Page 1
Inverter
FUE 6
0213321en 002
05.2008
Operator's manual
Page 2
Page 3
FUE Contents
3
1 Foreword .................................................................................................................... 5
2 Introduction ...............................................................................................................6
2.1 Means of representation for this operator's manual ........................................... 6
2.2 WACKER representative .................................................................................... 7
2.3 Described machine parts.................................................................................... 7
3 Safety information .................................................................................................... 8
3.1 Principle.............................................................................................................. 8
3.2 Qualification of the operating personnel ........................................................... 10
3.3 Protective gear ................................................................................................. 11
3.4 Transport .......................................................................................................... 11
3.5 Operating safety ............................................................................................... 12
3.6 Safety during the operation of electric appliances............................................ 13
3.7 Maintenance..................................................................................................... 14
3.8 Safety labels..................................................................................................... 15
4 Scope of delivery ....................................................................................................16
5 Description ..............................................................................................................17
5.1 Application........................................................................................................ 17
5.2 Functionality ..................................................................................................... 17
5.3 Components and operator's controls................................................................ 18
6 Transport .................................................................................................................19
7 Operation .................................................................................................................20
7.1 Prior to starting the machine............................................................................. 20
7.2 Starting up ........................................................................................................ 21
7.3 Decomissioning ................................................................................................ 22
8 Maintenance ............................................................................................................23
8.1 Maintenance schedule...................................................................................... 23
8.2 Maintenance work ............................................................................................ 23
9 Troubleshooting ...................................................................................................... 25
10 Disposal ...................................................................................................................26
10.1 Disposal of the machine ................................................................................... 26
11 Accessories ............................................................................................................. 27
Inhalt
Page 4
4
Contents FUE
12 Technical data ......................................................................................................... 28
12.1 FUE 6 ............................................................................................................... 28
12.2 Notes regarding class rating and protection class............................................ 29
12.3 Extension cable ................................................................................................ 30
EC Declaration of Conformity ................................................................................ 31
DIN EN ISO 9001 Certificate ................................................................................... 33
Page 5
Foreword
5
1Foreword
This operator's manual contains information and procedures for the safe operation and maintenance of your WACKER machine. In the interest of your own
safety and to prevent accidents, you should carefully read through the safety information, familiarize yourself with it and observe it at all times.
This operator's manual is not a manual for extensive maintenance and repair
work. Such work should be carried out by WACKER Service or authorized specialists.
The safety of the operator was one of the most important aspects taken into consideration when this machine was designed. Nevertheless, improper use or incorrect maintenance can pose a risk. Please operate and maintain your
WACKER machine in accordance with the instructions in this operator's manual.
Your reward will be troublefree operation and a high degree of availability.
Defective machine parts must be replaced immediately!
Please contact your WACKER representative if you have any questions concerning operation or maintenance.
All rights reserved, especially reproduction and distribution rights.
Copyright 2008 Wacker Construction Equipment AG
No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without the expressed written permission of WACKER.
Any type of reproduction, distribution or storage on data media of any type and
form not authorized by WACKER represents an infringement of copyright and will
be prosecuted.
We expressly reserve the right to make technical modifications – even without
special notice – which aim at further improving our machines or their safety standards.
Page 6
6
Introduction
2 Introduction
2.1 Means of representation for this operator's manual
Warning symbols
This operator's manual contains safety imformation of the categories:
DANGER, WARNING, CAUTION, NOTICE.
They should be followed to prevent danger to life and limb or damage to equipment or improper service.
Notes
Note: Complementary information will be displayed here.
Instructions
f This symbol indicates there is something for you to do.
1. Numbered instructions indicate that you have to carry out something in a defined
sequence.
This symbol is used for lists.
DANGER
This warning notice indicates hazards that result in serious injury or even death.
f Danger can be avoided by the following the actions mentioned.
WARNING
This warning notice indicates hazards that can result in serious injury or even
death.
f Danger can be avoided by the following the actions mentioned.
CAUTION
This warning notice indicates hazards that can result in minor injury.
f Danger can be avoided by the following the actions mentioned.
