Vykon VT7200 Series, VT7300 Series Integration Manual

Download

PIR Ready VT7200 & VT7300 Series

24 Vac Fan Coil and Zoning Thermostats

For Commercial and Lodging HVAC Applications

LonWorks Integration Manual

September 1, 2010

VT7200X Series Product Overview

The VT7200 PI thermostat family is specifically designed for zoning applications. Typical applications include local hydronic reheat valve control and pressure dependent VAV with or without local reheat. The product features a backlit LCD display with dedicated function menu keys for simple operation. Accurate temperature control is achieved due to the product’s PI proportional control algorithm, which virtually eliminates temperature offset associated with traditional, differential-based thermostats. Models are available for 3 point floating and analog 0 to 10 Vdc control. In addition remote room sensing is available.

They all contain an SPST auxiliary switch that can be used to control lighting or auxiliary reheat. 3 additional inputs are also provided for monitoring and / or various advanced functions.

Fig.1 - VT7200 Series

VT73xxX Series Product Overview

The VT7300 PI thermostat family is specifically designed for fan coil control. The product features a backlit LCD display with dedicated function menu buttons for simple operation. Accurate temperature control is achieved due to the product’s PI proportional control algorithm, which virtually eliminates temperature offset associated with traditional, differential-based thermostats.

Models are available for On/Off, 3 point floating and analog 0 to 10 Vdc control and can control up to three fan speeds. Three additional inputs are also provided for monitoring and / or various advanced functions.

All models feature configurable System and Fan button functions to meet all possible applications. They all contain an SPST auxiliary switch that can be used to control lighting or auxiliary reheat.

All devices are also available with Echelon, BACnet MS-TP or Zigbee wireless network adapter. The thermostats are also compatible with the new Vykon PIR cover accessories. Thermostats equipped with a

PIR cover provide advanced active occupancy logic, which will automatically switch occupancy levels from Occupied to Stand-By and Unoccupied as required by local activity being present or not. This advanced occupancy functionality provides advantageous energy savings during occupied hours without sacrificing occupant comfort. All thermostats can be ordered with or without a factory installed PIR cover.

The additional following documents are available :

• VYKONStat PIR Ready VT7200 Series Installation Guide.

• VYKONStat PIR Ready VT7300 Series Installation Guide.

• VYKONStat PIR Application Guide

• VYKONStat PIR Cover Assembly Installation Guide

Contents

• PID History Revision Table

• Thermostat Objects

• Applicable SNVTs and SCPTs Table Per Model

• Input Network Variables (nvi’s) Description

• Output Network Variables (nvo’s) Description

• Configuration Properties (nci’s) Description

• Integration - Global Commands

• Integration - Graphic User Interface (GUI) Objects

• Integration - Configuration Objects

• Wiring Guide

 Overview  Network Configuration  Maximum Number Of Devices  Maximum Cable Length  Terminators

• Network Adapter

• Software Files

• Device Identification

• Tips And Things You Need To Know

• Troubleshooting Section

PID History Revision Table XIF, APB and NXE File Names and Corresponding PIDs. This manual information is to be used only with the

current released VT7200X & VT73xxX PIR ready thermostats.

Used on current

released thermostat

APB / NXE / XIF file

names

Revision Level Associated PID

PIR Ready VT7200 / VT7300 Series VT72_73_PIR.XIF Rev 3.0 80:00:C5:55:00:04:04:20 This manual information is NOT to be used only with the previously released VT7200X & VT7300X thermostats.

Previously

released thermostat

APB / NXE / XIF file

names

Revision Level Associated PID

Non-RoHS VT7200 / VT7300 Series T7X-FC.XIF Rev 1.0 to 1.3 80:00:C5:55:00:04:04:0B RoHS VT7200 / VT7300 Series T7X-FCr.XIF Rev 1.0 to 1.3 80:00:C5:55:00:04:04:1B RoHS PIR VT7200 / VT7300 Series ** T7X-FC-PIR.XIF Rev 2.0 80:00:C5:55:00:04:04:1D

Thermostat Objects

VT7300 Space Comfort Controller

Object Type #8500

nviSpaceTemp SNVT_temp_p

nviOutdoorTemp SNVT_temp_p

nviSetpoint SNVT_temp_p

nviSpaceRH SNVT_lev_percent

nviFanSpeedCmd SNVT_switch

nviAuxHeatEnable SNVT_switch

nviOccManCmd SNVT_occupancy

nviApplicMode SNVT_hvac_mode

Mandatory

Network

Variables

Optional Network

Variables

nvoSpaceTemp SNVT_temp_p

nvoUnitStatus

SNVT_hvac_status

nvoDischAirTemp SNVT_temp_p

nvoSpaceRH SNVT_lev_percent

nvoEffectOccup SNVT_occupancy

nvoTerminalLoad SNVT_lev_percent

nviHeatCool SNVT_hvac_mode

nviRemLockout SNVT_count

nviDhumidLCK SNVT_switch

nviAuxOut SNVT_switch

Manufact u r er Con figuration Propertie s

Con figurat ion Prope r ties

Send Heartbeat (mandatory)

Temperature Setpoints (mandatory)

Minimum Send Time (optional )

Receive Heartbeat (optional)

Manufacturer

Network

Variables

Please se e the manual for deta ils. Plug-In for configuratio n pr ovided.

nvoSCCstatus SNVT_state_64

SNVTs

and SCPTs2 Table Per Model

1: SNVTs: Standard Network Variables Types 2: SCPTs: Standard Configuration Parameters Types

