Walker DSD56, DSD62, DGHS42, DGHS36, DGHS48 User Manual

ILLUSTRATED

PARTS MANUAL

Deck and Carrier Frame Assemblies (36”, 42”, 48”, 52”, 56”, 62” & 74”)

Effective Date: P/N 5000-19 08-01-08

KEY TO ABBREVIATIONS USED IN THIS MANUAL

Abbreviation What it Represents

º (Dimension) ....................................................................................................................................Degrees (Angle)

" (Dimension) ....................................................................................................................................................inches

(-) ...................................................................................................................................................Negative (Polarity)

(+).................................................................................................................................................... Positive (Polarity)

AT................................................................................................................................................................ All-Terrain

CCW ..............................................................................................................................................Counter-clockwise

Conn. ..........................................................................................................................................................Connector

CW.............................................................................................................................................................. Clockwise

D ...................................................................................................................................................................Diameter

DGHS......................................................................Deck, Grass Handling System (number refers to size in inches)

DML ............................................................................................... Deck, Mulching (number refers to size in inches)

DSD ..................................................................................... Deck, Side Discharge (number refers to size in inches)

DU................................................................................................................................................... Garlock (Bearing)

ESNA (Fastener)........... ... ...........................................................................................................Nylon Insert Locknut

FSC........................................................................................................................................ Forward Speed Control

GA.....................................................................................................................................................................Gauge

gal. .....................................................................................................................................................................gallon

GHS .......................................................................................................................................Grass Handling System

GR (Fastener)................................................................................................................................................... Grade

HP...........................................................................................................................................................Horse Power

HT .......................................................................................................................................................... Heat-Treated

ID ..............................................................................................................................Identification or Inside Diameter

L....................................................................................................................................................................... Length

LH ..........................................................................................................Left Hand (orientated with operator on seat)

LP...............................................................................................................................................................Low Profile

mm (Dimension).. ... .... ... ... ... ... .... ................................................................................................................ millimeters

MS (Fastener).....................................................................................................................................Machine Screw

NS (as part number)................................................................................... Item is not sold by Walker Manufacturing

OD................................................................................................................................................... Outside Diameter

oz. ......................................................................................................................................................................ounce

PFH (Fastener) ............................................................................................................................... Phillips Flat Head

P/N.......................................................................................................................................... .... ... ... ... ...Part Number

PPH (Fastener).......................................... ... ... .... ... ... .....................................................................Phillips Pan Head

PTH (Fastener) .............................................................................................................................Phillips Truss Head

PTO......................................................................................................................................... .... ... ... ..Power Take-Off

QKS ..........................................................................................................................................................Quick Slide

qt......................................................................................................................................................................... quart

RH....................................................................................................... Right Hand (orientated with operator on seat)

SAE (Fastener) ....................................................................................................... Society of Automotive Eng ine er s

SBH (Fastener).......................................... ... ... .... ... ... ........................................................Socket Button Head (Bolt)

SD.......................................................................................................................................................Side Discharge

SFH (Fastener) ................................................................................................................................Slotted Flat Head

SHC (Fastener)................... ... .........................................................................................................Socket Head Cap

SHL (Fastener) ................................................................................................................................... Shoulder (Bolt)

SM (Fastener).............................................................................................................................Sheet Metal (Screw)

S/N.......................................................................................................................................... .... ... ... ... Serial Number

Spg............................................................................................................................

(Fastener)

SQH

SS (Fastener).......................................................................................................................................Stainless Steel

ST (Fastener).............................................................................................................................Self-Tapping (Screw)

Term...............................................................................................................................................................Terminal

V...........................................................................................................................................................................Volts

......................................................................................................................................Square Head

........................................Spring

NOTE: In some instances, combinations of abbreviations may be used (e.g. PPHMS - Phillips Pan Head Machine Screw). Use only genuine Walker® replacement parts. Effective Date 08-01-08

ILLUSTRATED PARTS LIST

Section of Mower Covered Page Section of Mower Covered Page

Decals & Paint

Deck Decals / Touch-Up Paint ........................ .... ... . 2

Deck and Carrier Frame Assemblies

36 Inch Complete Carrier Frame Assembly ............4

DGHS36 Deck Assembly ............. ...... .... ... ... ... .... ... . 6

DSD36 Deck Assembly ........................................... 8

DML36 Inch Complete Carrier Frame Assembly .. 10

DML36 Deck Assembly ......................................... 12

42 Inch Complete Carrier Frame Assembly ..........14

DGHS42 Deck Assembly ............. ......................... 16

DSD42 Deck Assembly ......................................... 18

DML42A Deck Assembly ...................................... 20

DML42B Deck Assembly ...................................... 22

48 Inch Complete Carrier Frame Assembly ..........24

DGHS48 Deck Assembly ............. ......................... 26

DSD48 Deck Assembly ......................................... 28

52 Inch Complete Carrier Frame Assembly ..........30

DGHS52 Deck Assembly ............. ......................... 32

52 Inch Complete Carrier Frame Assembly ..........34

DSD52 Deck Assembly ......................................... 36

Mulching Kit (For DSD52 Deck Assembly) ...........38

56 Inch Complete Carrier Frame Assembly ..........40

DSD56 Deck Assembly ......................................... 42

62 Inch Complete Carrier Frame Assembly ..........44

DSD62 Deck Assembly ......................................... 46

74 Inch Complete Carrier Frame Assembly ..........48

DSD74 Deck Assembly ......................................... 50

Maintenance

Optional Break-Away Blades ................................ 52

Blade Usage Chart ................................................ 53

Deck Weldment Replacement Parts ..................... 54

Deck Height Adjuster Kit ....................................... 56

Lubrication Points ................................................. 58

Fastener Loctite

Torque Instructions ............................................... 60

MBSSD Deck Arm Adapter Kit .............................. 62

Maintenance And Service Record Sheet .............. 64

Deck / Tractor Compatibility Chart ........................ 64

Warranty

Limited Warranty ................................................... 65

®

Application &

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

1

DECK DECALS / TOUCH-UP PAINT

I TEM PAR T D ESC R I P TIO N L OCA TIO N NO . N O. NO. NO. REQ’D. GHS REQ’D SD

DSD52 And DSD62 Deck Decals

1 8653 Caution, Pivot Joint Carrier Frame 0 2 2 8748 Cutting Height Adjustment Footrest Pulley Guard 0 1 3 8746 Universal Joint Lube Mount Bracket/PTO Guard 0 1 4 5808-1 Danger, Rotating Blades (52" Deck) Deck Housing (one on each end) 0 2 5 8647 Danger, Tilt-Up Carrier Frame 0 1 6 8653-1 Transport Warning Deck Housing, Front 0 1 7 8732 Decal (52") Deck Housing, Front 0 1 8 5809 Walker Mower Logo (3") Carrier Frame, Front 0 1

9 8734 Drive Belt Routing Underneath Deck Cover Plate 0 1 10 5848 Danger, Side Discharge Shield Side Discharge Shield 0 1 11 5808 Danger, Rotating Blades (62" Deck) Cover Plate (one on each end) 0 2 12 8750 Decal (62") Deck Housing, Front 0 1 13 8749 Drive Belt Routing Underneath Deck Cover Plate 0 1 14 8746-1 Decal, Tele PTO Shaft U-Joint Shaft Assembly 0 1

36", 42", 48", DGHS52 & 56" Deck Decals

1 8653 Caution, Pivot Joint Carrier Frame 2 2

5 8647 Danger, Tilt-Up Carrier Frame 1 1

6 8653-1 Transport Warning Deck Housing, Front 0 1

7 8732 Decal (52") Deck Housing, Front 1 0

8 5809 Walker Mower Logo (3") Carrier Frame, Front 1 1 10 5848 Danger, Side Discharge Shield Side Discharge Shield 0 1 11 5808 Danger, Rotating Blades Deck Housing (one on each end) 2 2 15 5846 Grease Fitting Deck Cover Plate 1 1 16 6875 PTO Alignment Arrow Universal Joint Shaft Assembly 1 1 17 5807-3 Cutting Height Adjustment Gearbox Cover 1 1 18 5865 Blade Mounting Torque Carrier Frame 1 1 19 6789 Decal (56") Deck Housing, Front 0 1

DSD74 Deck Decals

1 8653 Caution, Pivot Joint Carrier Frame 0 2

4 5808-1 Danger, Rotating Blades Deck Housing (one on each end) 0 2

5 8647 Danger, Tilt-Up Carrier Frame 0 1

6 8653-1 Transport Warning Deck Housing, Front 0 1

8 5809 Walker Mower Logo (3") Carrier Frame, Front 0 1 10 5848 Danger, Side Discharge Shield Side Discharge Shield 0 1 15 5846 Grease Fitting Deck Cover Plate 0 1 16 6875 PTO Alignment Arrow Universal Joint Shaft Assembly 0 1 17 5807-3 Cutting Height Adjustment Middle Gearbox Cover 0 1 18 5865 Blade Mounting Torque Carrier Frame 0 1 20 7689 Decal (74") Deck Housing, Front 0 1

Touch-Up Paint

21 5866 Touch-Up Paint, Yellow (12 oz. Aerosol) NOTE: All parts requiring decals are shipped with decals applied.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

2

DECK DECALS / TOUCH-UP PAINT

10

1

2

4,11

14

3

1

9,13

8

5

4,11

7,12

10

18

1

25

VERY

E

GREASE

11

17

6

19

8

5

15

RS.

H

5846

DSD52 & DSD62

1

Deck Assemblies

16

6

11

DSD36, DSD42, DSD48 & DSD56 Deck Assemblies

10

4

18

16

1

RS.

H

25

VERY

E

5846

GREASE

6

8

17

15

1

5

16

1

18

11

RS.

H

25

VERY

E

5846

GREASE

17

7

8

15

20

DSD74

1

Deck Assembly

4

21

5

11

DGHS36, DML36, DGHS42, DML42A, DML42B, DGHS48 & DGHS52 Deck Assemblies

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

3

36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-4)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4

2 5744-1 Spring Clip Bracket 1

3 5743-1 Spring Cover 2

4 8667-10 Pivot Mount, LH/Adj. 1

5 5830-3 Grease Fitting (45 Degree) 4

6 8667-20 Pivot Mount, RH/Adj. 1

7 5743-4 Eyebolt (3/8-16 x 2-3/4) 2

8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8669 Lift Handle 1 12 5748-10 Rubber Mat (1-1/2 x 6) 2 13 5740-2 Deck Pin Bushing (5/8) 4 14 5708-6 36" Carrier Frame (Less Pivots) 1

(Includes Item # 12)

5708-1 36" Carrier Frame w/Forks (Less Pivots)

(Includes Items # 12, 21-23, 25,

F055, F068 & F098) 15 8674-10 Lever, Deck Lock, RH 1 16 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F020 5/16-18 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F084 5/16 Wave Spring Washer 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 2 F226 5/16-18 x 7/8 Hex Bolt 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker dealer.

NOTE: When installing Item # 8 on decks prior to S/N DX-62875,

the swivel hook end should be attached to the deck carrier frame.

Caster Wheel Components

17 5714-7 Bearing Cap 4 18 5714-5 Bearing, Caster Wheel 2 19 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 5,17 & 18)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

20 5714-3 Axle Spacer Tube 2 21 5770-1 Caster Wheel Fork 2 22 8768-1 Seal (1-3/4 x 1-1/8) 2 23 8037 Bearing Cone (3/4 ID) 4 24 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 25 8769-9 Dust Cap, Deck Caster 2

*

Use only genuine Walker® replacement parts. Effective Date 08-01-08

4

36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-4)

1

2

1

F166

3

7

10

23 24

24 23

22 21

25

F068

F098

F055

F047

3

7

8

15

10

F317

F336 F335

F117

16

14

13

6

5

F014

F317

12

16

F123

F226

F084

F020

4 F317

9

F012

17

20

19

5

18

11

F020

F084

F226

17

RS.

H

25

VERY

E

5846

GREASE

RS.

H

25

VERY

E

5846

GREASE

Refer to DGHS36 DECK ASSEMBLY, Page 6

Refer to DSD36 DECK ASSEMBLY, Page 8

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

5

DGHS36 DECK ASSEMBLY (P/N 5710-15)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619-2 PTO Shaft Guard 1

8618-3 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 24, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076)

6 5704-40 Gearbox and Tube Assembly 1

(Includes Items # 12-20, F124, F136,

F179, F211 & F229)

5704-45 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 12-16, 18-20, F136,

F179, F211 & F229)

7 5794 Discharge Chute W/O Spring Mount 1

(6-1/2 Diameter)

(Includes Items # 7, 10, 11, F223 & F224)

5794-1 Discharge Chute Assembly with

Spring Mount

(Includes Items # 7, 8, 10, 11, F223 & F224)

8 8678 Spring Mount, Chute 1

9 8677 Extension Spring (1 x 6-1/16) 1 10 5726 Chute Hinge (2 x 8) 1 11 5755 Chute Lower Lip 1 12 6054 Spline Coupling 3 13 P007 Gasket, Cap (Peerless #788030) 4 14 5061 Gearbox Connector Tube (6-11/16) 1 15 6732-2 Connecting Shaft (4-1/8) 1 16 5052-1 Gearbox (LH Rotation) 2

5052-5 Heavy Duty Gearbox (LH Rotation) 17 5706-4 Seal Protector Plate 2 18 5704-1 Gearbox Cover Support 2 19 5051-16 Tee Gearbox, Shear 1

5051-6 Heavy Duty Tee Gearbox, Shear 20 5060 Gearbox Connector Tube (2-5/16) 1 21 5052-3 1.375 x .750 x .187 Washer 4 22 5747-11 Rubber Mat (3 x 6) 2 23 5746-4 36" Gearbox Cover (Includes Item # 22) 1 24 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

25 5830 Grease Fitting 1

Deck Housing Components

26 8670 Tilt-Up Hook 1 27 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 28 8490 Roller Wheel Axle Bolt 2 29 5710-16 36 GHS Deck Housing 1

(Includes Items # 35 & 36) 30 NS Deck Serial Number Plate 1

*

**

*

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

31 5705-0 Blade, 20" (RH Rotation) 1 32 5705-2 Blade, 20" (LH Rotation) 1

5705-6 36 GHS Blade Set W/Hubs *

(Includes Items # 31-33, F002 & F202) 33 5706 Blade Hub & Trash Guard 2 34 7775-1 Hitch Pin, LH (Silver) #6 2 35 8735-10 Rubber Mat (5 x 6) 2 36 8788-1 Rubber Mat (1 x 2) 1 37 7775-2 Hitch Pin, RH (Gold) #6 2 38 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 9 F004 1/4-20 Keps Nut 2 F005 1/4-20 ESNA Nut 2 F013 3/8-16 Whiz Locknut 6 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F036 1/4-20 x 1/2 SBH Screw 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F087 #10 x 7/8 Fender Washer 2 F124 10-32 x 3/8 Taptite Machine Screw 9 F129 10-24 x 1/2 PTHMS 3 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F223 3/16 x 5/16 Semi-Tube Rivet F224 3/16 x 7/16 Semi-Tube Rivet * F229 C-Clip (13/16) 2 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

4***

***

*

* Service Part Only ** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD and MC.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

6

DGHS36 DECK ASSEMBLY (P/N 5710-15)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

RS.