NOTICE
This warning notice indicates hazards that can result in material damage.
f Danger can be avoided by the following the actions mentioned.
Page 7
Introduction
7
2.2 WACKER representative
Depending on your country, your WACKER representative is your WACKER
Service, your WACKER affiliate or your WACKER dealer.
You can find the addresses in the Internet at www.wackergroup.com.
The addresses of the WACKER main locations are located at the end of this operator's manual.
2.3 Described machine parts
This operator's manual is valid for different machine parts from a product range.
Therefore some figures can differ from the actual appearance of your machine.
It is also possible that the descriptions include components which are not a part
of your machine.
Details for the described machine types can be found in the chapter Technical
Data.
Page 8
8
Safety information FUE 6
3 Safety information
3.1 Principle
State of the art
This machine has been constructed with state-of-the-art technology according to
the recognized rules of safety. Nevertheless, when used improperly, dangers to
the life and limb of the operator or to third persons or damage to the machine or
other materials cannot be excluded.
Proper use
The machine may only be used for the operation of internal and external vibrators.
The machines to be connected must have the appropriate connection specifications (voltage, frequency, phase number).
Its proper use also includes the observance of all instructions contained in this
operator's manual as well as complying with the required service and maintenance instructions.
Any other use is regarded as improper. Any damage resulting from improper use
will void the warranty and the liability on behalf of the manufacturer. The operator
assumes full responsibility.
Structural modifications
Never attempt to modify the machine without the written permission of the manufacturer. To do so will endanger your safety and the safety of other people! In
addition, this will void the warranty and the liability on behalf of the manufacturer.
Requirements for operation
The ability to operate the machine safely requires:
Proper transport, storage and setup.
Careful operation.
Careful service and maintenance.
Operation
Operate the machine only as intended and only when in proper working condition.
Operate the machine in a safety-conscious manner with all safety devices attached and enabled. Do not modify or disable any safety devices.
Before starting operation, check that all control and safety devices are functioning properly.
Never operate the machine in a potentially explosive environment.
Page 9
FUE 6 Safety information
9
Maintenance
Regular maintenance is required in order for the machine to operate properly and
reliably over time. Neglected maintenance work can make the machine dangerous to use.
Strictly observe the prescribed maintenance intervals.
Do not use the machine if it requires maintenance or repairs.
Malfunctions
If you detect a malfunction, you must shut down and secure the machine immediately.
Eliminate the malfunctions that impair safety immediately!
Have damaged or defective components replaced immediately!
For further information, refer to chapter Troubleshooting.
Spare parts, accessories
Only use spare parts and accessories from WACKER. Non-compliance will exempt the manufacturer from all liability.
Exclusion of liability
WACKER will refuse to accept liability for injuries to persons or for damage to
materials in the following cases:
Structural modifications.
Improper use.
Improper handling.
Use of spare parts and accessories not produced by WACKER.
Operator's manual
Always keep the operator's manual near the machine or near the worksite for
quick reference.
If you have misplaced the operator's manual or require an additional copy, contact your WACKER representative or download it from the Internet
(www.wackergroup.com).
Always hand over this operator's manual to other operators or to the future owner
of the machine.
Country-specific regulations
Observe the country-specific regulations, standards and guidelines in reference
to accident prevention and environmental safety, for example those pertaining to
hazardous materials and wearing protective gear.
Complement the operator's manual with additional instructions taking into account the operational, regulatory, national or generally applicable safety guidelines.
Page 10
10
Safety information FUE 6
Operator's controls
Always keep the operator's controls of the machine dry, clean and free of oil or
grease.
The function of the operator's controls must not be manipulated or rendered ineffective.
Cleaning
Always keep the machine clean and be sure to clean it each time you have finished using it.
Do not use gasoline or solvents. Danger of explosion!
Checking for signs of damage
Inspect the machine when it is switched off for any signs of damage at least once
per work shift.
Do not start the machine if there is visible damage or defects.
Have any damage or defects eliminated immediately.
3.2 Qualification of the operating personnel
Operator qualifications
Only trained personnel are permitted to start and operate the machine. The following rules also apply:
You are physically and mentally fit.
