Operating instructions
Adora TSL WP
Tumble dryer
Thank you for choosing to buy one of our products. Your appliance is made to
high standards and is easy to use. Nevertheless, please take the time to read
these operating instructions in order to familiarize yourself with the appliance
and get the best use out of it.
Please follow the safety precautions.
Modifications
Text, diagrams and data correspond to the technical standard of the appliance
at the time these operating instructions went to press. The right to make technical modifications for the purpose of the further development of the appliance
is reserved.
Validity
The product family (model number) corresponds to the first alphanumerics on
the identification plate. These operating instructions apply to:
Model Type Product range
Adora TSL WP WT-ATSLWP 12003
Variations depending on the model are noted in the text.
© V-ZUG Ltd, CH-6301 Zug, 2015
2
Contents
1 Safety precautions 5
1.1 Symbols used..............................................................................................5
1.2 General safety precautions.......................................................................6
1.3 Appliance-specific safety precautions ....................................................7
1.4 Instructions for use.....................................................................................9
2 Disposal 12
3 Using for the first time 13
3.1 Note ............................................................................................................13
3.2 Function description ................................................................................13
3.3 Selecting language for the function test..............................................14
3.4 Starting the function test.........................................................................14
3.5 Selecting language for the display .......................................................16
3.6 Where is the identification plate? ..........................................................16
4 Appliance description 17
4.1 Appliance overview..................................................................................17
4.2 Appliance construction ...........................................................................18
4.3 Operating and display elements ...........................................................19
5 Programme overview 21
5.1 Programme sequence for the automatic programmes ....................21
5.2 Automatic programmes ..........................................................................22
5.3 Standard programme ..............................................................................23
5.4 Fabric types...............................................................................................23
5.5 Additional functions .................................................................................26
5.6 Favourites .................................................................................................27
6 User settings 30
6.1 Adjusting user settings............................................................................30
6.2 Language...................................................................................................32
6.3 Childproof lock .........................................................................................33
6.4 Level of dryness .......................................................................................34
6.5 Brightness..................................................................................................35
6.6 ReversePlus ..............................................................................................36
6.7 Standard mode.........................................................................................37
6.8 Button tone................................................................................................38
6.9 Restoring factory settings.......................................................................39
7 Drying 40
7.1 Preparing the appliance..........................................................................40
3
7.2 Loading the appliance.............................................................................40
7.3 Selecting a programme ..........................................................................41
7.4 Changing selection..................................................................................44
7.5 Interrupting a programme.......................................................................45
7.6 Aborting a programme before time......................................................45
7.7 Programme selection with childproof lock activated .......................46
7.8 End of programme .................................................................................48
8 Care and maintenance 49
8.1 Cleaning intervals.....................................................................................49
8.2 Error message A9, Clean filter and mats............................................50
8.3 Build-up of fluff..........................................................................................50
8.4 Cleaning the door filter............................................................................51
8.5 Basic cleaning of the door filter including mat...................................51
8.6 Cleaning the front mat.............................................................................53
8.7 Moisture sensor........................................................................................54
9 Trouble-shooting 55
9.1 What to do if ... .........................................................................................55
10 Drying tips 61
10.1 Fabric care symbols................................................................................61
10.2 General tips...............................................................................................61
10.3 Energy-saving tips....................................................................................62
11 Spare parts 63
12 Technical data 64
12.1 Consumption values................................................................................65
12.2 Note for testing institutes........................................................................67
12.3 Automatic energy-saving stand-by........................................................67
13 Index 68
14 Service & Support 71
4
1 Safety precautions
1.1 Symbols used
Caution, risk of fire!
Denotes important safety precautions.
Failure to observe said precautions can result in injury or in damage
to the appliance or fittings!
Information and precautions that should be observed.
Information on disposal
Information about the operating instructions
► Indicates step-by-step instructions.
– Describes how the appliance reacts to the steps taken.
• Indicates a list.
5
1 Safety precautions
1.2 General safety precautions
• Read the operating instructions before using the appliance for
the first time!
• This appliance can be used by children aged 8 and above
and by persons with reduced physical, sensory or mental capabilities, or lack of experience and/or knowledge, provided
they are supervised or have been instructed on the safe use
of the appliance and have understood the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be undertaken by children without supervision.
• If an appliance is not equipped with a mains cable and a plug
or other means for disconnecting from the mains with a contact opening on each pole complying with the conditions of
overvoltage category III for full isolation, an isolating device
must be incorporated into the permanently installed electrical
installation in accordance with the installation regulations.
• If the mains cable of this appliance is damaged, it must be replaced by the manufacturer or its Customer Services or a similarly qualified person in order to avoid hazard.
6
1 Safety precautions
1.3 Appliance-specific safety precautions
• Children under 3 years of age must be kept away from the
appliance unless they are constantly supervised.
• The appliance has a maximum dry load capacity of 7 kg.
• This appliance is only suitable for drying textiles which have
been washed in water.
• The appliance is only to be used with the recommended vaporizing medium. The use of other substances may give rise
to a toxic or fire risk.
• The appliance has hot surfaces to evaporate active components. These surfaces should not be touched during use.
• The tumble dryer may not be used if industrial chemicals were
used for cleaning.
• Clean the fluff filters regularly.
• Do not allow fluff to build up around the tumble dryer.
• Do not dry unwashed items in the tumble dryer.
• Textiles that have been cleaned, treated or soaked with flam-
mable chemicals, detergents or solvents (such as white spirit,
alcohol, stain remover, oil, turpentine, acetone, paint, wax,
etc.) are a fire and explosion hazard! Wash materials containing such substances first by hand with water or allow the
solvent to evaporate completely.
• Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble
dryer.
• Do not use a fabric conditioner or other fabric care solutions
in the wash. Otherwise pay attention to the manufacturer's instructions.
7
1 Safety precautions
• Remove objects such as lighters and matches and the like.
• Never stop a tumble dryer before the end of the drying cycle
unless all items are quickly removed and spread out so that
the heat is dissipated.
• If the appliance is installed on a carpeted floor ensure that
any ventilation openings on the base of the appliance are not
obstructed.
• If the appliance is installed in a housing, the ventilation openings are to be kept free of obstruction.
• Exhaust air must not be discharged into a flue which is used
for exhausting fumes from appliances burning gas or other
fuels.
• Do not install the appliance behind a door that locks, a sliding
door or a door with a hinge that lies opposite the hinge of the
appliance.
To minimize the risk of fire in a tumble dryer, the following should be observed:
• Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The items
become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling, stacking or storing oilaffected items can prevent heat from escaping and so create
a fire hazard. If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair
care products be placed in a tumble dryer they should first be
washed in hot water with extra detergent – this will reduce,
but not eliminate, the hazard.
8
1 Safety precautions
1.4 Instructions for use
Before using for the first time
• The appliance must be installed and connected to the electricity supply in
accordance with the separate installation instructions. Have a qualified fitter/
electrician carry out the necessary work.
