Walker A10 Operator's Manual

A10 Dethatcher Attachment

Operator’s Manual

Safety, Assembly, Operation, and Maintenance

Compatible with decks: 36”, 42”, 48” and 52”

Please Read and Save These Instructions

For Safety, Read All Assembly and Operation Instructions Prior to Operating Attachment

Beginning S/N: 2018-22223

P/N: 6605-15

Foreword

Thank you. . .for purchasing a Walker Dethatcher Attachment. Every effort has been made to provide you with

the most reliable machine on the market, and we are sure you will be among our many satised customers. If for

any reason this product does not perform to your expectations, please contact your local dealer. Every customer is important to us. Your satisfaction is our goal.

Please. . .read this manual thoroughly! Before you operate your machine, please read this entire manual. Some of the information is crucial for proper operation - it will help protect your investment and ensure that the machine performs to your satisfaction. Some of the information is important to your safety, and must be read and understood

to help prevent possible injury to the operator or others. If anything in this manual is confusing or hard to understand, please contact your local authorized dealer or call our service department, at (970) 221-5614, for clarication before

operating or servicing this machine.

This manual covers the A10 Dethatcher Attachment.

All shields and guards must be in place for the proper and safe operation of this machine. Where they are shown removed in this manual, it is for illustration purposes only. Do not operate this machine unless all shields

and guards are in place.

Walker Mfg. Co. is continually striving to improve the design and performance of its products. We reserve the right to

make changes in specications and design without thereby incurring any obligation relative to previously manufactured

products.

Sincerely,

i

WALKER MANUFACTURING

COMPANY

Bob Walker, President

Table of Contents

General Information 1

HIGHLIGHTED INFORMATION 1

GLOSSARY 1

IDENTIFYING NUMBER LOCATIONS 1

SERVICING OF DETHATCHER 2

UNIT DESCRIPTION 2

Specications 3

Component Identication 4

Safety Instructions 5

BEFORE OPERATING 5

OPERATING 6

MAINTENANCE 8

Assembly Instructions 9

ATTACH DETHATCHER TO DECK 10 ADJUST TINES 11

Operating Instructions 12

OPERATING THE DETHATCHER 12

TINE ACTION 12

Storage Instructions 13

WALL BRACKET (OPTIONAL) 13

END OF SEASON 13

Maintenance Instructions 13

Parts List/Diagram 15

MAINTENANCE AND SERVICE

RECORDS SHEET 17

Warranty 20

ii

General Information

HIGHLIGHTED INFORMATION

Walker Manufacturing recommends that any service requiring special training or tools be performed by an authorized Walker Tractor dealer. There are several general practices to be aware of in the area of safety. Most accidents associated with the operation or maintenance of a Walker Tractor are caused

by disregarding basic safety precautions or specic

warnings. Such accidents, in most cases, can be prevented by being aware of the dangers present.

Information of special importance has been

high-lighted in bold type in this manual. Refer to

Safety Instructions for the meanings of DANGER, WARNING, CAUTION, IMPORTANT, and NOTE.

GLOSSARY

There are many terms that are either unique to this equipment or that are used as acronyms. The following terms and their denitions will help while using this manual:

● DECK is the mowing attachment mounted on

the front of the tractor which includes the carrier frame, deck housing, blade spindles, and cutter blades.

IDENTIFYING NUMBER LOCATIONS

The dethatcher serial number is afxed to the

mounting bracket. Model and serial numbers are helpful when obtaining replacement parts and maintenance assistance. For ready reference, please record these numbers in the space provided.

Dethatcher Serial No.

Date of Purchase

Refer to the Operator’s manual that accompanies the tractor for the tractor serial number.

Serial Number

● FORWARD SPEED CONTROL (FSC) controls

the maximum forward speed of the tractor; functioning as a cruise control.

● LEFT HAND (LH) refers to the left-hand side of

the tractor when the operator is seated facing forward in the tractor seat.

● MACHINE consists of the dethatcher, tractor,

and deck functioning as a single unit.

● POWER TAKE-OFF (PTO) transmits engine

power to run the cutter blades and GHS blower.