H

5846

15

F002

F069

13

27

16

28

1

F136

2

F050 F029

F295

F211

Refer to 36 INCH CARRIER FRAME ASSEMBLY , Page 4

6

4

F076

F002

5

7

F087

3

9

8

F002

18

F129

F005

17

10

F124

F036

11

F223

14

13

27

F229

12

F224

F246

F025

F050

F039

21 16

F013

23

22

18

F136

F179

25

VERY

E

GREASE

24

25

13

20

13

19

12

F229

F004

26

F403

38

F059

F013

37

35

36

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

35

34

F202

21

33

F278

33

F038

29

F206

30

Hardware Used on Heavy Duty Gearboxes

F002 F055

F056

F018

32

31

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

7

DSD36 DECK ASSEMBLY (P/N 5710-17)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619-2 PTO Shaft Guard 1

8618-3 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 21, F069 & F295) 4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076) 6 5704-43 Gearbox and Tube Assembly 1

(Includes Items # 7-16, F124,

F136, F179, F211 & F229)

5704-46 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 7, 9-16, F136,

F179, F211 & F229) 7 5704-1 Gearbox Cover Support 2 8 5706-4 Seal Protector Plate 2 9 6054 Spline Coupling 3

10 P007 Gasket, Cap (Peerless #788030) 4 11 5061 Gearbox Connector Tube (6-11/16) 1 12 6732-2 Connecting Shaft (4-1/8) 1 13 5052-1 Gearbox (LH Rotation) 1

5052-5 Heavy Duty Gearbox (LH Rotation)

14 5051-16 Tee Gearbox, Shear 1

5051-6 Heavy Duty Tee Gearbox, Shear 15 5060 Gearbox Connector Tube (2-5/16) 1 16 5053-1 Gearbox (RH Rotation) 1

5053-5 Heavy Duty Gearbox (RH Rotation) 17 5052-3 1.375 x .750 x .187 Washer 4 18 5747-11 Rubber Mat (3 x 6) 2 19 5746-4 36" Gearbox Cover 1

(Includes Item # 18) 20 5830 Grease Fitting 1 21 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

22 8670 Tilt-Up Hook 1 23 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 24 8490 Roller Wheel Axle Bolt 2 25 5710-18 36 SD Deck Housing 1

(Includes Items # 23, 24, 29 & 31) 26 NS Deck Serial Number Plate 1 27 5705-1 Blade, 20" (RH Rotation) 2

5705-5 36 SD Blade Set W/Hubs

(Includes Items # 27, 28, F002 & F202)

*

**

** **

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

28 5706 Blade Hub & Trash Guard 2 29 8735-10 Rubber Mat (5 x 6) 2 30 7775-1 Hitch Pin, LH (Silver) #6 2 31 8788-1 Rubber Mat (1 x 2) 1 32 7775-2 Hitch Pin, RH (Gold) #6 2 33 5709-2 36/42 SD Discharge Shield 1 34 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 2 F013 3/8-16 Whiz Locknut 6 F014 3/8-16 ESNA Nut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 6 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 4 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F124 10-32 x 3/8 Taptite Machine Screw 9 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F229 C-Clip (13/16) 2 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

4***

***

*

* Service Part Only ** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS and MB.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

8

DSD36 DECK ASSEMBLY (P/N 5710-17)

CARRIER FRAME ASSEMBLY ,

INCL. OPTIONAL HEAVY DUTY GEARBOXES

F039

F025

F246

19

F050

VERY

E

GREASE

1

Refer to 36 INCH

2

RS.

H

25

5846

F050 F029

4

Page 4

F076

F039

17 16

F013

18

F002

7

F136

21

F179

3

F295

20

5

7

10

15

10

14

F069

6

9

13

9

F229

12

F004

33

34

22

F403

10

F136

23

F211

24

F014

8

F124

11

10

F229

23

9

F059

F013

32

F059

29

31

F202

30

28

27

29

28

17

F278 F038

25

F206

26

Hardware Used on Heavy Duty Gearboxes

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

F002 F055

F056 F018

27

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

9

DML36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-5)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-4 Eyebolt (3/8-16 x 2-3/4) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 8667-20 Pivot Mount, RH/Adj. 1 7 5830-3 Grease Fitting (45 Degree) 4 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8669 Lift Handle 1 12 5748-10 Rubber Mat (1-1/2 x 6) 2 13 5740-2 Deck Pin Bushing (5/8) 4 14 5708-8 DML36 Carrier Frame 1

(Includes Item # 12)

5708-7 DML36 Carrier Frame W/Forks

(Includes Items # 12, 21-23, 25,

F055, F068 & F098) 15 8674-10 Lever, Deck Lock, RH 1 16 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F020 5/16-18 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F084 5/16 Wave Spring Washer 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 2 F226 5/16-18 x 7/8 Hex Bolt 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker dealer.

Caster Wheel Components

17 5714-7 Bearing Cap 4 18 5714-5 Bearing, Caster Wheel 2 19 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 7, 17 & 18)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

20 5714-3 Axle Spacer Tube 2 21 5770-1 Caster Wheel Fork 2 22 8768-1 Seal (1-3/4 x 1-1/8) 2 23 8037 Bearing Cone (3/4 ID) 4 24 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 25 8769-9 Dust Cap, Deck Caster 2

*

Use only genuine Walker® replacement parts. Effective Date 08-01-08

10

DML36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-5)

1

2

1

3

F166

4

F014

F117

7

8

4

6

16

F336

15

10

F317

F335

16

14

25

13

F068

F098 F055

F317

23 24

24 23

22 21

16

F123

F226

12

F084

F020

3

5

F317

9

10

F047

F012

17

20

11

F020

F084

F226

19

7

18

17

RS.

H

25

VERY

E

5846

GREASE

Refer to DML36 DECK ASSEMBLY, Page 12

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

11

DML36 DECK ASSEMBLY (P/N 5710-11)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619-2 PTO Shaft Guard 1

8618-3 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 21, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076)

6 5704-82 DML36 Gearbox Tube Assembly 1

(Includes Items # 7-16, F136,

F179, F211 & F229)

7 5706-4 Seal Protector Plate 2 8 6054 Spline Coupling 3

9 P007 Gasket, Cap (Peerless #788030) 4 10 5065 Connector Tube (7-11/16) 1 11 6732-4 Connecting Shaft (5-5/16) 1 12 5052-4 Gearbox (LH 1.2:1) 1 13 5704-1 Gearbox Cover Support 2 14 5051-16 Tee Gearbox, Shear 1 15 5060 Connector Tube (2-5/16) 1 16 5053-4 Gearbox (RH 1.2:1) 1 17 5052-3 1.375 x .750 x .187 Washer 4 18 5747-11 Rubber Mat (3 x 6) 2 19 5746-6 DML36 Gearbox Cover 1

(Includes Item # 18) 20 5830 Grease Fitting 1 21 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

28 8735-10 Rubber Mat (5 x 6) 2 29 7775-1 Hitch Pin, LH (Silver) #6 2 30 8788-1 Rubber Mat (1 x 2) 1 31 5702-7 DML36 Deck Housing 1

(Includes Items # 28 & 30) 32 7775-2 Hitch Pin, RH (Gold) #6 2 33 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 2 F013 3/8-16 Whiz Locknut 6 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F039 3/8-16 x 1-1/4 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F124 10-32 x 3/8 Taptite MS 6 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F229 C-Clip (13/16) 2 F246 1/4-20 x 1/2 PTHMS 2 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

*

22 8670 Tilt-Up Hook 1 23 9772 Roller Wheel Assembly (2-1/2) 2

(Includes Item # F059) 24 8490 Roller Wheel Axle Bolt 2 25 NS Deck Serial Number Plate 1 26 5705-23 Blade 19" Mulch, Special 2 27 5706 Blade Hub & Trash Guard 2

Use only genuine Walker® replacement parts. Effective Date 08-01-08

12

* Service Part Only

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS and MB.

DML36 DECK ASSEMBLY (P/N 5710-11)

CARRIER FRAME ASSEMBLY ,

F025

1

F246 F050

18

F039

19

RS.

H

25

VERY

E

5846

GREASE

17

16

F013

9

15

13

F136

F179

14

2

F050

4

F029 F002

21

3

F295

20

13

12

F069

Refer to DML36 INCH Page 10

F076

5

6

9

8

7

F124

8

F004

22

33

F403

F229

11

9

F136

F211

10

9

F059

F229

8

24

23

F013

32

28

31

30

28

29

F202

26 F002

27

F206

25

27

26

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

F055 F056 F018

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

13

42 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5700-11)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-3 Eyebolt (3/8-16 x 2) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 8667-20 Pivot Mount, RH/Adj. 1 7 5830-3 Grease Fitting (45 Degree) 4 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8669 Lift Handle 1 12 5748-10 Rubber Mat (1-1/2 x 6) 2 13 5740-2 Deck Pin Bushing (5/8) 4 14 8660-13 42" Carrier Frame (Less Pivots) 1

(Includes Item # 12)

8660-12 42" Carrier Frame w/Forks (Less Pivots)

(Includes Items # 12, 21-23, 25,

F055, F068 & F098) 15 8674-10 Lever, Deck Lock, RH 1 16 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F020 5/16-18 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F084 5/16 Wave Spring Washer 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 2 F226 5/16-18 x 7/8 Hex Bolt 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker dealer.

NOTE: When installing Item # 8 on decks prior to S/N DX-62875,

the swivel hook end should be attached to the deck carrier frame.

Caster Wheel Components

17 5714-7 Bearing Cap 4 18 5714-5 Bearing, Caster Wheel 2 19 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 7, 17 & 18)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

20 5714-3 Axle Spacer Tube 2 21 5770-1 Caster Wheel Fork 2 22 8768-1 Seal (1-3/4 x 1-1/8) 2 23 8037 Bearing Cone (3/4 ID) 4 24 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 25 8769-9 Dust Cap, Deck Caster 2

*

Use only genuine Walker® replacement parts. Effective Date 08-01-08

14

42 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5700-11)

DECK ASSEMBLY,

1

2

1

3

F166

4

15

10

14

25

13

F317

F336

16

F068 F098

F055

F317

F014

F117

8

F335

7

4

6

3

5

23 24

24 23

22

21

16

F226

F123

F084

F020

F084

F047

12

F317

9

10

F226

F012

17

11

20

19

7

18

17

RS.

H

25

VERY

E

5846

GREASE

RS.

H

25

VERY

E

5846

GREASE

Refer to DSD42 DECK ASSEMBLY, Page 18

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

Refer to DGHS42 Page 16

®

replacement parts.

15

DGHS42 DECK ASSEMBLY (P/N 5705)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 26, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076)

6 5704-50 Gearbox and Tube Assembly 1

(Includes Items # 12-21, F124, F136,

F179, F211 & F229)

5704-8 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 12-16, 18-21, F136,

F179, F211 & F229)

7 5794 Discharge Chute W/O Spring Mount

(6-1/2 Diameter) 1

(Includes Items # 7, 10, 11, F223 & F224)

5794-1 Discharge Chute Assembly with

Spring Mount

(Includes Items # 7, 8, 10, 11, F223 & F224)

8 8678 Spring Mount, Chute 1

9 8677 Extension Spring (1 x 6-1/16) 1 10 5726 Chute Hinge (2 x 8) 1 11 5755 Chute Lower Lip 1 12 6054 Spline Coupling 4 13 P007 Gasket, Cap (Peerless #788030) 4 14 5063 Gearbox Connector Tube (8-5/8) 1 15 6732-3 Connecting Shaft (6-1/4) 1 16 5052-1 Gearbox (LH Rotation) 2

5052-5 Heavy Duty Gearbox (LH Rotation) 17 5706-4 Seal Protector Plate 2 18 5704-1 Gearbox Cover Support 2 19 5051-16 Tee Gearbox, Shear 1

5051-6 Heavy Duty Tee Gearbox, Shear 20 6732-1 Connecting Shaft (2") 1 21 5062 Gearbox Connector Tube (4-3/8) 1 22 5052-3 1.375 x .750 x .187 Washer 4 23 5747-11 Rubber Mat (3 x 6) 2 24 5785-5 42" Gearbox Cover (Includes Item # 23) 1 25 5830 Grease Fitting 1 26 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

27 8670 Tilt-Up Hook 1 28 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 29 8490 Roller Wheel Axle Bolt 2 30 NS Deck Serial Number Plate 1 31 5705-3 Blade, 22" (RH Rotation) 1 32 5706 Blade Hub & Trash Guard 2

*

**

*

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

33 5705-4 Blade, 22" (LH Rotation) 1

5705-8 42 GHS Blade Set with Hubs

(Includes Items # 31-33, F002 & F202) 34 8735-10 Rubber Mat (5 x 6) 2 35 7775-1 Hitch Pin, LH (Silver) #6 2 36 8788-1 Rubber Mat (1 x 2) 1 37 5704-4 42 GHS Deck Housing 1

(Includes Items # 34 & 36) 38 7775-2 Hitch Pin, RH (Gold) #6 2 39 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 9 F004 1/4-20 Keps Nut 2 F005 1/4-20 ESNA Nut 2 F013 3/8-16 Whiz Locknut 6 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F036 1/4-20 x 1/2 SBH Screw 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F087 #10 x 7/8 Fender Washer 2 F124 10-32 x 3/8 Taptite Machine Screw 6 F129 10-24 x 1/2 PTHMS 3 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F223 3/16 x 5/16 Semi-Tube Rivet F224 3/16 x 7/16 Semi-Tube Rivet * F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

*

***

*

***

* Service Part Only ** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD and MC.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

16

DGHS42 DECK ASSEMBLY (P/N 5705)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

F246

F050

24

23

F039

22

16

F179

F013

12

F229

13

21

13

20

F229

12

F004

27

39

F403

18

F136

F025

12

1

2

RS.

