VXI VM4016 User Manual

s

VM4016

ANALOG COMPARATOR

USER’S

ANUAL

M

82-0022-000

Rev. December 1, 2003

VXI Technology, Inc.

2031 Main Street

Irvine, CA 92614-6509

[phone]

bu

2

www.vxitech.com

TABLE OF CONTENTS

NTRODUCTION

I

Certification ..........................................................................................................................................................5

Warranty ...............................................................................................................................................................5

Limitation of Warranty .........................................................................................................................................5

Restricted Rights Legend......................................................................................................................................5

Declaration of Conformity.......................................................................................................................................6

General Safety Instructions......................................................................................................................................7

Terms and Symbols...............................................................................................................................................7

Warnings...............................................................................................................................................................7

Support Resources ...................................................................................................................................................9

SECTION 1.................................................................................................................................................................11

Introduction............................................................................................................................................................11

Introduction.........................................................................................................................................................11

Description..........................................................................................................................................................12

VM4016 General Specifications.........................................................................................................................14

SECTION 2.................................................................................................................................................................15

Preparation for Use ................................................................................................................................................15

Installation ..........................................................................................................................................................15

Calculating System Power and Cooling Requirements.......................................................................................15

Setting the Chassis Backplane Jumpers ..............................................................................................................16

Setting the Logical Address ................................................................................................................................16

Front Panel Interface Wiring ..............................................................................................................................16

SECTION 3.................................................................................................................................................................19

Programming .........................................................................................................................................................19

Examples of SCPI Commands............................................................................................................................19

FETCH:CONDITIONED? ..............................................................................................................................19

FETCH:LATCHED? .......................................................................................................................................20

FETCH:RAW? ................................................................................................................................................21

INHOUSE:PSEUDO.......................................................................................................................................22

INHOUSE:REGINT........................................................................................................................................23

INHOUSE:REG_ENABLE.............................................................................................................................24

INHOUSE:CLEAR_LATCH ..........................................................................................................................25

INPUT:DEBOUNCE.......................................................................................................................................26

INPUT:MASK.................................................................................................................................................27

INPUT:MASK:INTERRUPT..........................................................................................................................28

INPUT:OFFSET..............................................................................................................................................29

INPUT:POLARITY.........................................................................................................................................30

INPUT:RANGE ..............................................................................................................................................31

OUTPUT:POLARITY:EXTERNAL:INTERRUPT .......................................................................................32

OUTPUT:POLARITY:EXTERNAL:LATCHED...........................................................................................33

Application Examples............................................................................................................................................34

Single Channel Operation ...................................................................................................................................35

Bracketing a Voltage...........................................................................................................................................38

Register Access Examples .....................................................................................................................................41

Pseudo Register Access ......................................................................................................................................43

VXIplug&play Driver Examples...........................................................................................................................44

SECTION 4.................................................................................................................................................................47

Command Dictionary.............................................................................................................................................47

Introduction.........................................................................................................................................................47

Alphabetical Command Listing ..........................................................................................................................47

Command Dictionary..........................................................................................................................................51

VM4016 Preface 3

VXI Technology, Inc.

Common SCPI Commands....................................................................................................................................52

*CLS ...................................................................................................................................................................52

*ESE ...................................................................................................................................................................53

*ESR? .................................................................................................................................................................54

*IDN? .................................................................................................................................................................55

*OPC...................................................................................................................................................................56

*RST ...................................................................................................................................................................57

*SRE ...................................................................................................................................................................58

*STB? .................................................................................................................................................................59

*TRG ..................................................................................................................................................................60

*TST? .................................................................................................................................................................61

*WAI ..................................................................................................................................................................62

Instrument Specific SCPI Commands....................................................................................................................63

FETCh:CONDitioned? .......................................................................................................................................63

FETCh:LATChed?..............................................................................................................................................64

FETCh:RAW? ....................................................................................................................................................65

INHOUSE:CLEAR_LATCH .............................................................................................................................66

INHOUSE:PSEUDO ..........................................................................................................................................67

INHOUSE:REGINT ...........................................................................................................................................68

INHOUSE:REG_ENABLE ................................................................................................................................69

INPut:DEBounce ................................................................................................................................................70

INPut:MASK ......................................................................................................................................................71

INPut:MASK:INTerrupt .....................................................................................................................................72

INPut:OFFSet .....................................................................................................................................................73

INPut:POLarity...................................................................................................................................................74

INPut:RANGe.....................................................................................................................................................75

OUTPut:POLarity:EXTernal:INTerrupt.............................................................................................................76

OUTPut:POLarity:EXTernal:LATChed.............................................................................................................77

Required SCPI Commands ....................................................................................................................................78

STATus:OPERation:CONDition? ......................................................................................................................78

STATus:OPERation:ENABle.............................................................................................................................79

STATus:OPERation[:EVENt]? ..........................................................................................................................80

STATus:PRESet .................................................................................................................................................81

STATus:QUEStionable:CONDition? .................................................................................................................82

STATus:QUEStionable:ENABle........................................................................................................................83

STATus:QUEStionable[:EVENt] .......................................................................................................................84

SYSTem:ERRor?................................................................................................................................................85

SYSTem:VERSion?............................................................................................................................................86

SECTION 5.................................................................................................................................................................87

Theory of Operation ..............................................................................................................................................87

Introduction.........................................................................................................................................................87

Input Range Control............................................................................................................................................88

Signal Comparison..............................................................................................................................................90

Interrupt Generation............................................................................................................................................91

INDEX........................................................................................................................................................................93

4 VM4016 Preface

www.vxitech.com

CERTIFICATION

VXI Technology, Inc. (VTI) certifies that this product met its published specifications at the time of shipment from
the factory. VTI further certifies that its calibration measurements are traceable to the United States National
Institute of Standards and Technology (formerly National Bureau of Standards), to the extent allowed by that
organization’s calibration facility, and to the calibration facilities of other International Standards Organization
members.

WARRANTY

The product referred to herein is warranted against defects in material and workmanship for a period of three years
from the receipt date of the product at customer’s facility. The sole and exclusive remedy for breach of any
warranty concerning these goods shall be repair or replacement of defective parts, or a refund of the purchase price,
to be determined at the option of VTI.

For warranty service or repair, this product must be returned to a VXI Technology authorized service center. The
product shall be shipped prepaid to VTI and VTI shall prepay all returns of the product to the buyer. However, the
buyer shall pay all shipping charges, duties, and taxes for products returned to VTI from another country.

VTI warrants that its software and firmware designated by VTI for use with a product will execute its programming
when properly installed on that product. VTI does not however warrant that the operation of the product, or
software or firmware will be uninterrupted or error free.

LIMITATION OF WARRANTY

The warranty shall not apply to defects resulting from improper or inadequate maintenance by the buyer, buyer­supplied products or interfacing, unauthorized modification or misuse, operation outside the environmental
specifications for the product, or improper site preparation or maintenance.

