ ” button to select Mode. Press “

” or “ ” button to choose from one of these options:

Cinema, Dynamic and Natural.

Brightness/Contrast/Colour/Sharpness/
Hue

Press “ ” or “ ” button to select the desired option.
Press “

” or “ ” button to set the level.

Note: Hue option can only be visible when the TV
receives an NTSC signal.

Colour Temp

Press “ ” or “ ” button to select Colour Temp. Press
“ ” or “ ” to choose from one of these options: Cool,

Normal and Warm.

Note:

• Setting Cool option gives white colours a slight
blue stress.

• Setting Warm option gives white colours a slight
red stress.

• For normal colours, select Normal option.

Noise Reduction

If the broadcast signal is weak and the picture is
noisy, use Noise Reduction setting to reduce the
noise amount.

English - 12 -

Press “ ” or “ ” button to select Noise Reduction.
Press “

” or “ ” to choose from one of these options:

Low, Medium, High or Off.

Film Mode

Films are recorded at a different number of frames per
second to normal television programmes.

Press “

” or “ ” button to select Film Mode.

Press “

” or “ ” button to set this feature On or Off.

Turn this feature on when you are watching.

lms to see the fast motion scenes clearly.

Game Mode

Select Game Mode by pressing “ ” or “ ” button.
Use “ ” or “ ” button to set Game Mode as On or

Off. When Game Mode is set to On, specic game
mode settings, which are optimized for better video
quality, will be loaded.

Also; Picture Mode, Contrast, Brightness, Sharpness,

Colour and Colour Temp settings will be invisible and

disabled while Game Mode is on.

Note:

Picture mode selection button on the remote control
will have no function while Game Mode is on.

If the TV is switched to PIP/PAP mode, Game Mode
setting will be disabled and be removed from the
Picture menu.

Picture Zoom

Select Picture Zoom by pressing “ ” or “ ”
button.

Use “

” or “ ” buttons, to change picture zoom to
Auto, 16:9, 4:3, Panoramic, 14:9, Cinema, Subtitle
or Zoom.

Reset

Press “ ” or “ ” button to select Reset. Press
“ ” or “ ” or OK button to reset the picture modes to
factory default settings.

Store

Press “ ” or “ ” button to select Store. Press “ ”
or OK button to store the settings. “Stored...” will be
displayed on the screen.

Sound Menu

Volume

Press “ ” or “ ” button to select Volume. Press “ ”
or “ ” button to change the level of the Volume.

Equalizer

Press “ ” or “ ” button to select Equalizer. Press
“ ” button to view equalizer menu.

Press “ ” or “ ” button to change the preset. In

equalizer menu, the preset can be changed to Music,
Movie, Speech, Flat, Classic and User.

Select the desired frequency by pressing “

” or “ ”
button and increase or decrease the frequency gain
by pressing “ ” or “ ” button.

Press the “M” button to return to the previous menu.

Note: Equalizer menu settings can be changed only
when the Equalizer Mode is in User.

Balance

This setting is used for emphasizing left or right
speaker balance.

Press “

” or “ ” button to select Balance. Press “

” or “ ” button to change the level of the balance.

Balance level can be adjusted between -32 and +

32.

Headphone

Press “ ” or “ ” button to select Headphone. Press
“ ” button to view the headphone menu.

Headphone sub-menu options are described below:

Volume

Press “

” or “ ” button to select Volume. Press “
” button to increase headphone volume level. Press
“ ” button to decrease headphone volume level.

Headphone volume level can be adjusted between

0 and 63.

Headphone Sound (optional)

Press “

” or “ ” button to select Headphone Sound.
Using “ ” or “ ” button, you can select Main, PIP/PAP,
Active or Inactive.

Main : Main window sound.

PIP/PAP : PIP/PAP window sound.

English - 13 -

Active : Sound of the current selection.

Inactive : Sound of the currently inactive window.

Sound Mode (optional)

Press “ ” or “ ” button to select Sound Mode. Using
“ ” or “ ” button, you can select Mono, Stereo, Dual I

or Dual II mode, only if the selected channel supports

that mode.

