Itona D51S
A exible, expandable, 1.6GHz high performance thin client designed
to deliver excellent productivity and functionality. The new Itona DS
series thin client represents a signicant advance in the provision of
low cost server based computing. Highly specied with exceptional
build quality, this thin client incorporates the most advanced features
designed to handle the most demanding applications.
Not only is the D51S a powerful and innovative thin client, it’s also
designed with the environment and durability in mind. The efcient
internal power supply combined with fan-less design ensures extremely
low power consumption with excellent reliability and virtually silent
operation.
The Itona D51S incorporates an impressive three year warranty
backed by a worldwide support network and represents an unbeatable
combination of affordability, quality, performance and service.
Linux SUSE operating system•
VIA C7 1.6 GHz processor•
North Bridge : VIA VX800•
Highly reliable fanless design •
- very low power consumption
1 GB RAM & 1 GB GB Flash •
Memory - Expandable
4 USB ports•
In-built 10/100/1000 •
Networking
32 Bit graphics supports •
1920 x 1200 wide screen
resolution
Fully featured
About VXL
VXL is one of the world’s largest
suppliers of thin clients. Established
in 1976, VXL has grown steadily
and now has over three hundred
people worldwide – with ofces in
Germany, France, India, the United
States and the United Kingdom.
The company’s headquarters are in
Bangalore, India.
Itona D51S
High Performance Desktop Thin Client
Networking ideas thin solutions
The ideal desktop client
Seen and not heard – that’s Itona. That’s
because its fan-less design ensures
totally silent operation. And, of course,
it is pleasing and compact – freeing up
valuable desk space.
Green Credentials
With an average power consumption of
only 10.3 watts, the Itona is more than 4
times more efcient than a PC. It is also
substantially lower than almost all its
competitors.
Page 2
Model
D51S Linux SUSE Operating System.
Standard Client Software
XDMCP, ICA, PN Agent, RDP, VNC,
VMware View Client, REXEC standard,
PPTP VPN, Mozilla Browser, Open Ofce
Processor
VIA C7 1.6 GHz Processor (North •
Bridge: VIA VX800
System Memory
Ram: 1 GB & Flash: 1 GB - •
Expandable
Display Support
Display Data Control (DDC) for •
automatic setting of resolution and
refresh rate
Video RAM: 16/32/64/128/256 •
MB. Selectable from BIOS (default
32MB). Display Res. 4:3 up to
1920x1440 32bit colour. Widescreen
up to 1920 x 1200 32 bit colour.
Interfaces
2 x Serial Port with optional 3rd•
4 x USB 2.0 •
2 x PS/2 port•
1 x VGA type video output•
1 x DVI-I Port•
Optional internal Wireless and/or •
Smartcard reader
Built-in Kensington Security Slot•
Networking
Autosensing, 10/100/1000 Ethernet•
Wake On Lan•
PXE boot •
Audio
Line Out & Mic •
Environmental
Powered on: 0 to 40 ˚C •
Powered off: –20 to 60 ˚C•
Convectional cooling, fanless design•
Humidity : 20% to 80% maximum, •
non-condensing
Physical Characteristics
Worldwide auto-sensing •
100-240 VAC
External Power Supply•
50/60 Hz, less than 20W (max)•
Average power usage: 10.3 •
Watts(Only with KBD, Mouse and
Monitor)
Height: 229 mm •
Depth: 226 mm •
Width: 50 mm•
Weight: Approx 2.5Kg •
Software
Citrix ICA latest client •
RDP6 x Compatible CLient•
Mozilla Browser with Multimedia •
Java, other plugin support
Open Ofce•
Ericom Webconect•
NX Client•
Quest Access Client•
VMware View Client•
PPTP VPN•
VNC Client •
VNC Shadowing•
SAMBA Support•
XDMCP Protocol: Remote X •
connection based on X server.
ThinPrint Client Agent•
Rexec command, RSH, SSH, •
LaunchPA , telnet, CMD standard
Local Operating System feature :
Updated latest Kernel•
X11R6 local windows manager•
LPR, ThinPrint, CUPS, SAMBA print •
support
Touch screen support•
Server OS Compatibility/Support :
Microsoft Windows Terminal Server •
Edition,Windows server 2003/2008
Citrix XenApp / Citrix Presentation •
Server/ Citrix XenDesktop.
UNIX/Linux Servers (Redhat etc)•
Protocol Support :TCP/IP, NTP, DHCP, •
FTP, HTTP
User Interface:
Boot from Local ash•
User Interface Language: US English, •
French, German.
Keyboard language support: U.S. •
English Standard, French, German,
Italian,U.K English, 30 others
included.
Management:
Remote management, conguration, •
and upgrades through XLmanage
client management software
(included)
Wake terminal remotely (Wake-on-•
LAN)
Terminal conguration (IP •
information, name, etc.)
Remote Shadowing•
Complete image upgrade•
Pull/Push Updates •
Regulatory Compliance
Ergonomics: German EKI-ITB 2000•
Safty: cTUVus, TUV-GS, VCCI•
RF Interference: FCC B, CE, C-Tick •
RoHS, WEEE, Energy Star 5.0.
Warranty
Three years limited warranty•
E & OE: Specications subject to change without notice. All trademarks are acknowledged and remain the property of their respective owners.
Head Ofce: ‘House of Excellence’, No 17 Electronics City, Hosur Road, Bangalore 560 100, India
Tel: +91 80 30222525 (5 lines) Fax: +91 80 28520095 E-mail: [email protected] Web: www.vxl.net
European Headquarters: Carrington Business Park, Carrington, Manchester, UK M31 4DD
Tel: +44 (0) 16 17 75 47 55 Fax: +44 (0) 16 17 75 48 66 E-mail: [email protected]
Regional Ofces France Germany United States
Tel: +33 (0) 1 42 17 00 03 Tel: +49 (0) 8761 1093 Tel: +1 713 589 3273
Itona D51S
Networking ideas thin solutions
Part No
D51S - F6R6 1 GB Flash / 1 GB RAM