Snivet Type

Sub

N/A: Not applicable on this model 0 nviSpaceTemp SNVT_temp_p X X X X X X X X X X X X 1 nviOutdoorTemp SNVT_temp_p X X X X X X X X X X X X 2 nviSetpoint SNVT_temp_p X X X X X X X X X X X X 3 nviSpaceRH SNVT_lev_percent N/A N/A N/A N/A X N/A N/A X N/A X N/A X 4 nviFanSpeedCmd SNVT_switch N/A N/A X X X X X X X X X X 5 nviAuxHeatEnable SNVT_switch X X X X X X X X X X X X 6 nviOccManCmd SNVT_occupancy X X X X X X X X X X X X 7 nviApplicMode SNVT_hvac_mode X X X X X X X X X X X X 8 nviHeatCool SNVT_hvac_mode X X X X X X X X X X X X 9 nviRemLockout UNVT_count X X X X X X X X X X X X

10 nviDhumiLCK SNVT_switch N/A N/A N/A N/A X N/A N/A X N/A X N/A X 11 nviAuxOut SNVT_switch X X X X X X X X X X X X 12 nvoSpaceTemp SNVT_temp_p X X X X X X X X X X X X 13 nvoDischAirTemp SNVT_temp_p X X X X X X X X X X X X 14 nvoSpaceRH SNVT_lev_percent N/A N/A N/A N/A X N/A N/A X N/A X N/A X 15 nvoEffectOccup SNVT_occupancy X X X X X X X X X X X X 16 nvoUnitStatus SNVT_hvac_status X X X X X X X X X X X X

1 mode x x x x x x x x x x x x

2 heat_output_primary x x x x x x x x x x x x

4 cool_output x x x x x x x x x x x x

6 fan_output N/A N/A x x x x x x x x x x

7 in_alarm x x x x x x x x x x x x

17 nvoSccStatus UNVT_thermo_state_fc X X X X X X X X X X X X

Associate with UNVT_thermo_state_fc format file

1 bi1_status True bit index 2 x x x x x x x x x x x x

2 bi2_status True bit index 1 x x x x x x x x x x x x

3 ui3_ status True bit index 0 x x x x x x x x x x x x

4 dehumidification_active True bit index 7 N/A N/A N/A N/A x N/A N/A x N/A x N/A x

5 state_terminal_bo1 True bit index 13 x N/A N/A x x N/A x x N/A N/A N/A N/A

6 state_terminal_bo2 True bit index 12 x N/A x x x x x x N/A N/A N/A N/A

7 state_terminal_bo3 True bit index 15 x N/A x x x x x x N/A N/A N/A N/A

8 state_terminal_bo4 True bit index 14 x N/A N/A x x N/A x x N/A N/A N/A N/A

9 state_terminal_bo5 True bit index 20 x x x x x x x x x x x x

10 fan_low True bit index 21 N/A N/A x x x x x x x x x x

11 fan_med True bit index 22 N/A N/A x x x x x x x x x x

12 fan_high True bit index 23 N/A N/A x x x x x x x x x x

13 window_opened True bit index 24 x x x x x x x x x x x x

14 service_alarm True bit index 28 x x x x x x x x x x x x

15 filter_alarm True bit index 29 x x x x x x x x x x x x

16 local_pir_motion True bit index 39 x x x x x x x x x x x x

18 nvoTerminalLoad SNVT_lev_percent X X X X X X X X X X X X 19 nciSetpoints SNVT_temp_setp X X X X X X X X X X X X

1 occupied_cool x x x x x x x x x x x x

2 standby_cool x x x x x x x x x x x x

3 unoccupied_cool x x x x x x x x x x x x

4 occupied_heat x x x x x x x x x x x x

5 standby_heat x x x x x x x x x x x x

6 unoccupied_heat x x x x x x x x x x x x

Point Name

Enumeration and

Signature Type

VT7200C5x28E

VT7200F5x28E

VT7300A5x28E

VT7300C5x28E

VT7350C5x28E

VT7305A5x28E

VT7305C5x28E

VT7355C5x28E

VT7300F5x28E

VT7350F5x28E

VT7305F5x28E

VT7355F5x28E

Snivet Type

Sub

20 nciCfg2FcuZn UNVT_cfg_2_fcu_zn X X X X X X X X X X X X

Associate with UNVT_cfg_2_fcu_zn format file

1 bi1_config Enumeration Set Used:

2 bi2_config Enumeration Set Used:

3 ui3_config Enumeration Set Used:

4 room_humidity_display Enumeration Set Used:

5 dehumidification_setpoint SNVT_lev_percent N/A N/A N/A N/A x N/A N/A x N/A x N/A x

6 dehumumidification_hysterisis SNVT_lev_percent N/A N/A N/A N/A x N/A N/A x N/A x N/A x

7 dehumidification_max_cooling SNVT_lev_percent N/A N/A N/A N/A x N/A N/A x N/A x N/A x

8 calib_room_humidity_sensor SNVT_lev_percent N/A N/A N/A N/A x N/A N/A x N/A x N/A x

22 nciSccModel UNVT_model_info_2 X X X X X X X X X X X X

Associate with UNVT_model_info_2 format file

1 Thermostat Model x x x x x x x x x x x x

2 Thermostat Software Version x x x x x x x x x x x x

23 nciHvacType SNVT_hvac_type X X X X X X X X X X X X 24 nciSndHrtBt SNVT_time_sec X X X X X X X X X X X X 25 nciMinOuttM SNVT_time_sec X X X X X X X X X X X X 26 nciRcvHrtBt SNVT_time_sec X X X X X X X X X X X X 27 nciMajVer SCPT_maj_ver X X X X X X X X X X X X 28 nciMinVer SCPT_min_ver X X X X X X X X X X X X

