Assembly Instructions
Caution: You must read this before you proceed
TABLE
Caution: This Table is NOT a TOY.
Keep your child / children at bay during the assembly process.
Whenever lifting or moving the Table and to prevent damage to the Table, two adults
may be needed to execute these actions.
1
Label Picture Description QTY
A Table Top 1
B Leg Panel 2
C Leg Support Bar 1
D Corner Block 4
Label Picture Description QTY
①
Bolt
(M8*55mm)
5
②
Screw
(M6*40mm)
9
③
Screw
(M6*60mm)
3
④ Allen Key 2
Parts List
Hardware
2
Assembly Preparation
Assembly Steps
This Table has multiple parts and may require up to 30 minutes to assemble. To give
you an overview of the Table parts, the above picture is to help you put the various
parts into perspective. Please read through the instructions below to familiarise
yourself with the parts and steps before assembly.
Overview
Before Beginning Assembly:
3
Unpack and place all parts on a clean, non-marring surface.
Attach Leg Panel(B) to Table Top(A) using Bolts(①) with Allen Key(④) as shown
above.
Do not fully tighten the Bolts.
Repeat the same process with the remaining Leg Panel(B).
Step 2
Step 1
4
Insert the tenons on the Leg Support Bar(C) into the mortises of the Leg Panels(B).
Attach Leg Support Bar(C) to Leg Panels(B) using Screws(③) with Allen Key(④) as
shown above.
Do not fully tighten the Screws.
Align the Corner Blocks(D) to the Table Top(A) and Leg Panels(B) and attach using
Screws(②) with Allen Key(④) as shown above.
Do not fully tighten the Screws.
Step 3
Step 4
5
Stand the Table up, with assistance from your adult partner.
Exert pressure floorwards, onto the Table with both your hands.
This pressure will help the Legs and Table Top reach full alignment status.
Check for wobbles on a LEVEL surface.
If no wobbles are found proceed to tighten the Bolts and Screws in a sequential
manner, until evenly secured.
When tightening the Bolts and Screws tighten sequentially.
Do not tighten any Bolt or Screw fully and then move on towards the next one.
If there are still wobbles, loosen the Bolts and Screws and excute the same
above process.
Your Table is ready for use.
This Table can only be used on a flat, level surface.
Step 5
