Page 1
CATALOG NUMBER
PROJECT
TYPE
FLEXRAIL1™ – Components CONNECTORS
Ordering Matrix
Model Part Number Finish
HM1 I (length) IDEC (length) VA (length) PT DB
Ordering Example (model number – part number – finish): HM1-I12-PT
Track Connectors
I Connector
HM1-I6-finish
HM1-I12-finish
HM1-I24-finish
HM1-I36-finish
HM1-I48-finish
Description Description
Connects two sections of track with electrical continuity. Allows
seamless connection of track sections and also works as a
suspension support.
3” canopy. Comes in lengths from 6” to 48”.
Two HM1-I’s can be combined to make a longer drop with the
addition of the XI coupler. An HM1-I can be field shortened and then
re-threaded with the addition of the HM1-XADJ field shortening
adaptor.
Variable Angle I
Connector
HM1-VA6-finish
HM1-VA12-finish
HM1-VA24-finish
HM1-VA36-finish
HM1-VA48-finish
I Dead-End Connector
HM1-IDEC6-finish
HM1-IDEC12-finish
HM1-IDEC24-finish
HM1-IDEC36-finish
HM1-IDEC48-finish
Connects two sections of track without electrical continuity. Allows
seamless connection of track sections and also works as a suspension
support.
3” canopy. Comes in lengths from 6” to 48”.
Two HM1-IDEC’s can be combined to make a longer drop with the
addition of the XI coupler. An HM1-IDEC can be field shortened and then
re-threaded with the addition of the HM1-XADJ field shortening adaptor.
Description
Connects two sections of track with electrical continuity.
Track can be connected at any angle up to 270˚.
3” canopy. Comes in lengths from 6” to 48”.
Two HM1-VA’s can be combined to make a longer drop with the
addition of the XI coupler. An HM1-VA can be field shortened and
then re-threaded with the addition of the HM1-XADJ field shortening
adaptor.
WAC Lighting reserves the right to modify the design of our products as part of the company’s continuous improvement program. Dec 2009
