WAC Lighting WAC4336 Specifications

H TRACK CURRENT LIMITER

120V Track System

Low Cost Energy Code Compliance Made Easy

• Easy to install and assures compliance toCalifornia Title 24 or ASHRAE 90.1 requirements

• Energy code track installations are subject to wattage limitations based upon the size
and usage of the space

• To order appropriate current limiter, select the model number which corresponds to
the H system to the maximum allowable wattage

• If the track is overloaded the current limiter circuit breaker will trip and
shut down power to the track.

• May be reset when the overall sum of  xture wattages are reduced below the circuit
breaker rating

Model Circuit Breaker Max Wattage Finish

1d"

THL-HLES

THL-HLE

1/5A
1/2A
1A
2A
5A
7A
10A

Slim Single Live End

Single Live End

18"

58"

6w"

18"

58"

6s"

Fixture Type:

Catalog Number:

Project:

Location:

200mA
500mA
1A

2.5A
5A

7.5A
10A

24W
60W
120W
300W
600W
900W
1200W

Double Live End

58"
88"

Double Live End (Left)

58"

6s"

Double Live End
(Right)

6s"

Example: THL-LEFT-1-1/5A-WT

WAC Lighting

www.waclighting.com
Phone [phone] • Fax [phone]

58"

THL-HI

18"

THL-LEFT

18"

THL-RIGHT

18"

Headquarters/Eastern Distribution Center

44 Harbor Park Drive • Port Washington, NY 11050
Phone [phone] • Fax [phone]

1-1/5A
2-1/5A

1-1/2A
2-1/2A

1-1A
2-1A

1-2A
2-2A

1-5A
2-5A

1-7A
2-7A

1-10A
2-10A

200mA
200mA per end

500mA
500mA per end

1A
1A per end

2.5A

2.5A per end

5A
5A per end

7.5A

7.5A per end

10A
10A per end

BK

24W
24W per end

60W
60W per end

120W
120W per end

300W
300W per end

600W
600W per end

900W
900W per end

1200W
1200W per end

Western Distribution Center

1750 Archibald Avenue • Ontario, CA 91760
Phone [phone] • Fax [phone]

BN
DB
WT

Black
Brushed Nickel
Dark Bronze
White

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. OCT 2015