AVL

Automatic Volume Limiting (AVL) function adjusts the
sound to obtain xed output level between programmes
(For instance, volume level of advertisements tend to

be louder than programmes).

Press “

” or “ ” button to select AVL. Press “ ” or

“

” button to set the AVL as On or Off.

Spdif Out

Press “ ” or “ ” button to select Spdif Out. Press “ ”
or “ ” button to set the Spdif Out. as On or Off.

Note: If Spdif Out is set to On, headphone will be
disabled.

Effect

If you are watching a mono broadcast, set Effect on to

obtain a better sound effect which will be more stereo-

like. If the current sound system is stereo, switching

this effect on will give a more spatial effect.

Press “

” or “ ” button to select Effect. Press “ ”

or “ ” button to set as On or Off .

Store

Press “ ” or “ ” button to select Store. Press “

” or OK button to store the settings. “Stored...” will

be displayed on the screen.

Feature Menu

Pip-Pap

In the Feature menu, highlight PIP item by pressing
“ ” or “ ” buttons. Press “ ” button to enter PIP
submenu:

Using “ ” or “ ” button, you can switch to PIP, PAP
mode or turn off the feature.

If the TV is switched to PIP or PAP mode, Pip-Pap

submenu will change accordingly and the following
settings will appear on the same menu screen.

Note that if you switch to PAP mode by using Pip-Pap
setting, only Source and Swap options will be active
among the menu settings.

Pip-Pap

This line controls Pip/Pap modes. Use “

” or “ ”

buttons to switch the TV to Pip, Pap or Off.

Pip Size

Using this setting, you can set the size of the Pip

window. Press “

” or “ ” button to highlight Pip
Size item. Use “ ” or “ ” button to set Pip Size to
Small or Large.

Note: This setting will be inactive if the TV is set to
Pap mode.

PIP Position

This setting is used for moving the sub picture.

Select PIP Position item by using “

” or
“ ” button. Use “ ” or “ ” button to adjust PIP
position.

Positions available are: Bottom Right,Bottom Left, Top

Left and Top Right.

Source

PIP Source setting enables you to select the source
of the sub picture.

Select PIP Source item by using “

” or “ ”

button. Use “ ” or “ ” button to set PIP source.

Program

This setting will be unavailable to be used.

Swap

Select Swap item by using “

” or “ ” button. Use “

” or “ ” button to set. This function enables to swap

between the main and the PIP picture.

Note: See Appendix E for all PIP/PAP modes.

English - 14 -

Sleep Timer

Press “ ” or “ ” button to select Sleep Timer. Use
“ ” or “ ” button to set the Sleep Timer.

The timer can be programmed between Off and 120
minutes in steps of 10 minutes.

If Sleep Timer is activated, at the end of the selected

time, the TV goes automatically to standby mode.

Child Lock

Press “ ” or “ ” button to select Child Lock.

Use “

” or “ ” button to set the Child Lock On or Off.

When On is selected, the TV can only be controlled

by the remote control handset. In this case the control
panel buttons (except for the STANDBY button) will
not work.

Hence, if one of those buttons is pressed, Child Lock
On will be displayed on the screen when the menu

screen is not visible.

Language

Press “ ” or “ ” button to select Language. Use “
” or “ ” button to select the Language.

Default Zoom

While zoom mode is set as AUTO, the TV will set

the zoom mode in accordance with the signal of
the broadcast. If there is no WSS or aspect ratio

information, the TV will then use this setting to

adopt. Press “ ” or “ ” button to select Default
Zoom. You can set Default Zoom to Panoramic,
16:9, 4:3 or 14:9 by pressing “ ” or “ ” button.

Blue Background

If the signal is weak or absent, the TV will automatically
change to a blue screen. To enable this, set Blue

Background to On.

By pressing “

” or “ ” button, select Bl u e

Background. Press “ ” or “ ” button to set Blue
Background as On or Off.

Menu Background

Press “ ” or “ ” button to select Menu Background.
You can set menu background level by pressing “
” or “ ” button.