VXI Technology, Inc. shall not be liable for injury to property other than the goods themselves. Other than the
limited warranty stated above, VXI Technology, Inc. makes no other warranties, express or implied, with respect to
the quality of product beyond the description of the goods on the face of the contract. VTI specifically disclaims the
implied warranties of merchantability and fitness for a particular purpose.

RESTRICTED RIGHTS LEGEND

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subdivision (b)(3)(ii) of
the Rights in Technical Data and Computer Software clause in DFARS 252.227-7013.

VXI Technology, Inc.
2031 Main Street
Irvine, CA 92614-6509 U.S.A.

VM4016 Preface 5

VXI Technology, Inc.

D ECLARATION OF C ONFORMITY

Declaration of Conformity According to ISO/IEC Guide 22 and EN 45014

M

ANUFACTURER’S NAME VXI Technology, Inc.

ANUFACTURER’S ADDRESS 2031 Main Street

M

Irvine, California 92614-6509

RODUCT NAME Analog Comparator

P

ODEL NUMBER(S) VM4016

M

P

RODUCT OPTIONS All

RODUCT CONFIGURATIONS All

P

VXI Technology, Inc. declares that the aforementioned product conforms to the requirements of
the Low Voltage Directive 73/23/EEC and the EMC Directive 89/366/EEC (inclusive 93/68/EEC)
and carries the “CE” mark accordingly. The product has been designed and manufactured
according to the following specifications:

AFETY EN61010 (2001)

S

EMC EN61326 (1997 w/A1:98) Class A

CISPR 22 (1997) Class A
VCCI (April 2000) Class A
ICES-003 Class A (ANSI C63.4 1992)
AS/NZS 3548 (w/A1 & A2:97) Class A
FCC Part 15 Subpart B Class A
EN 61010-1:2001

The product was installed into a C-size VXI mainframe chassis and tested in a typical configuration.

I hereby declare that the aforementioned product has been designed to be in compliance with the relevant sections
of the specifications listed above as well as complying with all essential requirements of the Low Voltage Directive.

December 2003

_________________________

Jerry Patton, QA Manager

6 VM4016 Preface

www.vxitech.com

Review the following safety precautions to avoid bodily injury and/or damage to the product.
These precautions must be observed during all phases of operation or service of this product.
Failure to comply with these precautions, or with specific warnings elsewhere in this manual,
violates safety standards of design, manufacture, and intended use of the product.

Service should only be performed by qualified personnel.

TERMS AND SYMBOLS

These terms may appear in this manual:

WARNING

CAUTION

These symbols may appear on the product:

GENERAL SAFETY INSTRUCTIONS

Indicates that a procedure or condition may cause bodily injury or death.

Indicates that a procedure or condition could possibly cause damage to
equipment or loss of data.

WARNINGS

ATTENTION - Important safety instructions

Follow these precautions to avoid injury or damage to the product:

Use Proper Power Cord

Use Proper Power Source

Use Proper Fuse

Frame or chassis ground

To avoid hazard, only use the power cord specified for this
product.

To avoid electrical overload, electric shock, or fire hazard,
do not use a power source that applies other than the
specified voltage.

To avoid fire hazard, only use the type and rating fuse
specified for this product.

VM4016 Preface 7

WARNINGS (CONT.)

Avoid Electric Shock

Ground the Product

Operating Conditions

Improper Use

VXI Technology, Inc.

To avoid electric shock or fire hazard, do not operate this
product with the covers removed. Do not connect or
disconnect any cable, probes, test leads, etc. while they are
connected to a voltage source. Remove all power and

unplug unit before performing any service. Service should

only be performed by qualified personnel.

This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground.

To avoid injury, electric shock or fire hazard:

- Do not operate in wet or damp conditions.

- Do not operate in an explosive atmosphere.

- Operate or store only in specified temperature range.

- Provide proper clearance for product ventilation to
prevent overheating.

- DO NOT operate if you suspect there is any damage to

this product. Product should be inspected or serviced

only by qualified personnel.

The operator of this instrument is advised that if

equipment is used in a manner not specified in this
manual, the protection provided by this equipment be
may be impaired.

8 VM4016 Preface

www.vxitech.com

SUPPORT RESOURCES

Support resources for this product are available on the Internet and at VXI Technology customer
support centers.

VXI Technology
World Headquarters

VXI Technology, Inc.
2031 Main Street
Irvine, CA 92614-6509

Phone: [phone]
Fax: [phone]

VXI Technology
Cleveland Instrument Division

VXI Technology, Inc.
7525 Granger Road, Unit 7
Valley View, OH 44125

Phone: [phone]
Fax: [phone]

VXI Technology
Lake Stevens Instrument Division

VXI Technology, Inc.
1924 - 203 Bickford
Snohomish, WA 98290

Phone: [phone]
Fax: [phone]

Technical Support

Phone: [phone]
Fax: [phone]
E-mail: [e-mail]

Visit http://www.vxitech.com for worldwide support sites and service plan information.

VM4016 Preface 9

VXI Technology, Inc.

10 VM4016 Preface

www.vxitech.com

A

V

V

V

SECTION 1

INTRODUCTION

INTRODUCTION

The VM4016 is a high-performance Analog Comparator module which has been designed to
monitor analog signals and cause VXIbus interrupts to occur when programmed input limits have
been exceeded. The instrument uses the message-based word serial interface for programming
and data movement, as well as supporting direct register access for very high-speed data retrieval.
The VM4016 command set conforms with the SCPI standard for consistency and ease of
programming.

The VM4016 is a member of the VXI Technology VMIP™ (VXI Modular Instrumentation
Platform) family and is available as a 16-, 32- or 48-channel, single-wide VXIbus instrument. In

addition to these three standard configurations, the VM4016 may be combined with any of the
other members of the VMIP family to form a customized and highly integrated instrument (see
Figure 1-1). This allows the user to reduce system size and cost by combining the VM4016 with
two other instrument functions in a single-wide C-size VXIbus module. Figure 1-2 shows the
48-channel version of the VM4016. The 32-channel version would not have J200 and its
associated LEDs and nomenclature while the 16-channel version would also eliminate J202.

MIP

INSTRUMENT

MODULE #1

I
N
T
E

V
X

I
B
U
S

MIP

INTERFACE

R
N

L

M
P
B

U
S

MIP

INSTRUMENT

V
I

MODULE #2

VMIP

INSTRUMENT

MODULE #3

FIGURE 1-1: VMIP™ PLATFORM

VM4016 Preparation for Use 11

VXI Technology, Inc.

Regardless of whether the VM4016 is configured with other VM4016 modules or with
other VMIPmodules, each group of 16 channels is treated as an independent instrument
in the VXIbus chassis and, as such, each group has its own FAIL and ACCESS light.

The FAIL LED is a Power/Fault indicator. When normal power up conditions exist, the
FAIL LED will illuminate green. When a power on fault condition occurs, the FAIL

ACC/
ERR

FAIL

LED will illuminate red. The ACC/ERR LED indicates communication status. When a
successful Access occurs, the LED will blink green during data transfer and
command/query operations. In the event of an unrecognized command, or other data
related error, the ACC/ERR LED will illuminate red. If there is no command/query
activity, and no errors, the ACC/ERR LED will be extinguished. The normal state of the
LEDs on a properly functioning idle instrument is for the FAIL LED to be green, and the
ACC/ERR LED to be off.