You have received instruction on how to independently use the machine.
You have received instruction in the proper use of the machine.
You are familiar with required safety devices.
You are authorized to start machines and systems in accordance with the
standards governing safety.
You have been assigned to work on the machine by your company.
Incorrect operation
Incorrect operation or misuse by untrained personnel can endanger the health
and safety of the operator and also cause machine and material damage.
Operating company responsibilities
The operating company must make the operator's manual available to the operator and ensure that the operator has read and understood it.
Page 11
FUE 6 Safety information
11
Work recommendations
Please observe the recommendations below:
Work only if you are in a good physical condition.
Work attentively, particularly as you finish.
Do not operate the machine when you are tired.
Carry out all work calmly, circumspectly and carefully.
Never operate the machine under the influence of alcohol, drugs or medica-
tion. This can impair your vision, reactions and your judgment.
Work in a manner that does not endanger others.
3.3 Protective gear
Work clothing
Clothing should be appropriate, i.e. should be close-fitting but not restrict your
movement.
When on construction sites, do not wear long hair loosely, loose clothing or jewelry including rings. These objects can easily get caught or be drawn in by moving machine parts.
Personal protective gear
Wear personal protective gear to avoid injuries or health hazards:
Non-skid, hard-toed shoes.
Work gloves made of durable material.
Overalls made of durable material.
Hard hat.
Ear protection.
3.4 Transport
Switching off the machine
Before you transport the machine, switch it off and pull the plug out of the plug
receptacle.
Transporting the machine
Secure the machine on the transport device against tilting, falling or slipping.
Page 12
12
Safety information FUE 6
3.5 Operating safety
Work environment
Familiarize yourself with your work environment before you start work. This includes e.g. the following items:
Obstacles in the work and traffic area.
Load-carrying capacity of the ground.
The measures needed to cordon off the construction site from public traffic.
The measures needed to secure walls and ceilings.
Options available in the event of an accident.
Starting the machine
Observe the safety information and warning notices located on the machine.
Never attempt to switch on a machine that requires maintenance or repairs.
Switch on the machine as directed in the operator's manual.
Avoid body contact with grounded components.
Switching off the machine
Switch off the machine and pull the plug out of the plug receptacle in the following
situations:
Before breaks.
If you are not using the machine.
Store the machine or put it down in such a way that it cannot tilt, fall down or slip.
Storage location
Store the machine after operation at a sealed off, clean and dry location inaccessible to children.
Page 13
FUE 6 Safety information
13
3.6 Safety during the operation of electric appliances
Specific regulations for electrical appliances
Observe the safety information provided in the brochure General Safety Rules
which is included in the scope of delivery of your machine.
Also observe the country-specific regulations, standards and guidelines in reference to accident prevention in connection with electrical equipment and machines.
Electric power supply for electrical appliances of class rating I
Note: The rated voltage is indicated on the nameplate of your machine.
The machine must be connected to a 16 A (1~) shock-proof plug receptacle
(continental type) with a corresponding overload protection.
A standard fault current protective switch (AC sensitive, Type A) is required.
The machine may only be connected to an electric power supply with all machine
parts in proper working condition. Take special notice of the following machine
parts:
Plug.
Power cable over the entire length.
All plug receptacles.
Note: Make sure that the plugs and power cables of the machines to be con-
nected are in proper working condition.
The machine may only be connected to an electric power supply whereby the
connector of the grounded conductor (PE) is intact.
There must be at least one of the following safety devices if connected to a stationary or mobile generator:
Fault current protective switch.
Isolation (earth leakage) monitor.
IT-net.
If you connect your machine to a worksite distribution board, the worksite distribution board must be grounded.
Note: Observe the respective national safety regulations!
Page 14
14
Safety information FUE 6
Extension cable
The machine may only be operated with undamaged extension cables!
Only use extension cables with grounded conductor and correct connection of
the grounded conductor to the plug and coupling (only for machines of class
rating I).
Only use extension cables which are suitable for use at construction sites: Average rubber hose H05RN-F or better – WACKER recommends H07RN-F or a
country-specific equivalent design.