Backlight

This setting controls the backlight level. Select
Backlight by pressing “ ” or “ ” button. Press“
” or “ ” button to set Backlight to Auto, Medium,

Maximum or Minimum.

Menu Timeout

To set a specic display timeout for menu screens,

set a value for this option.

Press “

” or “ ” button to select Menu Timeout. Use

“ ” or “ ” button to change menu timeout to 15 sec,

30 sec or 60 sec.

Teletext Language

Press “ ” or “ ” button to select Teletext Language.
Use “ ” or “ ” button to change Teletext Language to

West, East, Turk/Gre, Cyrillic, Arabic or Persian.

Ext Out

Press “ ” or “ ” button to select Ext Out. Use “ ” or
“

” button to set the Ext Out as On or Off.

Note:

For copying from a DVD or VCR device, you should

choose desired source from source menu and turn
“On” to EXT Out from feature menu.

HDMI PC Full Mode (optional)

If you want to view PC screen in HDMI mode by using

external connection, HDMI PC FULL MODE option
should be On to adjust the screen ratio correctly. This

item might be inactive in some resolutions.

Note: If you connect an HDMI device and switch the
TV to HDMI mode, this feature will be visible (except
for 1080i/1080P resolution).

Full Mode (optional)

If you connect a device via HDMI or YPbPr connectors

and set 1080i/1080P resolutions, Full Mode item will
be visible.You can set Full Mode as 1:1 or Normal

by using “

” or “ ”.If you select 1:1, screen ratio will

be adjusted correctly. If you set Normal, screen ratio

may expand.

Install Menu

Program

Press “ ” or “ ” button to select Program. Use “ ”
or “ ” button to select the program number. You can
also enter a number using the numeric buttons on the
remote control. There are 200 programme storage
between 0 and 199.

Band

Band can be selected either C or S. Press “ ” or “
” button to set Band.

English - 15 -

Channel

Channel can be changed by “ ” or “ ” button or
numeric buttons.

Colour System

Press “ ” or “ ” button to select Colour System. Use
“ ” or “ ” button to change the colour system to PAL,

PAL 60, SECAM or AUTO.

Sound System

Press “ ” or “ ” button to select Sound System.
Press “ ” or “ ” button to change the sound system

to BG,DK, I, L or L’.

Fine Tune

Press “ ” or “ ” button to select Fine Tune. Press “

” or “ ” button to adjust the tuning.

Search

Press “ ” or “ ” button to select Search. Use “ ”
or “ ” button to start programme searching. You can
also enter the desired frequency using the numeric
buttons while Search item is highlighted.

Store

Press “ ” or “ ” button to select Store. Press “ ”
or OK button to store the settings. “Stored...” will be
displayed on the screen.

Install Menu in AV Modes

The following screen appears in the install menu when

the TV is in AV modes. Note that limited options will

be available. Switch to TV mode for viewing complete
version of the Install menu.

Colour System

Press “

” or “ ” button to select Colour System. Use

“ ” or “ ” button to change the colour system to PAL,

SECAM, PAL60, AUTO, NTSC 4,43 or NTSC 3,58.

Store

Press “ ” or “ ” button to select Store Program.
Press “ ” or OK button to store the settings.
“Stored...” will be displayed on the screen.

Program Table

Select Program Table by pressing “ ” or “ ”
button.

By moving the cursor in four directions you can reach
20 programmes in the same page. You can scroll the
pages up or down by pressing the navigation buttons
to see all the programmes in TV mode (except for the

AV modes). By cursor action, programme selection is

done automatically.

Name

To change the name of a programme, select the

programme and press the RED button.

The rst letter of the selected name will be highlighted.

Press “

” or “ ” button to change that letter and “ ”
or “ ” button to select the other letters. By pressing
the RED button, you can store the name.

Move

Select the programme which you want to insert by
navigation buttons. Press the GREEN button. By
navigation buttons move the selected programme to
the decided programme space and press the GREEN
button again.

Delete

To delete a programme, press the YELLOW button.
Pressing the YELLOW button again erases the

selected programme from the programme list, and

the following programmes shift one line up.

