Wagan 2404 User Manual

3 Million Brite-Nite Spotlight Lantern
Brite-Nite Linterna Reectora 3 Millones
Item # / Artículo #2404
User’s Manual
Manual de Usuario
3 Million Brite-Nite™ Spotlight Lantern by Wagan Tech
®
1
www.wagan.com
User’s Manual—Read before using this equipment
2
©2012 Wagan Corporation
All Rights Reserved.
Wagan Tech and wagan.com are trademarks used by Wagan Corporation.
Thank you for purchasing the 3 Million Brite-Nite™ Spotlight Lantern by Wagan Tech®. With normal care and proper treatment, it will provide years of reliable service. It is important to read all operating instructions carefully before use and keep this user’s manual for future reference.
INTRODUCTION
This spotlight-lantern is useful for accomplishing a variety of activities. It has a stand that can be used to aim the spotlight beam in a convenient position. In the field, it serves as a powerful spotlight. At the campground, the lantern feature is very useful as a bright, steady, reading light. During tire changes at night, the lantern can light the area while the red, flashing Emergency Light warns motorists to avoid the area. Two chargers are included allowing for either DC charge from a cigarette lighter socket or AC charge from any wall outlet.
FEATURES
• Bright spotlight beam is visible up to one mile.
• Fluorescent Lantern and Area Light operates from to 2-4 hours.
• User can select operation with one or two fluorescent tubes.
• Rechargeable 6 volt sealed lead- acid battery.
• Charge in vehicle from cigarette lighter socket (DC adapter included).
• Charge at home (AC adaptor included).
• Weather-resistant casing provides for outdoor and emergency use.
• Large handle for easy carrying.
• Red flashing emergency warning light.
• Spotlight power switch located right at finger tips, allowing for single-hand operation
while being carried.
• Red LED charging indicator lets the user know that charging power is connected.
• Retractable wire stand allows the spotlight beam to be positioned in a variet y
of angles.
SPECIFICATIONS
• Operating Voltage: 6 Volts DC
• Sealed Lead Acid Battery: 6V DC, 4.5 AH
• Quartz Halogen Bulb: 6 Volt 55 Watt H3
• Fluorescent Tubes (2): 7 Watt, U shape
• Dimensions: 11 in. x 7 in. x 7 in.
• Weight: 4.5 lbs
Emergency Flare Light
Spotlight Power Switch
Charging Jack
Fluorescent Lantern (2 U-shaped tubes)
Halogen Spotlight
Retractable Stand
Lantern Power Switch
3 Million Brite-Nite™ Spotlight Lantern by Wagan Tech
®
3
www.wagan.com
User’s Manual—Read before using this equipment
4
©2012 Wagan Corporation
All Rights Reserved.
Wagan Tech and wagan.com are trademarks used by Wagan Corporation.
GENERAL SAFETY PRECAUTIONS
• Do not turn on light while charging the unit. Doing so will damage the unit and will void your warranty.
• As with all lead-acid cell batteries, when storing, be sure to recharge the battery fully every 3-6 months to prolong the life of the battery.
• Turn OFF all lamp functions and allow unit to cool before storage.
• Though durable and built to last, do not drop the unit excessively as this will greatly
reduce the life of the unit.
• Though weather resistant, do not submerge the unit.
• Lens becomes very hot during operation.
• Do not cover lens or reflector during operation.
• Do not shine directly into eyes.
• Switch off and allow it to cool before storage or maintenance.
• When servicing always wear safety glasses when working with hardware.
• Use only supplied chargers.
• This unit is intended to be correctly orientated in a vertical or floor mount position.
OPERATING INSTRUCTIONS
This Spotlight Lantern is versatile and convenient to use. The large handle and rocker switch placement allows for easy control of all lamp functions while carrying the unit. Two Rocker type switches have three positions each and are marked I, O, and II. Always store the lamp with both switches in the “O” position.
The two rocker switches and their functions are shown in the table below.
Switch Location/Function Rocker Switch 1 (closest to
spotlight end)
Rocker switch 2
“O” Position Function OFF OFF “I” Position Function Spotlight ON Single fluorescent tube ON “II” Position Function Flashing Red Emergency
Beacon
Two fluorescent tubes ON
RECHARGING THE UNIT
Your spotlight is supplied with two charging adapters. One adapter is powered by standard 115 volts AC. This is the AC/DC Charging Adapter. The other charging adapter is the DC/DC Charging Adapter. This adapter has a user-replaceable fuse in the DC plug that connects to a cigarette lighter outlet (accessory outlet). Be sure to charge the unit completely before the first use (charge for 24 hours). This step will prolong the life of the internal batter y. Use the AC/DC Charging Adapter for the first charge.
AC Charging
The AC/DC adapter provides a slow steady charge to the unit. Do not operate the lamp while the AC/DC Charging Adapter is charging the lamp, you may damage the charging adapter and discharge the lamp’s batteries. Charge for a maximum of sixteen hours; DO NOT overcharge.
1. Make sure that all switches are set to “O”, the off position.
2. Using the AC/DC adaptor, insert the DC end into the Charging Jack (next to the flare light).
3. Plug the AC end into a wall outlet.
4. The red Charging LED light will come on to indicate the lamp is charging.
DC Charging
Any 12 Volt DC power outlets, such as in vehicles, boats, and jump starters can charge this lamp using the DC/DC Charging Adapter. For full charge, the power source must be from a vehicle or boat DC outlet and the engine should be running. Charge for five hours maximum; DO NOT overcharge.
1. Make sure that all switches are set to “O”, the off position.
2. Using the DC/DC charger, insert the DC end into the Charging Jack (next to the flare light).
3. Plug the larger DC plug into the cigarette lighter outlet.
4. The red Charging LED light will come on to indicate the lamp is charging.