Immediately replace damaged extension cables (e.g. tears in the sheathing) or
loose plugs and couplings.
Protecting the power cable
Do not use the power cable to pull or lift the machine.
Do not unplug the power cable by pulling on the cable.
Protect the power cable from heat, oil and sharp edges.
If the power cable is damaged or the plug is loose, have it replaced immediately
by your WACKER representative.
3.7 Maintenance
Maintenance work
Service and maintenance work must only be carried out to the extent described
in these operating instructions. All other procedures must be performed by your
WACKER representative.
For further information, refer to chapter Maintenance.
Disconnecting the machine from the electric power supply
Before carrying out service or maintenance work, pull the plug out of the plug receptacle in order to disconnect the machine from the electric power supply.
Page 15
FUE 6 Safety information
15
3.8 Safety labels
Your machine has adhesive labels containing the most important instructions
and safety information.
Make sure that all the labels are kept legible.
Replace any missing or illegible labels.
Item Label Description
1 Warning
- Read manual.
- Warning of hot surface.
2 For service personnel: Warning
- Before housing can be opened, disconnect from power!
- Wait 1 minute until capacitors are discharged!
SES
Vor Öffnen des Gehäuses Netzstecker ziehen!
Entladung der Kondensatoren 1 Minute abwarten!
Before housing can be opened, disconnect from power!
Wait 1 minute until capacitors are discharged!
Avant d’enlever le capot debrancher l’apareil!
Attendre 1 minute la decharge du condensateur!
Desconectar antes de abrir la carcasa! Esperar 1
minuto para que los condensadores descarguen!
0201610
Page 16
16
Scope of delivery FUE 6
4 Scope of delivery
The scope of delivery includes:
Machine.
Operator's manual.
Parts book.
General safety instructions.
Page 17
FUE 6 Description
17
5 Description
5.1 Application
The machine may only be used for the operation of internal and external vibrators.
The machine is used to convert the current on the construction site into current
that can be used by the machines to be connected.
5.2 Functionality
Principle
The machine converts the current on the construction site (e.g. 230 V 1~) in order to operate machines with special specifications. Voltage, frequency and
phase number are adjusted during this process.
Machine features
Short-circuit and earth-fault proof.
Shutdown in the case of excess temperature and fault voltage.
Overload current detection.
Protective low voltage provided by safety isolation transformer (applicable to
42 V machines).
Inverter
The inverter comprises a current rectifier and a d.c.-a.c. converter monitored by
an electronic control.
The current rectifier converts the input voltage (AC single phase) to DC voltage.
The d.c.-a.c. converter converts the generated DC voltage to three phase current
(AC three phase).
When the machine is switched on, the control electronics provides a soft start
and thus prevents critical starting currents.
Page 18
18
Description FUE 6
5.3 Components and operator's controls
Status LED
If the machine is correctly connected, the status LED lights green.
In the case of different indications, a fault has occurred, see Chapter Trouble-
shooting.
Thumbwheel for frequency adjustment for FUE6 ... SC
Use the thumbwheel to adjust the output frequency of the machine and, as a result, affect the speed of the connected machines.
Item Designation Item Designation
1 Ventilation slots 5 Status LED
2 Protective frame 6 Plug receptacle with protective
cover (3 pieces)
3 Power cable (not shown) 7 ON/OFF switch
4 Lifting strap 8 Thumbwheel for frequency ad-
justment (only FUE6 ... SC)
Page 19
FUE 6 Transport
19
6Transport
Transporting the machine
1. Switch off the machine via the ON/OFF switch.
2. Pull the plug from the plug receptacle.
3. Disconnect all connected machines from the inverter.
4. Wind up the power cable.
5. Set the machine on or into a suitable transport vehicle.
Note: Do not place the machine on the side where the plug receptacle is located.
6. Fasten the machine to the protective frame.
WARNING
Improper handling can result in injury or serious material damage.
f Read and follow all safety instructions of this operator's manual, see chapter
Safety information.
Page 20
20
Operation FUE 6
7 Operation
7.1 Prior to starting the machine
After unpacking, the machine is ready for operation.