Point Name

Enumeration and

Signature Type t

input_cfg_model_a_t input_cfg_model_b_t input_cfg_model_c_t off_on_state_t

VT7200F5x28E

VT7200C5x28E

x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x

N/A N/A N/A N/A x N/A N/A x N/A x N/A x

VT7300A5x28E

VT7300C5x28E

VT7350C5x28E

VT7305A5x28E

VT7305C5x28E

VT7355C5x28E

VT7300F5x28E

VT7350F5x28E

VT7305F5x28E

VT7355F5x28E

Snivet Type

Sub

21 nciCfg1FcuZn UNVT_cfg_1_fcu_zn X X X X X X X X X X X X

Associate with UNVT_cfg1_fcu_zn format file

1 password Unsigned-Long x x x x x x x x x x x x

2 control_type Enumeration Set Used:

3 floating_actuator_time Unsigned-Short x N/A x x x x x x N/A N/A N/A N/A

4 cycles_per_hour Unsigned-Short N/A N/A x x x x x x N/A N/A N/A N/A

5 reverse_or_direct_acting_output Enumeration Set Used:

6 menu_scroll Enumeration Set Used:

7 auto_mode Enumeration Set Used:

8 temperature_scale Enumeration Set Used:

9 pipe_number_main_out_config Enumeration Set Used:

10 sequence_of_operation Enumeration Set Used:

11 fan_menu_sequence Enumeration Set Used:

12 heat_maximum_setpoint SNVT_temp_p x x x x x x x x x x x x

13 cool_minimum_setpoint SNVT_temp_p x x x x x x x x x x x x

14 calib_room_sensor SNVT_temp_diff_p x x x x x x x x x x x x

15 deadband Unsigned-Short x x x x x x x x x x x x

16 setpoint_type Enumeration Set Used:

17 setpoint_function Enumeration Set Used:

18 temporary_occ_time Unsigned-Short x x x x x x x x x x x x

19 proportional_band Unsigned-Short x x x x x x x x x x x x

20 aux_contact_config Enumeration Set Used:

21 reheat_time_base Enumeration Set Used:

22 fan_mode Enumeration Set Used:

23 auto_fan Enumeration Set Used:

24 pir_standby_time Unsigned-Short x x x x x x x x x x x x

25 pir_unoccupied_time Unsigned-Short x x x x x x x x x x x x

22 nciSccModel UNVT_model_number X X X X X X X X X X X X

1 Thermostat Model x x x x x x x x x x x x

2 Software Version x x x x x x x x x x x x

Point Name

Enumeration and

Signature Type t

clrl_type_t

da_ra_type_t scroll_type_t

off_on_state_t

temp_unit_t pipe_system_t seq_operation_t fan_sequence_t

permanent_temporary_t setpts_func_t

aux_contact_model_a_t reheat_option_t fan_mode_t auto_fan_t

VT7200F5x28E

VT7200C5x28E

x N/A N/A x x N/A x x N/A N/A N/A N/A

N/A x N/A N/A N/A N/A N/A N/A x x x x

x x x x x x x x x x x x

N/A N/A x x x x x x x x x x

x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x

N/A N/A x x x x x x x x x x

x x x x x x x x x x x x

N/A N/A x x x x x x x x x x

x x x x x x x x x x x x

x x x x x x x x x x x x N/A N/A x x x x x x x x x x N/A N/A x x x x x x x x x N/A

VT7300A5x28E

VT7300C5x28E

VT7350C5x28E

VT7305A5x28E

VT7305C5x28E

VT7355C5x28E

VT7300F5x28E

VT7350F5x28E

VT7305F5x28E

VT7355F5x28E

Input Network Variables (nvi’s) Description

Parameter Variable Name Function

Room Temperature

network input SNVT_temp_p

nviSpaceTemp

¾ This input network variable provides a network remote temperature

value to the thermostat. When linked of written to, the internal temperature reading (internal sensor) is no longer used.

¾ Valid Range: 40 to 122°F (-40 to 50°C) ¾ Default Null (release) Value: 621.81°F (327.67°C or 0x7FFF) ¾ This network variable is subject to the Receive HeartBeat Time,

nviRcvHrtBt. Outdoor Air Temperature

network input SNVT_temp_p

nviOutdoorTemp

¾ This input network variable provides outdoor air temperature

information to the thermostat from a network value temperature

value. The device will automatically display the value on its display

when linked.

¾ Valid Range: 40 to 122°F (-40 to 50°C) ¾ Default Null (release) Value: 621.81°F (327.67°C or 0x7FFF)

Occupied Cool & Heat Setpoints

network Input SNVT_temp_p

nviSetpoint

¾ This input network variable is used to allow the occupied

temperature setpoints only to be changed via the network from a

single analog value. (Note: the Stand-By and Unoccupied setpoints

are not changed). The corresponding heating and cooling value s

are derived from the minimum deadband configuration value

¾ Default Null Value: 621.81°F (327.67°C or 0x7FFF) ¾ Ex. If the minimum deadband configuration value = 2 °F and

nviSetpoint = 70°F.

• The resulting Occupied heating setpoint will equal 69 °F which is derived from 70 °F minus ½ the minimum deadband configuration value of 2 °F

• The resulting Occupied cooling setpoint will equal 71 °F which is derived from 70 °F plus ½ the minimum deadband configuration value of 2 °F

Room Humidity

network input SNVT_lev_percent

nviSpaceRH

¾ This input network variable is the measured room humidity in

percent monitored by the thermostat.

¾ Valid Range: 5 to 90% ¾ Default Null Value: +163.835 (0x7FFF) ¾ This network variable is subject to the Receive HeartBeat Time,

nviRcvHrtBt

Parameter Variable Name Function

Fan Mode network input

SNVT_switch

nviFanSpeedCmd

¾ This input network variable is used to connect an external fan

speed switch to the node or to allow any supervisory device to override the fan speed controlled by the node’s control algorithm.