H 25

VERY

E

5846

GREASE

F050 F029

F002

4

F076

Refer to 42 INCH CARRIER FRAME ASSEMBLY , Page 14

6

5

3

26

F295

25

F069

F002

18

9

F002

8

F087

7

19

16

17

F124

F005

10

F129

F036

F229

11

F223

F224

12

F229

15

13

F136

28

F211

14

13

29

F059

28

F013

38

34

37

36

34

35

32

F002

F202

F206

33

32

F278 F038

22

30

Hardware Used on Heavy Duty Gearboxes

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

F055 F056 F018

31

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

17

DSD42 DECK ASSEMBLY (P/N 5707-10)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 22, F069 & F295) 4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076) 6 5704-51 Gearbox and Tube Assembly 1

(Includes Items # 7-17, F124, F136,

F179, F211 & F229)

5704-54 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 8-17, F136,

F179, F211 & F229) 7 5706-4 Seal Protector Plate 2 8 6054 Spline Coupling 4 9 P007 Gasket, Cap (Peerless #788030) 4

10 5063 Gearbox Connector Tube (8-5/8) 1 11 6732-3 Connecting Shaft (6-1/4) 1 12 5052-1 Gearbox (LH Rotation) 1

5052-5 Heavy Duty Gearbox (LH Rotation) 13 5704-1 Gearbox Cover Support 2 14 5051-16 Tee Gearbox, Shear 1

5051-6 Heavy Duty Tee Gearbox, Shear 15 6732-1 Connecting Shaft (2") 1 16 5062 Gearbox Connector Tube (4-3/8) 1 17 5053-1 Gearbox (RH Rotation) 1

5053-5 Heavy Duty Gearbox (RH Rotation) 18 5052-3 1.375 x .750 x .187 Washer 4 19 5747-11 Rubber Mat (3 x 6) 2 20 5785-5 42" Gearbox Cover 1

(Includes Item # 19) 21 5830 Grease Fitting 1 22 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

*

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

30 8735-10 Rubber Mat (5 x 6) 2 31 8788-1 Rubber Mat (1 x 2) 1 32 5703-3 42 SD Deck Housing 1

(Includes Items # 30 & 31) 33 7775-2 Hitch Pin, RH (Gold) #6 2 34 5709-2 36/42 SD Discharge Shield 1 35 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 2 F013 3/8-16 Whiz Locknut 6 F014 3/8-16 ESNA Nut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 6 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 4 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F124 10-32 x 3/8 Taptite Machine Screw 6 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

***

*

***

* Service Part Only

Deck Housing Components

23 8670 Tilt-Up Hook 1 24 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 25 8490 Roller Wheel Axle Bolt 2 26 NS Deck Serial Number Plate 1 27 5705-3 Blade, 22" (RH Rotation) 2

5705-7 42 SD Blade Set with Hubs

(Includes Items # 27, 28, F002 & F202) 28 5706 Blade Hub & Trash Guard 2 29 7775-1 Hitch Pin, LH (Silver) #6 2

Use only genuine Walker® replacement parts. Effective Date 08-01-08

18

*

** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS and MB.

DSD42 DECK ASSEMBLY (P/N 5707-10)

CARRIER FRAME ASSEMBLY ,

INCL. OPTIONAL HEAVY DUTY GEARBOXES

F039

8

F229

F246 F050

20

19

F039

18 17

F179

F013

9

16

9

15

F229

8

13

F136

F025

1

2

RS.

H

25

VERY

E

5846

GREASE

F050 F029

F002

4

F076

Refer to 42 INCH Page 14

5

3

22 21

F295

13

F069

6

14

12

7

F124

8

F004

23

35

F403

F229

11

9

F136

F211

24

10

9

F014

25

F229

F059

8

24

F013

34

F059

33

30

32

31

30

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

28

F002

29

F202

F206

27

28

18

F278 F038

26

Hardware Used on Heavy Duty Gearboxes

F055 F056 F018

27

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

19

DML42A DECK ASSEMBLY (P/N 5707-1)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-3 U-Joint Shaft, 90 Degree (14-7/8) 1

(Includes Items # 21, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076)

6 5704-55 42" Mulch Gearbox and 1

Tube Assembly, Heavy Duty

(Includes Items # 7-16, F136, F179 & F229)

7 6054 Spline Coupling 4 8 P007 Gasket, Cap (Peerless #788030) 4

9 5063 Gearbox Connector Tube (8-5/8) 1 10 6732-3 Connecting Shaft (6-1/4) 1 11 5052-8 Heavy Duty Gearbox (LH Rotation) 1 12 5704-1 Gearbox Cover Support 2 13 5051-6 Heavy Duty Tee Gearbox, Shear 1 14 6732-1 Connecting Shaft (2") 1 15 5062 Gearbox Connector Tube (4-3/8) 1 16 5053-8 Heavy Duty Gearbox (RH Rotation) 1 17 5052-3 1.375 x .750 x .187 Washer 4 18 5747-11 Rubber Mat (3 x 6) 2 19 5785-5 42" Gearbox Cover 1

(Includes Item # 18) 20 5830 Grease Fitting 1 21 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

22 8670 Tilt-Up Hook 1 23 9772 Roller Wheel Assembly (2-1/2) 2

(Includes Item # F059) 24 8490 Roller Wheel Axle Bolt 2 25 NS Deck Serial Number Plate 1 26 5705-28 Blade 22" Mulch 2

5705-19 DML42A Blade Set W/Hubs *

(Includes Items # 27, F002 & F202)

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

27 5706 Blade Hub & Trash Guard 2 28 8735-10 Rubber Mat (5 x 6) 2 29 7775-1 Hitch Pin, LH (Silver) #6 2 30 8788-1 Rubber Mat (1 x 2) 1 31 5701-11 DML42A Deck Housing 1

(Includes Items # 28 & 30) 32 7775-2 Hitch Pin, RH (Gold) #6 2 33 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 2 F013 3/8-16 Whiz Locknut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

*

* Service Part Only

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS and MB.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

20

DML42A DECK ASSEMBLY (P/N 5707-1)

7

F229

F246

F025

F050

19

E

GREASE

18

12

F136

F179

F038

F278

16

17

8

15

8

14

F229

7

13

1

2

4

21

F050 F029

F002

3

F295

RS.

H

25

VERY

5846

20

12

11

F069

Refer to 48 INCH CARRIER FRAME ASSEMBLY , Page 24

F076

5

6

7

F004

22

33

F403

F229

10

8

F136

F211

9

8

24

23

F059

F229

7

F013

32

28

31

30

29

28

F202

27

F206

25

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

26

F002

27

26

F055 F056 F018

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

21

DML42B DECK ASSEMBLY (P/N 5707-2)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 5285-3 U-Joint Shaft, 90 Degree (14-7/8) 1

(Includes Items # 21, F069 & F295) 4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076) 6 5704-54 42" Mulch Gearbox and 1

Tube Assembly, Heavy Duty

(Includes Items # 7-16, F136,

F179, F211 & F229) 7 6054 Spline Coupling 4 8 P007 Gasket, Cap (Peerless #788030) 4 9 5063 Gearbox Connector Tube (8-5/8) 1

10 6732-3 Connecting Shaft (6-1/4) 1 11 5052-5 Heavy Duty Gearbox (LH Rotation) 1 12 5704-1 Gearbox Cover Support 2 13 5051-6 Tee Gearbox, Shear 1 14 6732-1 Connecting Shaft (2") 1 15 5062 Gearbox Connector Tube (4-3/8) 1 16 5053-5 Heavy Duty Gearbox (RH Rotation) 1 17 5052-3 1.375 x .750 x .187 Washer 4 18 5747-11 Rubber Mat (3 x 6) 2 19 5785-5 42" Gearbox Cover 1

(Includes Item # 18)

20 5830 Grease Fitting 1 21 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

22 8670 Tilt-Up Hook 1 23 9772 Roller Wheel Assembly (2-1/2) 2

(Includes Item # F059)

24 8490 Roller Wheel Axle Bolt 2 25 NS Deck Serial Number Plate 1 26 5706 Blade Hub & Trash Guard 2 27 5705-10 Blade, 21" (Lower Mulching) 2

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

28 5705-11 Blade, 22" (Upper Mulching) 2

5705-12 42DML Blade Set W/Hubs

(Includes Items # 26-28, F002 & F202) 29 7775-1 Hitch Pin, LH (Silver) #6 2 30 8735-10 Rubber Mat (5 x 6) 2 31 8788-1 Rubber Mat (1 x 2) 1 32 5701-11 DML42A Deck Housing 1

(Includes Items # 30 & 31) 33 7775-2 Hitch Pin, RH (Gold) #6 2 34 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 2 F013 3/8-16 Whiz Locknut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 4 F050 1/4 SAE Washer 4 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

*

* Service Part Only

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MS and MB.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

22

DML42B DECK ASSEMBLY (P/N 5707-2)

7

F229

F246

F025

F050

19

VERY

E

GREASE

18

12

F136

F179

F038

F278

16

17

8

15

8

14

F229

7

13

1

2

4

21

F050 F029

F002

3

F295

RS.

H

25

5846

20

12

11

F069

Refer to 48 INCH CARRIER FRAME ASSEMBLY , Page 24

F076

5

6

7

F004

22

34

F403

F229

10

8

F136

F211

9

8

24

23

F059

F229

7

F013

33

30

32

31

29

30

F202

26

27

F206

25

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

28

26

28

F002 F056 F018

27

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

23

48 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7700-2)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-3 Eyebolt (3/8-16 x 2) 2 5 5830-3 Grease Fitting (45 Degree) 4 6 8667-10 Pivot Mount, LH/Adj. 1 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8669 Lift Handle 1 12 5748-10 Rubber Mat (1-1/2 x 6) 2 13 5740-2 Deck Pin Bushing (5/8) 4 14 8661-2 48" Carrier Frame (Less Pivots) 1

(Includes Item # 12)

8661-1 48" Carrier Frame w/Forks (Less Pivots)

(Includes Items # 12, 21-23, 25,

F055, F068 & F098) 15 8674-10 Lever, Deck Lock, RH 1 16 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F020 5/16-18 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F084 5/16 Wave Spring Washer 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 4 F226 5/16-18 x 7/8 Hex Bolt 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker dealer.

NOTE: The 48 Inch Carrier Frame is also used on the DML42A

Mulching Deck (5707-1) and DML42B Mulching Deck (5707-2).

Caster Wheel Components

17 5714-7 Bearing Cap 4 18 5714-5 Bearing, Caster Wheel 2 19 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 5, 17 & 18)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

20 5714-3 Axle Spacer Tube 2 21 5770-1 Caster Wheel Fork 2 22 8768-1 Seal (1-3/4 x 1-1/8) 2 23 8037 Bearing Cone (3/4 ID) 4 24 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 25 8769-9 Dust Cap, Deck Caster 2

*

Use only genuine Walker® replacement parts. Effective Date 08-01-08

24

48 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7700-2)

1

2

1

3

F166

4

15

10

F317

16

F336

F335

8

F117

3

25

F068 F098

F055

23

14

13

F014

7

F317

4

5

6

24 24

23

22 21

F047

16

F123

F226

F084

F020

12

F317

9

10

F084

F226

F012

11

17

20

19

RS.

H 25

VERY

E

5846

GREASE

5

18

17

RS.

H

25

VERY

E

5846

GREASE

Refer to DGHS48 DECK ASSEMBLY, Page 26

RS.

H 25

VERY

E

5846

GREASE

Refer to DSD48 DECK ASSEMBLY, Page 28

Refer to DML42A

Refer to LUBRICATION POINTS, Page 58.

DECK ASSEMBLY, Page 20 or

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

DML42B DECK ASSEMBLY, Page 22

25

DGHS48 DECK ASSEMBLY (P/N 7702-1)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 7285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 25, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 7794 48 GHS Discharge Chute W/O Spring 1

(Includes Items # 5, 9, 10, F223 & F224)

7794-1 Discharge Chute Assembly with

Spring Mount

(Includes Items # 5, 7, 9, 10, F223 & F224)

6 5704-58 Gearbox and Tube Assembly 1

(Includes Items # 11-20, F124,

F136, F179, F211 & F229)

5704-9 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 11-14, 16-20,

F136, F179, F211 & F229)

7 8678 Spring Mount, Chute 1 8 8677 Extension Spring (1 x 6-1/16) 1

9 7726 Chute Hinge (2 x 11) 1 10 7755 Chute Lower Lip 1 11 6054 Spline Coupling 4 12 P007 Gasket, Cap (Peerless #788030) 4 13 5066 Gearbox Connector Tube (9-5/16) 1 14 6732-6 Connecting Shaft (7") 1 15 5706-4 Seal Protector Plate 2 16 5052-1 Gearbox (LH Rotation) 2

5052-5 Heavy Duty Gearbox (LH Rotation) 17 5704-1 Gearbox Cover Support 2 18 7751-16 Tee Gearbox (1.2:1 Ratio) 1

7751-5 Heavy Duty Tee Gearbox (1.2:1 Ratio) 19 6732-2 Connecting Shaft (4-1/8) 1 20 5061 Gearbox Connector Tube (6-11/16) 1 21 5052-3 1.375 x .750 x .187 Washer 4 22 5747-12 Rubber Mat (3 x 6) 2 23 7785-3 48" Gearbox Cover 1

(Includes Item # 22) 24 5830 Grease Fitting 1 25 8067-10 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

26 8670 Tilt-Up Hook 1 27 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 28 8490 Roller Wheel Axle Bolt 2 29 NS Deck Serial Number Plate 1 30 7705-1 Blade, 25" (RH Rotation) 1

*

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

31 5706 Blade Hub & Trash Guard 2 32 7705-2 Blade, 25" (LH Rotation) 1

7705-3 48 GHS Blade Set with Hubs

(Includes Items # 30-32, F002 & F202) 33 7775-1 Hitch Pin, LH (Silver) #6 2 34 8735-10 Rubber Mat (5 x 6) 2 35 8788-1 Rubber Mat (1 x 2) 1 36 7701 48 GHS Deck Housing 1

(Includes Items # 34 & 35) 37 7775-2 Hitch Pin, RH (Gold) #6 2 38 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 9 F004 1/4-20 Keps Nut 2 F005 1/4-20 ESNA Nut 2 F013 3/8-16 Whiz Locknut 6 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F036 1/4-20 x 1/2 SBH Screw 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F087 #10 x 7/8 Fender Washer 2 F124 10-32 x 3/8 Taptite Machine Screw 4 F129 10-24 x 1/2 PTHMS 3 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F223 3/16 x 5/16 Semi-Tube Rivet F224 3/16 x 7/16 Semi-Tube Rivet * F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

4***

*

***

*

* Service Part Only ** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

26

DGHS48 DECK ASSEMBLY (P/N 7702-1)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

11

F229

22

F039

21 16

F013

F246 F050

F025

23

17

F136

F179

1

Refer to 48 INCH

2

RS.

