ACCESSORIES & COMPONENTS
120V Track System
Fixture Type:
Catalog Number:
Project:
Location:
Accessories Model Finish Description
Suspension
Loop
15’ Cord,
Male Plug
w/ Switch LCORDSET L Track
T-Bar Drop
Ceiling
Attachment
H-LOOP
L-LOOP
J-LOOP
HCORD
T-BARCLIP
H Track
L Track
J /J2Track
H Track
J /J2Track
BK
BN*
1a” × 1a” × 3”
WT
DB**
BK
15' Maximum capacity: 7A, 800W, 120V.
WT
12” × 14”
3 inch electrical loop accepts chain hung xtures up to 35lbs. Contains
compartment for electrical connections.
Attaches track to T-bar drop ceilings. Use two for 2 foot or 4 foot tracks, three for
6 foot or 8 foot tracks.
Monopoint
Canopy Adapter
Canopy Plate CP
All Track
Suspension Kit
Suspension Kit
Extender
Sloped Ceiling
Adapter
Rod Coupler
Suspension
Adjustment
Collar kit
Low Voltage
Track Head
Extension
Line Voltage
Track Head
Extension
Wall Mount
Suspension
Bracket
*BN nish only available for H, L, J Track **DB nish only available for H Track
WAC Lighting
www.waclighting.com
Phone (800) 526.2588 • Fax (800) 526.2585
HMP
LMP
JMP
SK
R
SK14 Use with suspension kits for sloped ceilings
RI Join two rods for suspensions longer than 48".
SK05
X
H
TBKT 18" Extends track 24" from wall. Use two per 4’ length, three per 8’ length.
H Track
L Track
J /J2Track
18
18"
24
24"
36
36"
48
48"
18
18"
24
24"
36
36"
48
48"
72
72"
6
6"
12
12"
18
18"
24
24"
36
36"
48
48"
18
18"
24
24"
36
36"
48
48"
Ø 4w”
Ø 4a”
5a” x 5a”
42” × 42”
BK
BN*
WT
DB**
Headquarters/Eastern Distribution Center
44 Harbor Park Drive • Port Washington, NY 11050
Phone (516) 515.5000 • Fax (516) 515.5050
Mount a single H, L or J system track xture to a junction box. When used with
a low voltage track head the transformer box will protrude o of the face of the
monopoint.
Covers a standard 4 inch junction box. Use with any powerable connectors.
Extends track from ceiling. Includes track bracket, rod and ceiling canopy.
Use with Rod Coupler (RI) to further extend track from ceiling.
Used when suspension rod is eld cut to custom lengths. One kit of two required
for each rod. Includes two collars
Extends low voltage track heads from track. Specify extension, xture and nish.
Only available as complete unit.
Extends H Track System line voltage track heads.
Western Distribution Center
1750 Archibald Avenue • Ontario, CA 91760
Phone (800) 526.2588 • Fax (800) 526.2585
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. AUG 2014