¾ This input is used in conjunction with FanMenu bit in nciGenOpts. ¾ Default Null Value: AUTO (state = 0xFF) ¾ Valid Range:

Fan

State Value Equivalent Menu Value

0xFF N/A N/A Auto – Not Used 1

0 n/ N/A Off – Not Used

1 0 0% Off – Not Used

1 0 to 100 0.5 to 50% Low

1 101 to 200 50.5 to 100% High

1 201 to 255 100% 2 – Not Used

0xFF N/A N/A Auto – Not Used 2

0 N/A N/A Off - Not Used

1 0 0% Off - Not Used

1 1 to 66 0.5 to 33% Low

1 67 to 133 33.5 to 66.5% Medium

1 134 to 200 67 to 100% High

1 201 to 255 100% 3 – Not Used

0xFF N/A N/A Auto 3

0 n/ N/A Off – Not Used

1 0 0% Off – Not Used

1 0 to 100 0.5 to 50% Low

1 101 to 200 50.5 to 100% High

1 201 to 255 100% 2 – Not Used

0xFF N/A N/A Auto 4

0 n/ N/A Off – Not Used

1 0 0% Off – Not Used

1 1 to 200 0.5 to 100% On (High)

1 201 to 255 100% On – Not Used

0xFF N/A N/A Auto

Sequence of Operation

network input SNVT_switch

nviAuxHeatEnable

See note 1 below

¾ This input network variable is used to enable or disable the

auxiliary heat stage.

¾ This input is used in conjunction with nviHeatCool and SeqOper. ¾ Default Null Value: AUTO (state = 0xFF) ¾ Set value to 100% for both On & Off state ¾ Valid Range:

State Value Auxiliary Heat Operation 0 N/A Disabled – Not Used 1 0 % Disabled 1 1 to 99% Partially Enabled – Not Used 1 100% Enabled 0xFF N/A Enabled (invalid)

Requested Speed

Percent

N/A N/A Off - Not Used 0 0% Off - Not Used 1 to 66 0.5 to 33% Low 67 to 133 33.5 to 66.5% Medium 134 to 200 67 to 100% High 201 to 255 100% 3 – Not Used

Parameter Variable Name Function

Occupancy Command

network input SNVT_occupancy

nviOccManCmd

¾ This input network variable is used to command the Space

Comfort Controller into different occupancy modes. It is typically set by a supervisory node to remotely control the occupancy modes to override the local occupancy routines of the thermostat.

¾ Default Null Value: OC_NUL = 0xFF ¾ Valid Range:

0 = OC_OCCUPIED *

1 = OC_UNOCCUPIED )

2 = OC_BYPASS – Not Used

3 = OC_STANDY – Not Used

0xFF = OC_NUL (Release to internal occupancy)**

* OC_OCCUPIED and OC_UNOCCUPIED commands will

always have full authority over the local occupancy routines

of the thermostat may they be a local input or a PIR cover.

** OC_NUL command will release the thermostat to use its

own internal occupancy routine driven from one of the digital

input or a PIR cover installed on board.

System Mode network input

SNVT_hvac_mode

nviApplicMode

¾ This network variable input is used to coordinate the Space

Comfort Controller with any node that may need to control the heat/cool changeover of the unit.

¾ This input is used in conjunction with nviHeatCool and SeqOper. ¾ Default Null Value: HVAC_AUTO. ¾ This network variable is subject to the receive heartbeat time,

nciRcvHrtBt

¾ Valid Range:

0 = HVAC_AUTO

1 = HVAC_HEAT

2 = HVAC_MRNG_WRMUP – Not Used

3 = HVAC_COOL

4 = HVAC_NIGHT_PURGE – Not Used

5 = HVAC_PRE_COOL – Not Used

6 = HVAC_OFF

7 = HVAC_TEST – Not Used

8 = HVAC_EMERG_HEAT – Not Used

9 = HVAC_FAN_ONLY – Not Used

12 = HVAC_MAX_HEAT – Not Used

13 = HVAC_ECONOMY – Not Used

14 = HVAC_DEHUMID – Not Used)

15 = HVAC_CALIBRATE – Not Used)

0xFF = HVAC_NUL – Not Used

Parameter Variable Name Function

Sequence of operation

network input SNVT_hvac_mode

nviHeatCool

See note 1 below

¾ This network variable input is used to coordinate the Space

Comfort Controller with any node that may need to control the heat/cool changeover of the unit. This input is overridden by nviApplicMode, unless nviApplicMode is HVAC_AUTO. If nviApplicMode is HVAC_AUTO, then nviHeatCool determines the effective mode of the unit.

¾ Default Null Value: HVAC_AUTO. ¾ This network variable is subject to the receive heartbeat time,

nciRcvHrtBt

¾ Valid Range:

0 = HVAC_AUTO 1 = HVAC_HEAT 2 = HVAC_MRNG_WRMUP – Not Used 3 = HVAC_COOL 4 = HVAC_NIGHT_PURGE – Not Used 5 = HVAC_PRE_COOL – Not Used 6 = HVAC_OFF 7 = HVAC_TEST – Not Used 8 = HVAC_EMERG_HEAT – Not Used 9 = HVAC_FAN_ONLY – Not Used 12 = HVAC_MAX_HEAT – Not Used 0xFF = HVAC_NUL – Not Used

Remote Lockout

network input SNVT_count

nviRemLockout

¾ This network variable input is used to enable or disable user

access to thermostat

¾ Default Null Value: Level 0. ¾ Valid Range:

Level Occupied

Temperature

Setpoints 0 Yes access Yes access Yes access Yes access 1 Yes access Yes access Yes access No access 2 Yes access No access No access Yes access 3 Yes access No access No access No access 4 No access No access No access Yes access 5 No access No access No access No access

Dehumidificati on Lockout

network input SNVT_switch

nviDhumiLCK

¾ This network variable input is used to enable or disable

dehumidification

¾ Default Null Value: Dehumidification not allowed ¾ Set value to 100% for both On & Off state ¾ Valid Range:

State =0 = Dehumidification not allowed (Thermostat’s default value) State = 1 = Dehumidification allowed

Auxiliary Contact Remote Control

network input SNVT_switch

nviAuxOut

¾ This network variable input is used remotely command the

Auxiliary Output (BO5). NOTE Auxiliary Contact configuration NEEDS to be set to 5 for this function to operate ( 5 = Output to follow secondary network occupancy command )

¾ Set value to 100% for both On & Off state ¾ Default Null Value: Auxiliary contact Off ¾ Valid Range:

State = 0 = Auxiliary contact Off (Thermostat’s default value) State = 1 = Auxiliary contact On

System

Mode

Settings

Fan Mode

Settings

Unoccupied

Override

Output Network Variables (nvo’s) Description All output network variables will be updated no faster than the Minimum Send Time (nciMinOutTm) configuration

value. An output network variable will be transmitted immediately when its value has changed significantly (manufacturer’s defined). Additionally, this variable will also be transmitted as a heartbeat output on a regular basis as dictated by the Maximum Send Time (nciSndHrtBt) configuration value.

Parameter Variable Name Function

Room Temperature

network output SNVT_temp_p

nvoSpaceTemp

¾ This output network variable is used to monitor the effective space

temperature sensor that the Space Comfort Controller is using for control. This output echoes the value of the input.

¾ Valid Range: 14 to 122°F (-10 to 50°C) ¾ The value 621.07°F (327.67°C or 0x7FFF) will be sent as an

invalid value in case of a sensor failure. Supply Temperature

network output SNVT_temp_p

nvoDischAirTemp

¾ This output network variable is used to monitor the temperature of

the air that leaves the Space Comfort Controller

NOTE: UI3 needs to be configured to (SS) Supply air sensor

monitoring

¾ Valid Range: -40 to 122°F (-40 to 50°C) ¾ The value 621.81°F (327.67°C or 0x7FFF)will be sent as an invalid

value in case of a sensor failure. Room Humidity

network output SNVT_lev_percent

nvoSpaceRH

¾ This output network variable indicates the space humidity in

percent.

¾ Valid Range: 0 to 100%. ¾ The value 0x7FFF = +163.835% will be set as an invalid value to

indicate a humidity sensor failure. Effective Occupancy

network output SNVT_occupancy

nvoEffectOccup

¾ This output network variable is used to indicate the actual

occupancy mode of the unit. This information is typically reported

to a supervisory controller or provided to another Space Comfort

Controller to coordinate the operation of multiple units

¾ Valid Range:

0 = OC_OCCUPIED 1 = OC_UNOCCUPIED 2 = OC_BYPASS1 3 = OC_STANDBY

Note 1: OC_BYPASS can be initiated by either nviOccManCmd or a local input. NvoEffectOccup will only be in OC_BYPASS for the duration of the ToccTime (nciGenOpts), until reinitiated by either a

transition of the local input or an update to nviOccManCmd. Unit Status network output

SNVT_hvac_status

nvoUnitStatus

¾ This output network variable is available to report the Space

Comfort Controller status. It combines the operating mode, the capacity of heating and cooling used and an indication if any alarms are present in the object.

Sub Name Valid Value

01 mode HVAC_AUTO

HVAC_HEAT

HVAC_MRNG_WRMUP – Not Used

HVAC_COOL

HVAC_NIGHT_PURGE – Not Used

HVAC_PRE_COOL – Not Used

HVAC_HVAC_OFF

HVAC_HVAC_TEST – Not Used

HVAC_HVAC_EMERG_HEAT – Not Used

Parameter Variable Name Function

Unit Status network output

SNVT_hvac_status nvoUnitStatus

Sub Name Valid Value

HVAC_FAN_ONLY – Not Used

HVAC_MAX_HEAT – Not Used

02: heat_output

_primary

03 heat_output

_secondary

04 cool_output: 0-100%, 0x7FFF (Invalid)

05 econ_output

06 fan_output 0-100%, 0x7FFF (Invalid)

07 In_alarm 0 (No alarms)

Thermostat’s I/O status

network output UNVT_thermo_ state_fc

nvoSccStatus

¾ This network variable output is used to report the Space Comfort

Controller inputs’ and outputs’ status.

Sub Name Valid value True Bit Index

01 bi1 status 0 = activated

02 bi2 status 0 = activated

03 ui3 status 0 = activated

04 dehumidification

active

05 state terminal bo1 0 = Off

06 state terminal bo2 0 = Off

07 state terminal bo3 0 = Off

08 state terminal bo4 0 = Off

09 state terminal bo5 0 = Off

10 fan low 0 = Off

11 fan med 0 = Off

12 fan high 0 = Off

13 window opened 0 = No alarm

14 service alarm 0 = No alarm

15 filter alarm 0 = No alarm

16 local pir motion 0 = No motion Heating/

Cooling demand

network output SNVT_lev_percent

nvoTerminalLoad

¾ This output indicates the current heat/cool energy demand of the

unit. Positive values indicate that cooling energy is in use by the space comfort controller, while negative values indicate that heating energy is in use by the space comfort controller.