DESCRIPTION

The VM4016 is a high-performance Analog Comparator module with 16 input channels

J200

per VMIP daughter module. Each input channel consists of a differential amplifier with
a gain of 1 or 0.1 giving an input range of ±10 volts or ±100 volts. Each input is

ACC/
ERR

FAIL

compared against a reference voltage derived from an independent 8-bit DAC.

Each input signal is digitally debounced for a programmed time ranging from

µ

approximately 10

s to 0.5 seconds. This prevents input signal noise from causing
undesired interrupts. After debounce, the signal may be programmatically inverted to
select the input transition edge of interest (rising or falling edge) and masked to prevent
unused channels from causing interrupts.

All of the masked inputs are OR’d together to produce a single interrupt signal. This
interrupt signal is used to generate a VXIbus interrupt as well as the front panel interrupt
outputs. All active input is recorded as a 1. Once the VXIbus interrupt is serviced by the
slot 0 controller, the First Latched Register will be cleared.

J201

The state of each channel’s debounced input and the inverted and masked status may be

ACC/
ERR

FAIL

read directly in the user defined area of the VXIbus registers as can the First Latched
register. This information may also be retrieved using the message-based word serial
interface.

The block diagram of Figure 1-3 shows the overall functionality of the VM4016 Analog
Comparator instrument.

J202

bus

FIGURE 1-2: FRONT PANEL LAYOUT

12 VM4016 Preparation for Use

www.vxitech.com

V

XI MODULE

PANEL

CH1+
CH1-

DIFFERENTIAL

AMPLIFIER
X1 OR X0.1

CHANNEL 1 OF

COMPARATOR

DEBOUNCE

10 uS TO 0.5 S

TO VXIBU S
COMPARE

REGISTERS

8 BIT DAC

+5V

IRQ

CHANNEL 16 OF

INVER T

REGISTER

FIRST LIMIT

INVER T

REGISTER

INTERRUPT

INVER T

REGISTER

MASK

REGISTER

FIRST LIMIT

LATCH

REGISTER

INTERRUPT
AND FIRST
LIMIT LOGIC

VXIbus

INTERR UPT

TO VXI BUS
FIRST LIMIT

REGISTER

+5V

L IRQ

FIGURE 1-3: VM4016 BLOCK DIAGRAM

VM4016 Preparation for Use 13

GENERAL SPECIFICATIONS

CHANNELS
VM4016-1
VM4016-2
VM4016-3
INPUT RANGE

INPUT THRESHOLD
±10.0 V
±100.0 V
INPUT TYPE

INPUT IMPEDANCE

INPUT POLARITY

DEBOUNCE TIME

IRQ OUTPUT

LATCHED IRQ OUTPUT

VXI INTERFACE

LOGICAL ADDRESSING

RAW DATA REGISTER

MASKED DATA REGISTER

FIRST LATCHED REGISTER

POWER REQUIREMENTS
VM4016-1
VM4016-2
VM4016-3
COOLING REQUIREMENTS
VM4016-1
VM4016-2
VM4016-3

VXI Technology, Inc.

VM4016 GENERAL SPECIFICATIONS

16
32
48

±10.0 V, ±100 V

78 mV
780 mV

Differential, may be configured for single-ended by grounding the negative input

200 kΩ Differential
100 kΩ Single-ended

Rising or Falling Edge

9.6 µs to 0.6291456 s, 9.6 µs resolution

Open Collector Driver, 200 mA max. sink
Internally pulled up to +5 V with 10 k resistor

Open Collector Driver, 200 mA max. sink
Internally pulled up to +5 V with 10 k resistor

Message-based word serial interface
Direct register access in the user defined area of the VXIbus register map

Static or Dynamic Configuration

Logical Address + 20H

Logical Address + 28H

Logical Address + 30H

+5 V @ 1.43 A, -5.2 V @ 0.17 A, +24 V @ 0.05 A, -24 V @ 0.05 A
+5 V @ 2.12 A, -5.2 V @ 0.29 A, +24 V @ 0.10 A, -24 V @ 0.10 A
+5 V @ 2.81 A, -5.2 V @ 0.41 A, +24 V @ 0.15 A, -24 V @ 0.15 A

See Power Cooling Table
See Power Cooling Table
See Power Cooling Table

14 VM4016 Preparation for Use

www.vxitech.com

Section 2

SECTION 2

PREPARATION FOR USE

INSTALLATION

When the VM4016 is unpacked from its shipping carton, the contents should include the
following items:

One VM4016 VXIbus module
One VM4016 Analog Comparator Module User’s Manual (this manual)

All components should be immediately inspected for damage upon receipt of the unit.

Once the VM4016 is assessed to be in good condition, it may be installed into an appropriate
C-size or D-size VXIbus chassis in any slot other than slot 0. The chassis should be checked to
ensure that it is capable of providing adequate power and cooling for the VM4016. Once the
chassis is found be adequate, the VM4016’s logical address and the chassis’ backplane jumpers
should be configured prior to the VM4016’s installation.

CALCULATING SYSTEM POWER AND COOLING REQUIREMENTS

It is imperative that the chassis provide adequate power and cooling for this module. Referring to
the chassis user’s manual, confirm that the power budget for the system (the chassis and all
modules installed therein) is not exceeded and that the cooling system can provide adequate
airflow at the specified backpressure.

It should be noted that if the chassis cannot provide adequate power to the module, the instrument
may not perform to specification or possibly not operate at all. In addition, if adequate cooling is
not provided, the reliability of the instrument will be jeopardized and permanent damage may
occur. Damage found to have occurred due to inadequate cooling would also void the warranty of
the module.

VM4016 Preparation for Use 15

SETTING THE CHASSIS BACKPLANE JUMPERS

Please refer to the chassis User’s Manual for further details on setting the backplane jumpers.

SETTING THE LOGICAL ADDRESS

The logical address of the VM4016 is set by a single 8-position DIP switch located near the
module’s backplane connectors (this is the only switch on the module). The switch is labeled with
positions 1 through 8 and with an ON position. A switch pushed toward the ON legend will
signify a logic 1; switches pushed away from the ON legend will signify a logic 0. The switch
located at position 1 is the least significant bit while the switch located at position 8 is the most
significant bit. See Figure 2-1 for examples of setting the logical address switch.

VXI Technology, Inc.

ON ON

1ON2345678

SET TO 4

ON ON

12345678

SET TO 168

1ON2345678

SET TO 8

1

2345678

SET TO 255

(Dynamic)

Switch

Position

1
2
3
4
5
6
7
8

Switch

Value

1
2
4
8

16
32
64

128

FIGURE 2-1: LOGICAL ADDRESS SWITCH SETTING EXAMPLES

The VMIP may contain three separate instruments and will allocate logical addresses as required
by the VXIbus specification (revisions 1.3 and 1.4). It is necessary that the address of the first
instrument (the instrument closest to the top of the module) be set at an address which is divisible
by 4 and not set to 0. Switch positions 0 and 1 must always be set to the OFF position. Therefore
only addresses of 4, 8, 12, 16 ... 252 are allowed. The address switch should be set for one of
these legal addresses and the address for the second instrument (the instrument in the center
position) will automatically be set to the switch set address plus one; while the third instrument
(the instrument in the lowest position) will automatically be set to the switch set address plus two.

