NONENCLOSED ELECTRONIC
Transformers
Fixture Type:
Catalog Number:
Project:
Location:
PRODUCT DESCRIPTION
Low Voltage electronic transformer designed to be used as a replacement part for factory installed transformers or installed in a properly listed enclosure.
FEATURES
• 1W minimum load
• All connections must be made in an enclosure for proper installations
• Dimmable with electronic low voltage dimmers. Dimmers should always
be installed on the primary side of the transformer.
ORDER NUMBER
Model Voltage Wattage Min Load L W H Class 2 Auto Reset
EN-1260-R2*
EN-1260-R-AR
EN-1275-R-AR
EN-12100-R-AR
EN-12150-R-AR
*U.L. Listed Class 2 Component
120VAC
120VAC
120VAC
120VAC
120VAC
12VAC 60W
12VAC 60W
12VAC 75W
12VAC 100W
12VAC 150W
1W
1W
1W
1W
1W
2a"
2a"
2a"
32"
32"
1a"
1a"
1a"
12"
12"
SPECIFICATIONS
Construction: Built-in auto reset, soft start, short and overload circuit
protection features. The soft start delayed start feature extends lamp life
by delaying the abrupt inrush current to the lamp.
Output: 12V
Frequency: 20khz
Details: In the case of a system overload or short circuit the transformer
will revert to a “hold” position and then automatically reset the syst
em when the problem is solved. System protection is designed to last
several hours.
Standards: UL recognized component part.
1"
1"
1"
18"
18"
Yes
Yes
No
No
No
Yes
Yes
Yes
Yes
Yes
ACCESSORIES
Model L W H
MTB-01 Multiple Terminal Block
METB Enclosure & Connection Box
waclighting.com
Phone (800) 526.2588
Fax (800) 526.2585
WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. NOV 2015
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
34" 1w" d"
6s" 1s" 18"
Central Distribution Center
1600 Distribution Ct
Lithia Springs, GA 30122
Western Distribution Center
1750 Archibald Avenue
Ontario, CA 91760