H 25

VERY

E

5846

GREASE

F050 F029

CARRIER FRAME ASSEMBLY , Page 24

4

6

F002

3

25

F295

24

F002

12

20

12

18

F069

17

8

19

F229

11

F229

F004

26

38

F403

16

15

F124

F005

9

F036

10

14

12

F136

F211

27

13

12

F229

28

F059

11

F002

F129

7

F087

F223

F224

5

27

F013

37

34

36

35

34

33

31

F202

32

31

21

F278 F038

29

Hardware Used on Heavy Duty Gearboxes

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

F206

F002 F055

F056

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

F018

30

Refer to LUBRICATION POINTS, Page 58.

27

DSD48 DECK ASSEMBLY (P/N 7701-17)

INCL. OPTIONAL HEAVY DUTY GEARBOXES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 7285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 22, F069 & F295) 4 7275-16 U-Joint Tube Assy, Spline 1 5 5275-15 U-Joint Tube (9.5" OAL), Spline 1

(Includes Item # F076) 6 5704-60 Gearbox and Tube Assembly 1

(Includes Items # 7-17, F124,

F136, F179, F211 & F229)

5704-61 Heavy Duty Gearbox and Tube Assembly

(Includes Items # 8-17, F136,

F179, F211 & F229) 7 5706-4 Seal Protector Plate 2 8 6054 Spline Coupling 4 9 P007 Gasket, Cap (Peerless #788030) 4

10 5066 Gearbox Connector Tube (9-5/16) 1 11 6732-6 Connecting Shaft (7") 1 12 5052-1 Gearbox (LH Rotation) 1

5052-5 Heavy Duty Gearbox (LH Rotation) 13 5704-1 Gearbox Cover Support 2 14 5051-16 Tee Gearbox, Shear 1

5051-6 Heavy Duty Tee Gearbox, Shear 15 6732-2 Connecting Shaft (4-1/8) 1 16 5061 Gearbox Connector Tube (6-11/16) 1 17 5053-1 Gearbox (RH Rotation) 1

5053-5 Heavy Duty Gearbox (RH Rotation) 18 5052-3 1.375 x .750 x .187 Washer 4 19 5747-12 Rubber Mat (3 x 6) 2 20 7785-3 48" Gearbox Cover 1

(Includes Item # 19) 21 5830 Grease Fitting 1 22 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

*

**

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

30 8735-10 Rubber Mat (5 x 6) 2 31 8788-1 Rubber Mat (1 x 2) 1 32 7701-18 48 SD Deck Housing 1

(Includes Items # 30, 31 & 34) 33 7775-2 Hitch Pin, RH (Gold) #6 2 34 7707-10 48 SD Skid Bar 1 35 6709-5 48 SD Discharge Shield 1 36 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 6 F004 1/4-20 Keps Nut 6 F013 3/8-16 Whiz Locknut 6 F014 3/8-16 ESNA Nut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F031 1/4-20 x 5/8 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 4 F039 3/8-16 x 1-1/4 Hex Bolt 6 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 4 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw 1 F124 10-32 x 3/8 Taptite Machine Screw 6 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 14 F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

***

Deck Housing Components

23 8670 Tilt-Up Hook 1 24 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 25 8490 Roller Wheel Axle Bolt 2 26 NS Deck Serial Number Plate 1 27 7705-1 Blade, 25" (RH Rotation) 2

7705-5 48 SD Blade Set with Hubs

(Includes Items # 27, 28, F002 & F202) 28 5706 Blade Hub & Trash Guard 2 29 7775-1 Hitch Pin, LH (Silver) #6 2

Use only genuine Walker® replacement parts. Effective Date 08-01-08

28

*

* Service Part Only ** Item(s) used on the Heavy Duty version of standard gear-

boxes. The Heavy Duty cast iron gearboxes are interchangeable with Standard aluminum gearboxes.

*** Used on Heavy Duty gearbox configuration.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 5 to use the splined deck PTO shaft with

Model MB.

DSD48 DECK ASSEMBLY (P/N 7701-17)

CARRIER FRAME ASSEMBLY ,

INCL. OPTIONAL HEAVY DUTY GEARBOXES

F039

8

F229

F246

F050

F025

20

19 18

17

F039

13

F136

F179

F013

9

1

2

RS.

H

25

VERY

E

5846

GREASE

F050 F029

F002

Refer to 48 INCH Page 24

4

F076

5

3

22

F295

21

6

F069

13

16

9

14

15

F229

8

12

7

F124

36

F031

8

F229

F004

23

F014

F403

F059

F004

35

11

9

F136

F211

24

10

9

24

F229

8

25

F059

F211

34

F013

33

30

32

31

30

29

28

F202

F206

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

18

28

27

F278 F038

26

Hardware Used on Heavy Duty Gearboxes

F002 F055

F056

Effective Date 08-01-08 Use only genuine Walker

F018

27

Refer to LUBRICATION POINTS, Page 58.

®

replacement parts.

29

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811-1)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-3 Eyebolt (3/8-16 x 2) 2 5 5830-3 Grease Fitting (45 Degree) 4 6 8667-10 Pivot Mount, LH/Adj. 1 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8669-4 52GHS Lift Handle 1 12 5748-10 Rubber Mat (1-1/2 x 6) 2 13 5740-2 Deck Pin Bushing (5/8) 4 14 8811-3 52GHS Carrier Frame 1

(Includes Item # 12)

8811-2 52GHS Carrier Frame W/Pivots

(Includes Items # 12, 21-25,

F055, F068 & F098) 15 8674-10 Lever, Deck Lock, RH 1 16 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F020 5/16-18 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F084 5/16 Wave Spring Washer 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 4 F226 5/16-18 x 7/8 Hex Bolt 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker dealer.

Caster Wheel Components

17 5714-7 Bearing Cap 4 18 5714-5 Bearing, Caster Wheel 2 19 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 5, 17 & 18)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

20 5714-3 Axle Spacer Tube 2 21 5770-1 Caster Wheel Fork 2 22 8768-1 Seal (1-3/4 x 1-1/8) 2 23 8037 Bearing Cone (3/4 ID) 4 24 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 25 8769-9 Dust Cap, Deck Caster 2

*

Use only genuine Walker® replacement parts. Effective Date 08-01-08

30

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811-1)

1

2

3

F166

1

4

15

10

F317

16

F336 F335

25

F068 F098

F055

23

13

14

F014

F317

8

F117

4

5

6

7

16

3

24

F084

12

F317

9

10

16

24 23

22

21

16

F123

F226

F084

F020

F047

F226

F012

11

17

20

19

5

18

17

RS.

H

25

VERY

E

5846

GREASE

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

Refer to DGHS52 DECK ASSEMBLY, Page 32

®

replacement parts.

31

DGHS52 DECK ASSEMBLY (P/N 8810-1)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619-3 PTO Shaft Guard, 52GHS 1

8618-4 PTO Shaft Guard Assy/52

(Includes Items # 1, 2, F002 & F025)

3 7285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 24, F069 & F295)

4 7275-16 U-Joint Tube Assy, Spline 1 5 5794 Discharge Chute W/O Spring Mount

(6-1/2 Dia.) 1

(Includes Items # 5, 9, 10, F223 & F224)

5794-1 Discharge Chute W/Spring Mount

(Includes Items # 5, 7, 9, 10, F223 & F224)

6 5704-56 52 GHS Gearbox and Tube Assy 1

(Includes Items # 11-19 & F229)

7 8678 Spring Mount, Chute 1 8 8677 Extension Spring (1 x 6-1/16) 1

9 5726 Chute Hinge (2 x 8) 1 10 5755 Chute Lower Lip 1 11 6054 Spline Coupling 4 12 P007 Gasket, Cap (Peerless #788030) 4 13 5068-3 Connector Tube (10-5/16) 1 14 6732-10 Connecting Shaft (8-1/32) 1 15 5052-5 Gearbox, HD (LH Rotation) 2 16 5704-1 Gearbox Cover Support 2 17 7751-8 Tee Gearbox/Shear (1.2:1) 1 18 6732-4 Connecting Shaft (5-5/16) 1 19 5065 Connector Tube (7-11/16) 1 20 5052-3 1.375 x .750 x .187 Washer 4 21 5747-12 Rubber Mat (3 x 6) 2 22 6786-2 52 GHS Gearbox Cover 1

(Includes Item # 21) 23 5830 Grease Fitting 1 24 8067-10 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

Deck Housing Components

25 8670-9 Tilt-Up Hook 1 26 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059) 27 8490 Roller Wheel Axle Bolt 2 28 NS Deck Serial Number Plate 1 29 7705-7 Blade 27" (LH Rotation) 1 30 5706 Blade Hub & Trash Guard 2

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

31 7705-6 Blade 27" (RH Rotation) 1

7705-9 48 GHS Blade Set W/Hub

(Includes Items # 29-31, F002 & F202) 32 7775-1 Hitch Pin, LH (Silver) #6 2 33 8735-10 Rubber Mat (5 x 6) 2 34 8788-1 Rubber Mat (1 x 2) 1 35 8810-2 52 GHS Deck Housing 1

(Includes Items # 33 & 34) 36 7775-2 Hitch Pin, RH (Gold) #6 2 37 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 9 F004 1/4-20 Keps Nut 2 F005 1/4-20 ESNA Nut 2 F013 3/8-16 Whiz Locknut 2 F018 5/8-18 Hex Nut 2 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F036 1/4-20 x 1/2 SBH Screw 2 F038 3/8-16 x 1 Hex Bolt 4 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 2 F056 5/8 Split Lock Washer 2 F059 3/8 Wave Spring Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F087 #10 x 7/8 Fender Washer 2 F129 10-24 x 1/2 PTHMS 3 F136 AN960C416L Washer 16 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 4 F206 #2 x 3/16 Drive Pin 2 F211 1/4-20 x 7/8 Hex Bolt 12 F223 3/16 x 5/16 Semi-Tube Rivet F224 3/16 x 7/16 Semi-Tube Rivet * F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 4 F295 3/16 x 1-1/2 Split Spring Pin 1 F403 1/4-20 x 1/2 PTHMS, SS 2

*

* Service Part Only

Use only genuine Walker® replacement parts. Effective Date 08-01-08

32

DGHS52 DECK ASSEMBLY (P/N 8810-1)

11

F229

F246

1

F050

22

F025

21

2

RS.

H 25

VERY

E

5846

GREASE

F050 F029

4

Refer to 52 INCH CARRIER FRAME ASSEMBLY , Page 30

6

F002

15

20

F278 F038

16

F179

F136

3

24

F295

23

F002

12

19

12

17

F069

16

8

F002

7

5

F087

18

F229

11

15

F129

F005

12

F036

F229

F059

9

10

F223

F224

11

F229

F004

37

25

F403

F013

14

12

F136

F211

26

13

26

27

F206

36

33

35

34

33

32

30

F202

F002

28

30

F013

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

F055

31

F056

Refer to LUBRICATION POINTS, Page 58.

F018

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

29

33

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-4 Eyebolt (3/8-16 x 2-3/4) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 5830-3 Grease Fitting (45 Degree) 4 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8811-12 52 SD Carrier Frame 1

8811-10 52 SD Carrier Frame, with Pivots

(Includes Items # 9, 10, 15,

F317, F335 & F336) 12 5850-5 Handle Grip (1 x 1 x 3-3/4) 1 13 8811-25 Tilt Bar, with Grip (35") 1

(Includes Item # 12) 14 7775-5 Lock Pin (5/16) 1 15 8674-10 Lever, Deck Lock, RH 1 16 8740 Deck Pin Bushing (3/4 ID) 4 17 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Caster Wheel Components

18 8766 Axle Nut (3/4-16) 2 19 8768-2 Seal, Reverse Lip 4 20 8037 Bearing Cone (3/4 ID) 4 21 8037-2 Bearing Race 4 22 8768 Caster Wheel, Pneumatic (11 x 4.00-5) 2

(Includes Items # 6 & 21)

8768-3 Tire, Pneumatic (11 x 4.00-5) 8768-5 Caster Wheel (5 x 3) *

23 8767 Axle, Caster Wheel (5-1/8) 2 24 8765-10 Caster Wheel Fork 2 25 8769-7 Seal 2 26 8769-6 Bearing Cone (1" ID) 4 27 8769-5 Bearing Cup (2 x 1-5/8) 4 28 8769-8 Dust Cap, Deck Caster 2

Fasteners

F014 3/8-16 ESNA Nut 2 F117 Retainer Ring 2 F140 7/16-14 x 1 Hex Bolt 4 F166 Retainer Ring 2 F218 7/16 Split Lock Washer 4 F263 1-1/4 External Snap Ring 4 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2 F344 3/4-16 Slotted Hex Nut 2 F347 3/4 SAE Washer 2 F348 1/8 x 1-1/2 Cotter Pin 2

*

* Service Part Only

NOTE: The E-Z Pin Puller P/N 8770 can be ordered to assist

removing and installing height adjustment hitch pins on larger decks. This item stows on tractor when not in use.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

34

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811)

1

2

3

F166

1

ORDER AS P/N 8770

F348

28

F344 F347

26 27

27 26

25

F140

F218

23

19

20

21

15

10

17

24

22

F218

F140

21

F317

13

20

19

18

16

7

17

14

F263

11

F336

F335

4

F317

F014

12

F117

6

8

4

3

5

F317

9

10

6

Refer to DSD52 DECK ASSEMBLY, Page 36

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

35

DSD52 DECK ASSEMBLY (P/N 8810)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Blade Drive Components

1 8789-5 Pulley Guard 1 2 8786-15 Footrest Assembly (Includes Item # 18) 1 3 8754-3 Edge Molding 2 4 8754-10 52 SD Cover Plate 1

(Includes Items # 3 & F354)

5 8245 Idler Pulley (6") 3 6 8755 Blade Drive Pulley (3-7/8) 3 7 8762 Dampening Spring (Gas) 1 8 5146 10mm Ball Stud 2

9 8373-3 Idler Arm (2-Hole) 1 10 5830 Grease Fitting 3 11 8374-1 Idler Arm Guide 1 12 7201-3 DU Bearing 2 13 7201-4 Inner Race (1-1/2) 1 14 5841 Retainer Washer (3/8 x 1-1/4) 1 15 8736 Blade Drive Belt (R3VX1000-2) 1 16 6240-2 Drive Pulley (4-1/2 / 3V) 1