• Ensure access to the place of disconnection (e.g. socket outlet, wall switch,
fuse) and the water tap.
Correct use
• The appliance is only suitable for drying home textiles. It is designed for use
in the home and for the above-mentioned purpose only. No liability is assumed for any damage caused by improper or incorrect use.
• Any repairs, modifications or manipulations to the appliance, especially any
electrically live parts, may only be carried out by the manufacturer, its Customer Services or a similarly qualified person. Repairs if carried out incorrectly could cause serious injury or damage to the appliance and fittings as
well as affect the functioning of the appliance. If the appliance is not working properly or in case of a repair order, follow the instructions given in the
'Repair service' section. If necessary, please contact our Customer Services.
• Use original spare parts only.
• Before closing the appliance door and starting a programme, ensure that
there are no foreign objects or pets in the drum.
Note on use
• If the appliance is not operating properly, disconnect it from the power supply immediately.
• To protect your washing, follow the fabric care symbols and the hints and
advice in the 'Drying tips' section.
• Do not use a fabric conditioner or other fabric care solutions in the wash.
Otherwise pay attention to the manufacturer's instructions.
• Do not operate the appliance without a door filter or with a damaged door
filter. Fluff can destroy the appliance!
9
1 Safety precautions
Caution: Burns hazard!
• Do not dry fabrics that contain traces of hair spray, hair gel, nail varnish remover or other similar substances. Danger of gas build-up!
Caution: Risk to life!
• Packaging material, e.g. plastic film and polystyrene, can be dangerous for
children. Danger of suffocation! Keep packaging material away from children.
10
1 Safety precautions
Fron
t
Front
Front Back
Front,
upside down Side
How to avoid damaging the appliance
• Transport the appliance in an upright position only! Transporting it in any
other position will result in damage to the appliance! When carried carefully
without being shaken, the appliance may be tilted a maximum of 90° to the
left (viewed from the front).
• Close the appliance door carefully.
• When cleaning the appliance make sure no water gets inside it. Use a mod-
erately damp cloth. Do not spray the outside or the inside of the appliance
with water. If water gets inside the appliance, it will cause damage.
11
2 Disposal
Packaging
• All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS))
are marked and should, if possible, be collected for recycling and disposed
of in an environmentally friendly way.
Disconnection
• Disconnect the appliance from the mains. With a fixed appliance, this is to
be carried out by a qualified electrician!
Safety
• Disable the appliance to prevent accidents caused by improper use, especially through children playing.
• Pull the plug out of the mains socket or have the appliance disconnected
from the mains by an electrician. Then cut the mains cable off flush with the
appliance.
• Remove or disable the lock on the appliance door.
Disposal
• The old appliance should not be discarded as worthless rubbish. If disposed of correctly, the raw materials can be recovered for recycling.
• The symbol on the identification plate warns that the appliance may not
be disposed of in normal household waste.
• The appliance must be disposed of in accordance with local regulations on
waste disposal. For more information on the handling, disposal and recycling of the product, please contact the local authorities, the local recycling
facilities for household waste or the retailer from whom you purchased the
appliance.
Note on heat pump
This appliance is CFC-free (the cold circuit contains R134a).
12
3 Using for the first time
3.1 Note
The appliance can only be operated after standing in the normal operating position for about 2 hours.
The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work.
3.2 Function description
The function test must not be confused with the definitive initial use.
See installation instructions: TL WP J12001 or TS WP/TSL WP
J12002.
When the appliance is connected to the power supply for the first time, it is
possible to select a function test. The purpose of the function test is to check
the installation. It takes about 3 minutes. The function test can be selected immediately after installation. The heat pump is not started during the function
test. Before the definitive initial start-up of the appliance, it must stand in the
normal operating position for around 2 hours, otherwise the heat pump could
become damaged.
The function test cannot be aborted by interrupting the power supply.
Once the function test has been run or aborted, it can no longer be
selected and the appliance enters the normal selection mode.
13
3 Using for the first time
German
fr/it/rm/... OK
English
it/rm/en...
OK
Start function test?
NO: YES:
Function test 0h03
Pause function test
Close appliance door
Continue function test?
NO: YES:
Continue function test?
NO: YES:
3.3 Selecting language for the function test
► Connect the appliance to the mains and
wait for the following to appear in the display:
Press «OK» to confirm language selection:
► Press the button.
Changing the language:
► Press the button repeatedly until the
required language appears in the display, e.g.:
► Press the button.
– The setting is accepted and in the
display appears:
3.4 Starting the function test
► Press the button.
The function test can be interrupted in two ways:
1. Open the appliance door.
– In the display appears:
– After closing the appliance door,
in the display appears:
or:
2.
Press the button.
– In the display appears:
Continuing the function test «continue»:
14
3 Using for the first time
Function test 0h01
Function test
aborted
Function test complete
► Press the button.
– The remaining duration of the func-
tion test appears in the display, e.g.:
Aborting the function test «abort»:
► Press the button.
– The function test is aborted and in
the display appears:
• The display goes out automatically after
15 seconds or after taking the following
action:
End of function test:
– Once the function test is completed,
the following appears in the display:
• The display goes out automatically after
30minutes or after the following action:
► Open the appliance door or press the
button.
Before the appliance is ready to operate, the user language must be
selected once – see «Selecting language for the display».
15
3 Using for the first time
English
fr/it/rm/... OK
Select programme
1
3.5 Selecting language for the display
On initial use, the language must be selected once. It can be changed at any
time under 'User settings'.
► Press the button repeatedly until the
desired language appears in the display,
e.g.:
► Press the button to confirm the lan-
guage selection.
– The setting is accepted.
3.6 Where is the identification plate?
Identification plate with serial number (FN)
1
Note down the serial number (FN) of your appliance on the back page of
these operating instructions.
16
4 Appliance description
4.1 Appliance overview
The appliance operates with a closed air circuit. Moisture is extracted from the
air with the help of a heat pump and then the air is reheated. Recovering heat
in this way sharply reduces energy consumption.
Thanks to the heat pump, the appliance dries at lower temperatures.
All the programmes are therefore gentler on your laundry. The condensate water collected is discharged through an outlet at the rear into the drainage system.
As a general rule, rooms containing a heat pump dryer must be ventilated as
these produce some humidity. If the room is kept closed, it should be aired
occasionally (either by opening the door to the room or a window) between
several consecutive drying programmes.
• Load capacity: 7 kg dry washing
• 5 automatic programmes
• 3 favourite programmes
• Timed drying
• Programme for fabric types:
– WetClean fin-
ish
– Airing – Outdoor garments – Hygiene
– Silks – Denim – Towelling
– Fluffing – Baby garments – Basket programme*
– Crease guard
* The basket can be ordered as an accessory.
