Wahl Creativa Instructions Manual

Creativa

Instructions

Creativa

Please read all instructions carefully to familiarise yourself

with your new Wahl Creativa Clipper before using.

Save these instructions for further reference.

For any further assistance or information call Customer Services on

T: 01227 740066

or visit

W: www.wahl.co.uk

E: [e-mail]

CONTENTS

GENERAL USER INFORMATION
IMPORTANT SAFEGUARDS
TECHNICAL DATA
DESCRIPTION OF PARTS
OPERATING INSTRUCTIONS
CLEANING AND MAINTENANCE
BATTERY REPLACEMENT, REMOVAL & DISPOSAL
WIRING

Page 13

TROUBLESHOOTING
GUARANTEE

Page 3

Page 4

Page 7

Page 8

Page 10

Page 12

Page 12

Page 14

Page 15

2

Creativa

GENERAL USER INFORMATION

Information about using the operation manual

►Before using the appliance for the rst time,

you must read and understand the operation
manual completely.

►Consider the operation manual as part of the

product and store it in a safe and accessible
place.

►Include this operation manual if passing the

appliance on to a third party.

►In the case of conicts with national safety

specications or instructions, the national

requirements must be followed.

Explanation of symbols and notes

DANGER

Danger of electric shock which may result in serious physical injury or death.

DANGER

Danger of explosion which may result in serious physical injury or death.

WARNING

Warning of possible physical injury or a health risk.

CAUTION

Information about danger of material damage.

Note with useful information and tips.

Action to be taken by owner.

Carry out these actions in the sequence described.

1.

·

List

3

Creativa

Please retain this leaet for future reference.

READ ALL INSTRUCTIONS BEFORE USING.

IMPORTANT SAFEGUARDS

When using this electrical appliance, especially when
children are present, basic safety precautions should

always be observed including the following.

Requirements

► Read the instruction manual in full to

familiarise yourself with the product

before the rst use.

► This appliance can be used by children

from aged 14 years and above and
persons with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.

► Use this appliance only for its intended

purpose.

4

Creativa

HAZARDS

Danger! Electric shock due to damage to
appliance

► Do not operate the appliance with a broken

cord, plug or charger, or if the appliance
malfunctions, or is dropped or damaged in
anyway.

► Any servicing or repairs must be performed

by Wahl (UK) Ltd or a suitably qualied

professional.

► The use of attachments that are not

supplied by the manufacturer may cause

re, electric shock or injury and damage to

the appliance.

Danger! Electric shock due to
penetration of liquid

► To protect against risk of electrical shock,

never immerse the unit or let it come into
contact with water or any other liquids.
Do not use the unit with wet hands. If the
appliance should become wet, damp or fall
in water, remove plug from mains socket
immediately. Do not put your hands in the
water. Do not take into bathroom.

5

Creativa

Danger of explosion

► This appliance must never be sprayed

with aerosol (spray) products classied
as ammable.

► Do not expose the appliance to

temperatures below 0˚C and above
+40˚C for any length of time. Avoid direct

exposure to sunlight.

Warning! Injuries due to incorrect
handling

► Cutting blades may become hot after

prolonged use.

► Switch o󰀨 the appliance and unplug from

outlet when not in use, before putting on

or taking o󰀨 attachments and also before

cleaning the appliance.

► Never use your appliance without paying

attention! Except when charging always
unplug this appliance from the electricity
outlet immediately after using.

► These appliances are intended for animal

hair trimming and clipping only.

6

Creativa

Caution! Danger of product damage

► Do not wrap the cord around the

appliance.

► During use do not place or leave the

appliance where it may be damaged by
an animal or exposed to the weather.

► Never carry the unit by its power cord.
► Do not drop or insert any object into any

opening.