● RIGHT HAND (RH) refers to the right-hand side

of the tractor when the operator is seated facing forward in the tractor seat.

● STEERING LEVERS steer the tractor by con-

trolling the two transaxles.

● TRACTOR is the prime mover, including the en-

gine, drivetrain, operator seat, and controls to operate the mower.

Dethatcher Serial Number Location

(Front LH View)

1

General Information

SERVICING OF DETHATCHER

Only routine maintenance and general service instructions are provided in this manual. Any unau- thorized work done on the dethatcher during the warranty period may void the warranty. If you have any difculty nding an authorized outlet or obtaining warranty service, please contact our Service Department for assistance:

Walker Manufacturing Company

5925 E. Harmony Road

Fort Collins, CO 80528

1-970-221-5614

www.walker.com

UNIT DESCRIPTION

The dethatcher can be installed on the front of 36 in., 42 in., 48 in., and 52 in. gear driven decks without any tools. When used with a GHS equipped machine, lawn thatch and debris are removed with one pass.

2

Specications

A10 DETHATCHER

MODEL A10

Height in. (cm) 35.75 (91)

Width in. (cm) 41 (104)

Length in. (cm) 25 (64)

Overall Length Installed on Tractor in. (cm)* 107.75 (274)

Weight lb (kg) 55 (25)

NOTE: The manufacturer reserves the right to make changes in specications shown herein at any time without

notice or obligation.

3

Component Identication

Mounting Bracket

Optional Wall Mount

Lift Lever

(Foldable)

Foot Trigger

RH Mounting Bracket

Caster Wheel

Mount

Channel Mount

Carrier Frame

Channel Mount

LH Mounting Bracket

Tine Tray

Caster Wheel

Mount

Dethatching Tines

Caster Wheels

A10 Dethatcher Front View (Not Installed)

4

Safety Instructions

Pay particular attention to any information labeled DANGER, WARNING, CAUTION, IMPORTANT, and NOTE in this manual.

When you see the Safety Alert Symbol ( ), read, understand, and follow the instructions. Fail ure to comply with safety instructions may result in personal injury.

The seriousness or degree of importance of each

type of information is dened as follows:

DANGER

An IMMEDIATE hazard that WILL result in severe personal injury or DEATH, if warning is ignored and proper safety precautions are not taken.

WARNING

A POTENTIAL hazard that COULD result in severe personal injury or DEATH, if warning is ignored and proper safety precautions are not taken.

CAUTION

Possible hazards or unsafe practices that MAY result in MODERATE personal injury or property damage, or machine damage, if warning is ignored and proper safety precautions are not taken.

IMPORTANT: Identies mechanical information

demanding special attention, since it deals with the possibility of damaging a part or parts of the machine.

Walker Manufacturing cannot predict every potentially dangerous situation. Therefore, items labeled as such in this manual do not cover all conceivable situations. Any person using procedures, tools, or control techniques not recommended by Walker Manufacturing must take full responsibility for safety.

The Walker Rider Lawnmower has been designed with many safety features to protect the operator from personal harm or injury. However, it is necessary for the operator to use safe operating procedures at all times. Failure to follow safety instruc-

tions contained in this manual may result in personal injury or damage to equipment or property.

If you have any questions concerning setup, operation, maintenance, or safety, please contact your authorized Walker Mower dealer or call Walker Manufacturing Company at (970) 221-5614.

BEFORE OPERATING

1. Read and understand the contents of this Operator’s Manual before starting and operating the machine. Become thoroughly famil-

iar with all machine controls and how to stop the machine and disengage the controls quickly. Replacement Operator’s Manuals are available by sending the Model and Serial Number to:

Walker Manufacturing Company

5925 East Harmony Road

Fort Collins, CO 80528

2. Never allow children to operate rider mower. Do not allow adults to operate without proper instruction.

3. Do not allow anyone other than the operator on the machine.

4. Keep everyone, especially children and pets, a safe distance away from the area of operation.

Do not mow with bystanders in the area.

