Wago 880-687/999-940 Data Sheet

Data sheet | Item number:880-687/999-940

3-conductor ground terminal block; 4 mm²; side and center marking; for DIN­rail 35 x 15 and 35 x 7.5; CAGE CLAMP®; 4,00 mm2; green-yellow

Color:

Data

Connection data

Connection technology

CAGE CLAMP

®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.08 4mm²/ 28 12AWG

Fine-stranded conductor 0.08 4mm²/ 28 12AWG

880-687_999-940

22.08.2019Page /1 10

Data sheet | Item number:880-687/999-940

Strip length 8 9mm/ 0.31 0.35inch

Total number of connection points 3

Total number of potentials 1

Number of levels 1

Type of wiring Front-entry wiring

Geometrical Data

Width 5mm/ 0.197inch

Height from upper-edge of DIN-35 rail 29mm/ 1.142inch

Depth 73mm/ 2.874inch

Mechanical data

Design horizontal

Type of mounting DIN-35 rail

Marking level Center/side marking

Material Data

Color green-yellow

Insulating material Polyamide 66 (PA 66)

Fire load 0.12 MJ

Weight 11.899g

Commercial data

Country of origin DE

GTIN 4045454084783

Customs Tariff No. 85369010000

Approvals / Certificates

Radio-Approvals

Logo Approval Additional Approval Text

Certificate
name

CCA

DEKRA Certification B.V.

EN 60947 NTR-NL

7339

CCA

DEKRA Certification B.V.

EN 60947 2174152.01

Country specific Approvals

Certificate

880-687_999-940

22.08.2019Page /2 10

Data sheet | Item number:880-687/999-940

Logo Approval Additional Approval Text name

ABS

American Bureau of Shipping

EN 60947 14-

HG1293677­PDA

CCA

DEKRA Certification B.V.

EN 60947 NTR-NL

7339

CCA

DEKRA Certification B.V.

EN 60947 2174152.01

Ship Approvals

Logo Approval Additional Approval Text

Certificate
name

ABS

American Bureau of Shipping

EN 60947 14-

HG1293677­PDA

DNV GL

Det Norske Veritas, Germanischer Lloyd

- TAE00001V2

Other Approvals

Logo Approval Additional Approval Text

Certificate
name

UL

Underwriters Laboratories Inc.

UL 1059 20170731-

E45172

UL-Approvals

Logo Approval Additional Approval Text

Certificate
name

UL

Underwriters Laboratories Inc.

UL 1059 20170731-

E45172

Compatible products