APS (Auto Programming System)

When you press the BLUE button for starting
automatic tuning, Auto Programming System menu
will appear on the screen:

English - 16 -

Country

Press “

” or “ ” button to select your country. If you
want to exit from A.P.S. function, press the BLUE
button.

When you press OK or RED button for starting

automatic tuning, all stored programmes will be erased

and the TV will search for available channels. During

the search, the following OSD will be displayed:

Whenever you press the BLUE button, APS function
stops and Program Table appears on the screen.

If you wait until the end of APS, Program Table will be

displayed with the programmes found and located.

Source Menu

Press “ ” or “ ” button and select the sixth icon.
Then press “ ” or OK button. Source menu appears
on the screen:

In source menu, highlight a source by pressing “ ” or “
” button and switch to that mode by pressing “ ” button.
Source options are; TV, EXT-1, EXT-2, FAV , HDMI-1,
HDMI-2,YPbPr or PC-VGA.

Note: Once you have connected optional equipment
systems to your TV, you should select the required
input to view pictures from that source.

PC Mode Menu System

See “Connecting the LCD TV to a PC” section for
connecting a PC to the TV set.

For switching to PC source, press “

” button on your
remote control and select PC input. You can also use
“Source” menu to switch to PC mode.

Note that PC mode menu settings are available only
while the TV is in PC source.

PC Position Menu

Select the first icon by pressing “ ” o r
“ ” button. PC Position menu appears on the screen:

Autoposition

If you shift the picture horizontally or vertically to an

unwanted position, use this item to put the picture

into correct place automatically. This setting therefore
automatically optimizes the display.

Select Autoposition item by using “

” or “ ” buttons.

Press OK or “ ”, “ ” button.

Warning: Please ensure auto adjustment is performed
with a full screen image to ensure best results.

H (Horizontal) Position

This item shifts the image horizontally to right hand
side or left hand side of the screen.

Select H Position item by using “

” or “ ” button. Use

“ ” or “ ” button to adjust the value.

V (Vertical) Position

This item shifts the image vertically towards the top
or bottom of the screen.

Select V Position item by using “

” or “

” button. Use “ ” or “ ” bu t to n t o ad jus t

the value.

Phase

Depending on the resolution and scan frequency that

you input to the TV set, you may see a hazy or noisy

picture on the screen. In such a case you can use this
item to get a clear picture by trial and error method.

Select Phase item by using “

” or “ ” buttons. Use

“ ” or “ ” button to adjust the value.

English - 17 -

Dot Clock

Dot Clock adjustments correct the interference

that appear as vertical banding in dot intensive
presentations like spreadsheets or paragraphs or
text in smaller fonts.

Select Dot Clock item by using “

” or “ ” buttons. Use

“ ” or “ ” button to adjust the value.

PC Picture Menu

For adjusting PC picture items, do the following:

Press “

” or “ ” button to select the second icon. PC

Picture menu appears on the screen.

Brightness, Contrast, Colour and C olou r
Temperature settings in this menu are identical to

settings dened in TV picture menu under “Analogue

TV Menu System”.

Note: If you set Colour Temp as User, you can dene

R, G, B settings manually.

Sound, Feature and Source settings are identical
to the settings explained in Analog TV menu
system.

Displaying TV Information

Programme Number, Programme Name, Sound
Indicator and Zoom Mode information is displayed

on the screen when a new programme is entered or
“INFO/

” button is pressed.

Mute Function

Press “ ” button to disable sound. Mute indicator will
be displayed in the upper side of the screen.

To cancel mute, there are two alternatives; the rst

one is pressing the “

” button and the second one

is increasing the volume level.

PIP (Picture-in-Picture) and PAP
(Picture-and-Picture) Modes

Press the “ ” button to switch to PIP mode.

At PIP Mode, a small picture (PIP picture) is displayed

on the main picture. There are 1 size and 4 positions

(upper left, upper right, bottom left and bottom right)

available for the PIP window. You can use “

” button

to change the PIP position. Aspect Ratio of the PIP

window is xed and 4:3.