– Shirts – Thick/thin down
filling
17
4 Appliance description
1
1
6
5
7
8
23
4
• Additional functions:
– Eco – Ultra care – SilentPlus
– Sprint – ReversePlus – Delayed start
– Easy care
• Crease guard at end of pro-
gramme
• Plain text display • Electric door opener
• Language selection • Automatic energy-saving stand-by
• Childproof lock
4.2 Appliance construction
The appliance door can be set to open to the left or to the right. Our
Customer Services can make the necessary adjustments to the appliance.
Operating and display elements
1
(pivoting operating panel)
Appliance door
2
Cover for door filter
3
Door filter with mat
4
Front grille
5
Front mat
6
Ventilation grille
7
8
Identification plate / serial number
(FN)
18
4 Appliance description
+
*
*
4.3 Operating and display elements
* Depending on the serial number (FN)
Display (plain text display)
Various information appears in the display during the programme selection
and the programme sequence:
• Programme name with duration
• Moisture level with duration remaining
• Additional functions
• Delayed start
• User settings
• Hints and trouble-shooting
Automatic programmes
Extra dry Iron dry Woollens
Normal dry* Damp Fabric types
Normal dry / standard programme* Favourites
Additional programme
Timed drying
19
4 Appliance description
+
Additional functions
Eco / standard programme*
or*
Eco*
Ultra care Delayed start
ReversePlus End of pro-
gramme
Sprint SilentPlus Door opener
Easy care
* Depending on the serial number (FN)
Indicator lights
The buttons for the automatic programmes, the additional programme and the
additional functions are equipped with an indicator light.
Indicator light flashes
Programme or function can be selected.
Indicator light is illuminated
Programme or function is active.
Indicator light is dark
Programme or function is switched off.
20
5 Programme overview
5.1 Programme sequence for the automatic programmes
The drying programme has 3 phases:
Drying
The washing is tumble dried until it reaches the set level of dryness. The drying programme is monitored by a moisture sensor. As soon as the required
level of dryness is reached, the «Cooling down/Airing» phase starts.
Cooling down/Airing
The washing is cooled down to a temperature at which the risk of creasing is
minimized.
This phase lasts between 1–10 minutes. Afterwards the washing can be unloaded.
«Crease guard» starts if the appliance is not unloaded.
Crease guard
The dried washing is moved at frequent intervals to prevent creasing.
If the additional «Ultra care» function has been selected, «Crease guard» runs
90 minutes; with all other programmes it runs 30 minutes. «Crease guard» can
be stopped at any time by opening the appliance door or by pressing the
button.
21
5 Programme overview
5.2 Automatic programmes
To select the right programme, follow the fabric care symbols on the
labels of the wash items, e.g. .
Extra dry
For thick, multi-layered fabrics and mixed loads.
Not suitable for knitted or woven articles such as T-shirts and under-
wear as they could shrink.
* Depending on the serial number (FN)
Normal dry*
or*
For similar items of washing (e.g. t-shirts or underwear).
Iron dry
For items that are to be ironed.
Damp
For items that are to be pressed in a mangle (e.g. table linen).
1–7 kg
1–7 kg
1–7 kg
1–7 kg
22
Timed drying
For drying off textiles. Also for drying suitable sleeping bags and
quilts, and any individual items of washing.
1–7 kg
5 Programme overview
+
Woollens
For woollen fabrics labelled as washable. Gentle drying through a
gentle drum action and a low temperature (approx. 45°C).
Favourites
3 programmes that can be freely put together and saved ( ).
5.3 Standard programme
Normal dry Eco
The standard cotton programme to which the information in the label
and the fiche relates. This programme is suitable for drying normal
wet cotton laundry and is the most efficient programme in terms of
energy consumption for cotton laundry.
5.4 Fabric types
1 kg
1–7 kg
Use the button to select one of the following fabric types.
WetClean finish
For loosening up delicate fabrics (unload immediately after programme finishes).
Airing
For refreshing or airing little-worn garments.
1kg
1–1.5 kg
23
5 Programme overview
Silks
1–1.5 kg
For drying silk fabrics. Follow the fabric care labels as silk tends to
crease easily. Low temperature for gentle drying.
Fluffing
1 kg
Brings the bounce back to woollen textiles. Unload as soon as the
programme ends.
The textiles are not dried!
Crease guard
1 kg
Creases that come from spinning are reduced (e.g. shirts, blouses).
The laundry is ready for ironing.
Shirts
1–7 items
Fabrics are gently dried to «cupboard dry».
Outdoor garments
1–3 kg
Leisure- and sportswear (sympatex, goretex, ...) are dried gently.
24
Denim
1–4 kg
Denim fabrics are dried to «cupboard dry». Follow the fabric care labels as denim material can shrink.
Baby garments
1–7 kg
Baby garments are gently dried to «cupboard dry». The washing is
dried hygienically through an extended drying phase.
5 Programme overview
Thin down filling
1–2 kg
For light-weight down textiles (e.g. thin duvets and jackets).
Optimum wash load: 1 item
Thick down filling
1–2 kg
For bulky down textiles (e.g. pillows, jackets and thick duvets).
If recommended, tennis balls can be used for fluffing up the down
during drying.
Optimum wash load: 1 item
Hygiene
1–3 kg
The washing is dried hygienically through an extended drying phase.
Ensures all germs are killed. Use for non-delicate fabrics only.
Towelling
1–3 kg
For drying thick towels and terry towelling.
Basket programme
For drying clean canvas shoes/trainers and small items such as
gloves, hats and soft toys in the basket*.
* The basket can be ordered as an accessory.
Always use the basket with the basket programme. This programme is
not suitable for leather or synthetic leather shoes.
25
5 Programme overview
5.5 Additional functions
Eco*
Most energy-efficient drying for all textiles.
or*
Energy saving: up to 13%
* Depending on the serial number (FN)
Sprint
Quickest drying for less delicate fabrics.
Time saving: up to 25minutes
Easy care
Gentle drying for mixed fabrics (e.g. shirts, pullovers and T-shirts).
The level of dryness is reduced.
Optimum wash load: 1–2.5 kg
Ultra care
26
Very gentle programme with reduced temperature. Particularly suitable
for fine textiles.
Optimum wash load: 1–2.5 kg
5 Programme overview
+
Define favourite
1
Normal dry 1h55
1
YES: NO:
save changes?
ReversePlus
By additionally reversing the direction of spin of the drum against the
main direction, the washing dries more evenly and is less likely to get
tangled.
SilentPlus
Particularly quiet programme.
Delayed start
Take advantage of cheap-rate electricity (setting range of up to 24
hours).
During shut-off periods – determined by the local electricity supplier –
the delayed start time is extended by the length of time the electricity
is shut off. This is not shown in the display.
5.6 Favourites
Simplifies selecting frequently used programmes. You can compile
your own favourites. Favourites are easy to start.
• A maximum of 3 favourites can be saved.
The appliance door has to be open to define, change or delete a favourite.
Defining your favourites
► Open the appliance door.
► Press the button.
► Press the button again.
► Select the desired automatic programme,
additional programmes and additional
functions, e.g.:
► Press the button.
