WAC Lighting WAC4813 Specifications

InvisiLED® Daylight to Sunset / Palette

LED Tape Light Power Supplies & Controllers

Fixture Type:

Catalog Number:

Project:

Location:

Wireless controller (accessory for wired controller)

LED-TO24-WS

Class II Transformers

Remote

Plug-in

Controllers

Wired
Controller

Wireless
Controller

Wired controller

LED-TC-CTR-MSD

Pause/Play

White/color mode DMX port

Model Power Dim Input Output L W H Details

EN2460DC 60W Yes 120V AC 24V DC 60W

EN2460DCP 60W Yes 120V AC 24V DC 60W

Model Input Output L W H Details

LEDTCCTRMSD 120V AC 24V DC

LEDTO24WS 4"

Brightness
Color changing speed

6d" 3c" 1w"

34" 1a"

54" 1a" 14"

1"

22" s"

Master/Slave/DMX switch

Low Voltage Class 2 electronic DC
power supply designed to be used as
indoor damp location suitable power
unit. Includes 6 ft lead wire.

4 function wired controller
with master and slave options.
Allows brightness control, preset
color selection, or playing a rotation
of color transitions with variable
speed control.

Wireless remote control (for use in
conjunction with wired controller),
dimming for brightness, color change
and change frequency. Manual
control and program set up.

Signal Wire

Signal Wire

WAC Lighting

www.waclighting.com
Phone [phone] • Fax [phone]

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. APR 2014

Model Length Details

LEDTC24SW60
LEDTC24SW120

Headquarters/Eastern Distribution Center

44 Harbor Park Drive • Port Washington, NY 11050
Phone [phone] • Fax [phone]

60"
120"

Extends distance between Master
Controller and Slave Controller

Western Distribution Center

1750 Archibald Avenue • Ontario, CA 91760