When PIP Mode is entered, the default active window

is the PIP window and the active window is indicated
by a red frame around it. The active window can be
changed by pressing “

” or “ ” button. The status
info OSD belongs to active window. The place of the
status OSDs are same for both windows.

Press the “

” button again to exit the PIP mode.

Press the “

” button to switch to PAP mode.

At PAP Mode, two pictures with equal sizes are

displayed on the screen. Aspect Ratios of the windows

are xed.

When you switch to PAP Mode, main window in PIP

Mode will be displayed on the right side of the screen.
The active window can be changed by pressing “
” or “ ” button.

Press the “

” button again to exit the PAP mode.

Picture Mode Selection

By pressing PP button, you can change Picture
Mode settings in accordance with your viewing

requirements. Available options are Dynamic, Natural

and Cinema.

Freezing Picture

You can freeze the picture on the screen by pressing
the “OK” button on the remote control. Press the
“OK” button to freeze picture. Press again to quit
freeze mode.

Note: This feature is available for analogue TV mode
only.

Zoom Modes

You can change the aspect ratio (image size)
of the TV for viewing the picture in different
zoom modes.

Press “ ” button to directly change the zoom
mode.

Available zoom modes are listed below.

Note:

In YPbPr and HDMI modes, while in 720p-1080i
resolutions, only 16:9 mode is available.

In PC mode, only 16:9 mode is available.

Auto

When a WSS (Wide Screen Signalling) signal, which
shows the aspect ratio of the picture, is included in

the broadcast signal or the signal from an external
device, the TV automatically changes the ZOOM
mode according to the WSS signal.

• When the AUTO mode does not function correctly
due to poor WSS signal quality or when you want to
change the ZOOM mode, change to another ZOOM
mode manually.

16:9

This uniformly stretches the left and right sides of a

normal picture (4:3 aspect ratio) to ll the wide TV

screen.

English - 18 -

• For 16:9 aspect ratio pictures that have been
squeezed into a normal picture (4:3 aspect ratio),

use the 16:9 mode to restore the picture to its
original shape.

4:3

Use to view a normal picture (4:3 aspect ratio) as this
is its original size.

Panoramic

This stretches the left and right sides of a normal

picture (4:3 aspect ratio) to ll the screen, without

making the picture appear unnatural.

The top and bottom of the picture are slightly cut off.

14:9

This zooms up the wide picture (14:9 aspect ratio) to the
upper and lower limits of the screen.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to
the full screen.

Subtitle

This zooms up the wide picture (16:9 aspect ratio)
with subtitles to the full screen.

Zoom

This option zooms to the picture.

Note: You can shift to screen up or down by pressing
“ ” / “ ” buttons while picture zoom is selected as
panaromic, 14:9, Cinema or Subtitle.

Teletext

Teletext system transmits information such as news,
sports and weather on your TV. Note that is the signal
degrades, for example in poor/adverse weather
conditions, some text errors may occur or the teletext

mode may be aborted.

Teletext function buttons are listed below:

“

” Teletext On-Off / PAT Mode

Activates teletext mode when pressed once. Pressing

this button again will split the screen into two windows,

one displaying the teletext and the other displaying
the current channel. Pressing again will quit the
teletext mode.

“

” Index

Selects the teletext index page.

“

” Mix

Places the teletext screen over the programme.

“

” Expand

Press once to enlarge top half of the page, press again

to enlarge the bottom half of the page. Press again to
revert back to normal size.

“

” Reveal

Shows hidden information (e.g. solutions of games).

“

” Hold

Holds a text page when convenient. Press again to
resume.

“

” Subcode Pages / Time

Selects subcode pages if available when the teletext

is activated. When the teletext is not activated,

displays time info if the programme has teletext
transmission.

P+ / P- and numbers (0-9)

Press to select a page.

Note: Most TV stations use code 100 for their index
pages.

Coloured Buttons

(RED/GREEN/YELLOW/BLUE)

Your TV supports both FASTEXT and TOP text

systems. When these systems are available, the

pages are divided into groups or topics.

When FASTEXT system is available, sections in a
teletext page will become colour-coded and can be
selected by pressing the coloured buttons. Press
a coloured button that corresponds to with your
needs.