27
5 Programme overview
1
Normal dry 1h55
1
Normal dry 1h55
1
Normal dry 1h55
1
Extra dry 2h30
1
YES: NO:
save changes?
1
Extra dry 2h30
Save favourite:
«YES»:
► Press the button.
– The changes are saved.
«NO»:
► Press the button.
– The changes are not
saved.
Starting your favourite
► Close the appliance door.
► Press the button repeatedly until the
desired favourite appears in the display,
e.g.:
– The programme starts automatically
after 20seconds.
Changing your favourite
► Open the appliance door.
► Press the button repeatedly until the
desired favourite appears in the display,
e.g.:
► To change favourites: Select new auto-
matic programme, additional programmes
and additional functions, e.g.:
► Press the button.
Save changes:
«YES»:
► Press the button.
– The changes are saved.
28
5 Programme overview
1
Normal dry 1h55
1
Normal dry 1h55
1
YES: NO:
Clear?
1
Normal dry 1h55
«NO»:
► Press the button.
– The changes are not
saved.
Deleting a favourite
► Open the appliance door.
► Press the button repeatedly until the
favourite to be deleted appears in the display, e.g.:
► Hold the button depressed for about 3
seconds.
Delete a favourite:
«YES»:
► Press the button.
– The favourite is deleted.
«NO»:
► Press the button.
– The favourite remains
saved.
29
6 User settings
User settings
FN XXXXX XXXXXX
Childproof lock
OFF
Childproof lock
ON
6.1 Adjusting user settings
Providing no programme is running and no error message is displayed, the
user settings can be changed with the appliance door open or closed. The
procedure is generally the same for all settings.
Changing user settings
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
required setting appears in the display,
e.g.:
► To change, press the button.
– The setting is taken over automatic-
ally and must not be confirmed.
Exiting user settings
► Press the button repeatedly until the display goes out.
If no button is pressed within the next 20seconds, user settings is exited and the display goes out.
30
6 User settings
Hold the button depressed for 5 seconds
Text in Deutsch
Texte en français
Testo in italiano
Text in English
…
1 very low drying
2 low drying
3 normal drying *
4 strong drying
5 sery strong drying
OFF *
ON
1 very dark
2 dark
3 medium *
4 bright
5 very bright
YES
NO
* Factory setting
OFF *
ON
No additional function *
SilentPlus
Sprint
Eco
OFF
ON *
Childproof lock
OFF
Brightness
3
Factory settings
restore?
User settings
FN XXXXX XXXXXX
Language D/F/I/R/E
English
Level of dryness
3
ReversePlus
OFF
Standard mode
No additional function
Button tone
ON
Possible user settings
The following diagram gives an overview of the possible user settings.
31
6 User settings
User settings
FN XXXXX XXXXXX
D/F/I/R/E
English
Language
Language
D/F/I/R/E
English
6.2 Language
On initial use, the language in the display is selected under «Selecting language for the display». It can be changed at any time, as described in this
section.
Changing the language
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
current language appears in the display,
e.g.:
► Press the button repeatedly until the
required setting appears in the display,
e.g.:
– The setting is taken over automatically
and must not be confirmed.
► Press the button repeatedly until the
display goes out.
32
6 User settings
User settings
FN XXXXX XXXXXX
Childproof lock
OFF
Childproof lock
ON
6.3 Childproof lock
The childproof lock is to prevent children accidentally starting or stopping a
programme. When the childproof lock is on, a programme can only be started
by pressing two buttons simultaneously.
Switching the childproof lock on/off
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
current setting appears in the display, e.g.:
► Press the button.
– The setting is taken over automatically
and must not be confirmed.
► Press the button repeatedly until the
display goes out.
33
6 User settings
User settings
FN XXXXX XXXXXX
Level of dryness
3
Level of dryness
5
6.4 Level of dryness
The appliance is designed to provide the most energy-efficient drying. The
moisture sensor continually monitors the level of dryness of the washing. If the
washing is not being dried sufficiently – or being overdried – the level of dryness can be reset.
Changing the level of dryness alters the level of dryness setting of all
the programmes. Care should be taken when increasing the level of
dryness as overdrying can weaken fabrics.
Changing the level of dryness
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
current level of dryness appears in the display, e.g.:
► Press the button repeatedly until the
required setting appears in the display,
e.g.:
► Press the button repeatedly until the
display goes out.
Levels of dryness
1 Very low drying
2 Low drying
3 Normal drying (factory setting)
4 Strong drying
5 Very strong drying
34
6 User settings
User settings
FN XXXXX XXXXXX
3
Brightness
5
Brightness
6.5 Brightness
This function can be used to change the contrast between the text and the
background of the display.
Changing the brightness of the display
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
current brightness level appears in the dis-
play, e.g.:
► Press the button repeatedly until the
required setting appears in the display,
e.g.:
► Press the button repeatedly until the
display goes out.
Levels of brightness
1 Very dark
2 Dark
3 Medium (factory setting)
4 Bright
5 Very bright
35
6 User settings
User settings
FN XXXXX XXXXXX
ReversePlus
OFF
ReversePlus
ON
6.6 ReversePlus
By additionally reversing the direction of spin of the drum against the main direction, the washing dries more evenly and is less likely to get tangled.
Particularly suitable for drying larger items, e.g. bedding.
Switching ReversePlus on/off
► Hold the button pressed for
5seconds.
► Press the button repeatedly until the
current setting appears in the display, e.g.:
► Press the button.
– The setting is taken over automatically
and must not be confirmed.
► Press the button repeatedly until the
display goes out.
The ReversePlus function is set to either on or off in the user settings.
The additional function can be selected or deselected for the currently
selected programme by pressing the + button. The user setting remains unchanged.
36
6 User settings
User settings
FN XXXXX XXXXXX
Standard mode
no additional function
Standard mode
Eco
6.7 Standard mode
Any of the additional functions – SilentPlus, Sprint and Eco – can be selected
as the default via the user settings for any of the automatic programmes.
Setting the standard mode
► Hold the button depressed for 5
seconds.
► Press the button repeatedly un-
til the desired additional function ap-
pears in the display, e.g.:
► Press the button repeatedly un-
til the required setting appears in
the display, e.g.:
► Press the button repeatedly un-
til the display goes out.
The additional function can be deselected for the current programme
by pressing the corresponding button. The user setting remains unchanged.
37
6 User settings
User settings
FN XXXXX XXXXXX
Button tone
ON
Button tone
OFF
6.8 Button tone
The button tone can be switched on/off.
Switching the button tone on/off
► Hold the button depressed for 5
seconds.
► Press the button repeatedly until the
current setting appears in the display, e.g.:
► Press the button.
– The setting is taken over automatically
and must not be confirmed.
► Press the button repeatedly until the
display goes out.
38
6 User settings
User settings
FN XXXXX XXXXXX
Factory setting
restore?
Factory settings
YES: NO:
Factory settings
restored!
6.9 Restoring factory settings
The factory settings can be restored.