If dynamic address configuration is desired, the address switch should be set for a value of 255.
Upon power-up, the slot 0 resource manager will assign logical addresses to each instrument in
the VMIP module.

FRONT PANEL INTERFACE WIRING

The VM4016’s interface is made available on the front panel of the instrument. The 16-channel
version (VM4016-1) will have J201 that contains all signals for this instrument. The 32-channel
version (VM4016-2) will have J201 and J202 provided, while the 48-channel version (VM4016-

3) will have J200, J201 and J202. The wiring for each of these connectors is identical and since
each group of 16 channels is treated as a separate instrument, the module will have three Channel
1s, three Channel 2s, three Channel 3s, etc.

16 VM4016 Preparation for Use

www.vxitech.com

CHANNEL 1 + 1 GROUND 23
CHANNEL 1 - 2 CHANNEL 11 + 24
GROUND 3 CHANNEL 11 - 25
CHANNEL 4 + 4 CHANNEL 14 + 26
CHANNEL 4 - 5 CHANNEL 14 - 27
CHANNEL 7 + 6 GROUND 28
CHANNEL 7 - 7 CHANNEL 16 + 29
GROUND 8 CHANNEL 16 - 30
CHANNEL 10 + 9 CHANNEL 3 + 31
CHANNEL 10 - 10 CHANNEL 3 - 32
CHANNEL 13 + 11 GROUND 33
CHANNEL 13 - 12 CHANNEL 6 + 34
GROUND 13 CHANNEL 6 - 35
IRQ OUTPUT 14 CHANNEL 9 + 36
GROUND 15 CHANNEL 9 - 37
CHANNEL 2 + 16 GROUND 38
CHANNEL 2 - 17 CHANNEL 12 + 39
GROUND 18 CHANNEL 12 - 40
CHANNEL 5 + 19 CHANNEL 15 + 41
CHANNEL 5 - 20 CHANNEL 15 - 42
CHANNEL 8 + 21 GROUND 43
CHANNEL 8 - 22 LATCHED IRQ OUT 44

The connector used in the VM4016 is a commonly available 44-pin high density DSUB receptacle
connector. A mating solder cup pin connector from AMP is included, crimp type connectors are
available from a variety of sources.

TABLE 2-1: ANALOG COMPARATOR PIN OUTS

SIGNAL PIN NUMBER SIGNAL PIN NUMBER

VM4016 Preparation for Use 17

VXI Technology, Inc.

The mating connector to J200, J201 or J202 is available from the following company:

Assmann Electronic, Inc. P/N AHDS44LL-T Mating Connector

The pin locations for J200, J201 and J202 are shown in Figure 2-2.

16

31

1

44

15

30

FIGURE 2-2: J200, J201 AND J202 PIN LOCATIONS

18 VM4016 Preparation for Use

www.vxitech.com

SECTION 3

PROGRAMMING

EXAMPLES OF SCPI COMMANDS

FETCH:CONDITIONED?

The FETCh:CONDition query returns the 16-bit value that represents the current conditioned
(masked and inverted) state of the inputs. It is important to note that this information is also
available at the VXIbus register level at offset 0x28.

FETCh:CONDitioned? No query parameters.

EXAMPLES

FETCh:CONDitioned? Returns the state of the conditioned 0

(masked and inverted) inputs.

VM4016 Programming 19

VXI Technology, Inc.

FETCH:LATCHED?

The FETCh:LATChed query returns a 16-bit value that reports the active signals in the First
Latched register. The First Latched register records the active signals when the first new input
channel crossed its threshold. It is important to note that the above information is also available at
the VXIbus register level at offset 0x30.

FETch:LATChed? No query parameters

EXAMPLES

FETCh:LATChed? Returns the active signals in the First
1 Latched register. Channel 1.

FETC:LATC? Returns the active signals in the First
3 Latched Register. Channels 1 and 2.

20 VM4016 Programming

www.vxitech.com

FETCH:RAW?

The FETCh:RAW query returns the 16-bit value that represents the current unconditioned
(unmasked and non-inverted) state of the inputs. It is important to note that the above information
is also available at the register level at offset 0x20.

FETCH:RAW? No query parameters

EXAMPLES

FETch:RAW? Returns the state of the unconditioned
1 (unmasked and non-inverted) inputs

Channel 1.

FETC:RAW? All 16 channels crossed the programmed
65535 threshold.

VM4016 Programming 21

VXI Technology, Inc.

INHOUSE:PSEUDO

The INHOUSE:PSEUDO command controls the use of the register interface. Pseudo set true
specifies that pseudo register interface should be used. Pseudo set false specifies that the
hardware register interface should be used. The value set takes effect next time the unit powers
up [does not take effect immediately]. The pseudo register interface allows the use of
REG_ENABLE and CLEAR_LATCH capability from the registers. Although the hardware
register interface is much faster than the pseudo register interface, it lacks the above two features.
It is important to note that when the module is shipped from the factory, pseudo is set to 1. It is
also important to note that all letters of the command must be provided as there is no short form
for this command.

INHOUSE:PSEUDO <boolean> Where <boolean> is 0 | OFF | 1 | ON.

EXAMPLES

INHOUSE:PSEUDO 1 Sets the pseudo register interface ON. (The

unit must be powered for the change to take
effect.)

INHOUSE:PSEUDO? Returns 1 which states that the register
1 interface is set to pseudo.

22 VM4016 Programming

www.vxitech.com

INHOUSE:REGINT

The INHOUSE:REGINT command controls the type of module’s response to an interrupt
acknowledge cycle [ack cycle]. When regint is set to false, the module uses reqt | reqf (request
true | request false), provided the latched interrupt bit is set in the SRE.

It is important to note that all the letters of the command must be provided as there is no short
form for this command.

INHOUSE:REGINT <boolean> Where <boolean> is 0 | OFF | 1 | ON.

EXAMPLES

INHOUSE:REGINT 1 Sets the type of module interrupt response to

one backplane interrupts for every first
latched event.

INHOUSE:REGINT? Returns the type of module interrupt
1 response as 1.

INHOUSE:REGINT 0 Sets the type of module interrupt response

as two backplane interrupts for each latched
event.

INHOUSE:REGENT? Returns the type of module interrupt
0 response as 0.

VM4016 Programming 23

VXI Technology, Inc.

INHOUSE:REG_ENABLE

The INHOUSE:REG_ENABLE command controls the masking for REGINT. REG_ENABLE 0
means that backplane interrupts cannot be generated. If the REG_ENABLE is 1, then backplane
interrupts can be generated. If PSEUDO is set, then a write to the register at offset 0x38 also
controls the masking. Enable or disable capabilities are provided in the pseudo register interface
to allow a complete register interface. It is important to note that all letters of the command must
be provided as there is no short form for this command.