English - 19 -

The coloured writings will appear, showing you which

coloured buttons to use when TOP text transmission
is present. Pressing P - or P + commands will request
the next or previous page respec tively.

Tips

Screen Care

Clean the screen with a slightly damp, soft cloth. Do

not use abrasive solvents as they may damage the
coating layer of the TV screen.

For your safety, unplug the mains plug when cleaning
the set. When moving the TV, hold it properly from

the bottom part.

Image Persistence

Please note that ghosting may occur while displaying
a persistent image. LCD TVs’ image persistence may
disappear after a short time. Try turning off the TV
for a while.

To avoid this, do not leave the screen in still picture

for extended periods.

No Power

If your TV system has no power, please check the

main power cable and connection to the mains
socket outlet.

Poor Picture

Have you selected the correct TV system? Is your TV
set or house aerial located too close to a non-earthed

audio equipment or neon lights, etc.?

Mountains or high buildings can cause double pictures
or ghost images. Sometimes you can improve the
picture quality by changing the direction of the
aerial.

Is the picture or teletext unrecognisable? Check if you
have entered the correct frequency. Please retune
the channels.

The picture quality may degrade when two peripherals
are connected to the TV at the same time. In such a

case, disconnect one of the peripherals.

No Picture

Is the aerial connected properly? Are the plugs
connected tightly to the aerial socket? Is the aerial
cable damaged? Are suitable plugs used to connect

the aerial? If you are in doubt, consult your dealer.

No Picture means that your TV is not receiving a

transmission. Have you selected the correct button
on the remote control? Try once more.

Also make sure the correct input source has been
selected.

Sound

You can not hear any sound. Did you perhaps interrupt
the sound, pressing the button?

Sound is coming from only one of the speakers. Is the
balance set to one extreme? See Sound Menu.

Remote Control

Your TV no longer responds to the remote control.
Perhaps the batteries are exhausted. If so you can still
use the local buttons at the bottom of the TV.

Input Sources

If you cannot select an input source, it is possible that

no device is connected.

Check the AV cables and connections if you have tried
to connect a device.

English - 20 -

Appendix A: PC Input Typical
Display Modes

The display has a maximum resolution of 1920 x

1200. The following table is an illustration of some of

the typical video display modes.

Your TV may not support different resolutions.
Supported resolution modes are listed below.

If you switch your PC to an unsupported mode, a

warning OSD will appear on the screen.

Note: Resolution modes indicated with (*) are not
available for PIP/PAP modes.

Index

Resolution

Frequency

Standard

Hor

Ver

Ver (Hz)

Hor

(KHz)

1

640 350 85 37.9 VESA

2

640 400 85 37.9 VESA

3

640 400 70 31.5 IBM VGA

4

640 480 60 31.5 VESA

5

640 480 66 35.0 MAC

6

640 480 72 37.9 VESA

7

640 480 75 37.5 VESA

8

640 480 85 43.3 VESA

9

800 600 56 35.2 VESA

10

800 600 60 37.9 VESA

11

800 600 70 43.8

12

800 600 72 48.1 VESA

13

800 600 75 46.9 VESA

14

800 600 85 53.7 VESA

15

832 624 75 49.7 MAC

16

1024 768 43 35.5

VESA

(interlace)

17

1024 768 60 48.4 VESA

18*

1024 768 70 56.5 VESA

19*

1024 768 72 57.7

20*

1024 768 75 60.0

21*

1024 768 85 68.3

22

1152 864 60 53.8

23*

1152 864 70 64.2 VESA

24*

1152 864 75 67.5 VESA

25*

1152 864 85 77.1 VESA

26*

1152 870 75 68.9 MAC

27

1280 768 60 47.7 VESA

28

1360 768 60 47.7

29*

1280 768 75 60.2 VESA

30

1280 960 60 60.0 VESA

31*

1280 960 75 75.0 VESA

32*

1280 960 85 85.9 VESA

33

1280 1024 60 64.0 VESA

34*

1280 1024 75 80.0 VESA

35*

1280 1024 85 91.1 VESA

36

1400 1050 60 65.3

37*

1400 1050 75 82.3

38

1440 900 60 55.9

39*

1440 900 75 70.6

40*

1600 1200 60 75.0 VESA

41

1680 1050 60 65.3

42*

1920 1200 60 74.5

Appendix B: AV and HDMI Signal
Compatibility (Input Signal Types)