5. Do not operate the machine barefoot or wearing sandals, sneakers, tennis shoes, or similar lightweight footwear. Wear substantial pro-

tective footwear.

NOTE: Identies information worthy of special

attention.

5

6. Do not wear loose tting clothing that could get caught in moving parts. Do not operate this machine while wearing shorts; always wear adequate protective clothing, including long pants. Wearing safety glasses, safety shoes, and a helmet is advisable and required by some local ordinances and insurance regulations.

Safety Instructions

7. Prolonged exposure to loud noise can cause im-

pairment or loss of hearing. Operator hearing protection is recommended. Wear a suitable hearing protective device, such as earmuffs or earplugs.

8. Keep all protective shields and safety devices in place. If a protective shield, safe- ty device, or decal is damaged, unusable, or missing, repair or replace it before operating the machine.

9. Be sure interlock switches are functioning correctly, so the engine cannot be started unless the Forward Speed Control lever is in the NEUTRAL-PARK position, and the PTO clutch is in the DISENGAGED position. Also, the engine should stop if the operator lifts off the seat with either the Forward Speed Control (FSC) out of the NEUTRAL-PARK position or the PTO clutch in the ENGAGED position.

10. Handle gasoline with care. Gasoline is highly

ammable and its vapors are explosive:

a. Use an approved fuel container.

b. Never add fuel to a running engine or hot

engine (allow hot engine to cool several minutes).

c. Keep matches, cigarettes, cigars, pipes,

open ames, or sparks away from the fuel

tank and fuel container.

WARNING

This product can expose you to chemicals including Phenylethane which is known to the State of California to cause cancer, and N-Methyl-2-Pyrrolidone, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www. P65Warnings.ca.gov.

OPERATING

NOTE: Refer to your tractor Operator’s Manual

for safety instructions for operating the tractor.

1. Operate the machine only in daylight or in

good articial light with good visibility of areas

being cleaned.

2. Sit on the seat when starting the engine and operating the machine. Keep feet on footrests at all times when the tractor is moving and/or the mower blades are operating.

3. For a beginning operator, learn to steer (ma-

neuver) the tractor with a slow engine speed before attempting any mowing operation.

Be aware that, with the front mounted mower

deck conguration, the back of the machine

swings to the outside during turns.

d. Always ll the fuel tank outdoors using care.

Fill to about one inch from the top of the tank. Use a funnel or spout to prevent spilling.

e. Replace the machine fuel cap and contain-

er cap securely and clean up any spilled fuel before starting the engine.

12. Never attempt to make any adjustments while the engine is running, except where

specically instructed to do so.

13. The electrical system battery contains sulfuric acid. Avoid any contact with skin, eyes, and clothing. Keep the battery and acid out of reach of children.

DANGER

Do not operate around overhanging tree branches or bushes at the same height as the operator’s torso and head where inadvertent contact may cause injury.

4. Remember, for an emergency stop, the forward motion of the tractor can always be stopped by pulling the Forward Speed Control (FSC) into the NEUTRAL-PARK position.

6

Safety Instructions

5. In case either of the transmission drive belts break during operation, and if the machine is on a slope, the machine will freewheel down

the slope. To maintain control, immediately (1) Release the steering levers and simultaneously (2) Move the FSC to the NEUTRAL-PARK po- sition. When the machine is stopped or moving slowly, engage the parking brake.

NOTE: The emergency stop procedure is exactly the same procedure used to normally stop and park the machine.

6. Disengage the PTO clutch and put the FSC in the NEUTRAL-PARK position before starting the engine (an ignition interlock switch normally prevents starting of the tractor if these controls are in the OPERATING position).

7. Do not operate machine if the operator pres- ence safety switch system is not working. Verify proper operation by having the operator lift off the seat with the engine running and moving two controls, one at a time; (1) Move the FSC lever out of the NEUTRAL-PARK position, and (2) Engage the PTO Clutch. Moving either control should stop the engine immediately.

8. Do not run the engine in a conned area without adequate ventilation. Exhaust fumes are hazardous and can be deadly.

9. Do not carry passengers - maximum seating capacity is one (1) person.

10. Avoid sudden starts or stops. Before back- ing the machine up, look to the rear to be sure no one is behind the machine. Watch carefully for trafc when crossing or working near roadways.