INHOUSE:REG_ENABLE <boolean> Where <boolean> is 0 | OFF | 1 | ON.

EXAMPLES

INHOUSE:REG_ENABLE 1 Enables the REGINT type interrupt
generation

INHOUSE:REG_ENABLE? Returns 1 to state that backplane
1 interrupting is currently enabled.

INHOUSE:REG_ENABLE 0 Disabling REGINT interrupt generation.
INHOUSE:REG_ENABLE? Returns 0 to state that backplane

0 interrupting is currently disabled.

24 VM4016 Programming

www.vxitech.com

INHOUSE:CLEAR_LATCH

The INHOUSE:CLEAR_LATCH command determines whether the first latched information will
be cleared when the information is read by word serial FETch:LATChed? Command or if pseudo
is set and a register read of the first latched information occurs. The information will not be
cleared if a hardware register read is used. When the first latched information is cleared, all the
following reads will return a value of 0 until a new first latched event occurs. It is important to
note that all letters in the command must be provided as there is no short form for this command.

INHOUSE:CLEAR_LATCH <boolean> Where <boolean> is 0 | OFF | 1 | ON.

EXAMPLES

INHOUSE:CLEAR_LATCH 1 Clears the first latched information on a

read.

INHOUSE:CLEAR_LATCH? Returns 1 stating that the first latched
1 information will be cleared on a read.

FETC:LATC? Reading the first latched information. This
1 also clears the latched information.

FETC:LATC? Reading the first latched information
0 returns a value of 0 once the clearing of

latch information was enabled (assuming
no further latching occurred).

VM4016 Programming 25

VXI Technology, Inc.

INPUT:DEBOUNCE

The INPut:DEBounce command sets the time period for the digital debounce circuitry. This
command affects all the 16 channels of the instrument. It is important to note that the debounce

µ

resolution is 9.6

INPut:DEBounce <value> Where <value> ranges from 9.6

EXAMPLES

INPut:DEBounce 9.6e-6 Sets the input debounce time for all

INP:DEB 0.6 Setting input debounce time to 0.6 s.
INP:DEB? Returns the input debounce time as 0.6 s.

0.6

s.

µ

s, i.e.,

0.0000096 s to 0.6291456 s.

channels to 0.0000096 s. This will not
allow a signal to generate an interrupt
unless the input signal crosses the signal for
more than 9.6 e-6 seconds.

26 VM4016 Programming

www.vxitech.com

INPUT:MASK

The INPut:MASK command enables or disables input channels from generating interrupts or
recording data in the conditional register. If a channel is programmed to be ON or 1, then it is
enabled to generate interrupts. If a channel is programmed to be OFF or 0, then it cannot generate
VXIbus interrupts.

INPut:MASK <state>, <channel_list> Where <state> is 0 | OFF | 1 | ON.

Where <channel_list> is standard channel
list format supporting channels 1 through

16.

EXAMPLES

INPut:MASK ON,(@1:8) Enables channels 1 through 8 to generate

interrupts.

INPut:MASK? 3 Reports that channel 3 is enabled for
1 voltage comparison.

INP:MASK? 9 Reports that channel 9 is not enabled for
0 voltage comparison.

VM4016 Programming 27

VXI Technology, Inc.

INPUT:MASK:INTERRUPT

The INPut:MASK:INTerrupt command enables or disables interrupt generation when changing
MASK values. When set to 0 (the *RST state), interrupts are temporarily disabled whenever
MASK values are changed. When set to 1, interrupts are generated even as MASK values are
changed.

INPut:MASK:INTerrupt <boolean> Where <boolean> is 0 | OFF | 1 | ON.

EXAMPLES

INPut:MASK:INT 0 Disables interrupt generation
INPut:MASK:INT? Reports that interrupt generation is disabled

0

28 VM4016 Programming

www.vxitech.com

INPUT:OFFSET

The INPut:OFFSet command sets the input threshold for a channel or group of channels, over

which the input signal must cross to cause an interrupt event. This command sets the value in the
8-bit DAC to which the input signal is compared. It is important to note that the actual input

offset value is affected by the INPut:RANGe command, as the response has been normalized to

±10 V range. The actual input offset for the allowable ranges are as follows:

Range Entered Threshold Actual Threshold

±10.0 x 1.0x
±100.0 x 10.0x

INPut:OFFSet <voltage_level>,<channel_list> Where <voltage_level> ranges from -10.00

volts to +9.96 volts.

Where <channel_list> is the standard
channel list format supporting Channels 1
through 16.

EXAMPLES

INPut:RANGe 100,(@5:10) Sets the input range for Channels 5 through

10 to ±100 V

INPut:OFFSet -5.0,(@5:10) Sets the input offset for Channels 5 through

10 to -50 V

INP:OFFS? 9 Returns the normalized input offset of -50 V

-5.000 for Channel 9
INP:RANG 10,(@1:4) Sets the input range for Channels 1 through

4 to ±10 V

INP:OFFS -5.0,(@1:4) Sets the input offset for Channels 1 through

4 to -5 V

INP:OFFS? 3 Returns the normalized input offset of -5 V

-5.000 for Channel 3

VM4016 Programming 29

VXI Technology, Inc.

INPUT:POLARITY

The input polarity command selects the input polarity for one or more channels. When a channel
is programmed for normal polarity, an interrupt will be generated when the input voltage is
greater than the programmed input offset for the channel. The invert polarity will cause an
interrupt when the input voltage is less than the programmed input offset for the channel.

INPut:POLarity <polarity>,<channel_list> Where <polarity> is either NORMal or

INVerted

Where <channel_list> is the standard
channel list format supporting channels 1
through 16.

EXAMPLES

INPut:POLarity NORM,(@3:5) Sets the input polarity for Channels 3

through 5 to NORMal. This will generate
an interrupt when the input signal on
Channels 3, 4 or 5 is greater than the input
offset.

INPut:POLarity? 5 Returns the input polarity for Channel 5 as
NORM NORMal

INP:POL INV,(@6) Sets input polarity for Channel 6 to invert.

30 VM4016 Programming

www.vxitech.com

INPUT:RANGE

The input range command selects the input range of one or more channels. The input range may
be either set for ±10 volts or ± 100 volts. It is important to note that the input offset is normalized
to ± 10 volt range. The actual input offset in the 100 volt range is ten times the set value.

INPut:RANGe <range>,<channel_list> Where <range> is 10 V | 100 V.

Where <channel_list> is the standard
channel list format supporting channels 1
through 16.

EXAMPLES

INPut:RANGe 100,(@1:16) Sets the input range for Channels 1 through

16 to 100 V.

INPut:RANGe? 7 Returns the input range for Channel 7 as
100 100 V.

INP:RANG 10,(@4:6) Sets the input range for Channels 4 through

6 to 10 V.

INP:RANG? 5 Returns the input range for Channel 5 as
10 10 V.

VM4016 Programming 31

VXI Technology, Inc.

