Item no. 2561
User’s Manual
www.wagan.com
1
Solar e Charger™ Exec Duo by Wagan Tech
©2010 Wagan Corporation
All Rights Res erve d
Wagan and wagan.com are trademarks used by Wagan Corporation
2
User’s Manual—Read before using this equipment
Basic Operation
1. Insert and attach the iPhone
®
to the charging jack inside the
Solar e Charger™ Exec-Duo.
2. Turn the power switch to “ON” to charge the iPhone. The batter y
charge indicator next to the “Power Display” button and the red micro
LED on the front solar panel will both turn on. (If none of the LEDs light
up, the solar charger’s internal battery might be depleted and may
need to be recharged.)
3. Once the iPhone is fully charged, turn off the solar charger.
4. PRESS and HOLD the “Power Display” button to check the battery
status of the solar charger. Four micro LEDs, located to the right of the
power button, will light up to indicate the percentage of charge on
the battery according to the designated intervals: 25%, 50%, 75%,
and 100%.
Charging iPhone & Solar e Charger
The Exec-Duo can charge both the iPhone and its own internal Lithium
polymer battery via sunlight or with a standard mini USB charging cable
(not included). When a solar charging source is available, the red micro
LED indicator light on the front solar panel will light up to show the unit is
charging via sunlight.
Charging with Sunlight via Solar Panels:
1. To charge the iPhone, follow the steps 1-2 in “Basic Operation”
section and expose the solar panels under direct sunlight. Under
continuous sunlight, the iPhone will be charged in less than 4 hours.
Once the iPhone’s battery is fully charged, turn the power switch off
to preserve the life of the solar charger’s internal battery.
Charging jack
Mini USB Port Power switch
Battery status button
Battery Status
(25%, 50%, 75%, 100%)
Battery Charge Indicator