► Hold the button pressed for
5seconds.
► Press the button repeatedly until in the
display appears:
► Press the button.
Restoring factory settings:
«YES»:
► Press the button.
«NO»:
► Press the button.
39
7 Drying
1
0
1
0
Select programme
7.1 Preparing the appliance
After the appliance is transported or re-sited, it must be left to
stand in the normal operating position for around 2 hours. Failure
to do this can result in damage to the appliance.
► Plug the appliance in at the mains or turn the wall switch
on.
7.2 Loading the appliance
► Open the appliance door (press at the edge of
door in the area marked by dots) or press the
button.
► Loosely load wet washing items one by one into
the appliance.
– See 'Programme overview' for maximum load
capacity.
– Ideally, fill the drum ½ full.
– Large blankets, in particular, need plenty of
room to tumble.
► Close the appliance door (pushing firmly to).
When closing the appliance door, check that no items of washing are
trapped.
– In the display appears:
40
7 Drying
Determining load 1h35
Calculating time
remaining
0h15
The indicator lights for the programme buttons flash.
If no programme selection is made within 20 seconds, all the displays go out.
However, it is still possible to make a programme selection.
7.3 Selecting a programme
«Press and go»
An automatic programme can be selected with the press of a single button. All
the necessary settings for the programme are provided automatically.
Additional functions can be selected or deselected by pressing the corresponding button.
If no other button is pressed within the next 20 seconds, the programme selected starts automatically.
Use the 'Programme overview' to determine which programme is the
most suitable for your washing.
Duration remaining indicator
During programme selection, the expected duration of a programme is shown.
This corresponds to a load containing similar wash items with a defined
weight.
Load determination occurs after the programme start:
– In the display appears:
– The letter «h» flashes: the expected duration remaining is calculated
and then displayed.
Depending on fabric type, the actual running time may differ from the
duration shown. The duration remaining shown – especially towards
the end of the programme – can freeze for several minutes. During
this period, the letter «h» flashes and the duration remaining is recalculated.
– The letter «h» flashes again and in the
display appears:
– This alternates with the level of dryness achieved.
– The time remaining is recalculated and then displayed.
41
7 Drying
*
*
+
Selecting an automatic programme
► Close the appliance door.
– The indicator lights for the programme buttons and the additional pro-
gramme flash.
* Depending on the serial number (FN)
► Press desired programme button.
– The indicator light for the programme selected illuminates.
– The programme selected and the likely duration (hours/minutes) ap-
pears.
– The indicator lights for the additional functions that may be selected
flash for 20seconds.
A new programme can be selected during this time. All additional
functions selected are cleared and must be reselected.
If no other button is pressed within the next 20seconds, the programme selected starts automatically.
42
7 Drying
*
*
+
+
Selecting timed drying
► Close the appliance door.
– The indicator lights for the programme buttons and the additional pro-
gramme flash.
* Depending on the serial number (FN)
► Press the button.
► Press repeatedly to select the desired duration, i.e. 10, 20, 30, 40, 50, 60,
90 or 120 minutes.
– The duration selected appears in the display.
– The indicator lights for the additional functions that may be selected
flash for 20seconds.
The duration selected always includes a 10-minute «Cool down/Airing» phase.
Selecting additional functions
► While the indicator lights flash, press one of the buttons.
or*
Eco*
Eco* Sprint
Easy care Ultra care
ReversePlus SilentPlus
43
7 Drying
*
*
+
Selecting a delayed start
* Depending on the serial number (FN)
► Immediately after programme selection, hold the button depressed or
press repeatedly until the required delayed start duration
(max.24 hours) appears in the display.
– The display goes dark.
– When the set duration is up, the programme selected starts automatic-
ally.
Washing can be added at any time.
The time remaining to the delayed start can be shortened in hourly
steps to zero by repeatedly pressing the button.
7.4 Changing selection
During programme selection
► Press a programme button again.
– All selected settings are cleared.
Once a programme has started, it is no longer possible to change it.
The programme must be aborted.
44
7 Drying
7.5 Interrupting a programme
A running programme can be interrupted at any time to add or remove an
item of washing before time.
After the appliance door is closed, the heat pump waits 5 minutes before starting again and the programme duration is correspondingly
lengthened.
► Open the appliance door.
– The indicator light for the programme selected illuminates.
– The programme name and time remaining or delayed start period flash
in the display.
► Close the appliance door (pushing firmly to).
– The indicator light for the programme selected flashes.
► Press the flashing programme button.
– The programme continues.
7.6 Aborting a programme before time
► Press the button.
– The programme is aborted and all settings are cleared.
45
7 Drying
Childproof lock
*
*
+
7.7 Programme selection with childproof lock activated
How to switch the childproof lock on/off is described in 'User settings'.
► Close the appliance door.
– In the display appears:
– The indicator lights for the pro-
gramme buttons flash.
* Depending on the serial number (FN)
► Hold the desired programme button depressed and at the same time press
the button.
– The indicator lights for the additional functions flash.
The appliance can now be operated without regard to the childproof
lock until the programme starts.
Interrupting a programme through opening the appliance door
► Open the appliance door.
– The programme running is interrupted.
► Close the appliance door.
► Hold the active programme button – the indicator light flashes – depressed
and at the same time press the button.
– The programme is resumed.
46
7 Drying
Aborting a programme through opening the appliance door
► Open the appliance door.
– The programme running is interrupted.
► Hold the active programme button – the indicator light flashes – depressed
and at the same time press the button.
– The programme is aborted.
Aborting a programme through button selection
With the appliance door closed, carry out the following step:
► Hold the active programme button – the indicator light illuminates – de-
pressed and at the same time press the button.
– The programme is aborted.
47
7 Drying
End of programme
Clean door filter
7.8 End of programme
– In the display appears:
– The indicator light for the programme that has finished illuminates and
the button flashes.
«Crease guard» starts if the appliance is not unloaded straightaway. When it
has finished, all displays go out.
Unloading the washing
► Open the appliance door or press the
button.
– All displays go out.
► Unload the washing.
► Clean the door filter.
► Close the appliance door.
If the appliance door is opened during the «Cool down» phase, the programme is aborted and all displays go out.
At the end of the wash day
► Clean the door filter.
► Close the appliance door.
48
8 Care and maintenance
12
3
To minimize the risk of fire hazard regularly clean the filters!
8.1 Cleaning intervals
Pos. Appliance
part
1
2
3
* A coating of fluff can build up more or less quickly depending on the type
Door filter Each time after
Door mat As required * Remove any fluff/wash at 40 °C.
Front mat Annually Check front mat and air duct and
Exterior of
appliance
of wash and the size of load.
Cleaning interval Clean
Remove any fluff.
the drying programme
Whenever there
is a heavier
build-up of deposits
Occasionally Clean with a damp cloth and wipe dry.
Using an abrasive liquid cleaning
agent and a sponge, rinse with water
and allow to drip dry; use cleaning vin-
egar to soften hard water.
clean as required
Do not clean the door mat with a vacuum cleaner.