(Includes Items # F114 & F277) 17 8787 Deck Cover Knob 3 18 8786-10 Rubber Mat (6 x 10-1/2) 2

Gearbox and Dolly Wheel Components

19 6206 Pressure Relief Valve 1 20 8745-25 Dolly Wheel/PTO Guard Assembly

(Includes Items # 21, 26, 28, 31, 34, 35,

F012, F013, F046, F052, F168,

F226, F339 & F355) 21 6715 Roller Wheel (3-7/8) 3 22 8810-30 Tilt Dolly Mount Frame 1 23 8810-34 Axle, Dolly Mount 1 24 8285-20 U-Joint Shaft Assy, T-Scope 1

(Includes Items # 25, F076 & F277) 25 5830-3 Grease Fitting (45 Degree) 2 26 8788 Rubber Bumper (Self-Adhesive Mount) 1 27 8745-14 Retract Lever 1 28 5850-1 Handle Grip 1 29 8745-12 Actuator Link 1 30 8745-13 Dolly Wheel Mount 1

(Includes Item # 10) 31 8745-15 Axle Spacer Tube 1 32 5229 Extension Spring (1/2 x 2-1/4) 1 33 8745-20 Mount Bracket 1

(Includes Items # 26, F052, F068 & F339) 34 5103-4 Pivot Bushing (3/8 ID) 2 35 8745-40 PTO Cover Plate 1 36 8051-10 Right Angle Gearbox (Includes Item # 19) 1

Deck Housing Components

37 8727 Washer Shim (13/16 x 1/4) 4 38 8775 Hitch Pin (#219) 4 39 8735-10 Rubber Mat (5 x 6) 2 40 8790 Rubber Cushion Strip 3 41 NS Deck Serial Number Plate 1

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

42 8810-10 52 SD Deck Housing 1

(Includes Items # 39 & 40) 43 8692-10 Baffle, DSD52 1 44 8052-2 Blade Spindle 3 45 5705-25 Blade Spacer 3 46 5705-14 Blade, 18-1/2 (RH Rotation) 3

8738-7 52 SD Blade Set

47 8910-5 Tie-Down Strap 2

(Used to secure deck in tilt-up position

during transport) 48 8707 52/62 SD Skid Bar 1 49 8709 52/62 SD Discharge Shield 1 50 5052-3 1.375 x .750 x .187 Washer 12 51 8670-10 Tilt-Up Hook 1

Fasteners

F004 1/4-20 Keps Nut 11 F009 5/16-18 Whiz Locknut 7 F012 3/8-16 Keps Nut 3 F013 3/8-16 Whiz Locknut 14 F014 3/8-16 ESNA Nut 3 F020 5/16-18 ESNA Nut 2 F023 10-24 ESNA Nut 2 F029 1/4-20 x 1/2 Hex Bolt 5 F032 1/4-20 x 3/4 Hex Bolt 2 F034 5/16-18 x 3/4 Hex Bolt 1 F039 3/8-16 x 1-1/4 Hex Bolt 2 F040 3/8-16 x 1-1/2 Hex Bolt 12 F041 3/8-16 x 1-3/4 Hex Bolt 3 F046 3/8-16 x 3-1/2 Hex Bolt 1 F048 1/2 SAE Washer 3 F051 3/8 SAE Washer 6 F052 5/16 External Star Lock Washer 2 F055 5/8 SAE Washer 3 F059 3/8 Wave Spring Washer 2 F068 1/8 x 1 Cotter Pin 3 F076 3/8-16 x 5/8 SQH Set Screw 1 F108 3/8-16 x 2 Hex Bolt 1 F114 5/16-18 x 5/8 SQH Set Screw 2 F134 AN960816L Washer 3 F168 5/16 Split Lock Washer 8 F206 #2 x 3/16 Drive Pin 2 F226 5/16-18 x 7/8 Hex Bolt 12 F246 1/4-20 x 1/2 PTHMS 2 F252 10-24 x 3/4 PFHMS 2 F276 5/8-11 Jam Nut 3 F277 3/16 x 5/8 Woodruff Key (#605) 5 F295 3/16 x 1-1/2 Split Spring Pin 2 F339 5/16-18 x 3/4 Self-Tapping Bolt 2 F343 1/2-20 x 2 Hex Bolt 3 F354 5/16 Knurled Thread Insert 2 F355 3/8-16 x 4 Hex Bolt 1 F356 1/4-20 x 5/8 PTHMS, SS 2

*

* Service Part Only

Use only genuine Walker® replacement parts. Effective Date 08-01-08

36

DSD52 DECK ASSEMBLY (P/N 8810)

F246

F039

F004

48

Secure to Vehicle According to 8653-1 Transport Warning Decal

7

2

4

F041 F051

F114

8 F009 9

F009

10

F252

11

F023

F277

5

F277

1

Refer to 52 INCH CARRIER FRAME ASSEMBLY , Page 34

F276 F055

6

24

10

23

21

22

20

19

36

37 38

39

40

41

F004

44

45

46

42

F029

F076

F277

F009

F226

F355

34

35

34

F013

F206

33

32

F020

F046

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

25

F295

21

F134

F068

F013

F012

F052

F014

F339

F134

27

29

F068

28

F020

F168

F226

30

26

10

31

21

F041 F051

F012

15

F034

F009

18

F041

F051

F108 14 13

F040

50

F004

46

F277

12

F029

44 45

F004

8

F051

F004

6

16

5

F356

46

51

F013

39 F226 40

3

F168

43

17

F354

6

49

F014

40

F059

F032

47

F277

44

45

F048

F343

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

37

MULCHING KIT (FOR DSD52 DECK ASSEMBLY)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Kit 8691 Mulching Kit (For DSD52 Deck Assembly)

Includes Items # 1-7, fasteners listed and instructions. May be ordered as a factory-installed option or as a kit for dealer installation. Contact your Walker dealer. Refer also to DSD52 DECK ASSEMBLY, page36.

1 8691-4 Baffle, RH 1 2 8691-3 Baffle, Center 1 3 8691-2 Baffle, LH 1 4 8052-9 Mulch Blade Spacer 3 5 5705-15 Blade, 18-3/8" Upper Mulch 3

8738-8 52 SD Mulching Blade Set 6 8691-10 Blade Saddle 3 7 5705-14 Blade, 18-1/2 (RH Rotation) 3

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F004 1/4-20 Keps Nut 9 F029 1/4-20 x 1/2 Hex Bolt 9 F048 1/2 SAE Washer 3 F343 1/2-20 x 2 Hex Bolt 3

* Service Part Only. Includes 5705-15 Blades (3 Pieces).

NOTE: Reuse Item # 7 from DSD52 DECK ASSEMBLY. Refer to

DSD52 DECK ASSEMBLY, page36.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

38

F004

MULCHING KIT (FOR DSD52 DECK ASSEMBLY)

F029

1

F004

F029

F004

6

7

F048 F343

F029

F004

F029

Refer to DSD52 DECK ASSEMBLY, Page 36

F004

F029

F004

4

F004

5

4

5

6

7

F029 F029

6

F004

3

F029

4 5

2

F004

7

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

39

56 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 6720)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-3 Eyebolt (3/8-16 x 2) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 5830-3 Grease Fitting (45 Degree) 4 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1

10 7406-1 Handle Grip, Red 2 11 5748-10 Rubber Mat (1-1/2 x 6) 2 12 6720-1 56 SD Carrier Frame 1

(Includes Item # 11) 13 5740-2 Deck Pin Bushing (5/8) 4 14 8674-10 Lever, Deck Lock, RH 1 15 5830 Grease Fitting 6 16 5850-5 Handle Grip (1 x 1 x 3-3/4) 1 17 6811-25 Tilt Bar With Grip (30") 1

(Includes Item # 16) 18 7775-5 Lock Pin (5/16) 1

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Caster Wheel Components

19 5714-7 Bearing Cap 4 20 5714-5 Bearing, Caster Wheel 2 21 5715-4 Caster Wheel, Pneumatic (8 x 3.00-4) 2

(Includes Items # 6, 19 & 20)

5715-10 Tire, Pneumatic (8 x 3.00-4) 5715-9 Tire Tube, Pneumatic (2.80/2.50-4) * 5715-3 Caster Wheel & Tire/No-Flat (8 x 3.00-4) ** 5715-11 Tire, Caster Wheel/No-Flat (8 x 3.00-4) **

22 5714-3 Axle Spacer Tube 2 23 5770-1 Caster Wheel Fork 2 24 8768-1 Seal (1-3/4 x 1-1/8) 2 25 8037 Bearing Cone (3/4 ID) 4 26 8769-1 Bearing Cup (1-3/4 x 1-7/16) 4 27 8769-9 Dust Cap, Deck Caster 2

Fasteners

F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F055 5/8 SAE Washer 2 F068 1/8 x 1 Cotter Pin 2 F098 5/8-18 Slotted Hex Nut 2 F117 Retainer Ring 2 F123 1" External Snap Ring 4 F166 Retainer Ring 2 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2

*

* Service Part Only ** May be ordered as a factory-installed option or as a kit for

dealer installation. Contact your Walker Dealer.

NOTE: When installing Item # 8 on decks prior to S/N DX-62875,

the swivel hook end should be attached to the deck carrier frame.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

40

56 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 6720)

Refer to LUBRICATION POINTS, Page 58.

1

2

1

3

F166

4

14

10

F317

F336

8

3

F335

F117

13

27

12 F068 F098

F055 25 26

15

4

5

6

7

F014

F317

11

26 25

24

16

F123

15

23

17

F047

F317

9

10

F012

18

19

22

21

6

20

19

RS.

H

25

VERY

E

5846

GREASE

Refer to DSD56 DECK ASSEMBLY, Page 42

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

41

DSD56 DECK ASSEMBLY (P/N 6720-20)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619-2 PTO Shaft Guard 1

8618-3 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025) 3 7275-16 U-Joint Tube Assy, Spline 1 4 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1

(Includes Item # F076) 5 5285-3 U-Joint Shaft, 90 Degree (14-7/8) 1

(Includes Items # 23, F069 & F295) 6 5052-6 Heavy Duty Gearbox, LH (1:2.2 Ratio) 1 7 6701-51 56 SD Gearbox and 1

Tube Assembly, Heavy Duty

(Includes Items # 6, 8-16, 21, 22, F136,

F179, F211 & F229) 8 6054 Spline Coupling 5 9 P007 Gasket, Cap (Peerless #788030) 6

10 5069 Gearbox Connector Tube (14-1/2) 1 11 6732-9 Connecting Shaft (12-1/8) 1 12 5058-6 Heavy Duty Tee Gearbox (1:1.2 Ratio) 1 13 5060 Gearbox Connector Tube (2-5/16) 1 14 6732-3 Connecting Shaft (6-1/4) 1 15 5063 Gearbox Connector Tube (8-5/8) 1 16 5053-6 Heavy Duty Gearbox, RH (1:1.2 Ratio) 1 17 5052-3 1.375 x .750 x .187 Washer 6 18 6786 56 SD Gearbox Cover 1

(Includes Items # 19 & 20)

19 5747-10 Rubber Mat, No-Hole (3 x 6) 2 20 8788-1 Rubber Mat (1 x 2) 2 21 5704-1 Gearbox Cover Support 2 22 5051-6 Heavy Duty Tee Gearbox, Shear 1 23 8067-13 Shear Pin w/Cotter (Set of 5)

(Includes Item # F069)

24 5830 Grease Fitting 1

Deck Housing Components

25 8670-8 Tilt-Up Hook 1 26 5162-11 Roller Wheel (5" Poly) 2

(Includes Item # F059)

27 8490 Roller Wheel Axle Bolt 2 28 NS Deck Serial Number Plate 1 29 5705-0 Blade, 20" (RH Rotation) 3

5705-9 56 SD Blade Set with Hubs

(Includes Items # 29, 30, F002 & F202)

30 5706 Blade Hub & Trash Guard 3 31 8735-10 Rubber Mat (5 x 6) 2 32 7775-1 Hitch Pin, LH (Silver) #6 2 33 6715 Roller Wheel (3-7/8) 2

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

34 8910-5 Tie Down Strap 2 35 6720-10 56 SD Deck Housing 1

(Includes Items # 20 & 31) 36 7775-2 Hitch Pin, RH (Gold) #6 2 37 6707-6 56 SD Skid Bar 1 38 6705-8 56 SD Discharge Shield 1 39 5727-1 Washer Shim (5/8 ID) 4

Fasteners

F002 10-24 Keps Nut 8 F004 1/4-20 Keps Nut 4 F013 3/8-16 Whiz Locknut 2 F014 3/8-16 ESNA Nut 2 F016 1/2-13 Self-Locking Nut 1 F018 5/8-18 Hex Nut 3 F020 5/16-18 ESNA Nut 1 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F032 1/4-20 x 3/4 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 6 F039 3/8-16 x 1-1/4 Hex Bolt 2 F050 1/4 SAE Washer 4 F055 5/8 SAE Washer 3 F056 5/8 Split Lock Washer 3 F059 3/8 Wave Spring Washer 4 F069 3/32 x 1/2 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw F136 AN960C416L Washer 24 F179 1/4-20 x 1 Hex Bolt 4 F202 10-24 x 5/8 SHC Screw, GR5 SS 6 F206 #2 x 3/16 Drive Pin 2 F208 5/16-18 x 2-1/4 Hex Bolt 1 F211 1/4-20 x 7/8 Hex Bolt 22 F229 C-Clip (13/16) 4 F246 1/4-20 x 1/2 PTHMS 2 F278 3/8 Split Lock Washer 6 F295 3/16 x 1-1/2 Split Spring Pin 1 F400 1/2-13 x 5-1/2 Hex Bolt 1

*

* Service Part Only

NOTE: Order Item # 3 to use the splined deck PTO shaft with

Model MT, MD, MC and MW.

NOTE: Order Item # 4 to use the splined deck PTO shaft with

Model MB.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

42

F039

DSD56 DECK ASSEMBLY (P/N 6720-20)

1

F025

F246 F050

RS.

H

25

VERY

E

5846

GREASE

18

19

F002

20

19

F038

9

21

F179

F136

23

22

F295

24

F069

16

F278

8

F229

9

F136

F211

15

17

9

14

F229

8

F029

12

F050

2

3 F076

4

5

21

6

13

9

8

F020 25

F229

F208

11

9

26

F136

26

F211

10

9

27

F059

F229

8

F013

28

F206

39

F032

F211

F014

F059

F004

38

F004

37

36

31

35

34

20

F400

33

31

32

F016

Refer to FASTENER LOCTITE APPLICATION &

30

TORQUE INSTRUCTIONS, Page 60.

