Wago 870-539 Data Sheet

Data sheet | Item number:870-539

3-conductor, double-deck terminal block; 6-conductor through terminal
block; N; suitable for Ex i applications; internal commoning; conductor entry
with violet marking; for DIN-rail 35 x 15 and 35 x 7.5; 2.5 mm²; CAGE CLAMP®

Color:

Item description

Safety information 1:

Max. insulation diameter: 4.4mm

Data

Electrical data

Ratings per IEC/EN 60664-1

Rated voltage (III / 3) 500 V

Rated impulse voltage (III / 3) 6 kV

Rated current 24 A

Connection data

Connection technology

CAGE CLAMP

®

Actuation type Operating tool

Connectable conductor materials Copper

Solid conductor 0.08 … 2.5mm²/ 28 … 12AWG

Fine-stranded conductor 0.08 … 4mm²/ 28 … 12AWG

Strip length 6 … 7mm/ 0.24 … 0.28inch

Total number of connection points 6

870-539

02.05.2019Page /1 10

Data sheet | Item number:870-539

Total number of potentials 1

Number of levels 2

Type of wiring Front-entry wiring

Geometrical Data

Width 5mm/ 0.197inch

Height from upper-edge of DIN-35 rail 40mm/ 1.575inch

Depth 91mm/ 3.583inch

Mechanical data

Design horizontal

Type of mounting DIN-35 rail

Potential marking N

Marking level Side marking

Material Data

Color blue

Insulating material Polyamide 66 (PA 66)

Fire load 0.205 MJ

Weight 14.4g

Commercial data

Country of origin DE

GTIN 4045454094546

Customs Tariff No. 85369010000

Approvals / Certificates

Country specific Approvals

Logo Approval Additional Approval Text

Certificate
name

CCA

DEKRA Certification B.V.

EN 60947 NTR NL

7468

CCA

DEKRA Certification B.V.

EN 60947 2189801.01

Ship Approvals

Logo Approval Additional Approval Text

Certificate
name

870-539

02.05.2019Page /2 10

Data sheet | Item number:870-539

ABS

American Bureau of Shipping

- 14­HG1293677­PDA

DNV GL

Det Norske Veritas, Germanischer Lloyd

- TAE00001V2

LR

Lloyds Register

EN 60947 91/20112

(E9)

UL-Approvals

Logo Approval Additional Approval Text

Certificate
name

cURus

UL International Germany GmbH

UL 1059 20160928-

E45172

Compatible products

End plate

Item no.: 870-573

End and intermediate plate; 2 mm thick

870-573

Item no.: 870-574

End and intermediate plate; 2 mm thick

870-574

Protective Warning Marker

Item no.: 280-405

Protective warning marker; with high-voltage symbol, black; for 5 terminal blocks

280-405

tools

Item no.: 210-657

Operating tool with partially insulated shaft; Blade (3.5 x 0.5) mm; short

210-657

Item no.: 210-658

Operating tool with partially insulated shaft; Blade (3.5 x 0.5) mm; short; angled

210-658

870-539

02.05.2019Page /3 10