Plug
The machine comes with a country-specific plug as a standard equipment.
Checking the machine
f Check the machine and all components for damages.
Checking the mains
f Check if mains or power distribution on the construction site have the correct
operating voltage (see nameplate of the machine or chapter Technical Data).
f Check if mains or power distribution on the constructions site are protected
in accordance with current standards and regulations.
Connecting internal or external vibrators
Applicable to inverters with frequency adjustment:
f During the operation of internal vibrators, set the thumbwheel to the maxi-
mum output frequency (highest number must be visible).
f During operation of external vibrators, use the thumbwheel to search the re-
quired output frequency.
The output frequency affects the speed of the connected machines.
WARNING
Improper handling can result in injury or serious material damage.
f Read and follow all safety instructions of this operator's manual, see chapter
Safety information.
0212683
Page 21
FUE 6 Operation
21
7.2 Starting up
Connecting the machine to the power supply
The machine may only be connected to AC single phase, connection values see
chapter Technical Data.
1. Switch off the inverter via the ON/OFF switch.
2. Switch off all connected machines via the respective equipment switch.
3. If required, connect the machine to a permitted extension cable.
Note: See chapter Technical data for the permitted lengths and cross-section
areas of extension cables.
4. Insert the plug into the plug receptacle.
WARNING
A damaged machine part or power cable can result in personal injury caused by
electric current.
f Do not operate a damaged machine!
f Have a damaged machine repaired immediately.
NOTICE
Electrical voltage.
Incorrect voltage can cause damage on the machine.
f Check if the voltage of the current source corresponds with the information
of the machine, see chapter Technical Data.
WARNING
Starting the connected machines.
Danger of injuries from uncontrolled starting of the machines.
f Deactivate all connected machines before connection to the electric power
supply.
WARNING
Electrical voltage.
Injuries from electrocution.
f Check power cable and extension cable for signs of damage.
f Only use extension cables for which grounded conductors are connected to
the plug and the coupling (only for machines of class rating I).
Page 22
22
Operation FUE 6
Switching on the machine
f Switch on the inverter via the ON/OFF switch.
If the machine is ready for operation, the status LED lights green.
7.3 Decomissioning
Switching off the machine
1. Switch off all connected machines via the respective equipment switch.
2. Switch off the inverter via the ON/OFF switch.
3. Pull the plug from the plug receptacle.
4. Disconnect all connected machines from the inverter.
5. Wind up the power cable.
Page 23
FUE 6 Maintenance
23
8 Maintenance
8.1 Maintenance schedule
Note: The time intervals mentioned here are reference values for normal op-
eration. For extreme operation, e.g. continuous use, the service intervals should be halved.
8.2 Maintenance work
Visual inspection for damage
f Check all machine parts and components for damage.
Have damages repaired by your WACKER representative.
WARNING
Improper handling can result in injury or serious material damage.
f Read and follow all safety instructions of this operator's manual, see chapter
Safety information.
Tas k Daily be-
fore operation
After operation
Visual inspection of all parts
for damage:
- Housing.
- Power cable.
- Lifting strap.
- Plug receptacle.
- ON/OFF switch.
Cleaning.
WARNING
A damaged machine part or power cable can result in personal injury caused by
electric current.
f Do not operate a damaged machine.
f Have a damaged machine repaired immediately.
Page 24
24
Maintenance FUE 6
Cleaning the machine
Note: Do not clean the machine with high pressure washers or steam jet
cleaners!
1. Clean the ventilation slots with a suitable tool.
2. Wipe the housing with a damp and clean cloth.
3. Clean the thumbwheel (applicable to inverters with frequency adjustment).
Page 25
FUE 6 Troubleshooting
25
9 Troubleshooting
Please refer to the following tables if the machine does not work properly. They
contain potential faults, their causes and remedies.
An LED makes troubleshooting easier.
Malfunction Cause Remedy
Inverter in operation.
LED lights red and green.
- Excessive current consumption of connected machines.
- Inverter operates within the
permissible overload range.
Reduce the current consumption of the connected machines.