29

30

29

Secure to Vehicle According to 8653-1 Transport Warning Decal

F202

30

29

F002 F055 F056

F018

Refer to LUBRICATION POINTS, Page 58.

Refer to 56 INCH CARRIER FRAME ASSEMBLY , Page 40

7

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

43

62 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8911)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-4 Eyebolt (3/8-16 x 2-3/4) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 5830-3 Grease Fitting (45 Degree) 4 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 8911-12 62 SD Carrier Frame 1

8911-10 62 SD Carrier Frame, with Pivots

(Includes Items # 5, 7, 9, 10, 15,

F317, F335 & F336) 12 5850-5 Handle Grip (1 x 1 x 3-3/4) 1 13 8911-25 Tilt Bar With Grip (42-1/2) 1

(Includes Item # 12) 14 7775-5 Lock Pin (5/16) 1 15 8674-10 Lever, Deck Lock, RH 1 16 8740 Deck Pin Bushing (3/4 ID) 4 17 5830 Grease Fitting 6

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Caster Wheel Components

18 8766 Axle Nut (3/4-16) 2 19 8768-2 Seal, Caster Wheel 4 20 8037 Bearing Cone (3/4 ID) 4 21 8037-2 Bearing Race 4 22 8768 Caster Wheel, Pneumatic (11 x 4.00-5) 2

(Includes Items # 6 & 21)

8768-3 Tire, Pneumatic (11 x 4.00-5) 8768-5 Caster Wheel (5 x 3) *

23 8767 Axle, Caster Wheel (5-1/8) 2 24 8765-10 Caster Wheel Fork 2 25 8769-7 Seal 2 26 8769-6 Bearing Cone (1" ID) 4 27 8769-5 Bearing Cup, (2 x 1-5/8) 4 28 8769-8 Dust Cap, Deck Caster 2

Fasteners

F014 3/8-16 ESNA Nut 2 F117 Retainer Ring 2 F140 7/16-14 x 1 Hex Bolt 4 F166 Retainer Ring 2 F218 7/16 Split Lock Washer 4 F263 1-1/4 External Snap Ring 4 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2 F344 3/4-16 Slotted Hex Nut 2 F347 3/4 SAE Washer 2 F348 1/8 x 1-1/2 Cotter Pin 2

*

* Service Part Only

NOTE: The E-Z Pin Puller P/N 8770 can be ordered to assist

removing and installing height adjustment hitch pins on larger decks. This item stows on tractor when not in use.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

44

62 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8911)

1

2

3

F166

1

ORDER AS P/N 8770

F140

F218

23

19

20

F348

28

F344

F347

26 27

27 26

25

21

22

15

10

17

24

F218

F140

21

20

F317

16 17

F263

14

13

19

18

7

F336

F335

4

F317

F014

6

8

F117

4

11

12

3

5

F317

9

10

6

Refer to DSD62 DECK ASSEMBLY, Page 46

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

45

DSD62 DECK ASSEMBLY (P/N 8910)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Blade Drive Components

1 8789-5 Pulley Guard 1 2 8786-15 Footrest Assembly (Includes Item # 18) 1 3 8754-3 Edge Molding 2 4 8785-10 62 SD Cover Plate 1

(Includes Items # 3 & F354)

5 8245 Idler Pulley (6") 3 6 8240 Blade Drive Pulley (4-1/2) 3 7 8762 Dampening Spring (Gas) 1 8 5146 10mm Ball Stud 2

9 8373-3 Idler Arm (2-Hole) 1 10 5830 Grease Fitting 2 11 8374-1 Idler Arm Guide 1 12 7201-3 DU Bearing 2 13 7201-4 Inner Race (1-1/2) 1 14 5841 Retainer Washer (3/8 x 1-1/4) 1 15 8731 Blade Drive Belt, (23VX1180) 1 16 6240-2 Drive Pulley (4-1/2 / 3V) 1

(Includes Items # F114 & F277) 17 8787 Deck Cover Knob 3 18 8786-10 Rubber Mat (6 x 10-1/2) 2

Gearbox and Dolly Wheel Components

19 6206 Pressure Relief Valve 1 20 8745-25 Dolly Wheel/PTO Guard Assembly

(Includes Items # 23, 24, 26, 29, 30, 33,

F012, F013, F046, F052, F168,

F226, F339 & F355) 21 8285-20 U-Joint Shaft Assy, T-Scope 1

(Includes Items # 22, F076 & F277) 22 5830-3 Grease Fitting (45 Degree) 2 23 5103-4 Pivot Bushing (3/8 ID) 2 24 8788 Rubber Bumper (Self-Adhesive Mount) 1 25 8745-14 Retract Lever 1 26 5850-1 Handle Grip 1 27 8745-12 Actuator Link 1 28 8745-13 Dolly Wheel Mount 1

(Includes Item # 10) 29 6715 Roller Wheel (3-7/8) 1 30 8745-15 Axle Spacer Tube 1 31 5229 Extension Spring (1/2 x 2-1/4) 1 32 8745-20 Mount Bracket 1

(Includes Items # 24, F052, F068 & F339) 33 8745-40 PTO Cover Plate 1 34 8051-10 Right Angle Gearbox (Includes Item # 19) 1

Deck Housing Components

35 8790 Rubber Cushion Strip 3 36 8727 Washer Shim (13/16 x 1/4) 4 37 8775 Hitch Pin (#219) 4 38 8735-10 Rubber Mat (5 x 6) 2 39 8720-30 Anti-Scalp Wheel Mount 3 40 8745-30 Axle Spacer Tube 3 41 6715-1 Roller Wheel (5") 3 42 NS Deck Serial Number Plate 1 43 8910-10 62 SD Deck Housing 1

(Includes Items # 35 & 38)

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

44 8792-10 Baffle, DSD62 1 45 8052-2 Blade Spindle 3 46 5705-3 Blade, 22" (RH Rotation) 3

5705-13 62 SD Blade Set 47 8728 Machine Bushing (1/2 x 1-1/2) 3 48 8910-5 Tie-Down Strap 2

(Used to secure deck in tilt-up position

during transport) 49 8707 52/62 SD Skid Bar 1 50 8709 52/62 SD Discharge Shield 1 51 5052-3 1.375 x .750 x .187 Washer 12 52 8670-10 Tilt-Up Hook 1

Fasteners

F004 1/4-20 Keps Nut 11 F009 5/16-18 Whiz Locknut 3 F012 3/8-16 Keps Nut 11 F013 3/8-16 Whiz Locknut 14 F014 3/8-16 ESNA Nut 3 F020 5/16-18 ESNA Nut 2 F023 10-24 ESNA Nut 2 F029 1/4-20 x 1/2 Hex Bolt 5 F032 1/4-20 x 3/4 Hex Bolt 2 F034 5/16-18 x 3/4 Hex Bolt 1 F038 3/8-16 x 1 Hex Bolt 6 F039 3/8-16 x 1-1/4 Hex Bolt 2 F040 3/8-16 x 1-1/2 Hex Bolt 12 F041 3/8-16 x 1-3/4 Hex Bolt 3 F046 3/8-16 x 3-1/2 Hex Bolt 4 F051 3/8 SAE Washer 6 F052 5/16 External Star Lock Washer 2 F055 5/8 SAE Washer 3 F059 3/8 Wave Spring Washer 2 F068 1/8 x 1 Cotter Pin 1 F076 3/8-16 x 5/8 SQH Set Screw 1 F108 3/8-16 x 2 Hex Bolt 1 F114 5/16-18 x 5/8 SQH Set Screw 2 F134 AN960816L Washer 1 F168 5/16 Split Lock Washer 8 F206 #2 x 3/16 Drive Pin 2 F226 5/16-18 x 7/8 Hex Bolt 8 F241 .375 x .875 x .10 Washer 6 F246 1/4-20 x 1/2 PTHMS 2 F252 10-24 x 3/4 PFHMS 2 F265 1/2-20 x 1-1/2 Hex Bolt 3 F276 5/8-11 Jam Nut 3 F277 3/16 x 5/8 Woodruff Key (#605) 5 F339 5/16-18 x 3/4 Self-Tapping Bolt 2 F354 5/16 Knurled Thread Insert 2 F355 3/8-16 x 4 Hex Bolt 1 F356 1/4-20 x 5/8 PTHMS, SS 2

*

* Service Part Only

Use only genuine Walker® replacement parts. Effective Date 08-01-08

46

DSD62 DECK ASSEMBLY (P/N 8910)

F246

50

F039

F004

Secure to Vehicle According to 8653-1 Transport Warning Decal

17

F354

6

F041

F051

F012

F034

F009

F014

35

F059

F032

F029

49

F004

48

F277

18

F041 F051

15

F040

51

F108 14

13

12

F356

F004

F013

F004

F051

8

F252

52

38

F041

5 16

6

F051

F226

F168

35

3

F009

10

F023

1

2

4

F114

5

7

8

F009

9

11

19

F277

34

F276 F055

6

20

36

37

Refer to 62 INCH CARRIER FRAME ASSEMBLY , Page 44

33

38

35

F038

42

F277

F206

21

F076

22

F355

23

F013

24

F013 32

31

F020

10

F046

F241

30

29

40

41

F241

39

F012

F046

F052

F014

F339

F134

25

27

F068

26

F020

F168 F226 28

45

F004

46

Effective Date 08-01-08 Use only genuine Walker

47

F265

F277

45

46

44

F277

45

46

43

F029

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

®

replacement parts.

47

74 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7803)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Spring and Pivot Mount Components

1 5975-3 Cable Tie (50# x 7") 4 2 5744-1 Spring Clip Bracket 1 3 5743-1 Spring Cover 2 4 5743-4 Eyebolt (3/8-16 x 2-3/4) 2 5 8667-10 Pivot Mount, LH/Adj. 1 6 5830-3 Grease Fitting (45 Degree) 4 7 8667-20 Pivot Mount, RH/Adj. 1 8 5743-6 Extension Spring (1-1/2 x 7-3/4) 2

(Includes Items # 1, F117 & F166)

Carrier Frame Components

9 8674-11 Lever, Deck Lock, LH 1 10 7406-1 Handle Grip (Red) 2 11 7803-1 74 SD Carrier Frame 1

(Includes Item # 15) 12 5850-5 Handle Grip (1 x 1 x 3-3/4) 1 13 8811-25 Tilt Bar with Grip (35") 1

(Includes Item # 12) 14 7775-5 Lock Pin (5/16) 1 15 5748-10 Rubber Mat (1-1/2 x 6) 2 16 8674-10 Lever, Deck Lock, RH 1 17 8740 Deck Pin Bushing (3/4 ID) 4 18 5830 Grease Fitting 6

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Caster Wheel Components

19 8766 Axle Nut (3/4-16) 2 20 8768-2 Seal, Reverse Lip 4 21 8037 Bearing Cone (3/4 ID) 4 22 8037-2 Bearing Race 4 23 8768 Caster Wheel, Pneumatic (11 x 4.00-5) 2

(Includes Items # 6 & 21)

8768-3 Tire, Pneumatic (11 x 4.00-5) 8768-5 Caster Wheel (5 x 3) *

24 8767 Axle, Caster Wheel (5-1/8) 2 25 8765-10 Caster Wheel Fork 2 26 8769-7 Seal 2 27 8769-6 Bearing Cone (1" ID) 4 28 8769-5 Bearing Cup (2 x 1-5/8) 4 29 8769-8 Dust Cap, Deck Caster 2

Fasteners

F014 3/8-16 ESNA Nut 2 F117 Retainer Ring 2 F140 7/16-14 x 1 Hex Bolt 4 F166 Retainer Ring 2 F218 7/16 Split Lock Washer 4 F263 1-1/4 External Snap Ring 4 F317 3/16 x 1 Split Spring Pin 4 F335 3/8-16 x 7/8 Set Screw, SS 2 F336 3/8-16 Jam Nut 2 F344 3/4-16 Slotted Hex Nut 2 F347 3/4 SAE Washer 2 F348 1/8 x 1-1/2 Cotter Pin 2

*

* Service Part Only

NOTE: The E-Z Pin Puller P/N 8770 can be ordered to assist

removing and installing height adjustment hitch pins on larger decks. This item stows on tractor when not in use.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

48

ORDER AS P/N 8770

F140

F218

24

20

21

F348 29

F344 F347

27 28

28

27 26

22

74 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7803)

1

2

1

3

16

10

F317

4

F336

18

17

F335

7

F117

6

F263

F014

F317

18

14

15

25

F218

13

F140

22

21

20

19

12

F166

8

4

5

F317

10

11

3

9

23

6

RS.

H

25

VERY

E

5846

GREASE

Refer to DSD74 DECK ASSEMBLY, Page 50

Refer to LUBRICATION POINTS, Page 58.

