Wade Antenna CG Towers User Manual

DELHI COMMERCIAL GUYED TOWER PRODUCTS

Width = 1.67 m

BASE STUBS
IN CONCRETE

76mm
CLEARANCE
152 x 152mm
WIRE MESH

NTS

DEPTH =

1.2 m

CONCRETE REQUIRED = 3.34 cu.m.

CG TOWERS

Ideal for supporting
Communications, Civil and
Amateur Antennas

Twelve models are available in heights from
62 ft. (8 sections) up to 147 ft. (19 sections)
plus mast.

Towers are designed to support a net
antenna weight of up to 80 lbs. with a
horizontal wind load of up to 300 lbs. plus
rotor and 2” O.D. x 10 ft. mast.

Instructions are supplied for 30 degree
guying with ground anchors 120 degrees
apart and about ½ tower height from base.

Hard Grade ¼” O.D. guy wire is
recommended.

Our new Towers have been enhanced in both
leg profile and taper facilitating an easier
installation and improved tower structure.

All tower sections are eight feet long with
twist reducing beaded-channel legs riveted
together with “X” braces. Legs and cross
braces are galvanized steel, rivets are solid
aluminum, anodized. Special nuts and bolts
are ½” O.D. and heat treated.

DMX-04T and DMX-04 sections are 19” wide
and have 16 ga. legs. DMX-05 and DMX-05S
sections are 21½” wide with 14 ga. legs.

Straight sections fit smoothly together, since
all leg bottoms are accurately swaged for a
perfect fit.

The three highest towers use tapered
sections at the base.

Special three-size guy stations are strong and
reliable. They are attached every
three sections from the base up (except
CG-19N) and at the top of the tower.

CG-15N

Model

Ground Anchor

244A

Cast Aluminum
Mast Clamp

BBMB

Ball Bearing
Mast bearing

www.wadeantenna.com

Top section with top plate, cast
aluminum mast clamp and rotor plate.

Guy Station where sections join.

DELHI COMMERCIAL GUYED TOWER PRODUCTS

CG TOWERS

TOWER SPECIFICATIONS

DESCRIPTIONMODEL NO. HEIGHT(FT.) WEIGHT(LBS)

All CG Commercial Guyed Towers are
shipped complete with the following items:

• 8 ft. tower sections

• Top plate with a No. 244A mast

clamp installed

• Rotor plate with No. 244A mast

clamp installed

• Guy stations

• Concrete base stubs

• Special nuts, bolts and washers

CG-19N
CG-18N
CG-17N
CG-16N
CG-15N
CG-14N
CG-13N
CG-12N
CG-11N
CG-10N

CG-9N
CG-8N

147
139
131
124
117
109
101

93
85
77
70
62

19 sections, 6 guy stations
18 sections, 6 guy stations
17 sections, 6 guy stations
16 sections, 6 guy stations
15 sections, 5 guy stations
14 sections, 5 guy stations
13 sections, 5 guy stations
12 sections, 4 guy stations
11 sections, 4 guy stations
10 sections, 4 guy stations
9 sections, 3 guy stations
8 sections, 3 guy stations

PARTS WHICH MAY BE ORDERED SEPARATELY

DESCRIPTIONPART NO. WEIGHT (LBS)

DMX-04T
DMX-04S

DMX-05

DMX-05S

DMX-06
DMX-07
DMX-08

ASSEMBLY DIAGRAM FOR ALL CG TOWERS

GS-456
CBS-05

GS-456

DMX-04T

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-05

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-06

DMX-07

DMX-08

GS-456

DMX-04T

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-05

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456
DMX-05S

DMX-06

DMX-07

GS-456

DMX-04T

DMX-04S

GS-456
DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-05

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456
DMX-05S

DMX-05S

DMX-06

GS-456

DMX-04T

DMX-04S
GS456

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-04S
GS-456

DMX-05

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456
DMX-04T

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-05

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S
GS-456

DMX-05S

DMX-05S

DMX-05S

CBS-06
CBS-07
CBS-08

244A

BBMB

GS-456

DMX-04T

DMX-04S
GS-456

DMX-04S

DMX-04S

DMX-04S
GS-456

DMX-04S

DMX-04S

DMX-05

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

CG-19 CG-18 CG-17 CG-16 CG-15 CG-14 CG-13 CG-12 CG-11 CG-10 CG-9 CG-8

Top section with 16 Ga. legs
Straight section with 14 Ga. legs
Offset section with 14 Ga. legs
Straight section with 13 Ga. legs
Offset section with 13 Ga. legs
Offset section with 12 Ga. legs
Offset section with 12 Ga. legs
Three-size guy station
Set of 3 base stubs for DMX-05
Set of 3 base stubs for DMX-06
Set of 3 base stubs for DMX-07
Set of 3 base stubs for DMX-08
Cast Aluminum clamp for 2.5” O.D. mast
Ball Bearing Mast Bearing for 2” O.D. mast

GS-456

DMX-04T

DMX-04S

GS-456

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-05

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-04T

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-05

DMX-05S

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456

DMX-04T

DMX-04S

GS-456
DMX-04S

DMX-04S

DMX-04S

GS-456

DMX-05

DMX-05S

DMX-05S

GS456

DMX-05S

DMX-05S

DMX-05S

GS-456
DMX-04T

DMX-04S

GS-456

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-05

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

GS-456
DMX-04T

DMX-04S

DMX-04S

GS-456

DMX-04S

DMX-05

DMX-05S

GS-456

DMX-05S

DMX-05S

DMX-05S

1021

967
908
850
780
601
569
516
481
431
399
354

39
31
42
43
56
65
70

8
13
13
20
21

3

2

GS-456
DMX-04T

DMX-04S

GS-456

DMX-04S

DMX-04S

DMX-05

GS-456

DMX-05S

DMX-05S

DMX-05S
