Page 1
Itona TC1520
The new, highly compact Itona TC 1520 desktop is a major breakthrough
in the provision of low cost, virtualisation-capable, thin client computing.
Measuring only 19cm (7.5”) high, this mid-range desktop offers an
affordable solution combined with advanced features and specication
well beyond its rivals. For example, the TC1520 incorporates the VMware
View client as standard making it “virtualisation ready”.
Built to VXL’s exacting specications, the fan-less design ensures the
TC1520 is extremely reliable and together with the energy efcient
power supply, achieves a very low average power consumption.
Backed by VXL’s comprehensive worldwide support network and an
impressive three year warranty, the new Itona represents an unbeatable
combination of affordability, performance, quality and service.
Microsoft Windows XP embedded •
SP3
VMware Virtualisation ready•
ViA C7-M processor (North •
Bridge: VIA VX855
Very small footprint - 19cm •
high x 14.2cm deep
Highly reliable fanless design •
- very low power consumption
512 Mb RAM & 512 Mb Flash •
Memory - Expandable
DVI-I Port (Dual Link).•
5 USB ports•
In-built 10/100/1000 •
Networking
32 Bit graphics•
Fully featured
About VXL
VXL is one of the world’s largest
suppliers of thin clients. Established
in 1976, VXL has grown steadily
and now has over three hundred
people worldwide – with ofces in
Germany, France, India, the United
States and the United Kingdom.
The company’s headquarters are in
Bangalore, India.
Itona TC1520
Mid-Range Desktop Thin Client
Networking ideas thin solutions
Green Credentials
With very low average power consump-
tion of 8 watts, the Energy Star 5.0 rated
Itona is far more efcient than a PC. It is
also substantially lower than the majority
of its competitors.
Remote management included
Every Itona comes with the powerful
XLmanage remote management soft-
ware, Workgroup Edition, making central
management a breeze.
Page 2
Model
TC1520 Windows XPe Sp3 Operating
System.
Standard Client Software
Citrix ICA, RDP, Microsoft Internet
Explorer 7.0, VMware View Client, Media
Player, Ericom Blaze Client, Acrobat
Reader Standard
Processor
VIA C7-M Processor (North •
Bridge: VIA VX855)
System Memory
Ram: 512 Mb & Flash: 512 Mb - •
Expandable
Display Support
Display Data Control (DDC) for •
automatic setting of resolution
and refresh rate
Video RAM: 32/64/128/256 MB, •
Selectable from BIOS (default
32MB). Display Res. 4:3 up
to 1920x1440 32bit colour.
Widescreen up to 1920 x 1200 32
bit colour.
Interfaces
5 x USB 2.0 •
1 x DVI-I port•
Built-in Kensington Security Slot•
Optional Internal USB WIreless •
LAN.
Networking
Autosensing, 10/100/1000 •
Ethernet, RJ-45
Wake On Lan•
PXE boot •
Audio
Line Out•
Mic •
Environmental
Temperature Range : Powered •
on: 5 to 35 ˚C
Powered off: –20 to 60 ˚C•
Convectional cooling, fanless •
design
Humidity : 20% to 80% •
maximum, non-condensing
Physical Characteristics
External power adapter with full •
range.
autosensing AC adapter •
(100/240 V) for worldwide usage
Height: 190 mm •
Depth: 142 mm •
Width: 36.5 mm•
Weight: Approx 0.7Kg•
Software
RDP Client 7.x•
Citrix ICA client 11.xx•
Internet Explorer 7.0: HTML, •
MHTML, XML, Active X, Media
Player, Citrix web client
VMware View Client•
Ericom Webconnect•
Ericom Blaze Client•
.Net Framework 2.0 • *
Leostream Client • *
NX Client • *
VNC Client •
Plug-ins: Adobe Acrobat Reader, •
Adobe Server OS compatibility
Server OS Compatibility/Support :
Microsoft Windows Terminal •
Server Edition,Windows server
2000, 2003 and 2008
Citrix MetaFrame, XEN APP•
Protocol Support :TCP/IP, NTP, •
DHCP, FTP, HTTP
Setup and Conguration:
Boot from Local ash•
Windows XP user interface •
language : US English French,
German, Spanish, italian, Dutch,
Turkish, Japanese optional add-
on’s,
Keyboard Language support: •
US English standard 36 other
languages supported.
Scanners & Camera Support•
VPN•
Customizable Thin print•
Smartcard Support•
ELO Touch screen Support•
PPP/DIAL-UP-Networking•
USB Input Devices Support•
My ODBC Client Support•
Management:
Remote management, •
conguration, and upgrades
through XLmanage client
management software version
1.29 or later
Wake terminal remotely (Wake-•
on-LAN)
Terminal conguration (IP •
information, name, etc.)
Remote Shadowing•
Reporting •
Regulatory Compliance
Ergonomics: German EKI-ITB •
2000
Safty: cULus, TUV-GS,•
RF Interference: FCC B, CE, RoHS, •
WEEE, Energy Star 5.0
Warranty
Three years limited warranty•
E & OE: Specications subject to change without notice. All trademarks are acknowledged and remain the property of their respective owners.
Head Ofce: ‘House of Excellence’, No 17 Electronics City, Hosur Road, Bangalore 560 100, India
European Headquarters: Carrington Business Park, Carrington, Manchester, UK M31 4DD
Regional Ofces France Germany United States
Tel: +33 (0) 1 42 17 00 03 Tel: +49 (0) 8761 1093 Tel: +1 713 589 3273
Itona TC1520
Networking ideas thin solutions
Part No
TC1520 - F5R5 512 MB Flash / 512 MB RAM
TC1520 - F6R6 1 GB Flash / 1 GB RAM
TC1520 - F7R7 2 GB Flash / 2 GB RAM
* Software option available only with 1GB and higher Flash size.