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

49

DSD74 DECK ASSEMBLY (P/N 7803-2)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Gearbox and Drive Components

1 8618-1 Cover, PTO Shaft Guard 1 2 8619 PTO Shaft Guard 1

8618 PTO Shaft Guard Assembly

(Includes Items # 1, 2, F002 & F025)

3 7275-16 U-Joint Tube Assy, Spline 1 4 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1

(Includes Items # 9, F069 & F295)

5 7865-6 74 SD Gearbox Cover, RH 1

(Includes Items # 6 & 8)

6 5747-10 Rubber Mat, No-Hole (3 x 6) 2 7 7865-5 74 SD Gearbox Cover, LH 1

(Includes Items # 6 & 8)

8 8790 Rubber Cushion Strip 2 9 8067-13 Shear Pin w/Cotter (Set of 5) 1

(Includes Item # F069) 10 5830 Grease Fitting 3 11 5052-3 1.375 x .750 x .187 Washer 8

Heavy Duty Drive Components

12 5053-6 Gearbox, RH (1:1.2) Heavy Duty 1 13 P007 Gasket, Cap (P#788030) 8 14 5058-6 Tee Gearbox (1:1.2) 2 15 5051-6 Tee Gearbox, Shear 1 16 5052-6 Gearbox, LH (1:2.2) Heavy Duty 1 17 5704-1 Gearbox Cover Support 3 18 6054 Spline Coupling 7 19 5069 Connector Tube (14-1/2) 2 20 6732-9 Connecting Shaft (12-1/8) 2 21 5063 Connector Tube (8-5/8) 1 22 6732-3 Connecting Shaft (6-1/4) 1 23 5060 Connector Tube (2-5/16) 1

Deck Housing Components

24 8786-10 Rubber Mat (6 x 10-1/2) 4 25 8670-8 Tilt-Up Hook 1 26 7803-3 74 SD Deck Housing 1

(Includes Items # 24 & 42) 27 NS Deck Serial Number Plate 1 28 7866-1 Lock Lever, Rear Caster 2 29 7775-5 Lock Pin (5/16) 2 30 5683 Pivot Bearing 4 31 7866 74 SD Rear Fork Mount 2

(Includes Items # 10 & 30) 32 7870 74 SD Rear Fork 2 33 5714-3 Axle Spacer Tube 2 34 7868 74 SD Caster Wheel/Rear 2 35 6715 Roller Wheel (3-7/8) 2

*

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

36 7807-1 74 SD Skid Bar 1 37 7809-1 74 SD Discharge Shield 1 38 5706 Blade Hub & Trash Guard 4 39 5705-0 Blade 20" (RH Rotation) 4

5705-16 74 SD Blade Set with Hubs

(Includes Items # 38, 39, F002 & F202) 40 8775 Hitch Pin (#219) 4 41 8727 Washer Shim (13/16 x 1/4) 4 42 8788-1 Rubber Mat (1 x 2) 1 43 5704-32 74 Gearbox and 1

Tube Assembly, Heavy Duty

(Includes Items # 5-8, 12-23 & F229)

Fasteners

F002 10-24 Keps Nut 10 F004 1/4-20 Keps Nut 4 F012 3/8-16 Keps Nut 2 F014 3/8-16 ESNA Nut 2 F016 1/2-13 Self-Locking Nut 2 F018 5/8-18 Hex Nut 4 F020 5/16-18 ESNA Nut 1 F025 10-24 x 3/8 PPHMS 2 F029 1/4-20 x 1/2 Hex Bolt 2 F031 1/4-20 x 5/8 Hex Bolt 2 F038 3/8-16 x 1 Hex Bolt 10 F039 3/8-16 x 1-1/4 Hex Bolt 2 F047 3/8-16 x 4-1/2 Hex Bolt 2 F050 1/4 SAE Washer 5 F055 5/8 SAE Washer 4 F056 5/8 Split Lock Washer 4 F059 3/8 Wave Spring Washer 2 F063 3/8 Int. Star Lock Washer 2 F069 3/32 x 1/2 Cotter Pin 1 F119 Rear Caster Spacer 4 F136 AN960C416L Washer 32 F179 1/4-20 x 1 Hex Bolt 6 F191 3/8 x 1-1/2 x 3/16 Washer 2 F202 10-24 x 5/8 SHC Screw, GR5 SS 8 F206 #2 x 3/16 Drive Pin 2 F208 5/16-18 x 2-1/4 Hex Bolt 1 F211 1/4-20 x 7/8 Hex Bolt 24 F229 C-Clip (13/16) 6 F246 1/4-20 x 1/2 PTHMS 3 F278 3/8 Split Lock Washer 8 F295 3/16 x 1-1/2 Split Spring Pin 1 F399 1/2-13 x 3-1/4 Hex Bolt 2

*

* Service Part Only

Use only genuine Walker® replacement parts. Effective Date 08-01-08

50

DSD74 DECK ASSEMBLY (P/N 7803-2)

Refer to 74 INCH CARRIER FRAME ASSEMBLY , Page 48

18

F229

20

F229

13

F136

F211

37

F014

F004

F059

F039

F211

36

Refer to FASTENER LOCTITE APPLICATION & TORQUE INSTRUCTIONS, Page 60.

43

F246

F050

5

F002

17

12

11

F278

F136

F179

6

14

F038

F025

1

2

RS.

H

25

VERY

E

5846

GREASE

F050 F029

F246 F050

9

7

3

F295

10

F069

4

F246

17

F050

6

19

13

18

13

23

F136

13

F031

F211

40

41

F004

18

F229

22

13

F136

24

F208

F211

25

F020

15

14

8

17

16

21

13

18

F229

20

24

26

F229

13

F136

27

F206

F211

19

24

28

13

18

29

F038 F063

F191

30 31

30

32

38

39

F002 F055

F056 F018

42

F399

F202

F399

35

F016

35

38

10

F012

38

39

F119

33

38

39

34

F119

F047

39

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

51

OPTIONAL BREAK-AWAY BLADES

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

F016 F048

F002 F382

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

RS.

H

25

VERY

F202

2

F202

E

5846

GREASE

1

F016 F048

F002 F382

Refer to DSD56 DECK ASSEMBLY, Page 42

DSD 42" Break-Away Blade Kit (5705-33)

1 5706 Blade Hub & Trash Guard 2 2 5706-27 Blade Hub, 42" 2 3 5705-30 Break Away Blade 4 4 5705-17 Special Bolt (1/2-13 x 1-7/16) 4

DSD 48" Break-Away Blade Kit (7705-8)

1 5706 Blade Hub & Trash Guard 2 2 5706-25 Blade Hub, 48" 2 3 5705-30 Break Away Blade 4 4 5705-17 Special Bolt (1/2-13 x 1-7/16) 4

DSD 56" Break-Away Blade Kit (5705-32)

1 5706 Blade Hub & Trash Guard 3 2 5706-26 Blade Hub, 36, 56 & 74 3 3 5705-30 Break Away Blade 3 4 5705-17 Special Bolt (1/2-13 x 1-7/16) 6

3

4

3

DSD 74" Break-Away Blade Kit (5705-34)

1 5706 Blade Hub & Trash Guard 4 2 5706-26 Blade Hub, 36, 56 & 74 4 3 5705-30 Break Away Blade 4 4 5705-17 Special Bolt (1/2-13 x 1-7/16) 8

Fasteners

F002 10-24 Keps Nut

*

F016 1/2-13 Self-Locking Nut * F048 1/2 SAE Washer * F202 10-24 x 5/8 SHC Screw, GR5 SS * F382 Belleville Washer (.650 x 1.36) *

* Quantities vary

NOTE: Optional blade kit featuring blades mounted on a break-

away hub, for use in mowing applications with lots of ground and debris contact, to minimize impact and shock loading.

NOTE: Break-Away blades are designed for use on Side

Discharge decks only.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

52

BLADE USAGE CHART

DECK ASSEMBLY,

RS.

H

25

VERY

E

5846

GREASE

F202

Refer to DGHS48

F002 F055

F056 F018

Right-Hand Blade

Left-Hand Blade

TWO BLADE DECKS RH BLADE LH BLADE BLADE SET

Page 26

DGHS36 5705-2 5705-0 5705-6

DSD36 5705-1 5705-1 5705-5 DML36 5705-23 5705-23

DGHS42 5705-4 5705-3 5705-8

DSD42 5705-3 5705-3 5705-7

DML42A 5705-28 5705-28 5705-19

DML42B

5705-11 (Upper Blade)

5705-10 (Lower Blade)

5705-11 (Upper (Blade)

5705-10 (Lower Blade)

DGHS48 7705-2 7705-1 7705-3

DSD48 7705-1 7705-1 7705-5

DGHS52 7705-6 7705-7 7705-9

THREE & FOUR BLADE DECKS SINGLE BLADE BLADE SET

DSD52 5705-14 8738-7*

DSD52 MULCHING

UPPER BLADE

DSD52 MULCHING

LOWER BLADE

5705-15 8738-8*

5705-14 8738-7*

DSD56 5705-0 5705-9

5705-12

DSD62 5705-3 5705-13 DSD74 5705-0 5705-16

Right hand and left hand orientated with operator on seat. All blade sets include 5706 (Blade Hub & Trash Guard), F002 & F202 unless otherwise specified. * Blade set consists of three (3) blades

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

53

DECK WELDMENT REPLACEMENT PARTS

I TEM PAR T DE S C R IPT I O N L OCA TIO N N O. NO. NO. REQ’D

NOTE: All parts listed in this section are for Weld-On Repair; Cutting, Grinding, and Welding are required to replace these parts.

DSD52 & DSD62 Weldments

1 8733-3 Rim Rod, RH Rear (20-3/4) DSD52 1

8751-2 Rim Rod, RH Rear (28-3/8) DSD62 1 2 8760-2 Rear Deck Pin (3/4 x 5-3/4) DSD52, DSD62 & DSD74 2 3 8733-63 Rim Rod, LH Rear (28-3/4) DSD52 1

8751-3 Rim Rod, LH Rear (34-3/8) DSD62 1 4 8733-5 Rim Rod, LH Front (22-7/8) DSD52 1

8751-4 Rim Rod, LH Front (28-5/16) DSD62 1 5 8760-1 Front Deck Pin (3/4 x 7-5/8) DSD52 & DSD62 2 6 8733-61 Rim Rod, Front Center (26-5/8) DSD52 1

8751-5 Rim Rod, Front Center (29-1/4) DSD62 1 7 8733-10 Rim Rod, RH Front (16-1/4) DSD52 1

8751-6 Rim Rod, RH Front (19-1/4) DSD62 1

DSD56 Weldments

8 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2 9 6752-6 Deck Cap Strip, 56SD LH (39") DSD56 & DSD74 1

10 5760-7 Front Deck Pin (5/8 x 5-3/4) DSD56 2 11 6752-4 Deck Cap Strip, 56SD Front (42") DSD56 1

DSD74 Weldments

8 8760-2 Rear Deck Pin (3/4 x 5-3/4) DSD52, DSD62 & DSD74 2

10 7865-18 Front Deck Pin (3/4 x 6-5/8) DSD74 2 12 8751-7 Rim Rod, LH DSD74 1 13 8751-8 Rim Rod, Front (13-1/2) DSD74 1

DGHS Weldments

8 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2

10 5760-3 Front Deck Pin (5/8 x 5-3/4) All Decks Except DSD52, DSD56, DSD62 & DSD74 2 14 5751-3 Deck Cap Strip, GHS LH (43-3/4) DGHS36 1

5751-1 Deck Cap Strip, GHS LH (49-3/8) DGHS42 1

7701-10 Edge Stiffener, Side (42-3/8) DGHS48 2

15 7701-11 Edge Stiffener, Front (21-7/8) DGHS48 1 16 5751-4 Deck Cap Strip, GHS RH (47-5/8) DGHS 36 1

5751-2 Deck Cap Strip, GHS RH (49-3/8) DGHS42 1

17 6752-7 Deck Cap Strip, 52GHS LH DGHS52 1 18 6752-8 Deck Cap Strip, 52GHS RH DGHS52 1

DSD & DML Weldments

8 5760-4 Rear Deck Pin (5/8 x 5-3/8) All Decks Except DSD52, DSD62 & DSD74 2

10 5760-3 Front Deck Pin (5/8 x 5-3/4) All Decks Except DSD52, DSD56, DSD62 & DSD74 2 19 5702-6 Deck Cap Strip, (47") DSD36 1

5751-5 Deck Cap Strip, 42" SD LH (47") DSD42 1

20 5751-6 Deck Cap Strip, 42" SD Front (3-9/16) DSD42 1 21 5751-11 DML42A Edge Stiffener DML42A 2 22 5751-12 DML42A Front Stiffener DML42A 1 23 5751-14 DML42A Deck Cap Strip, RH DML42A 1 24 5751-13 DML42A Deck Cap Strip, LH DML42A 1

Use only genuine Walker® replacement parts. Effective Date 08-01-08

54

DECK WELDMENT REPLACEMENT PARTS

2

20

21

DSD36, DSD42, DML42A & DML42B Deck & Carrier Frame Assemblies

5

1

7

5

10

22

8

23

10

19

21

8

DSD52 & DSD62 Deck & Carrier Frame Assemblies

24

6

4

2

3

16

10

15

18

DGHS36, DGHS42, DGHS48 & DGHS52 Deck & Carrier Frame Assemblies

17

10

8

10

14

8

11

DSD56 & DSD74 Deck & Carrier Frame Assemblies (DSD74 Outline Shown)

8

13

10

12

9

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

55

DECK HEIGHT ADJUSTER KIT

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

8639 36" Deck Height Adjuster Kit (Shown)

1 8642-2 Decal, Deck Height Position 1 2NA 3 8640-2 Chain Guide 4 4 8640-4 Joining Link 8 5 8640-7 Knob, Deck Height Adjuster 1 6 8640-8 Handle 1 9 8640-3 Bushing (1-3/8 x 3/4) 2

10 8640-6 Mount Block 4 11 8640-5 Chain Anchor, Front 4 12 8640-13 Front Chain (19 Links) 2 14 8640-9 Compression Spring (2-3/4) 1 15 8641-10 Extension Spring, (6-1/4") 1

(48" Carrier Frame)

16 8640-16 Roll Pin (8 x 20mm) 3

8640 42" Deck Height Adjuster Kit

1 8642-2 Decal, Deck Height Position 1 2 8640-12 Rear Chain 2 3 8640-2 Chain Guide 4 4 8640-4 Joining Link 8 5 8640-7 Knob, Deck Height Adjuster 1 6 8640-8 Handle 1 7 8640-15 Sprocket, LH (972) 1 8 8640-11 Chain Anchor, Rear 2 9 8640-3 Bushing (1-3/8 x 3/4) 2

10 8640-6 Mount Block 4 11 8640-5 Chain Anchor, Front 2 12 8640-13 Front Chain (19 Links) 2 13 8640-14 Sprocket, RH (973) 1 14 8640-9 Compression Spring (2-3/4) 1 15 8640-10 Extension Spring (1 x 5-3/8) 1

(42" Carrier Frame)

16 8640-16 Roll Pin (8 x 20mm) 3

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

8641 48" Deck Height Adjuster Kit

1 8642-2 Decal, Deck Height Position 1 2 8641-12 Rear Chain 2

(48" Carrier Frame - 41 Links) 3 8640-2 Chain Guide 4 4 8640-4 Joining Link 8 5 8640-7 Knob, Deck Height Adjuster 1 6 8640-8 Handle 1 7 8640-15 Sprocket, LH (972) 1 8 8640-11 Chain Anchor, Rear 2 9 8640-3 Bushing (1-3/8 x 3/4) 2

10 8640-6 Mount Block 4 11 8640-5 Chain Anchor, Front 2 12 8640-13 Front Chain (19 Links) 2 13 8640-14 Sprocket, RH (973) 1 14 8640-9 Compression Spring (2-3/4) 1 15 8641-10 Extension Spring (6-1/4) 1

(48" Carrier Frame)

16 8640-16 Roll Pin (8 x 20mm) 3

8643 52" Deck Height Adjuster Kit (Shown)

17 8643-8 Height Location Pin/Rope 1 18 8643-10 Height Locator Block 1 19 8643-2 Gas Spring 2 20 8643-1 Connecting Rod 2 21 8643-3 Shackle 8 22 8643-4 Chain (4 Links) 4 23 8643-5 Chain Anchor Bracket 4 24 8643-6 Chain Anchor Spacer 4 25 8643-7 Chain Anchor Doubler 4

8644 62" Deck Height Adjuster Kit

17 8643-8 Height Location Pin/Rope 1 18 8643-10 Height Locator Block 1 19 8643-2 Gas Spring 2 20 8643-1 Connecting Rod 2 21 8643-3 Shackle 8 22 8643-4 Chain (4 Links) 4 23 8643-5 Chain Anchor Bracket 4 24 8643-6 Chain Anchor Spacer 4 25 8643-7 Chain Anchor Doubler 4

NOTE: DML42A and DML42B Mulching Decks use the 48" Deck

Height Adjuster Kit (P/N 8641).