¾ Valid Range: -100% to 100%

0-100%, 0x7FFF (Invalid)

Not Used

1 (Alarm On) 0x7FF (Alarming disabled) – Not Used

1 = not activated

0 1 = not activated 0 = Off

7 1 = On

13 1 = On

12 1 = On

15 1 = On

14 1 = On

20 1 = On

21 1 = On

22 1 = On

23 1 = On

24 1 = Alarm on

28 1 = Alarm on

29 1 = Alarm on

39 1 = Motion

Configuration Properties (nci’s) Description

Parameter Variable Name Function

Temperature Setpoints

network input config SNVT_temp_setpt

nciSetPts

¾ This configuration property defines the space temperature

setpoints for various heat, cool and occupancy modes. ¾ Valid Range and Default values: Sub Name Valid Range Default value

01 occupied_cool 54 to 100°F 02 standby_cool 54 to 100°F 03 unoccupied_cool 54 to 100°F 04 occupied_heat 40 to 90°F 05 standby_heat 40 to 90°F 06 unoccupied_heat 40 to 90°F

RH Model Options

network input config

UNVT_cfg_2_fcu_zn

NciCfg2FcuZn

¾ This configuration property defines the space humidity parameters

and their settings. ¾ Valid Range and Default values: Sub Name Valid Range Default value

01 bi1 config 0 = None

02 bi2 config 0 = None

03 ui3 config 0 = None

04 room humidity display 0 = Not active 05 dehumidification

setpoint

06 dehumidification

hysterisys

07 dehumidification max

cooling

08 calib room humidity

sensor

75°F (24.0°C)

(12 to 37.5°C)

78°F (25.5°C)

(12 to 37.5°C)

80°F (26.5°C)

(12 to 37.5°C)

72°F (22.0°C)

(4.5 to 32°C)

69°F (20.5°C)

(4.5 to 32°C)

62°F (16.5°C)

(4.5 to 32°C)

0 = None 1 = Rem NSB 2 = Motion NO 3 = Motion NC 4 = Window

0 = None 1 = Door Dry 2 = Override 3 = Filter 4 = Service

0 = None 1 = COC/NH 2 = COC/NC 3 = COS 4 = SS

0 = Not active 1 = Active 30 to 100% RH 50% RH

2 to 20% RH 5% RH 20 to 100% RH 100% RH

-15 to +15% RH 0% RH

Parameter Variable Name Function

Thermostat Common Configuration Parameters

network input config

UNVT_cfg_1_fcu_zn

nciCfg1FcuZn

¾ This configuration property defines the thermostat’s common

configuration parameters and their settings. ¾ Valid Range and Default values: Sub Name Valid Range Default value

01 password 0 to 1000 0 02 control type 0 = On/Off Control

03 floating actuator time 0.5 to 9 minutes (0.5 04 cycles per hour 3, 4, 5, 6, 7 and 8 05 reverse or direct acting

output 06 temperature scale 0 = °C 07 auto mode 0 = Not Active 08 temperature scale 0 = °C 09 pipes number main out

config 10 sequence of operation 0 = Cooling Only

11 fan menu 0 = Low-Med-High

12 heat maximum

setpoint 13 cool minimum

setpoint 14 calib room sensor ± 5°F (±2.5°C) 0°C

15 deadband 2, 3, 4 or 5 °F 16 setpoint type 0 = Permanent 17 setpoint function 0 = Dual Setpoints

18 temporary occ time 0, 1, 2, 3, up to 24

1 = Floating Control increments) CPH

0 = Direct Acting (DA) 1 = Reverse Acting (RA)

1 = °F 1 = Active 1 = °F

2 = 2 pipe 4 = 4 pipe

1 = Heating Only 2 = Cooling & Reheat 3 = Heating & Reheat 4 = Cooling/Heating 4 pipes 5 = Cooling /Heating 4 pipes & Reheat

1 = Low-High 2 = Low-Med-HighAuto 3 = Low-High-Auto 4 = On-Auto 40 to 90°F (4.5 to 32°C) 54 to 100°F (12 to 37.5°C)

(1 to 2.5°C) 1 = Temporary 1 = Attached

Setpoints hours

0 = On/Off Control

1.5 minutes 4 CPH 0 = Direct

Acting (DA) °F 1 = Active °F 4 pipe 1 = Heating

Only

4 = On-Auto

90°F (32°C) 54°F (12°C)

2°F (1°C) 0 0 = Dual

Setpoints 2 hours

Parameter Variable Name Function

Thermostat Common Configuration Parameters

network input config

UNVT_cfg_1_fcu_zn

nciCfg1FcuZn

¾ This configuration property defines the thermostat’s common

configuration parameters and their settings. ¾ Valid Range and Default values: Sub Name Valid Range Default value

19 proportional band 3 to 10 F 3 F 20 aux contact config 0 = Aux Contact used

21 reheat time base 0 = 15 minutes 22 fan mode 0 = Low

23 auto fan 0 = Auto Speed

24 pir stand-by timer 0.5 to 24.0 Hours 0.5 Hours 25 pir unoccupied timer 0.0 to 24.0 Hours 0.0 Hours

for reheat 1 = Aux NO with occupancy 2 = Aux NC with occupancy 3 = Aux NO with

occupancy & Fan On

4 = Aux NC with

occupancy & Fan On

5 = Remote control

nviAuxOut 1 = 10 seconds 1 = Med

2 = High 3 = Auto 4 = On

1 = Auto Speed and Auto Demand

0 Depending on

Fan Menu Selected

0 = Auto Speed

Parameter Variable Name Function

Thermostat’s model number

network input config UNVT_model_info_2

nciSccModel

¾ This configuration property defines model number and software

version of the thermostat ¾ Valid Range and Default values: Sub Name Valid Range Default value

01 Thermostat

Model

02 Software

Version HVAC UnitType Identifier

network input config SNVT_hvac_type

nciHvacType

¾ This configuration property helps the user identify the type of

equipment being monitored. ¾ Valid Range: Sub Identifier Name

HVT_GENERIC – Not Used

HVT_FAN_COIL

HVT_VAV – Not Used

HVT_HEAT_PUMP– Not Used

HVT_ROOFTOP – Not Used

HVT_UNIT_VENT – Not Used

HVT_CHIL_CEIL – Not Used

HVT_RADIATOR – Not Used

HVT_AHU – Not Used

HVT_SLF_CONT – Not Used Maximum Send Time

network input config

SNVT_time_sec nciSendHrtBt

¾ This configuration property defines the maximum period of that

expires before the specified network variable outputs will automatically be updated

¾ Valid Range: 0 sec. to 6553.4 sec.. Setting nciSendHrtBt to 0

disables the Send Heartbeat mechanism.