11. When moving forward, do not suddenly put the tractor in reverse by rapidly pulling on the steering levers, especially when going downhill, as this can lift the tractor tail wheel off the ground and set up a bucking motion due to operator overcontrol. If bucking does occur, immediately stop the bucking action by pulling the Forward Speed Control (FSC) lever into the NEU-

TRAL-PARK position.

13. The maximum recommended slope operating angle is 15 degrees or 26% grade. When

operating the machine on a slope, reduce speed and use caution to start, stop, and maneuver. To prevent tipping or loss of control of the machine, avoid sharp turns or sudden changes in direction. Do not operate the machine on a slope greater than 15 degrees.

14. Never adjust dethatcher gauge wheels with the engine running. Before adjusting height or servicing, disengage the PTO clutch, stop the engine, and remove the ignition key. Wait for all movement to stop before getting off the seat.

NOTE: The PTO brake should stop drive line

rotation within ve (5) seconds of disengaging the PTO clutch. If the brake is not functioning

properly, adjust or repair the brake before operating the mower. Contact your Walker dealer for additional help.

15. If the cutting blades strike a solid object or the machine begins to vibrate abnormally,

immediately disengage the PTO clutch, stop the engine, and wait for all moving parts to stop. Disconnect the fuel solenoid wire [die-

sel engines] or the spark plug wire(s) [gasoline engines] to prevent accidental starting. Thoroughly inspect the mower and repair any damage before restarting the engine and operating the machine. Make sure cutting blades are in good condition and blade nuts are torqued to 60 lb•ft (81 N•m).

16. Do not touch the engine or mufer while the engine is running or immediately after stopping the engine. These areas may be hot enough to cause serious burns.

17. When leaving the machine unattended, disen-

gage the PTO clutch, stop the engine, and remove the ignition key.

12. Disengage the PTO clutch when transporting the machine.

7

Safety Instructions

MAINTENANCE

NOTE: Refer to your tractor Operator’s Manual

for safety instructions for tractor maintenance.

1. To prevent accidental starting of the engine when servicing or adjusting the machine, remove the key from the ignition switch and disconnect the fuel solenoid wire [diesel engines] or the spark plug wire(s) [gasoline engines].

2. To reduce re hazards, keep the engine free of grass, leaves, excessive grease, and dirt.

3. Keep all nuts, bolts, and screws tight to ensure the machine is in a safe, working condition. Check the blade mounting nuts frequently, making sure they are tight.

4. Perform only maintenance instructions de- scribed in this manual. Unauthorized main-

tenance operations or machine modications

may result in unsafe operating conditions.

5. If the engine must be running to perform a maintenance adjustment, keep hands, feet

and clothing away from moving parts. Do not wear jewelry or loose clothing.

6. Always use proper engine service manuals when working on the engine. Unauthorized

maintenance operations or modications to the

engine may result in unsafe operating conditions.

7. Altering the machine or engine in any manner which adversely affects its operation, performance, durability or use will VOID the war- ranty and may cause hazardous conditions.

8. Never attempt to disconnect any safety devices or defeat the purpose of these safety devices.

9. Do not change the engine governor settings or overspeed the engine. The governor has been factory-set for maximum-safe engine operating speed.

10. Use genuine factory replacement parts. Substitute parts may result in product malfunction and possible injury to the operator and/or others.

IMPORTANT: Keep all applicable manuals immediately accessible to anyone who may operate or service this machine.

8

Assembly Instructions

7

20

F255

F316

F255

20

F434

F017

21

23

5809-2

25

F009

The Walker Lawn Dethatcher will effectively dislodge excessive thatch from your lawn. Thatch is a layer of stems, clippings, runners, roots, and leaves that have not decayed. Excessive thatch prevents air, water, and fertilizer from reaching the roots. These instructions will help ensure proper assembly and operation.