Inverter not in operation.
LED lights red.
- Input voltage too high
(> 275 V) or too low
(< 155 V).
- Fluctuating input voltage.
Inverter starts automatically as
soon as the correct line voltage
is available (again).
Inverter not in operation.
LED flashes red.
- Short circuit in one of the
connected machines.
- 2-phase operation* in one of
the connected machines.
- Mechanical defect in one of
the connected machines.
* 2-phase operation: The connected machine only uses 2 phases for current intake. Therefore, the en-
gine does not turn. The connected machine hums and heats up quickly due to the high current consumption.
1. Carry out a reset:
Switch off the inverter and
switch it on again.
2. Disconnect the connected
machines and check them.
3. Repeat reset.
Short circuit in inverter. 1. Disconnect connected ma-
chines.
2. Carry out a reset:
Switch off the inverter and
switch it on again.
3. If the error persists, have the
inverter repaired. **
** Have the machine repaired by your WACKER representative.
Inverter not in operation.
LED flashes red twice.
Inverter has switched off due to
excess temperature (> 85 °C).
1. Allow the inverter to cool
down while the ventilator is
running.
Do not switch off the inverter!
2. Carry out a reset:
Switch off the inverter and
switch it on again.
Reduce the current consumption of the connected machines.
Thumbwheel jammed. Thumbwheel dirty. Remove dirt.
No air escapes from the ventilator outlet.
- Ventilator turns too slowly.
- Ventilator does not turn.
Have the ventilator repaired. **
Page 26
26
Disposal FUE 6
10 Disposal
10.1 Disposal of the machine
Your machine contains many valuable raw materials which should be disposed
and recycled in an environmentally friendly manner.
During disposal of the machine observe the country-specific rules and regulations, e.g. the European Directive for obsolete electrical and electronic devices.
Do not dispose of the machine in household rubbish. It
must be disposed at a recycling facility.
Page 27
FUE 6 Accessories
27
11 Accessories
The machine is available with a multiple plug receptacle for the connection of
2 external vibrators.
For more information on accessories, visit the following website:
www.wackergroup.com.
Page 28
28
Technical data FUE 6
12 Technical data
12.1 FUE 6
Designation Unit FUE 6/042/200W FUE 6/042/200W
SC
Item no. 0610176 0610084
Length x Width x Height mm (in) 524 x 325 x 325
(20.7 x 12.8 x 12.8)
Weight kg (lb) 32.5 (71.7)
Input rated voltage V 220-240 1~
Input rated frequency Hz 50
Input rated current A 14.8
Nominal input power kVA 3.4
Rated output voltage V 42 3~
Rated output frequency Hz 200 0-200
Rated output current
A52
Rated output power
kVA/kW 3.7/3.0
Class rating *
* According to DIN EN 61140, description see 12.2 Notes regarding class rating and
protection class (page 29).
I
Protection class **
** According to DIN EN 60529, description see 12.2 Notes regarding class rating and
protection class (page 29).
IP 44
Mains cable 2 m with shock-proof plug
Number of CEE plug
receptacles
3 x 32 A / 42 V
Sound pressure level L
pA
at op-
erator's station ***
*** According to ISO 11201
dB(A) 70
Page 29
FUE 6 Technical data
29
12.2 Notes regarding class rating and protection class
Class rating
The class rating according to DIN EN 61140 specifies the safety measures for
electrical equipment to avoid electrocution. There are four class ratings:
Protection class IP
The protection class according to DIN EN 60529 indicates the suitability of electrical equipment for use in certain ambient conditions as well as the protection
against risks.
The protection class is specified by an IP code according to DIN EN 60529.
Class rating Meaning
0 No special protection apart from the basic insulation.
No grounded conductor.
Plug connection without grounded conductor contact.
I Connection of all conductive housing components to the
grounded conductor.
Plug connection with grounded conductor contact.
II Reinforced or double insulation (protective insulation).
No connection to the grounded conductor.
Plug connection without grounded conductor contact.
III Equipment is operated on protective low voltage
(< 50 V).
Connection to the grounded conductor is not necessary.
Plug connection without grounded conductor contact.