OUTPUT:POLARITY:EXTERNAL:INTERRUPT

The output polarity external interrupt command sets the polarity of the front panel interrupt
output. When the poarity is set to normal, the output will be low when there is an interrupt event.
When the polarity is set to invert, the output will be high when there is an interrupt event.

OUTPut:POLarity:EXTernal:INTerrupt <polarity> Where <polarity> is either

NORMal or INVert.

EXAMPLES

OUTPut:POLarity:EXTernal:INTerrupt NORM Sets the external interrupt output

polarity to a low pulse (NORMal),
when an interrupt occurs.

OUTPut:POLarity:EXTernal:INTerrupt? Returns the external interrupt
NORM output polarity as NORMal.

OUTP:POL:EXT:INT INV Sets the external interrupt output

polarity to INVert.

OUTP:POL:EXT:INT? Returns the polarity of the external
INV interrupt output as INVert.

32 VM4016 Programming

www.vxitech.com

OUTPUT:POLARITY:EXTERNAL:LATCHED

The output polarity external latched command sets the polarity of the front panel latched interrupt
output. When the polarity is set to normal, the output will be low when there is an interrupt event.
When set to invert, the output will be high when there is an interrupt event.

OUTPut:POLarity:EXTernal:LATChed <polarity> Where <polarity> is either

NORMal or INVerted.

EXAMPLES

OUTPut:POLarity:EXTernal:LATChed NORM Sets the external latched output

polarity to low when an interrupt
occurs.

OUTPut:POLarity:EXTernal:LATChed? Returns the external latched output
NORM polarity as NORMal.

OUTP:POL:EXT:LATC INV Sets the external latched output

polarity to high when an interrupt
occurs.

OUTP:POL:EXT:LATC? Returns the external latched output
INV polarity as INVert.

VM4016 Programming 33

APPLICATION EXAMPLES

This section contains examples of using SCPI command strings for programming the VM4016
module. The code is functional and will contain a brief description about the operation.

Example 1

In this example, the VM4016 sets the output interrupt polarity on the front panel and the debounce
time period for the digital debounce circuitry.

OUTPut:POLarity:EXTernal:INTerrupt NORM Sets the external interrupt output polarity to

INPut:DEBounce 25e-6 Sets input debounce time for all channels to

Example 2

In this example, the VM4016 enables or disables the specified channels for interrupt generation,
sets the offset, polarity and voltage range. It returns the value of First Latched register which
records the first input channel to cross its threshold and queries the current state of inputs.

INP:MASK 1,(@1,2) Enables Channels 1 and 2 for interrupt

INP:MASK 0,(@3:16) Disables Channels 3 through 16 from

INP:RANG 10,(@1,2) Selects ±10 volts as the input range for

INP:OFFS +5.25,(@1,2) Selects +5.25 volts as the o ffset voltage for

INP:POL NORM,(@1,2) Selects both Channel 1 and 2 to generate an

FETC:LATC? Returns the active signal in the First

FETC:RAW?

65535 Returns the State of unconditioned

FETC:COND?

3 Returns the state of masked and inverted

VXI Technology, Inc.

high pulse when an interrupt occurs.

µ

s. This will not allow a signal to

25
generate an interrupt unless the channel is

µ

active for greater than 25

generation.

generating an interrupt.

Channel 1 and 2.

Channels 1 and 2.

interrupt when Channels 1 and 2 are
greater than the offset voltage.

Latched Register.

(ummasked and non-inverted) inputs.

inputs.

s.

34 VM4016 Programming

www.vxitech.com

SINGLE CHANNEL OPERATION

This example is for controlling a device that can tolerate a maximum input voltage level at
+35 VDC for a maximum time of 250 ms before damage will occur. The input power to this
device is provided from a remote source that can be disabled. A low signal applied to the power
source remote inhibit will disable its output. The controller will then be notified that an out-of­tolerance condition has occurred and the device was shut down.

The following code is for monitoring a single input for voltage level that exceeds +35VDC for
longer than 250 ms. A low latched output is required to be generated upon detection of the
interrupt that is used to inhibit the remote power source.

COMMANDS

INP:RANG 100,(@1) Selects ±100 volts as the input range for Channel 1.

INP:DEB 0.25 Sets the debounce time limit to 250 ms.

INP:MASK 1,(@1) Enables Channel 1 to generate an interrupt.

INP:MASK 0,(@2:16) Disables Channels 2 through 16 from generating an

INP:POL NORM,(@1) Selects Channel 1 to generate an interrupt when

INP:OFFS +3.5,(@1) Selects +35.0 volts as the offset (reference) voltage.

OUTP:POL:EXT:LATC INV Sets the external latched output to be active low.

Figure 3-1 and the explanation that follows illustrates what is occurring during this example.

DESCRIPTION

interrupt.

Channel 1 is greater than the offset voltage.

VM4016 Programming 35

VXI Technology, Inc.

VMIP
BUS

+CH1

DATA 0-15

DOE*

(FRONT PANEL

CONNECTOR)

-CH1

IRQ*

DATA
BUFFER

100K

100K

CONTROL

U3

DATA

100K

10K
10pf

-

U17A

+

100K

10K

DACDATA
DACLOAD#
DACCLK

RELAYCLK
RELAYDATA

RELAYENA*

K9

6K

2K

K9

VCC

VCC

4.7K

LATIRQOUT

Q34

4.7K

COMPCH1

TO FRONT PANEL
CONNECTOR

U8

DAC

TRIGLEV1

RELAY
DRIVER

1K

BUFCH1

TO RELAY K9

-

U13A

+

470K

10K

4.7K

1K

U15

ADDRESS
0-5, 29

CONTROL

U4

CONTROL
BUFFER

U1

CONTROL

FIGURE 3-1: SINGLE CHANNEL OPERATION

Due to the type of signal being monitored, input channel +CH1 is grounded. The command and

data for the SCPI command INP:RANG is received by the control (U1) and data (U4) buffers and

routed to the control FPGA (U3). The control FPGA converts the parallel data for the relay
drivers into a serial data stream. This data (RELAYDATA) is synched to the 10 MHz
(RELAYCLK) and written into the relay drivers when (RELAYENA*) goes low. The relay
drivers will energize relay K9 selecting a gain of 0.1 for the differential amplifier U17A.

36 VM4016 Programming

www.vxitech.com

The command and data for the SCPI command INP:DEB is received by the control (U1) and data

(U4) buffers and routed to the control FPGA (U3). The register for the debounce circuitry is
contained internally in the control FPGA. The debounce register will be loaded with a value that
corresponds to a 250 ms time delay.

The commands and data for the SCPI commands INP:MASK are received by the control (U1)

and data (U4) buffers and routed to the control FPGA (U3). The mask register circuitry is
contained internally in the control FPGA. This register will be loaded so that Channels 2 through
16 are disabled or masked out.

The command for the SCPI command INP:POL is received by the control (U1) and data (U4)

buffers and routed to the control FPGA (U3). The mask register and debounce circuitry uses this
command to determine whether the input signal is an active high or an active low. The input

polarity has been programmed to NORM to cause U3 to treat the input signal as an active high.

