Page 1
Ion 2" Round
❍❍❍
❍
New Construction Downlight
Model
R2DRDN F
Example: R2DRDN-F930-WT
DESCRIPTION
Minimum profile downlight with metal conduit and driver included for easy
remodel or new construction installation.
FEATURES
• Sold as new construction, may be configured in field for remodel
• Metal Conduit with Quick Connect to allow for easy installation
• Driver included
• 5 year warranty
SPECIFICATIONS
Construction:
Power:
Input:
Dimming:
Light Source:
Lens:
Rated Life:
Mounting:
Cut Out:
Finish:
Ceiling Thickness: 1/2" - 1 1/2"
Operating Temp: -4°F to 104°F (-20°C to 40°C)
Standards:
Beam
35° 930 3000K - 90 680 1390 WT White
Die-cast Aluminum with 20-gauge Cold Rolled
Steel Driver Box
9W
120-277 VAC, 50/60Hz
TRIAC: 100-5%, ELV: 100-10%
Integrated LED
Frosted TIR lens
50000 Hours
New construction housings included with
hanger bars
3"
Electrostatically Powder Coated White
ETL, cETL, Wet Location Listed, Energy Star 2.0,
Color Temp & CRI
Title 24 JA8-2016 Compliant, IC, Airtight
Lumens CBCP
FINISHES
White
LINE DRAWING
Fixture Type:
Catalog Number:
Project:
Location:
Finish
waclighting.com | Phone (800) 526.2588 | Fax (800) 526.2585 | Headquarters/Eastern Distribution Center 44 Harbor Park Drive Port Washington, NY 11050
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. May 2020
1