This could damage the door mat.
49
8 Care and maintenance
A9 Clean filter and mats
8.2 Error message A9, Clean filter and mats
A thick coating of fluff results in a reduced process air flow, which can
impair the drying process and trigger the «A9 Clean filter and mats»
error message.
Check and, if necessary, clean the following parts in the appliance:
• Door filter
• Door mat
• Front mat
If the error message still appears after cleaning the filter and mats, remove the front mat and clean carefully using a vacuum cleaner. See
section 8.6 on 'Cleaning the front mat'.
8.3 Build-up of fluff
Fluff is made up of fine textile fibres that largely come from the manufacturing
process, from wear and tear during use and from items being washed. Fluff is
not caused by excessive strain on the washing in the appliance. Even when
washing is hung out to dry on a washing line, fluff is shed when the washing is
shaken out or ironed.
Fluff sticks to washing when it is wet. The fluff is released during tumble drying
and gets trapped in the door filter. Fluff therefore builds up in the filter – sometimes more, sometimes less depending on the type of washing.
50
8 Care and maintenance
1
2
1
2
4
3
8.4 Cleaning the door filter
Each time after tumble drying
► Open the appliance door 1.
► Open the cover for door filter 2.
► Remove any fluff.
► Close the cover for door filter 2
again.
The appliance will not start without the door filter in place.
8.5 Basic cleaning of the door filter including mat
Do not clean the door mat 4 with a vacuum cleaner.
This could damage the door mat.
If required
51
8 Care and maintenance
40°
► Open the appliance door 1.
► Open the cover for the door filter 2.
► Take out the door filter 3, open and remove the filter mat 4.
► Hold the door filter 3 up to the light to detect deposits. Wash the door filter
3 to clean off heavier deposits.
– Clean with an abrasive liquid cleaning agent (immerse if necessary)
and a sponge; use cleaning vinegar with hard water.
– Clean the filter mat under running water and squeeze out the water.
– Wash on a 40 °C wash programme to clean off heavier deposits.
► Put back the filter mat 4 correctly.
► Put back the door filter 3. Ensure it is positioned correctly.
52
The appliance will not start without the door filter in place.
8 Care and maintenance
1
2
1 4
3
8.6 Cleaning the front mat
If the «A9 Clean filter and mats» error message still appears after the
filter and the mats have been cleaned, clean the front filter mat in front
of the heat pump very carefully using a vacuum cleaner.
Clean the front mat if necessary
► Open the appliance door 1.
► Remove the front grille 2.
► Press the lug 3 down slightly to release
and remove the front mat 4.
► Clean the front mat 4 carefully using a va-
cuum cleaner with the crevice tool attachment.
► Check the air duct in front of the front mat
4 and clean it with a vacuum cleaner or
moist cloth if required.
► Put back the front mat 4 and engage. En-
sure it is positioned correctly.
► Put back the front grille 2.
The appliance will not start without the front mat being correctly in
place.
53
8 Care and maintenance
A3 Clean moisture sensor
1
8.7 Moisture sensor
The moisture sensor 1 detects the level of moisture remaining in the washing.
If the moisture sensor is dirty, it may produce false readings.
The moisture sensor 1 must be cleaned
if the following appears in the display:
► Open the appliance door.
► Remove any fluff or foreign objects on the mois-
ture sensor 1. If necessary, clean with a damp
cloth and then wipe dry.
54
9 Trouble-shooting
FXX / EXX See instructions
FN XXXXX XXXXXX
A0 Check outlet
This section lists faults that can be solved simply by following the instructions
given. If another fault is displayed or the fault cannot be remedied, please call
Customer Services.
Before calling Customer Services, please note down the error message in full.
9.1 What to do if ...
... in the display appears
Possible cause Solution
• Drain hose is blocked,
kinked or defective.
• The pumping height of the
drain hose is too high (<1.2
m).
• The appliance is connected
to a concealed double
drain trap.
► Check the part of the drain hose that is not
housed in the appliance.
► Resolve the problem.
► Cancel the error message by pressing the
button.
► Start the programme.
► If the error appears again, note down the er-
ror message in full and the serial number
(FN) and then turn off the power supply.
► Call Customer Services.
55
9 Trouble-shooting
A3 Clean moisture sensor
A9 Clean filter and mats
... in the display appears
Possible cause Solution
• Moisture sensor is dirty or
wet.
► Clean the moisture sensor and then wipe
dry.
► Cancel the error message by pressing the
button.
► Start the programme.
► If the error appears again, note down the er-
ror message in full and the serial number
(FN) and then turn off the power supply.
► Call Customer Services.
... in the display appears
Possible cause Solution
• The following parts in the
appliance could be
blocked:
– Door filter
– Door mat
– Front mat
► Check and, if necessary, clean the parts.
► Cancel the error message by pressing the
button.
► Start the programme.
► If the error appears again, note down the er-
ror message in full and the serial number
(FN) and then turn off the power supply.
56
► Call Customer Services.
9 Trouble-shooting
FXX / EXX See instructions
FN XXXXX XXXXXX
U1 / E42 See instructions
FN XXXXX XXXXXX
... in the display appears
Possible cause Solution
• Various situations can lead
to a «F message».
► Cancel the error message by pressing the
button.
► Turn the power supply off for about 1 minute
and then turn it back on again.
► Next select a programme.
► If the error appears again, note down the er-
ror message in full and the serial number
(FN) and then turn off the power supply.
► Call Customer Services.
... in the display appears
Possible cause Solution
• Overvoltage
► Cancel the error message by pressing the
button.
► Turn the power supply off for about 1 minute
and then turn it back on again.
► Next select a programme.
If the error appears again:
► Switch the power supply off.
► Have an electrician check the house installa-
tion.
If the error appears again:
► Note down the error message in full and the
serial number (FN) and then disconnect the
power supply.
► Call Customer Services.
57
9 Trouble-shooting
Insert door filter
Close appliance door
Insert
front mat
... in the display appears
Possible cause Solution
• Door filter is missing.
Insert door filter and ensure it is positioned
correctly.
• The appliance door is
Close the appliance door.
open.
... in the display appears
Possible cause Solution
• Front mat is not in place or
Put the front mat in correctly.
is not in place correctly.
... it is not possible to select a new programme after closing the appliance door
Possible cause Solution
• A programme was interrupted.
Press the button.
Select a new programme.
... the appliance does not start
Possible cause Solution
• The appliance door is
open.
• The door filter is missing.
• The front mat is missing.
• Interruption in power sup-
ply.
58
► Close the appliance door.
► Insert door filter and ensure it is positioned
correctly.
► Insert the front mat.
► Insert the plug into the mains socket.
► Turn the wall switch on.
► Check the fuse or circuit breaker.
9 Trouble-shooting
Demo mode
ON
Demo mode
OFF
... the washing is not dry enough
Possible cause Solution
• Load contained mixed fabrics.