1. Attach the caster wheel mounts to the tine tray as

shown in Install Caster Wheels illustration. In- stall the caster fork/wheel assembly into the caster wheel mount as shown. Be sure to install the shock washer and three (3) spacers before in-

stalling the caster fork. Install the remaining three

(3) spacers at the top of the caster fork and install the lynch pin. Use this as a starting point for the spacer location.

5809-2

Safety Rod

F571

Dethatching Tine

Tine Retainer Clip

F170

F009

Install Dethatching Tines

(Caster Wheel Assembly Removed for Clarity)

Install Caster Wheels

(Carrier Frame and Tray Mounting Brackets

Removed for Clarity)

2. Attach the tines to the tine tray nger tight, as

shown in the Install Dethatching Tines illustra-

tion. It is important to be sure the loop between

the tine coils nests around the hardware on the tine tray. After all the tines are installed, tighten the tine mounting hardware.

3. Insert safety rods through the coils of the tines as

shown in the Install Dethatching Tines illustration. Secure by bending the end of the rod 1-1/2 in. to 2 in. from the end to prevent them from slipping back through the tines. The safety rod must be free to move slightly from side to side.

WARNING

Failure to install the safety rods can result in personal injury if a tine should disengage from the tine tray.

4. Install the foot trigger as shown in Foot Trigger

photo using the 5/16-18 x 1-3/4 Hex Bolt (F316),

5/16 x 1 x 7/64 Flat Washer (F170), Washer (F060) and 5/16-18 ESNA Nut (F020). Foot trigger should move freely after tightening nut.

9

Foot Trigger

Assembly Instructions

5. Attach the lift lever to the carrier frame and

tighten hardware as shown in Install Lift Lever photo and Install Lift Lever Compression Spring photo so that 2 - 3 threads protrude through the ESNA nut.

Install Bolt

and Washer

Place Over

Pivot Stud

Install Lift Lever

ATTACH DETHATCHER TO DECK

1. Select a smooth, at surface such as a driveway, sidewalk, garage oor, etc. It is a simple proce-

dure for attachment, with no tools required.

2. Hook the rear legs of the dethatcher under the front of the deck carrier frame as shown in Attach Dethatcher to Deck Carrier Frame, and slide the channel mounts out to the deck carrier frame arms.

Rear Leg Hooked on

Deck Carrier Frame

Slide Channel Mount

out to Carrier Frame

Install Spring

and ESNA Nut

Friction Washer

P/N 5141-5

(Not Visible)

Install Lift Lever Compression Spring

Attach Dethatcher to Deck Carrier Frame

3. Once the channel mounts are attached to the carrier frame arms, install the lock pins as shown in Install Lock Pins to Channel Mounts photo. The dethatcher should be centered between the carrier frame of the deck.

Install Lock

Install Lock Pins to Channel Mounts

4. To remove the dethatcher, reverse the installation process.

10

Assembly Instructions

ADJUST TINES

Check and adjust the dethatcher tine working height

on a at surface. With the dethatcher mounted on the

mower deck and the tines lowered into the working position, the tine ends should be approximately 1/2 in. (13mm) above the surface as shown in the Adjust Tine Working Height photo. The tines should touch the surface when pushed back. If the tine vertical position needs to be adjusted, use the spacer washers on the caster wheel forks as follows (each spacer washer gives 1/8 in. [3mm] of adjustment):

1. To raise the tines, remove the linch pin and move spacers from the top of the caster fork and place them on the bottom.

2. To lower the tines, remove spacers from the bottom of the caster fork and place them on the top of the caster fork.

1/2 in.

Adjust Tine Working Height

11

Operating Instructions

OPERATING THE DETHATCHER

The dethatcher can be raised or lowered to engage, or disengage, the tines as desired.

1. To engage the dethatcher, pull back on the lift lever. While holding the foot trigger, lower the dethatcher into the working position as shown in Engaging Dethatcher photo.

Pull Back on

Lift Lever

Hold Foot

Trigger

FREE POSITION

THATCHING POSITION

RELEASED POSITION

Engaging Dethatcher

2. To disengage the dethatcher, pull back on the lift lever until the trigger assembly engages the mounting bracket.

NOTE: When raising/disengaging the dethatcher, there is resistance due to the tines being en-

gaged. It is easier to disengage the tines by

stopping the tractor forward motion and reversing the tractor while lifting.

