COCKTAIL
Assembly Instructions
Top supports up to lb.
Shelf supports up to lb.
COCKTAIL
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware.
Carefully study the diagrams below.
You may receive extra hardware with your unit.
1 2PCS
Frames
4 4PCS
Metal Caps
5 12PCS
2 4PCS
Supports
6 1PC
3 4PCS
Legs
7 1PC
Metal Washers
A 8PCS
Bolts 5/16”x1-3/4”
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Avoid rubbing or scratching the surface with
rough or abrasive objects.
Glass Top
B 12PCS
Glass Pads
Assembly Tool Required
No.2 Phillips Screwdriver
Mirror Shelf
C 4PCS
Levelers
For replacement parts or questions, please
call customer service.
COCKTAIL
Figure 1
Assembly Instructions
Step 1
Unit assembly should begin with
parts turned upside down for Step
1.
Attach Metal Caps (4), Metal
Washers (5) and Supports (2) to
Top Frame (1) connecting with
Screws (A) as shown.
Please make sure the labels
reading BOTTOM under Frames
(1) are facing upwards.
:
Step 2
Attach Screws (A) to Supports (2),
then, attach Metal Washers (5) and
Shelf Frame (1) to Supports (2)
connecting with Screws (A) as
shown.
:
Figure 2
Step 3
Attach Metal Washers (5) to
:
Screws (A), and then attach Legs
C
(3) to Metal Washers (5).
Clockwise to tighten the parts.
Screw Levelers (C) to Legs (3).
Figure 3
Step 4
Attach Glass Pads (B) to the
brackets on Frames (1).
Place Glass Top (6) to Top Frame
(1) and insert Mirror Shelf (7) to
Shelf Frame (1) as shown.
Your Cocktail Table assembly is
now complete.
:
Figure 4
Parts Replacement Form
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
Style No Parts Letter Parts Description Quantity Needed