The commands and data for the SCPI command INP:OFFS are received by the control (U1) and

data (U4) buffers and routed to the control FPGA (U3). The control FPGA will convert the
parallel data for the DAC (U8) into a serial data stream. This data (DACDATA) is synched to the
10 MHz gated clock (DACCLK) and loaded into the DAC when the (DACLOAD) signal goes
high.

The command for the SCPI command OUTP:POL:EXT:LATC is received by the control (U1)

and data (U4) buffers and routed to the control FPGA (U3). The latch register uses this command
to determine whether the output signal should be an active high or an active low. This was

programmed for INV to cause U3 to output an active low EXTLATIRQ signal to the front panel

connector when an interrupt occurs.

Now that the VM4016 is configured, it can be determined how this works. The output of the
differential amplifier U17A (BUFCH1) is voltage divided by 4. Since the gain of U17A is 0.1,
this makes BUFCH1 0.875 V when -CH1 reaches +35.0 V. BUFCH1 is compared with the
output of U8 (TRIGLEV1) by comparator U13A. When BUFCH1 is greater than TRIGLEV1 the
output of U13A (COMPCH1) goes low. COMPCH1 is routed to the debounce circuitry inside
U3.

The debounce circuitry will count down for 250 ms before clocking through COMPCH1. This
circuitry is used to mask out transients from generating false interrupts. When the 250 ms time
limit has expired, U3 clocks COMPCH1 into the mask register. The mask register will AND
COMPCH1 with the mask value (0001). The mask register passes COMPCH1 to a 16 input
OR’ing function that determines which Channel was first to cross its threshold. The output of this
OR’ing then latches into the “First Latch Register”. This signal, arbitrarily called
FIRSTLATCHED, clocks an internal latch that drives the base of Q34. Q34 conducts and drives
a low out on the front panel connector signal EXTLATIRQ. When an interrupt condition is
detected by U3 a VXI IRQ* is generated to the VMIP bus.

VM4016 Programming 37

BRACKETING A VOLTAGE

In this example, an input voltage level will be bracketed for an over or under-voltage error
condition. The input voltage of 5.0 V will be monitored for an over-voltage of 5.25 V and an

under-voltage of 4.75 V. The error condition must be true for longer than 750 µs. An interrupt

will be generated if either of these conditions occur. Channel 1 will use for an over-voltage and
Channel 2 for an under-voltage. Channel 1 and Channel 2 positive (+) sides will be tied together
externally. Channel 1 and Channel 2 negative (-) sides will be grounded. The output interrupt
will not be latched but will be pulsed.

COMMANDS

INP:RANG 10,(@1,2) Selects ±10 Volts as the input range for Channel 1

INP:DEB 75e-5 Sets the debounce time limit to 750

INP:MASK 1,(@1,2) Enables Channel 1or 2 to generate an interrupt.

INP:MASK 0,(@3:16) Disables Channels 3 through 16 from generating an

INP:POL NORM,(@1) Selects Channel 1 to generate an interrupt when

INP:POL INV,(@2) Selects Channel 2 to generate an interrupt when

INP:OFFS +5.25,(@1) Selects +5.25 volts as the offset (reference) voltage

INP:OFFS +4.75,(@2) Selects +4.75 volts as the offset (reference) voltage

OUTP:POL:EXT:INT NORM Sets the external interrupt output to be active high.

Figure 3-2 and the explanation that follows illustrates what is occurring during this example.

DESCRIPTION

and 2.

interrupt.

Channel 1 is greater than the offset voltage.

Channel 2 is less than the offset voltage.

for Channel 1.

for Channel 2.

VXI Technology, Inc.

µ

s.

38 VM4016 Programming

www.vxitech.com

INPUT
SIGNAL

FROM
FRONT
PANEL
CONNECTOR

TO
VMIP
BUS

IRQ*

CONTROL

DATA 0-15

-CH2

+CH2

-CH1

+CH1

100K

CONTROL

U3

100K

100K

100K

+

100K

10K
10pf

-

U17B

100K

10K
10pf

-

U17A

+

100K

10K

DACDATA
DACLOAD#
DACCLK

K1

K9

6K

2K

K9

VCC

BUFCH1

-

DAC

U8

TRIGLEV2

6K

2K

TRIGLEV1

TRIGLEV2

1K

BUFCH2

1K

470K

+

U13B

-

U13A

+

470K

4.7K

COMPCH1

VCC

4.7K

4.7K

COMPCH2

4.7K

4.7K

VCC

10K

IRQOUT

Q33

1K

100K

10K

K1

FIGURE 3-2: BRACKETING AN INPUT VOLTAGE

The command and data for the SCPI command INP:RANG are received by the control (U1) and

data (U4) buffers (not shown for clarity) and routed to the control FPGA (U3). The control FPGA
converts the parallel data for the relay drivers into a serial data stream. This data (RELAYDATA)
is synched to the 10 MHz (RELAYCLK) and written into the relay drivers when (RELAYENA*)
goes low. The relay drivers de-energize relays K9 and K1 selecting a gain of 1.0 for the
differential amplifiers at U17A and U17B.

The command and data for the SCPI command INP:DEB are received by the control (U1) and

data (U4) buffers and routed to the control FPGA (U3). The register for the debounce circuitry is
contained internally in the control FPGA. The register will be loaded with a value that

corresponds to a 750 µs time delay.

VM4016 Programming 39

VXI Technology, Inc.

The commands for the SCPI commands INP:MASK are received by the control (U1) and data

(U4) buffers and routed to the control FPGA (U3). The mask register circuitry is contained
internally in the control FPGA. This register will be loaded so that Channels 3 through 16 are
disabled or masked out.

The command for the SCPI command INP:POL is received by the control (U1) and data (U4)
buffers and routed to the control FPGA (U3). Channel 1 has been programmed this to NORM so

that the debounce and mask circuitry will treat as an active high. Channel 2 has been programmed

as INV, causing the debounce and mask circuitry to treat Channel 2 as an active low.

The command and data for the SCPI command INP:OFFS are received by the control (U1) and

data (U4) buffers and routed to the control FPGA (U3). The control FPGA will convert the
parallel data for the DAC (U8) into a serial data stream. This data (DACDATA) is synched to the
10 MHz gated clock (DACCLK) and loaded into the DAC when the (DACLOAD) signal goes
high. The DAC output (TRIGLEV#) where # is equal to the Channel number. The DAC will
output TRIGLEV1 for the comparator at U13A and TRIGLEV2 for the comparator at U13B.

The commands for the SCPI command OUTP:POL:EXT:INT are received by the control (U1)

and data (U4) buffers and routed to the control FPGA (U3). U3 uses this command to determine
whether the external interrupt signal should be an active high or an active low. This has been

programmed to NORM so as to cause U3 to output an active high EXTIRQ signal to the front

panel connector when an interrupt occurs. This signal will be a pulse 500 ns wide.