Code Meaning
IP Code letter International Protection
4 1st code number for protection from contact and foreign bodies:
Protected against touch with a wire (diameter > 1 mm (0.04 in)).
Protected against granular foreign objects (diameter > 1 mm (0.04 in)).
4 2nd code number for protection from water and moisture:
Protected against spraying water from all directions.
Page 30
30
Technical data FUE 6
12.3 Extension cable
A permitted extension cable must fulfill the following criteria:
The extension cable must be undamaged.
The extension cable has to be connected correctly on plug and bushing.
The extension cable has to be suitable for use at construction sites: Average
rubber hose H05RN-F or better – WACKER recommends H07RN-F or a
country-specific equivalent design.
The extension cable must have been checked by a qualified electrician.
The required cross-section area of a designated extension has been taken
from the table below.
Note: Refer to the nameplate or the chapter Technical data (via the item
number) for the type designation and voltage rating of your machine.
Extension cable for the US market:
Example
You utilize a FUE 6/042/200W and want to use an extension cable with a length
of 45 m (148 ft).
The machine has an input voltage of 230 V.
According to the table, the extension cable must feature a cross-section area of
2.5 mm
2
(AWG 12).
Machine Voltage
[V]
Extension
[m]
Cross-section
area of cable
[mm
2
]
FUE 6 220-240 < 41 1.5
< 67 2.5
< 107 4.0
Machine Voltage
[V]
Extension
[ft]
Cross-section
area of cable
[AWG]
FUE 6 220-240 < 184 14
< 292 12
< 459 10
Page 31
EC Declaration of Conformity
Wacker Construction Equipment AG, Preußenstraße 41, 80809 München certifies that the
construction machines:
Category
Inverter
fulfill the requirements of the following directives:
2004/108/EC
EN 61000
2006/95/EC
Typ e FUE 6/042/200W FUE 6/042/200W SC
Machine type number 0610176 0610084
Dr. Fischer
Head of Research and Development
Beierlein
Head of product management
Page 32
Page 33
Prüf- und Zertifizierungsinstitut
VERBAND DER ELEKTROTECHNIK
ELEKTRONIK INFORMATIONSTECHNIK e.V.
C E R T I F I C A T E
Registration-Number: 6236/QM/06.97
This is to certify that the company
Wacker Construction Equipment AG
Wacker-Werke GmbH & Co. KG
at the following locations
Head Office Munich
Preußenstraße 41
80809 Munich
Production plant Reichertshofen
Karlsfeld logistics centre
Sales regions with all branches all over Germany
has implemented and maintains a
Qality Management System for the following scope:
Machine manufacture
Construction machines
This Q System complies with the requirements of
DIN EN ISO 9001:2000
and the requirements of the German and international Road Traffic Act.
This Certificate is valid until 2009-06-05.
VDE Testing and Certification Institute
Certification
Date: 2006-05-30
63069 Offenbach, Merianstraße 28
Telefon: +49 (0) 69 83 06-0, Telefax: +49 (0) 69 83 06-555
E-Mail: vde-institut@vde.com
, http://www.vde-institut.com
The VDE Testing and Certification Institute is accredited by DAR Accreditation
Bodies according to DIN EN ISO 17020 and DIN EN ISO 45012 and notified in the EU
under ID.No. 0366.
TGA-ZM-09-92-00
KBA-ZM-A 00021-97
DIN EN ISO 9001 Certificate
Page 34
Wacker Construction Equipment AG, Preußenstraße 41, 80809 München – Deutschland – Tel.: +49-(0)89-354 02-0 – Fax: +49-(0)89-354 02-390
Wacker Corporation – P.O. Box 9007 – Menomonee Falls, WI 53052-9007 – USA – Tel.: +1(1)262-255-0500 – Fax: +1(1)262-255-0550 – Support: 800-770-0957
Wacker Machinery (HK) Ltd.– Skyline Tower, Suite 2303, 23/F – 39 Wang Kwong Road, Kowloon Bay – Hong Kong – Tel.: +852-3188-5506, Fax: +852-2406-6021
Page 35
