Wago 745-853/006-000 Data Sheet
Data sheet | Item number:745-853/006-000
Stackable PCB terminal block; 16 mm²; Pin spacing 10 mm; 1-pole; CAGE
CLAMP®; commoning option; 16,00 mm2; light gray
Color:
Item description
745-853_006-000
22.08.2019Page /1 12
Data sheet | Item number:745-853/006-000
Modular PCB terminal blocks with screwdriver-actuated CAGE CLAMP for custom PCB terminal strip assemblies
®
Versions with Ex approval
Unrestricted UL approval up to 600 V with 20 mm pin spacing
Common and distribute potentials via comb-style jumper bars
Four solder pins for high mechanical stability
Integrated testing tap
Marker slot for Mini-WSB markers
Data
Electrical data
Ratings per IEC/EN 60664-1
Rated voltage (III / 3) 320 V
Rated impulse voltage (III / 3) 4 kV
Rated voltage (III / 2) 320 V
Rated impulse voltage (III / 2) 4 kV
Rated voltage (II / 2) 630 V
Rated impulse voltage (II / 2) 4 kV
Rated current 76 A
Approvals per UL 1059
Rated voltage UL (Use Group B) 300 V
Rated current UL (Use Group B) 10 A
Rated voltage UL (Use Group D) 300 V
Approvals per CSA
Rated voltage CSA (Use Group B) 300 V
Rated current CSA (Use Group B) 10 A
Rated voltage CSA (Use Group D) 300 V
Rated current CSA (Use Group D) 10 A
Connection data
Connection technology
CAGE CLAMP
®
Actuation type Operating tool
Solid conductor 0.2 16mm²/ 24 6AWG
Fine-stranded conductor 0.2 16mm²/ 24 6AWG
Fine-stranded conductor with ferrule with plastic collar 0.25 10mm²
Fine-stranded conductor with ferrule without plastic collar 0.25 10mm²
745-853_006-000
22.08.2019Page /2 12
Data sheet | Item number:745-853/006-000
Strip length 12 13mm/ 0.47 0.51inch
Conductor entry angle to the PCB 45 °
Total number of connection points 1
Total number of potentials 1
Number of connection types 1
Number of levels 1
Number of jumper slots 1
No. of poles 1
Geometrical Data
Pin spacing 10mm/ 0.394inch
Width 11.5mm/ 0.453inch
Height 33.5mm/ 1.319inch
Height from the surface 27mm/ 1.063inch
Depth 33.4mm/ 1.315inch
Solder pin length 6.5mm
Solder pin dimensions 1.2 x 1.6mm
Drilled hole diameter (tolerance)
2.2 mm
(- … +0.1)
PCB contact
PCB contact THT
Solder pin arrangement over the entire terminal strip, in line
Number of solder pins per potential 4
Material Data
Color light gray
Material group I
Insulating material Polyamide 66 (PA 66)
Flammability class per UL94 V0
Clamping spring material Chrome nickel spring steel (CrNi)
Contact material Electrolytic copper (E )
Cu
Contact plating tin-plated
Fire load 0.125 MJ
Weight 8.884 g
Environmental Requirements
Limit temperature range -60 +105°C
745-853_006-000
22.08.2019Page /3 12
Data sheet | Item number:745-853/006-000
Commercial data
Product Group 4 (Printed Circuit)
Country of origin PL
GTIN 4017332750561
Customs Tariff No. 85369010000
Approvals / Certificates
Radio-Approvals
Logo Approval Additional Approval Text
Certificate
name
CCA
DEKRA Certification B.V.
EN 60947 2160584.14
CCA
DEKRA Certification B.V.
EN 60947 NTR NL-
7094
Country specific Approvals
Logo Approval Additional Approval Text
Certificate
name
CCA
DEKRA Certification B.V.
EN 60947 NTR NL-
7094
CCA
DEKRA Certification B.V.
EN 60947 2160584.14
CSA
DEKRA Certification B.V.
C22.2 No. 158 1604421
Other Approvals
Logo Approval Additional Approval Text
Certificate
name
UR
Underwriters Laboratories Inc.
UL 1059 E45172
sec6
UL-Approvals
Certificate
745-853_006-000
22.08.2019Page /4 12
