Wagan 300 User Manual

R

300

300

TM

300

Item no. 9621

User's Manual

Pro Line 300 Watt Power Inverter by Wagan Tech

USER’S MANUAL — Please read before using this equipment.

_______________________________________________________________________________________________________________________

Your 300 Watt Power Inverter converts 12-volt vehicle
battery power into 115 volts of AC power. You can use
the inverter in your vehicle to operate many types of
appliances that use AC power such as TVs, VCRs,
portable computers, power tools, and lights for
emergency or camping use.

The inverter works with your vehicle’s engine turned on
or off (accessory mode). It provides a continuous output
of up to 300 watts.

BASIC OPERATION

x Use the right operating voltage for both input and

output of the inverter.

x Powering devices with power rating:

o Less than 150 Watts by connecting the

cigarette lighter plug into the vehicle’s
cigarette lighter socket.

o More than 150 Watts by connecting

Պ from

x Insert the plug of your appliances into AC socket at

the front of the inverter.

x Turn ON the power switch that is located at the front

of the inverter, and the green LED light will light as
indicator that the unit at work.

CAUTION:

x DO NOT USE THE INVERTER IN A POSITIVELY

GROUNDED VEHICLE.

x DO NOT POWER MORE THAN 150 WATT WHEN

THE POWER INVERTER IS CONNECTED TO THE
CAR CIGARETTE LIGHTER SOCKET POWER
SUPPLY. DOING SO MIGHT DAMAGE YOUR
CAR'S FUSE. MISUSE WOULD VOID THE
WARRANTY.

RECOMMENDATION

x If the power inverter makes a beeping sound, turn

OFF the power inverter and disconnect all
appliances from inverter and disconnect the inverter
from power supply. The beeping sound is simply the
low battery warning, which indicates that the voltage
of the battery power supply is getting low. Please
restart the vehicle engine before operating the
power inverter.

x When you are not using the inverter, turn the power

switch to OFF and disconnect the inverter from
power supply.

x Disconnect the inverter when starting the vehicle’s

engine.

inverter to

Ջ from inverter to Ջ of battery terminal.

www.wagan.com

Պ of battery terminal and connect

© 2003 Wagan Corporation.

All Rights Reserved.

Wagan and Wagan.com are trademarks used by Wagan Corporation.

Printed in China

2
