WAC Lighting WAC1218 Specifications

CLASS 2 PLUGIN ELECTRONIC 12V

Transformers

Fixture Type:

Catalog Number:

Project:

Location:

PRODUCT DESCRIPTION

Low Voltage plug-in Class II electronic transformer designed to be used as portable or plug-and-play style transformer. Contains an on/o toggle switch at the
base and a 6’ detachable cord.

FEATURES

• 1W minimum load

• UL listed Class 2 plug-in electronic transformers

• Plug-in power supply with on/o switch and 6' detachable cord

• Class 2 transformers are required for most cabinet listed xtures

ORDER NUMBER

Model Finish Output L W H

EN-1260-P-AR

BK WTBlack

White

12V, 1 x 60W

2w" 1s" 1w"

SPECIFICATIONS

Construction: Built-in auto reset, soft start, short and overload circuit

protection features. The soft start delayed start feature extends lamp life
by delaying the abrupt inrush current to the lamp.

Output: 12V

Frequency: 20khz

Dimming: Dimmable. Consult factory for options.

Details: Inherently protected and power limited, protecting the lighting

system from both normal and abnormal short circuits.

Standards: UL Listed

ACCESSORIES

Multiple Terminal Block

Accommodates up to 6 output connections for 14 AWG wires. Terminal
block is used to easily wire together multiple output connections for a
neat under cabinet installation without the use of open splices. Perfect
for wiring up to 3 button lights at 20W or 6 button lights at 10W.

Model L W H

EN-1260-P-AR-____

Example: EN-1260-P-AR-BK

waclighting.com

Phone [phone]
Fax [phone]

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. NOV 2015

Headquarters/Eastern Distribution Center

44 Harbor Park Drive
Port Washington, NY 11050

MTB-01

Central Distribution Center

1600 Distribution Ct
Lithia Springs, GA 30122

34" 1w" d"