¾ Default Null Value : 0.0 sec (no automatic update) Minimum Send Time

network input config SNVT_time_sec

nciMinOutTm

¾ This configuration property defines the minimum period of time

between automatic network variable outputs transmissions.

¾ Valid Range: 0 sec. to 6553.4 sec.. Setting nciRcvHrtBt to 0

disables the Minimum Send Time mechanism.

¾ Default Null Value : 0.0 sec (no minimum send time) Minimum Receive Time

network input config SNVT_time_sec

nciRcvHrtBt

¾ This configuration property is used to control the maximum time

that elapses after the last update to a specified network variable input before the Space Comfort Controller starts to use its default values.

¾ Valid Range: 0 sec. to 6553.4 sec.. Setting nciRcvHrtBt to 0

disables the Receive Heartbeat mechanism.

¾ Default Null Value : 0.0 sec (no failure detected) Hardware or Software revisions Hardware or Software revisions

network input config SCPT_maj_ver

nciMajVer

network input config SCPT_min_ver

nciMinVer

¾ This configuration property defines the major module hardware

and software revisions.

¾ Valid Range: 0 to 255

¾ This configuration property defines the minor module hardware

and software revisions.

¾ Valid Range: 0 to 255

60 = VT7200C 61 = VT7200F

Depend on model

being used 41 = VT7300A 42 = VT7305A 43 = VT7350C 44 = VT7300C 45 = VT7355C 46 = VT7305C 47 = VT7350F 48 = VT7300F 49 = VT7355F 50 = VT7305F Unsigned short Thermostat

dependent

Generic Fan Coil Variable Air Volume Terminal Heat Pump Rooftop Unit Unit Ventilator Chilled Ceiling Radiator Air Handling Unit Self-Contained Unit

Note 1:

How to use nviHeatCool, nviAuxHeatEnable and SeqOpera (Sequence of Operation) variables:

Current nviHeatCool

3 = HVAC_COOL 3 = HVAC_COOL 1 = HVAC_HEAT 1 = HVAC_HEAT

3 = HVAC_COOL 3 = HVAC_COOL 1 = HVAC_HEAT 1 = HVAC_HEAT 0 = HVAC_AUTO 0 = HVAC_AUTO

NviAuxHeat Enable = Enabled

NviAuxHeat Enable = Disabled

Current SeqOpera If nviHeatCool

changed to:

2 Pipe Application

0 = Cooling Only 1= HVAC_HEAT 1 = Heating Only 2 = Cooling & Reheat 1= HVAC_HEAT 3 = Heating & Reheat 1 = Heating Only 3= HVAC_COOL 1 = Cooling Only 3 = Heating & Reheat 3= HVAC_COOL 2 = Cooling & Reheat

4 Pipe Application

0 = Cooling Only 2 = Cooling & Reheat 1 = Heating Only 3 = Heating & Reheat 4 = Cool/Heat 4 Pipes

5 = Cool/Heat 4P &

Reheat

0= HVAC_AUTO 1= HVAC_HEAT 0= HVAC_AUTO 1= HVAC_HEAT 0= HVAC_AUTO 3= HVAC_COOL 0= HVAC_AUTO 3= HVAC_COOL 1= HVAC_HEAT 3= HVAC_COOL 1= HVAC_HEAT 3= HVAC_COOL

New SeqOpera

4 = Cool/Heat 4 Pipes 1 = Heating Only 5 = Cool/Heat 4P & Reheat 3 = Heating & Reheat 4 = Cool/Heat 4 pipes 1 = Cooling Only 5 = Cool/Heat 4P & Reheat 2 = Cooling & Reheat 1 = Heating Only 0 = Cooling Only 3 = Heating & Reheat 2 = Cooling & Reheat

Integration – Global Commands

The following figure shows, which objects from the thermostat, can be monitored and commanded from the BAS front-end.

Figure 1: Global commands from a BAS front-end to a VT7300 series tstat

VT7200X Integration – Graphic User Interface (GUI) objects

The following objects should be typically used in a GUI:

¾ nvoSpaceTemp; ¾ occupied_heat (nciSetpts); ¾ unoccupied_heat (nciSetpts); ¾ occupied_cool (nciSetpts); ¾ unoccupied_cool (nciSetpts); ¾ nvoOutdoorTemp ¾ nvoDischAirTemp ¾ nvoEffectOccup; ¾ heat_output_primary (nvoUnitStatus) ¾ cool_output (nvoUnitStatus) ¾ nvoTerminalLoad ¾ ServiceAlarm (nvoSccStatus) ¾ FilterAlarm (nvoSccStatus) ¾ WindowOpened (nvoSccStatus)

Graphical User Interface (GUI) example of a zoning thermostat

VT73xxX Integration – Graphic User Interface (GUI) objects

The following objects should be typically used in a GUI:

¾ nvoSpaceTemp ¾ occupied_heat (nciSetpts); ¾ unoccupied_heat (nciSetpts); ¾ occupied_cool (nciSetpts); ¾ unoccupied_cool (nciSetpts); ¾ nvoSpaceRH ¾ RHsetpoint (nciRHmodel); ¾ nvoOutdoorTemp ¾ nvoDischAirTemp ¾ nviOccManCmd ¾ nvoEffectOccup ¾ heat_output_primary (nvoUnitStatus) ¾ cool_output (nvoUnitStatus) ¾ ServiceAlarm (nvoSccStatus) ¾ FilterAlarm (nvoSccStatus) ¾ WindowOpened (nvoSccStatus)

Graphical User Interface (GUI) example of a Fan-Coil system

Configuration Property Objects

The following SNVT and UNVT should be typically used for configuration purposes:

¾ nciCfg1FcuZn; ¾ nciCfg2FcuZn; ¾ nciSetpoints;

Wiring Guide

Overview

For clarity we will use the term “Device” to represent any product with an active Echelon network connection, including Vykon and non-Vykon controllers.