Source

Supported Signals

Available

EXT-1

(SCART

1)

PAL 50/60 O

NTSC 60 O

RGB 50 O

RGB 60 O

EXT-2

(SCART-2)

PAL 50/60 O

NTSC 60 O

RGB 50 X

RGB 60 X

FAV

PAL 50/60 O

NTSC 60 O

YPbPr

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

HDMI1
HDMI2

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

1080P 24 HZ O

(X: Not Available, O: Available)

Note: In some cases a signal on the LCD TV may
not be displayed properly. The problem may be
an inconsistency with standards from the source
equipment (DVD, Set-top box, etc.). If you do
expereince such a problem please contact your dealer
and also the manufacturer of the source equipment.

English - 21 -

Appendix C: Supported DVI
Resolutions

When connecting devices to your TV’s connectors by

using DVI converter cables (not supplied), you can

refer to the following resolution information.

24Hz

25Hz

30Hz

50Hz

60Hz

480i

þ

480p

þ

576i

þ

576p

þ

720p

þ þ

1080i

þ þ

1080p

þ þ þ þ þ

Appendix D: PIP/PAP Mode
Combinations

MAIN

TV

Scart1

Scart2

FAV

HDMI1

HDMI2

YPbPr

PC-

VGA

TV





(RGB)

     

Scart1



(RGB)





(RGB)(RGB)

   

Scart2





(RGB)

     

FAV





(RGB)

     

HDMI1

       

HDMI2

       

YPbPr

       

PC-VGA

       

(RGB): This indicates that, selection is possible only
if Scart-1 has a RGB signal.

Restrictions: Scart-1 source must have RGB signal to
perform PIP\PAP with sources TV, Scart-2, FAV.

If these sources are set to main window, and Scart-1
does not have a RGB signal, Pip\Pap source can not

be switched to the Scart-1 source.

If scart-1 source is set to main window, and scart-1
does not have a RGB signal, Pip\Pap source can not
be switched to TV, Scart-2 and FAV sources.

English - 22 -

Specications

TV BROADCASTING

PAL/SECAM B/G D/K K’ I/I’ L/L’

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

NUMBER OF PRESET CHANNELS

200

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220-240V AC, 50 Hz.

AUDIO

German + Nicam Stereo

AUDIO OUTPUT POWER (W

RMS.

) (10% THD)

2 x 8

POWER CONSUMPTION (W)

190 W (max)

< 1W (Standby)

PANEL

16:9 display, 40” Screen Size

DIMENSIONS (mm)

DxLxH (With foot): 246 x 970 x 653

Weight (Kg): 15,1

DxLxH (Without foot): 99 x 970 x 613

Weight (Kg): 14,4

Products

Battery

Information for Users on Disposal of Old Equipment and
Batteries

[European Union only]

These symbols indicate that equipment with these symbols should not
be disposed of as general household waste. If you want to dispose

of the product or battery, please consider the collection systems or

facilities for appropriate recycling.

Notice: The sign Pb below the symbol for batteries indicates that

this battery contains lead.

English - 23 -

Important Instruction

For your own safety read following instruction carefully before attempting to connect this unit to the mains
supply.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured

markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal which is marked with

the letter E, or by the earth symbol, or coloured green or green and yellow.

The wire which is coloured blue or black must be connected to the terminal which is marked with the

letter N or coloured Black.

The wire which is coloured brown or red must be connected to the terminal which is marked with the
letter L or coloured Red.

For continued protection against risk of re, replace only with same type and rating of fuse (ASTA

approved 5A 250VAC fuse).

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE REMOVING
COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

SAFETY PRECAUTION

THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT
ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

GREEN

&

YELLOW

(Earth)

(if there is earth cable)

FUSE

BROWN

(Live)

BLUE

(Neutral)

50155716