► Select a longer programme.
► Select the programme.
► Change the level of dryness.
• Interruption in power sup-
ply.
► Insert the plug into the mains socket.
► Turn the wall switch on.
► Check the fuse or circuit breaker.
• The moisture sensor is
► Clean the moisture sensor.
dirty.
• The «demo mode» is
switched on.
► Open the appliance door.
► Hold the and buttons depressed.
► Simultaneously press the button.
– In the plain text display appears:
► Press the button.
– In the plain text display appears:
59
9 Trouble-shooting
... the programme takes significantly longer than indicated in the display
Possible cause Solution
• The following parts in the
► Check and, if necessary, clean the parts.
appliance could be
blocked:
– Door filter
– Door mat
– Front mat
• Very wet washing.
• The ambient temperature is
► Spin washing at higher speed.
► Improve the ventilation of the room.
too high.
... the washing is charged with static electricity
Possible cause Solution
• Wash items that are made
of man-made fibres.
► Static charge is a normal characteristic of
man-made fibres and nothing to do with the
appliance.
... the duration remaining indicator remains frozen for a longer period
Possible cause Solution
• Not yet reached level of
dryness required.
► This is not a malfunction. No action is ne-
cessary. Once the level of dryness required
is reached, the duration remaining indicator
will run automatically again.
• Wash load very mixed
(especially with coarser textiles).
• Build-up of fluff in the filters
60
► This is not a malfunction. No action is ne-
cessary. The duration remaining indicator
will run automatically in a while.
► Clean the filters.
10 Drying tips
10.1 Fabric care symbols
To select the right drying programme, follow the fabric care symbols on garment labels.
Tumble dry, medium heat
Tumble dry, low heat
Do not tumble dry
10.2 General tips
• For the wash you are recommended not to use fabric conditioners or other
fabric care solutions. Tumble drying automatically leaves fabrics soft and
fluffy to the touch.
• The use of fabric conditioner in the wash can lead over time to the formation of a thin, barely visible film in the drum and on the moisture sensors.
This can cause a malfunction resulting in the washing not being dried to the
level of dryness required.
• Use tumble dryer sheets sparingly.
• Protect items of washing from getting damaged.
– Fasten duvet and pillow cases, hook and eye fasteners and zips.
– Fasten cloth belts and apron ties.
• Put only a few items of washing in the drum when drying fabrics that crease
easily.
• For bulky items (e.g. sleeping bags, duvets, etc.) which fill the drum over
half full, follow the fabric care symbols on the labels of the items carefully.
• Woollen and silk fabrics often carry the «Do not tumble dry» label.
– For woollen and silk fabrics, follow the fabric care symbols on garment la-
bels.
– Select the relevant programme by pressing the or button.
61
10 Drying tips
• For easy-care fabrics (e.g. shirts and cotton-mix fabrics), select the additional easy care function and put only a few items in the drum.
• Knitted and woven items (e.g. T-shirts) tend to shrink. Select the additional
easy care function.
• Items of clothing with metal fasteners (e.g. overalls) should be tumble dried
using the additional timed drying programme. The metal fasteners
could cause the washing to be overdried in an automatic programme.
10.3 Energy-saving tips
• Use in addition. This can reduce energy consumption.
• Well-spun washing requires a shorter drying time, saving energy.
– Spin washing well before tumble drying. Tumble drying largely removes
creases that come from spinning in the washing machine.
• Dirty fluff filters and filter mats reduce the air flow rate when drying and result in longer drying times and higher energy consumption.
– Fluff filters and filter mats must be cleaned regularly in accordance with
the operating instructions.
• Always fill the drum to the maximum load capacity of the relevant programme.
• Small, light items of washing dry faster; different materials can have different
drying durations.
– Sort items according to type and size to avoid over-drying of individual
items.
62
11 Spare parts
Please give model number and exact description when ordering parts.
mesh door filter
Door mat
Front grille
Front mat
63
12 Technical data
1
Dimensions
Height: 85 cm
Width: 59.5 cm
Depth: 61 cm
Weight: 65 kg
Pumping height of pump: 1.2m
Dry load capacity: 7 kg
Ambient conditions
Permissible room temperature when appliance is in operation: 5°C to 35°C
Electrical connection
► See identification plate 1
64
12 Technical data
12.1 Consumption values
The stated values for the programme duration and energy apply for the maximum stated capacity with a wash spun at around 1200 rpm (corresponds to
a residual moisture of around 60%). A higher spinning speed or a smaller load
reduce them by around 20–30 %.
Automatic programmes
Programme Load
capacity kg
Extra dry 1–7 –4 to –1 2h30 1.60
Normal dry 1–7 –1 to 2 1h55 1.30
Normal dry +
Eco*
Iron dry 1–7 8 to 16 1h35 0.85
Damp 1–7 20 to 30 1h20 0.75
Woollens 1 0 to 5 1h05 0.65
Favourites – – – –
Timed drying 1–7 – 0h10 to 2h00 –
* Most energy-efficient programme for drying normal wet cottons laundry.
1–7 –1 to 2 2h10 1.24
Residual
moisture %
Programme duration
hrs./mins.
Energy
kWh
65
12 Technical data
Fabric types
Programme Load capacitykgResidual
moisture
%
Programme
duration
hrs./mins.
Energy
kWh
WetClean finish 1 – 0h06 0.03
Airing 1–1.5 – 0h10 0.02
Silks 1–1.5 0 to 2 0h50 0.45
Fluffing 1 – 0h06 0.03
Crease guard 1 – 0h20 0.09
Shirts 1–7items 0 to 2 0h40 0.25
Outdoor gar-
1–3 0 to 2 0h55 0.50
ments
Denim 1–4 –1 to 2 1h50 1.10
Baby garments 1–7 –1 to 1 3h00 1.80
Thin down filling 1–2 –1 to 1 2h00 1.05
Thick down
1–2 –1 to 1 2h40 1.70
filling
Hygiene 1–3 –5 to 2 2h20 1.55
Towelling 1–3 –1 to 1 1h45 1.10
Basket pro-
– 0h30 to 3h00
gramme
66
12 Technical data
12.2 Note for testing institutes
► The declaration data can be determined correctly only after a run-in phase
of 5 complete drying programmes with washing (automatic programme:
normal dry / ).
► Wash the door filter each time after completing a drying programme.
► The moisture sensor of the appliance is calibrated based on average water
hardness levels. To adjust the water conductivity value of the appliance according to the norm (75 mS/cm), the level of dryness must be set to «1» in
the user settings.
► The declaration data can be determined correctly only after a run-in phase
of 5 complete drying programmes with washing (automatic programme:
normal dry).
► Wash the door filter each time after completing a drying programme.
► The moisture sensor is calibrated based on average water hardness levels.
To adjust the water conductivity value of the appliance according to the
norm (0.45 mmol/l), set the level of dryness to «4» in the user settings.