Summary Specifications:

Parameter Details

Network Wiring 24 to 16AWG, twisted pair Maximum total wire length1 1600 feet (500 meters) in free topology Maximum device-to-device distance 1600 feet (500 meters) in free topology Polarity Polarity insensitive Multi-drop Free Topology Termination for Free Topology Network Segment Termination for Doubly Terminated Bus Network

One RC network with Ra = 52.3Ω±1%, 1/8W Two RC network with Ra = 105Ω±1%, 1/8W

Segment Number of transceivers per segment Up to 64 Baud rate 78000 bits per second

Network segment length varies depending on wire type.

Table 1: Summary of Specifications for a Vykon’ LON Network

Network Configuration

The Echelon network is designed to support free topology wiring and will accommodate bus, star, loop or any of these topologies. Echelon devices can be located at any point along the network wiring.

Figures 3.1 to 3.5 present five different network topologies. The actual termination circuit will vary by application.

Maximum Number Of Devices

Up to 64 transceivers are allowed per network segment. If your network requires more than 64 transceivers a repeater is then required to extend your network

Maximum Cable Length

The maximum length of a chain is related to its transmission speed. The longer the chain, the slower the speed. Using proper cable, Echelon supports a baud rate of 78 kilobits per second for distances up to 1600ft (500 m) in free topology and 8800 ft (2700 m) in bus topology with double terminations.

If you require a maximum network length of more than 1600-ft (500 m) or 8800 ft (2700 m), then a repeater is required to extend the network.

Repeater

In the event that the limits on the number of transceivers or total wire distance are exceeded, a physical layer repeater can be added to interconnect two or more network segments. A repeater will double the overall channel capability, including node count and network extent, but not bandwidth. Note that only one physical layer repeater should be placed in series between any two nodes on a channel. If additional cabling or network bandwidth is required, then a LonWorks Router should be used in place of a repeater.

Terminators

Echelon network segments requires termination for proper data transmission performance. The type of terminator varies depending on whether shielded or unshielded cable is used. Free topology and Bus networks also differ in their termination requirements. The following sections describe the various terminators and terminations procedure.

Free Topology Network Segment

In a free topology segment, only one termination is required and may be placed anywhere on the free topology segment. There are two choices for the termination:

1. RC network with Ra = 52Ω±1%, 1/8W

2. LPI-10 Link Power Interface, with jumper at “1 CPLR” setting.

Doubly Terminated Network Segment

In a doubly terminated bus topology, two terminations are required, one at each en of the bus. There are two choices for each termination:

1. RC network with Ra = 105Ω±1%, 1/8W

2. LPI-10 Link Power Interface, with jumper at “2 CPLR” setting.

Only one LPI-10 interface is supported per segment. The other terminator must be an RC-type.

Grounding Shielded Twisted Pair Cable

When using Shielded Twisted Pair, terminate the twisted pair as listed in the previous section and ground the cable shield by using a capacitor, to tie the shield to earth ground, and a large-value resistor to bleed off any static charge on the shield. Tying the shield to earth ground through a capacitor will avoid DC and 50/60Hz ground paths from being formed through the shield. Typical values for resistor and capacitor are as follows:

Capacitor = 0.1μF, 10%, Metalized Polyester, ≥ 100V Resistor = 470kΩ, 1/4W, ±5%

The cable shield should be grounded at least once per segment, and preferably at each node. Grounding the shield at every node will assist in suppressing 50/60Hz standing waves.

Network adapter

Although network connections are polarity insensitive, it is good practice to keep polarity consistent throughout the entire site. Figure 4 shows a network connection example and the location of the Status LED. This Status LED may help to troubleshoot network problems.

Figure 4: Network connections and location of the Status LED on a LON module

Table 2 shows the different possibilities with the Status LED behaviour of the LON module.

Condition of the Status LED Explanation

¾ Continuously ON The device has no application loaded in its memory and is

Un-configured

¾ Flashing at a rate of 1/2Hz The device has an application loaded in its memory but is

Un-configured. When a device is in the un-configured state, it does not know which devices to communicate with. A network management tool is used to logically bind the node to another in a LonWorks network.

¾ Continuously OFF The device has an application loaded into its memory and is

bound onto a LonWorks network.

Table 2: Status LED condition

Software Files XIF: When binding a node onto the network, an XIF file is needed. The XIF file has information that is used by

the network management tool to help ease the installation and maintenance process of a node. It is also used for offline configuration of the node.

APB and NXE: When running an application program associated with a XIF file, an APB or NXE file is needed. Please note that the thermostats have the APB file already flashed from the factory.

Device Resource File (DRF): When a LON network management tool is used; a DRF file must be installed. DRF files are needed to display special manufacturer defined variables or configurations correctly.

• Please note that all release notes for the XIF, APB & NXE software files will be included under the

following folder name on your hard drive: C:\LonWorks\Import\Vykon. The name of the file is: VT7xxxReadme.txt

Plug-Ins File: LNS Plug-Ins simplify start-up, maintenance, configuration and reduce the installation effort.

• Please note that all release notes for Plug-Ins files will be included under the following folder

name on your hard drive: C:\LonWorks\Plug-Ins\Vykon\VT7xxx. The name of the file is: Readme.txt.

• All the latest software files can be downloaded from VYKON’ web site at http://www.vykon.com

Vykon VT7200 Series, VT7300 Series Integration Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