Technical data

Hand-held appliance

Drive:
Battery:
Battery operating time:

Dimensions (LxWxH):
Weight:
Emission sound pressure level:
Vibration:

Charging Stand

Dimensions with accessories (LxWxH):
Weight:

Plug-in transformer

Type:
Power consumption:
Operating voltage:

Operating conditions ambient
temperature:

DC Motor
Lithium Ion battery
XXL BATTERY pack:
Up to 180 minutes

178 x 47 x 57 mm approx.
272 g Max.
60 dB(A) @ 25 cm
< 2.5 m/s2

119 x 91 x 57 mm
130 g

Adapter 6000
max. 12 W
100 – 240 V AC / 50/60 Hz

0°C – +40°C

7

Creativa

M

F

I

H

80 - 65%

30 - 10%

65 - 50%

10 - 0%

F

H

G

I

E

M

M

M

1

A

G

B

D

E

F

L K

J

J

I

8

C

D

H

Description of parts (Fig. 1)

A. Blade set

B. On/o󰀨 switch

C. Release button

D. Battery charge indicator

E. Interchangeable battery pack

F. Charging stand

G. Cutting-length adjustment

H. Charging stand socket

I. Cleaning brush

J. Oil for blade set

I

K. Plug-in transformer

L. Appliance plug

M. Attachment combs

* Attachment combs are optional
accessories and can vary from model
to model.

Creativa

432

6 75

8 9 10

b

a

b

b

a

a

5

a

b

b

a

1

a

9

Creativa

OPERATING INSTRUCTIONS

CHARGING THE BATTERY

This cordless clipper is supplied with two battery packs.
While the appliance is in use, the second battery pack can be
recharged on the charging stand. This means that the clipper
is always ready for use. Before the appliance is used for the

rst time, each battery pack should be charged for approx 120

minutes.

1. Connect the appliance plug (Fig. 1L) on the plug-in
transformer to the charging stand socket (Fig. 1H)

2. Connect the plug-in transformer to the mains
socket (Fig. 2b).

3. Insert the battery pack into the recess of the charging
stand (Fig. 4). The charging process starts. During

charging, the charging indicator (D) ashes red. It should

take around 120 minutes for the XXL BATTERY pack to
charge to full capacity. The second battery can remain

in the charging stand so that a charged battery pack is
always available.

4. Once charging is complete, the charging indicator (D)
lights up green.

BATTERY OPERATION
Battery Operation

Switch on the appliance using the on/o󰀨 switch and switch o󰀨

after use (Fig. 1B).

• In case of insu󰀩cient maintenance of the blade set,
the operating time can be reduced considerably. (See
cleaning and maintenance section page 12)

• While in operation with a fully charged battery, the
charging indicator (D) lights up green.

• Whenever the charging indicator (D) lights up red during
operation, the battery pack needs to be recharged. You
can now use the charged replacement battery pack.

10

Creativa

To recharge the battery:

1. Switch o󰀨 the clipper using the on/o󰀨 switch (Fig. 5b).

2. Press the release button (Fig. 1C) on the side and remove
the battery pack (Fig. 3a).

3. Remove the charged battery pack (Fig. 4) from the
charging stand and slide it into the hair clipper until it
locates with an audible click (Fig. 3b).

4. Fit the at battery pack to the charging stand (Fig. 4). See
section Charging the battery.

OPERATION
Setting the cutting length

The cutting length can be adjusted to between 0.7mm and
3mm (5 possible positions) using the cutting length adjustment
integrated into the blade set (Fig. 6).

Cutting with attachment combs

The appliance can also be operated with attachment combs. In
order to achieve the indicated cutting length, the cutting length
adjustment lever should be set to position 1 (Fig. 6).

Attaching/removing the attachment comb

1. Slide the attachment comb on to the blade set in the
direction of the arrow until it reaches the limit (Fig. 7a).

2. The attachment comb can be removed by pushing it in the
direction of the arrow (Fig. 7b).

CHANGING THE BLADE SET
Removing the blade set:

1. Switch the appliance o󰀨 using the on/o󰀨 switch (Fig. 5b)
and disconnect from the power supply.

2. Push the blade set o󰀨 the housing in the direction of the
arrow (Fig. 8a). Remove the blade set.

Replacing the blade set:

1. Replace the blade set by hooking it into the housing. The
small lug at the base of the blade should be aligned with
the indent on the clipper casing. Press the blade down
until it clicks into position (Fig. 8b).

11

Creativa

CLEANING AND MAINTENANCE

• Remove the attachment comb (Fig. 7b) after every use
and lift the blade set out of the housing (Fig. 8a).

• Use the cleaning brush to remove any cut hairs from the
housing opening and from the blade set (Fig. 9).

• The cleaning lever (Fig. 9a) can also be pressed. This
allows the cut hairs that accumulate between the bottom
blade and the top blade to be easily removed using the
cleaning brush.