Set to the standard programme according to AS/NZS 2442.2:2000:
• Cotton laundry, normal dry and Eco, 7 kg load capacity
► Press the and buttons.
12.3 Automatic energy-saving stand-by
The appliance is equipped with automatic energy-saving stand-by to avoid
consuming energy unnecessarily.
All displays go out within minutes of a programme finishing. The cooling fan
continues to run for about another 30 minutes after the programme has finished (left-on mode).
Then the appliance automatically changes over to the stand-by mode. Energy
consumption is reduced to an absolute minimum. The safety functions, however, remain activated.
67
13 Index
A
Additional functions .......................... 20, 43
Additional programme
Timed drying.......................................19
Airing........................................................... 21
Ambient conditions .................................. 64
Appliance
Preparing.............................................40
Appliance construction............................ 18
Appliance description.............................. 17
Automatic energy-saving stand-by ........ 67
Automatic programmes.................... 19, 22
Selecting..............................................42
B
Basic cleaning
Door filter including mat ...................51
Brightness
Changing .............................................35
Levels ...................................................35
Button tone ................................................ 38
Switching on/off .................................38
C
Care ............................................................ 49
Changing selection .................................. 44
Childproof lock.......................................... 46
Switching on/off .................................33
Cleaning
Moisture sensor..................................54
Cleaning intervals..................................... 49
Consumption data
Fabric types ........................................66
Cooling down ............................................ 21
Crease guard ............................................ 21
D
Delayed start ............................................. 27
Selecting..............................................44
Dimensions................................................ 64
Disconnection............................................ 12
Display (plain text display)...................... 19
Display elements ...................................... 18
Disposal...................................................... 12
Door filter
Cleaning...............................................51
Drying .................................................. 21, 40
Duration remaining indicator.................. 41
E
Easy care ................................................... 26
Eco .............................................................. 26
Eco / standard programme.................... 26
Electrical connection................................ 64
End of the wash day................................ 48
Energy-saving tips .................................... 62
Error messages ........................................ 55
A9 Clean filter and mats...................50
Extended warranty.................................... 71
F
Fabric care symbols ................................ 61
Fabric types
Airing ....................................................23
Baby garments ...................................24
Basket programme............................25
Crease guard......................................24
Denim...................................................24
Fluffing .................................................24
Hygiene................................................25
Outdoor garments..............................24
Shirts ....................................................24
Silks ......................................................24
Thick down filling ...............................25
Thin down filling .................................25
Towelling..............................................25
WetClean finish...................................23
Factory settings
Restoring .............................................39
Favourites................................................... 27
Changing .............................................28
Clearing ...............................................29
Defining................................................27
Starting.................................................28
Fluff.............................................................. 50
Front mat
Cleaning...............................................53
Function test.............................................. 13
Aborting ...............................................15
Continuing ...........................................14
End .......................................................15
68
13 Index
Language selection ...........................14
Starting.................................................14
I
Instructions for use ..................................... 9
L
Language
Changing .............................................32
Selecting..............................................16
Level of dryness
Changing .............................................34
Levels ...................................................34
M
Maintenance .............................................. 49
Model no....................................................... 2
N
Note for testing institutes ........................ 67
Note on heat pump.................................. 12
O
Operating elements.................................. 18
P
Packaging.................................................. 12
Power consumption ................................. 65
Automatic programme ......................65
Preparing the appliance.......................... 40
Press and go............................................. 41
Product family.............................................. 2
Programme
Aborting ...............................................45
End .......................................................48
Interrupting ..........................................45
Overview..............................................21
Selecting..............................................41
Sequence ............................................21
Programmes
Aborting through button selection
........................................................47
Aborting through opening door.......47
Interrupting through opening door
........................................................46
R
ReversePlus............................................... 27
Switching on/off .................................36
Room temperature ................................... 64
S
Safety .......................................................... 12
Safety precautions
Appliance-specific ................................7
General...................................................6
Serial number (FN)................................... 16
Service & Support .................................... 71
SilentPlus.................................................... 27
Softener ...................................................... 61
Spare parts ................................................ 63
Sprint........................................................... 26
Standard programme .............................. 23
Symbols........................................................ 5
T
Technical data........................................... 64
Technical enquiries .................................. 71
Testing institutes
Note......................................................67
Testing institutes: Note ............................ 67
Timed drying
Selecting..............................................43
Tips.............................................................. 61
Trouble-shooting....................................... 55
Tumble dryer sheets ................................ 61
Type............................................................... 2
U
Ultra care.................................................... 26
User settings
Changing .............................................30
Exiting...................................................30
V
Validity........................................................... 2
W
Washing
Loading................................................40
Unloading ............................................48
What to do if...
69
... A0 Check outlet appears in the dis-
play.................................................55
... A3 appears in the display............56
... appliance does not start ..............58
... Insert door filter appears in the dis-
play.................................................58
... Insert front mat appears in the dis-
play.................................................58
... it is not possible to select a new
programme after closing the appli-
ance door......................................58
... the duration remaining indicator re-
mains frozen for a longer period....
60
... the programme takes significantly
longer than indicated..................60
... the washing is charged with static
electricity .......................................60
…F.. See instructions appears in the
display ...........................................57
…U1 See instructions appears in the
display ...........................................57
What to do if…
... appears in the A9 display............56
... the washing is not dry enough
........................................................59
70
14 Service & Support
The «Troubleshooting» chapter provides valuable information for dealing with
minor operating faults. This saves you the time, effort and potential cost of having
to call out a service technician.
Information on the V-ZUG warranty can be found at www.vzug.com →Service →Warranty information. Please read this information carefully.
Please register your V-ZUG appliance online immediately at www.vzug.com→Service→Warranty registration. This will allow you to take advantage of the best possible support in the
event of an fault in the appliance during the warranty period. You will require the serial
number (FN) and appliance designation to complete the registration process. This information can be found on the identification plate for your appliance.
My appliance information:
FN: ___________________ Appliance: _____________________
Always have this appliance information to hand when you contact V-ZUG. Thank you.
► Open the appliance door.
– The identification plate is located bottom right.
Requesting repairs
You can find the telephone number for your nearest V-ZUG service centre at
www.vzug.com→Service→Service hotline.
Technical enquiries, accessories, extended warranty
V-ZUG is happy to help with your general administrative and technical enquiries, orders for
accessories and spare parts, or information relating to advanced service agreements.
71
Quick instructions
Please first read the safety precautions in the operating instructions!
► Open the appliance door
► Check the filter in the door
► Load the appliance
► Close the appliance door
► Select programme
► Select any additional function, if required
► The appliance starts automatically after 20 seconds
When the programme has finished:
► Unload the dry washing when «End of programme» appears in the display
► Clean the door filter
► Close the appliance door
At the end of the wash day:
► Clean the door filter
► Close the appliance door
V-ZUG Ltd
Industriestrasse 66, P.O. Box 59, CH-6301 Zug
info@vzug.com, www.vzug.com
J12003360-R04
Loading...