TINE ACTION

Grass should be less than 3 in. (8cm) tall for pro- per tine action. When in use, all of the tines should deect back independently and “ip” the thatch forward as shown in the Tine Action illustration. If

the tines drag without ipping forward, the tines are too low and need to be raised. If the tines remain

in the free position, the tines are too high and needs to be lowered. Refer to Adjust Tines in the Assembly Instructions and adjust as needed for proper dethatching action.

Tine Action

12

Storage Instructions Maintenance Instructions

WALL BRACKET (OPTIONAL)

Use the P/N 6606-11 Wall Mount and foldable Lift Lever to store dethatcher in trailer or storage area when not in use.

Lift Lever

Folded DOWN

Wall Mount

P/N 6606-11

END OF SEASON

1. Clean and inspect the dethatcher thoroughly, noting any replacement parts that will be needed before the next season.

The Walker Lawn Dethatcher is nearly mainten-

ance free. However, periodically grease will need to be added to the grease ttings on the caster

wheel mounts and the pivot points shown in A10 Lubrication Points Diagram will need to be oiled.

Also inspect for broken/worn tines and replace as needed.

2. Repaint all parts from which paint has worn.

NOTE: Rustproong or painting every year will

prolong the life of the dethatcher.

3. When the dethatcher is dry, apply oil to tines to prevent rust. Apply lubricant liberally to all exposed surfaces to protect against rust.

4. Store dethatcher in a dry place.

13

Maintenance Instructions LUBRICATION

Ident Lubrication No. No. Location Type Places

1 Caster Wheel Mounts Grease* 2 2 Carrier Frame Pivot Oil 2 3 Foot Trigger Pivot Oil 1

* Grease every twenty-ve (25) hours.

(3) Foot Trigger Pivot

(1) Caster Wheel Mount

Grease Fittings

A10 Lubrication Points Diagram

(2) Carrier Frame Pivot

14

DT40A DETHATCHER ASSEMBLY (A10)

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

DT40A Dethatcher (40”)

1 6605-9 Tine Tray 1

2 6607-8 Carrier Frame 1

3 6609-9 Mounting Bracket 1 4 6615-8 Tray Mounting Bracket, RH 1 5 6615-9 Tray Mounting Bracket, LH 1 6 6605-8 Caster Wheel Mount 2 7 5830 Grease Fitting 2 8 6770 Caster Wheel Fork 2 9 6604-6 Channel Mount 2 10 6606-1 Lift Lever (Includes Item # 11) 1 11 5850-2 Handle Grip, Foam (5-1/2) 1

12 6603-3 Trigger Assembly 1

13 6715-2 Roller Wheel 2 14 6715-3 Roller Wheel Bearing 4 15 6715-4 Axle Spacer Tube 2 16 6605-6 Tine Deector 4 17 6610 Dethatching Tine 12 18 6608-2 Safety Rod (42”) 2 19 7775-6 Wire Lock Pin (2-1/2”) 2 20 8662-5 Square Plug (1 x 1) 6 21 6770-2 Spacer (1-1/8 x .765 x .125) 12 22 6770-3 Shock Washer 2 23 2775-1 Lynch Pin (3/16 x 1-1/4) 2 24 6610-3 Tine Retainer Clip 12 25 6605-11 Backing Plate 2 26 6605-12 Compression Spring (.530 x .875) 1 27 5141-5 Friction Washer (1 x 5/16 x .031) 1 28 5809-2 Decal, Walker Logo 1

ITEM PART DESCRIPTION NO. NO. NO. REQ’D

Fasteners

F009 5/16-18 Whiz Locknut 22 F013 3/8-16 Whiz Locknut 4 F017 5/16-18 Keps Nut 2 F020 5/16-18 ESNA Nut 2 F042 3/8-16 x 2-1/4 Hex Bolt 2 F049 5/16 SAE Washer 1 F060 AN960516 Washer 1 F170 5/16 x 1 x 7/64 Flat Washer 13 F255 5/16-18 x 1-1/2 Hex Bolt 2 F316 5/16-18 x 1-3/4 Hex Bolt 6 F434 5/16-18 x 3-1/2 Hex Bolt 2 F551 5/16-18 Flange Top Lock Nut 4 F571 5/16-18 x 7/8 Carriage Bolt 20

Beginning S/N 2018-22223 Use only genuine Walker® replacement parts.