Use only genuine Walker® replacement parts. Effective Date 08-01-08

56

DECK HEIGHT ADJUSTER KIT

2

3

1

12

11

10

9

5

6

4

3

4

8

13

14

16

15

10

16

3

12

7

4

9

11

10

RS.

H 25

VERY

E

5846

GREASE

3

2 4

8

17

18

20

19

Refer to DGHS42

21

22

21

DECK ASSEMBLY, Page 16

20

19

22

21

23

24

21

22

21

22 21

23

24 23 24

25

Refer to DSD52 DECK ASSEMBLY, Page 36

Effective Date 08-01-08 Use only genuine Walker® replacement parts.

25

57

LUBRICATION POINTS

ITEM LOCATION LUBRICA TION NO. NO. TYPE PLACES

36", 42", 48", DGHS52 & 56" Assemblies

1 Deck Caster Wheel Fork Pivot Grease 2 2 Blade Drive Gearbox Oil 3 Tee Gearbox, Deck Oil 4 Deck Caster Wheel Bearing Grease 2 5 Universal Joint Shaft Assembly Grease 6 Pivot Assembly, Tilt-Up Deck Grease 4 7 Deck Support Arm Socket Grease 2

DSD52 & DSD62 Assemblies

1 Deck Caster Wheel Fork Pivot Grease 2 4 Deck Caster Wheel Bearing Grease 2 5 Universal Joint Shaft Assembly Grease 6 Pivot Assembly, Tilt-Up Deck Grease 4 7 Deck Support Arm Socket Grease 2 8 Idler Arm, 2-Hole Grease 1

9 Blade Spindle Grease 3 10 Right Angle Gearbox Oil 11 Dolly Wheel Retract Oil 1

Lever and Linkage

12 Dolly Wheel Pivot Grease 1

* 2 * 1

** 1

** 2

*** 1

ITEM LOCATION LUBRICA TION NO. NO. TYPE PLACES

DSD74 Assemblies

1 Deck Caster Wheel Fork Pivot Grease 2 2 Blade Drive Gearbox Oil 3 Tee Gearbox, Deck Oil 4 Deck Caster Wheel Bearing Grease 2 5 Universal Joint Shaft Assembly Grease 6 Pivot Assembly, Tilt-Up Deck Grease 4 7 Deck Support Arm Socket Grease 2

13 Rear Deck Caster Wheel Axle Grease 2

* 4 * 1

** 1

* Gearboxes are permanently lubricated and sealed requiring

no scheduled lubrication. Oil level should be checked only when an oil leak is noted.

** Grease every eight (8) hours. *** Check oil level every 100 hours. Refer to OWNER’S

MANUAL for Lubrication Instructions.

NOTE: Exact location of some Lubrication Points may vary slightly

from those shown in the illustration. Decks shown in the illustration are for reference only; for further information on location of parts not shown here, refer to the parts listings for individual Carrier Frames and Deck Assemblies.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

58

LUBRICATION POINTS

9

112 32

4

6

4

5

36", 42", 48", DGHS52 and 56" Assemblies

7

8

1

9

67

414

9

DSD52 and DSD62

4

Assemblies

1

DSD74 Assembly

5

6

4

1

127

11

2

10

7

3

6

2

13

6

7

6

13

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

59

FASTENER LOCTITE® APPLICATION & TORQUE INSTRUCTIONS

ITEM DESCRIPTION NO.

Heavy Duty Gear Drive Assemblies DSD, DGHS, DML42A Item # 1 applies to all Heavy Duty deck models EXCEPT DSD52 and DSD62.

®

1 Apply Loctite

Threadlocker # 277 (Red) to Item # 1 used on Heavy Duty Gearbox Connector Tubes. Torque to 115in-lb (13.0 N

·m).

DGHS & DSD Deck Assemblies Items # 2 & 3 apply to all deck models EXCEPT DSD52 and DSD62.

®

2 Apply Loctite

Threadlocker # 242 (Blue) to P/N F211 (1/4-20 x 7/8 Hex Bolt, used on Gearbox Connector Tubes) prior to assembly. Torque to 90 in-lb (10.2 N

3 Torque P/N F018 (5/8-18 Hex Nut, used on underside of

blades) to 60 ft-lb (81.4 N

·m). DO NOT apply Loctite

·m).

®

.

ITEM DESCRIPTION NO.

DSD52 & DSD62 Deck Assemblies

®

4 Apply Loctite

Threadlocker # 242 (Blue) to P/N F114 (5/16-18 x 5/8 SQH Set Screw, used on Drive Pulley) prior to assembly. Torque to 190 in-lb (21.5 N

5 Apply Loctite

®

Threadlocker # 242 (Blue) to P/N F076

·m).

(3/8-16 x 5/8 SQH Set Screw, used on U-Joint Shaft Assy, T-Scope) prior to assembly. Torque to 400 in-lb (45.2 N

·m).

6 Torque P/N F339 (5/16-18 x 3/4 Self-Tapping Bolt, used

on Mount Braket & PTO Guard) to 200 in-lb (22.6 N DO NOT apply Loctite

7 Apply Loctite

®

.

Threadlocker # 242 (Blue) to P/N F226

·m).

(5/16-18 x 7/8 Hex Bolt, used on Right Angle Gearbox) prior to assembly. Torque to 18 ft-lb (24.4 N

·m).

NOTE: Models DGHS48 and DSD52 are shown here. Refer to

individual deck assemblies for exact locations and quantities of items listed above.

Use only genuine Walker® replacement parts. Effective Date 08-01-08

60

FASTENER LOCTITE® APPLICATION & TORQUE INSTRUCTIONS

Refer to Heavy Duty

Gear Drive Components (GHS, SD, DML42A and DML42B Models)

Refer to Gear Drive Components (GHS and SD Models)

RS.

H

25

VERY

E

5846

GREASE

1

2

DGHS, DSD & DML Deck Assemblies

3

4

5

7

6

7

DSD52 & DSD62 Deck Assemblies

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

61

MBSSD DECK ARM ADAPTER KIT (P/N 2430-10)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Kit 2430-10 Deck Arm Adapter Kit

Includes Items # 1-6 and instructions. May be ordered as a kit for dealer installation. Contact your Walker dealer.

1 2744-2 Counter Weight Spring Extension 1 2 2431-1 Deck Arm Adapter, LH 1 3 5775-2 Hitch Pin (#6) 2 4 2430-1 Deck Arm Adapter, RH 1 5 2744-4 1/4" Quick Link 1 6 2744-5 Chain 1

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

NOTE: Installation of 2430-10 on the Walker Model MBSSD

allows the use of the following decks:

DSD48 DSD52 DSD56 DSD62 DSD74

Use only genuine Walker® replacement parts. Effective Date 08-01-08

62

T o T ilt-Up Latch

(Used in Tilt-Up Position)

MBSSD DECK ARM ADAPTER KIT (P/N 2430-10)

6

5

T o T ilt-Up Hook

(Used in Tilt-Up Position)

4

3

1

2

3

Effective Date 08-01-08 Use only genuine Walker

®

replacement parts.

63

MAINTENANCE AND SERVICE RECORD SHEET

DATE SERVICE ENGINE

ITEM HOURS

______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________

DECK / TRACTOR COMPATIBILITY CHART

MB MW

DGHS36 XXXXXX X

DSD36 XXX * X * X * X ***XX*

DML36 XXX * X * X * X *** X *

DGHS42 XXXXXX X

DSD42 XXX * X * X * X ***XX* DML42A XX X X X * X * X ***XX* DML42B XX X X X * X * X ***XX* DGHS48 XXXXX X

DSD48 XX X * X * X ***XX* *** DGHS52 XXXXX X

DSD52 X

DSD56 XX X * X * X ***XX*

DSD62 X * X ***XX* ***

DSD74 ** * ** XXXXXX* ***

MS

SDMSGHSMCSDMCGHSMTSDMTGHS

* X * X **

MTL/

MTEFI

SD

MTEFI

GHS

MTL GHS

MTL

EFI

GHS

*XX* ***

EFI SD

MD

SDMDGHS

MBS

***

X Deck and tractor are fully compatible.

* When using this deck on GHS tractors, installation of P/N 7541 (Blower Lockout Kit) is recommended.

Contact your Walker dealer.

** Using the DSD74 Deck with Model MT-23 is not recommended in all conditions. In certain conditions (tall, wet grass), the

performance of the deck may be marginal due to a limit of horsepower with the 23-hp engine.

*** DSD Decks that are compatible with the Walker Super B using Kit # 2430-10 (Deck Arm Adapter Kit).

Use only genuine Walker® replacement parts. Effective Date 08-01-08

64

LIMITED WARRANTY

FOR

WALKER

COMMERCIAL RIDER MOWER

1. WHAT THIS WARRANTY COVERS, AND FOR HOW LONG:

Walker Manufacturing company will, at its option, repair or replace, without charge, any part covered by this warranty which is found to be defective in material and/or workmanship within one (1) year* after date of sale to the original retail purchaser unless the product is used for rental purposes, in which case this warranty is limited to ninety (90) days. At Walker's request, customer will make the defective part available for inspection by Walker and/or return the defective part to Walker, transportation charges prepaid. All parts and components of the Walker Mower are covered by this warranty except the following components which are warranted separately by their respective manufacturers:

Kohler Engine Kubota Engine Kawasaki Engine Eaton Hydraulic Transmission Peerless Gearboxes Battery Tires

The available warranties covering these items are furnished with each mower. Walker does not assume any warranty obligation, liability or modification for these items, which are covered exclusively by the stated warranty of the respective manufacturers noted above.

* An extended three (3) year warranty is offered on the Walker P/N 6200-9 Gear Axle Assembly.

2. WHAT THIS WARRANTY DOES NOT COVER:

A. This warranty does not cover defects caused by depreciation or damage caused by normal wear, accidents, improper

maintenance, improper use or abuse of the product, alterations, or failure to follow the instructions contained in the Owner ’s Manual for operation and maintenance.

B. The customer sha ll pay any charges for making service calls and/or for transporting the mower to and from the place where the

inspection and/or warranty work is performed.

3. HOW TO OBTAIN SERVICE UNDER THIS WARRANTY:

Warranty service can be arranged by contacting the dealer where you purchased the mower or by contacting Walker Manufacturing Company, 5925 East Harmony Road, Ft. Collins, CO 80528. Proof of the date of purchase may be required to verify warranty coverage.

4. WARRANTY LIMITATION:

A. THERE IS NO OTHER EXPRESS WARRANTY. ANY WARRANTY THAT MAY BE IMPLIED FROM THIS PURCHASE

INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE IS HEREBY LIMITED TO THE DURATION OF THIS WARRANTY AND TO THE EXTENT PERMITTED BY LAW ANY AND ALL IMPLIED WARRANTIES ARE EXCLUDED. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not

apply to you.

B. WALKER WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES AND/OR

EXPENSES IN CONNECTION WITH THE PURCHASE OR USE OF THE MOWER. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation(s) or exclusion(s) may not apply to you.

C. Only the warranty expressed in this limited warranty shall apply and no dealer, distributor, or individual is authorized to amend,

modify, or extend this warranty in any way. Accordingly, additional statements such as dealer advertising or presentations, whether oral or written, do not constitute warranties by Walker, and should not be relied upon.

D. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

65

TM

W ALKER MFG. CO.  5925 E. HARMONY ROAD, FORT COLLINS, CO 80528  (970) 221-5614

Walker DSD56, DSD62, DGHS42, DGHS36, DGHS48 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

KEY TO ABBREVIATIONS USED IN THIS MANUAL

DECK DECALS / TOUCH-UP PAINT

DECK DECALS / TOUCH-UP PAINT

36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-4)

36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-4)

DML36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-5)

DML36 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5710-5)

DML36 DECK ASSEMBLY (P/N 5710-11)

DML36 DECK ASSEMBLY (P/N 5710-11)

42 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5700-11)

42 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 5700-11)

DML42A DECK ASSEMBLY (P/N 5707-1)

DML42A DECK ASSEMBLY (P/N 5707-1)

DML42B DECK ASSEMBLY (P/N 5707-2)

DML42B DECK ASSEMBLY (P/N 5707-2)

48 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7700-2)

48 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7700-2)

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811-1)

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811-1)

DGHS52 DECK ASSEMBLY (P/N 8810-1)

DGHS52 DECK ASSEMBLY (P/N 8810-1)

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811)

52 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8811)

DSD52 DECK ASSEMBLY (P/N 8810)

DSD52 DECK ASSEMBLY (P/N 8810)

MULCHING KIT (FOR DSD52 DECK ASSEMBLY)

MULCHING KIT (FOR DSD52 DECK ASSEMBLY)

56 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 6720)

56 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 6720)

DSD56 DECK ASSEMBLY (P/N 6720-20)

DSD56 DECK ASSEMBLY (P/N 6720-20)

62 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8911)

62 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 8911)

DSD62 DECK ASSEMBLY (P/N 8910)

DSD62 DECK ASSEMBLY (P/N 8910)

74 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7803)

74 INCH COMPLETE CARRIER FRAME ASSEMBLY (P/N 7803)

DSD74 DECK ASSEMBLY (P/N 7803-2)

DSD74 DECK ASSEMBLY (P/N 7803-2)

OPTIONAL BREAK-AWAY BLADES

BLADE USAGE CHART

DECK WELDMENT REPLACEMENT PARTS

DECK WELDMENT REPLACEMENT PARTS

DECK HEIGHT ADJUSTER KIT

DECK HEIGHT ADJUSTER KIT

LUBRICATION POINTS

LUBRICATION POINTS

FASTENER LOCTITE® APPLICATION & TORQUE INSTRUCTIONS

FASTENER LOCTITE® APPLICATION & TORQUE INSTRUCTIONS

MBSSD DECK ARM ADAPTER KIT (P/N 2430-10)

MBSSD DECK ARM ADAPTER KIT (P/N 2430-10)

MAINTENANCE AND SERVICE RECORD SHEET

DECK / TRACTOR COMPATIBILITY CHART

LIMITED WARRANTY
