Wago 2092-3422 Data Sheet
Data sheet | Item number: 2092-3422
THT male header; 1.4 mm Ø solder pin; angled; Pin spacing 7.5 mm; 2-pole
2092-3422
L = (pole number – 1) x pin spacing + 7.2 mm
A = 3.6 mm THT solder pin
Color:
A = 2.4 mm THR solder pin
Item description
Assembly of female connectors without loss of poles, allowing different functions to be divided within one male header
Coding pins inserted into the header interface prevent mismating, allowing subsequent coding in panel feedthrough applications
The female connector is fully shrouded by the male header's housing, providing vibration resistance up to 20 g
Safety information 1:
The picoMAX® pluggable connection system is designed without breaking capacity for compliance with DIN EN 61984. When used as intended, MCS Connectors shall not be connected/disconnected when live or under load. The circuit design should ensure header pins, which can be touched, are not live when unmated.
Data
Electrical data
Ratings per IEC/EN 60664-1
Rated voltage (III / 3) |
400V |
02.05.2019 Page 1/4
Data sheet | Item number: 2092-3422
2092-3422 |
|
Rated impulse voltage (III / 3) |
6kV |
Rated voltage (III / 2) |
630V |
Rated impulse voltage (III / 2) |
6kV |
Rated voltage (II / 2) |
1000V |
Rated impulse voltage (II / 2) |
6kV |
Rated current |
16A |
Approvals per UL 1059 |
|
Rated voltage UL (Use Group B) |
300V |
Rated current UL (Use Group B) |
15A |
Rated voltage UL (Use Group D) |
300V |
Rated current UL (Use Group D) |
10A |
Connection data |
|
No. of poles |
2 |
Total number of potentials |
2 |
Number of connection types |
1 |
Number of levels |
1 |
Geometrical Data |
|
Pin spacing |
7.5 mm / 0.295 inch |
Width |
14.7 mm / 0.579 inch |
Height |
18 mm / 0.709 inch |
Height from the surface |
14.4 mm / 0.567 inch |
Depth |
19.5 mm / 0.768 inch |
Solder pin length |
3.6mm |
Solder pin diameter |
1.4mm |
Drilled hole diameter (tolerance) |
1.6(- … +0.1) mm |
Plug connection |
|
Contact type (pluggable connector) |
Male connector/plug |
Connector connection type |
for PCBs |
Mismating protection |
No |
Mating direction to the PCB |
0° |
Locking of plug-in connection |
Male locking latch |
PCB contact |
|
PCB contact |
THT |
02.05.2019 Page 2/4