• Only wipe the appliance with a soft, slightly damp cloth.

• The charging contacts on the charging stand and on the
battery pack should always be kept clean.

• Clean the blade set regularly using hygienic spray.

• Oil the blade set with the blade set oil (Fig. 10)

• For long-lasting cutting performance, it is important to oil
the blade set frequently.

• If the cutting performance deteriorates after long use
despite regular cleaning and oiling, the blade set should
be replaced.

LITHIUM BATTERY REPLACEMENT, REMOVAL AND
DISPOSAL

Lithium-Ion Battery Replacement

The battery should only be replaced by the original
manufacturers spare, for safety reasons a substitute should not

be used. Lithium-Ion batteries can explode, catch re, and/or

cause burns if disassembled, damaged or exposed to water or
high temperatures.

Lithium Battery Disposal

Do not dispose of this product or the Lithium battery in the
normal household waste.
The product should be returned to Wahl Customer Services

where we o󰀨er a take back service or taken to a local collection

facility where they will be dealt with safely and sent for the
appropriate recycling.

12

Creativa

WASTE ELECTRICAL & ELECTRONIC EQUIPMENT
DIRECTIVE 2002/96/EC (WEEE)

Within the European Community, national regulations are

specied for the disposal of electrical appliances, based on

EU Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE). In accordance with this, the appliance
can no longer be disposed of with the local or domestic
waste.
The appliance will be accepted free of charge by local
collection points or recycling centres.

WIRING

WARNING:

If the transformer is damaged it must be replaced in order
to avoid a hazard.
This product must only be used with the transformer
supplied.
Should a replacement be required contact Wahl Customer
Service.

DISPOSAL

Handle with care. Environmental damage in the case of incorrect
disposal.

Correct disposal will ensure environmental protection and prevent
any potentially harmful impacts on people and the environment.

Adhere to the relevant legal requirements when disposing of the appliance.

Information on the disposal of electrical and electronic appliances in
the European Community.

13

Creativa

TROUBLESHOOTING
Blade set is cutting badly or pulling hair out.
Cause: Blade set is dirty, worn or blunt.

• Clean and oil the blade set (Fig. 9/10); if this does not
resolve the problem, replace the blade set (Fig. 8).

Skin injury
Cause: Too much contact pressure on the skin.

• Reduce contact pressure when cutting close to skin.

Cause: Damaged blade set.

• Check whether the blade edges or teeth are damaged and
replace the blade set if necessary.

• NEVER use a damaged blade as this will cause injury.

Battery life is too short.
Cause: Blade set and housing opening are dirty.

• Clean and oil the blade set (Fig. 9/10).

Cause: Battery is worn out.

• Replace the battery pack with an original spare part.

• Replacement battery packs are available from your dealer
or from our Customer Service team.

Charging indicator does not light up.
Cause: The battery pack is not correctly positioned on the

charging stand.

• Ensure that the battery pack has been correctly placed on
the charging stand.

Cause: Charging contacts are dirty.

• Clean the charging contacts on the charging stand and on
the battery pack.

Cause: Defective power supply.

• Ensure that the plug-in transformer is plugged into the
mains socket.

• Check the mains cable for possible damage.

14

Creativa

GUARANTEE

This product is guaranteed against defects in material and
workmanship for a period of 1 year from the date of original
purchase or receipt as a gift.

Should this product become defective during the guarantee
period, return it to the store of purchase together with your
proof of purchase for repair or replacement.

Alternatively within the guarantee period you can return the
product to Wahl (UK) Ltd who will repair any such defect or
elect to replace the product or any part of it, without charge,
provided that there is proof of purchase. Should a replacement

be o󰀨ered this will not extend the original guarantee period.

The guarantee becomes invalid in the case of misuse,
alteration or repair by unauthorised persons.

This guarantee does not include blades, cables, and cutters
etc, which are consumable parts.

This guarantee in no way a󰀨ects your rights under statutory law

in the United Kingdom.

15

WAHL (UK) LTD
STERLING HOUSE
CLIPPER CLOSE

RAMSGATE, KENT

CT12 5GG

CUSTOMER SERVICES T: 01227 740066
www.wahl.co.uk

Form No. ZB862
Rev.1 10-18