15

DT40A DETHATCHER ASSEMBLY (A10)

11

F255

F571

20

4

F571

F013

10

26

F042

F571

F013

F020

3

19

9

F170

F316

12

5

F013

F060

20

19

F049

F571

27

9

F013

F316

F020

F042

F551

20

2

F551

F009

25

F316

5809-2

20

F009

28

1

F255

21

7

F316

21

23

F017

16

14

15

13

14

16

6

22

8

18

F434

F009 F009

20

F571

20

F009

F170

F009

25

17

24

Beginning S/N 2018-22223 Use only genuine Walker® replacement parts.

16

MAINTENANCE AND SERVICE RECORD SHEET

DATE SERVICE ENGINE ITEM HOURS

______________________________________________________________________________________________________________

17

MAINTENANCE AND SERVICE RECORD SHEET

DATE SERVICE ENGINE ITEM HOURS

______________________________________________________________________________________________________________

18

MAINTENANCE AND SERVICE RECORD SHEET

DATE SERVICE ENGINE ITEM HOURS

______________________________________________________________________________________________________________

19

LIMITED WARRANTY

FOR WALKER

DETHATCHER (A10)

1.

2.

3.

What this warranty covers, and for how long:

Walker Manufacturing company will, at its option, repair or replace, without charge, any part covered by this warranty which is found to be defective in material and/or workmanship within one (1) year after date of sale to the original retail purchaser unless the product is used for rental purposes, in which case this warranty is limited to ninety (90) days. At Walker’s request, customer will make the defective part available for inspection by Walker and/or return the defective part to Walker, transportation charges prepaid. All parts and components of the Walker A10 Dethatcher are covered by this warranty.

What this warranty does not cover:

A. This warranty does not cover defects caused by depreciation or damage caused by normal wear, accidents, improper maintenance, improper use or abuse of the product, alterations, or failure to follow the instructions contained in the Operator’s Manual for operation and maintenance.

B. The customer shall pay any charges for making service calls and/or for transporting the attachment to and from the place where the inspection and/or warranty work is performed.

How to obtain service under this warranty:

Warranty service can be arranged by contacting the dealer where you purchased the attachment or by contacting Walker Manufacturing Company, 5925 East Harmony Road, Ft. Collins, CO 80528. Proof of the date of purchase may be required to verify warranty coverage.

4.

Warranty limitation:

A. THERE IS NO OTHER EXPRESS WARRANTY. ANY WARRANTY THAT MAY BE IMPLIED FROM THIS PURCHASE INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE IS HEREBY LIMITED TO THE DURATION OF THIS WARRANTY AND TO THE EXTENT PERMITTED BY LAW ANY AND ALL IMPLIED WARRANTIES ARE EXCLUDED. Some states do not allow limitations on how long an

implied warranty lasts, so the above limitations may not apply to you.

B. WALKER WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES AND/OR EXPENSES IN CONNECTION WITH THE PURCHASE OR USE OF THE MACHINE. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation(s) or exclusion(s) may not apply to you.

C. Only the warranty expressed in this limited warranty shall apply and no dealer, distributor, or individual is authorized to amend, modify, or extend this warranty in any way. Accordingly, additional statements such as dealer advertising or presentations, whether oral or written, do not constitute warranties by Walker, and should not be relied upon.

D. This warranty gives you speciﬁc legal rights, and you may also have other rights which vary from state to state.

20

WALKER MFG. CO. • 5925 E. HARMONY ROAD, FORT COLLINS, CO 80528 • (970) 221-5614

Walker A10 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