The output of the differential amplifier U17A (BUFCH1) is voltage divided by 4. Since the gain
of U17A is 1.0, this makes BUFCH1 1.250 V when -CH1 reaches +5.0 V. BUFCH1 is compared

with the output of U8 (TRIGLEV1) by comparator U13A. When BUFCH1 is greater than
TRIGLEV1 the output of U13A (COMPCH1) goes low. COMPCH1 is routed to the debounce

circuitry inside U3.

The output of the differential amplifier U17B (BUFCH2) is voltage divided by 4. Since the gain
of U17B is 1.0 this makes BUFCH2 1.250 V when -CH2 reaches +5.0 V. BUFCH2 is compared

with the output of U8 (TRIGLEV2) by comparator U13B. When BUFCH2 is less than
TRIGLEV2 the output of U13B (COMPCH2) goes high. COMPCH2 is routed to the debounce

circuitry inside U3. Note that the only difference in the way these two circuits are working is the
output of the comparator U13B is inverted from the output of U13A. This inversion will allow us
to determine if an under-voltage has occurred. Assume that -CH2 has fallen below +4.75 V. The
output of U13B is now high.

The debounce circuitry will count down for 750 µs before clocking through COMPCH2. When

µ

the 750
will AND COMPCH2 with the mask value (0003). The mask register passes COMPCH2 to a 16
input OR’ing function that determines which channel was first to cross its threshold, in this case
COMPCH2. The output of this OR’ing then latches into the “First Latch Register”. This signal,
arbitrarily named FIRSTLATCHED, clocks a series of internal latches that will stretch the pulse
to 500 ns. This pulse drives the base of Q33 low causing Q33 to shut off and the pull-up resistor
provides a high on the front panel connector signal EXTIRQ. When an interrupt condition is
detected by U3 a VXI IRQ* is generated to the VMIP bus.

s time limit has expired, U3 clocks COMPCH2 into the mask register. The mask register

40 VM4016 Programming

www.vxitech.com

REGISTER ACCESS EXAMPLES

TABLE 3-1: REGISTER MAP

3E
3C
3A

38
36
34
32

30
2E
2C
2A

28

26

24

22

20
1E
1C
1A

18

16

14

12

10

C
A

Interrupt enable (write only, pseudo only)

First latched (read only)

Conditioned (read only)

Raw (read only)

E

8
6
4
2
0

VM4016 Programming 41

VXI Technology, Inc.

The VM4016 module supports direct register access for very high-speed data retrieval. The
register map is as specified in Table 3-1.

In order to access the raw data using register access, the register at offset 0x20 must be read. Each
bit in this register corresponds to the state of the 16 channel inputs (unmasked and non-inverted).
Bit 1 corresponds to Channel 1, Bit 2 corresponds to Channel 2 and so on. This information can

also be accessed using the Word Serial FETC:RAW? query.

In order to access the conditioned data using register access, the register at offset 0x28 must be
read. Each bit in this register corresponds to the state of the 16 channel inputs (masked and
inverted). Bit 1 corresponds to Channel 1, Bit 2 corresponds to Channel 2 and so on. This

information can also be accessed using the Word Serial FETC:COND? query.

In order to access the first latched information using register access, the register at offset 0x30
must be read. Each bit in this register corresponds to the state of the 16 channel inputs. Bit 1
corresponds to Channel 1, Bit 2 corresponds to Channel 2 and so on. This information can also be

accessed using the Word Serial FETC:LATC? query.

For example:

a) if a value of 0x8000 is read from the first latched register, then it means that Channel 16’s

input has caused a latching.

b) if a value of 0xF000 is read from the first latched register, then it means that Channels 13
through 16 have caused a latching.

The Interrupt Enable register is a write-only register on which write operations take effect only in
the Pseudo mode. In order to enable backplane interrupting, any non-zero value must be written
to this register at offset 0x38. Writing a zero to this register will disable any backplane
interrupting. It must be noted that in non-pseudo mode, any writes to this register will take no
effect. Backplane interrupting can also be enabled/disabled using the Word Serial

INHOUSE:REG_ENABLE command.

42 VM4016 Programming

www.vxitech.com

PSEUDO REGISTER ACCESS

The VM4016 can be operated upon using (a) Word Serial Commands or (b) Register Access.

The VM4016 allows two types of register accesses (a) Direct Register Access using Hardware

registers (b) Pseudo Register Access. This can be configured using the INHOUSE:PSEUDO

command.

Direct Register Access is much faster than Pseudo Register Access. However, the former does
not provide certain features provided by the latter. Using Pseudo Register Access (a) a register

read of FIRST LATCHED data allow another FIRST LATCHED event to occur (b) allows for
clearing of the first latched register upon register access rather than a Word Serial FETC:LATC?

and (c) allows configuration of the type of backplane interrupting.

The module can be enabled for backplane interrupts using the INHOUSE:REG_ENABLE

command. It can also be done by writing a non-zero value to the Interrupt Enable Register at
offset 0x38 provided the module has been configured for Pseudo register access. The module can
be instructed to clear the first latched register on register access/WS read using the

INHOUSE:CLEAR_LATCH command. When VXIbus backplane interrupting is enabled, the

module will generate interrupts whenever latching of the first latched register takes place. If a
Pseudo register access of the first latched register at offset 0x30 is performed or a Word Serial

read (using FETC:LATC?) is performed, the latch register gets cleared allowing further latching

to occur provided the module has been instructed to clear the first latched register. If the clearing
of the first latched register is disabled, after the first latching takes place, the module cannot
generate backplane interrupts.

Using the Direct Register Access, backplane interrupts are generated when the latching takes

place for the first time. For further interrupting to occur, the Word Serial FETC:LATC? query

must be performed.

Two types of backplane interrupts can be generated. They are (a) the reqt/reqf (in response to an

IACK cycle) or (b) a single backplane interrupt. This can be configured using the
INHOUSE:REGINT command. However, it must be noted that the module can be configured

for only for mode at any given point of time. The former mode provides compatibility with the
VXI standards and is the default mode. The latter allows for faster processing since it cuts down
servicing of interrupts by 50% (since only 1 interrupt needs to be serviced for each latch event).

VM4016 Programming 43

VXI Technology, Inc.

VXIPLUG&PLAY DRIVER EXAMPLES

/**************************************************************************

Function: vtvm4016_setup_and_read_data

Formal Parameters

ViSession instr_hndl

- A valid sessionandle to the instrument.

ViInt16 channel_list[]

- This parameter specifies the channels which are to be setup.
Only the specified channels will be enabled, the rest will be
disabled.

Each channel number in the array has the range :
vtvm4016_MIN_CHANNEL_NO (1) to
vtvm4016_MAX_CHANNEL_NO (16)

ViInt16 num_of_channels

- This parameter specifies the number of channels in the channel
list.

Valid Range:
vtvm4016_MIN_CHANNEL_NO (1) to
vtvm4016_MAX_CHANNEL_NO (16)

ViReal32 offset[],

- This parameter specifies the offset voltage to be configured for
the input channels.

Valid Range:
vtvm4016_MIN_VOLTAGE_LEVEL (-10.00 V) to
vtvm4016_MAX_VOLTAGE_LEVEL (9.96 V)

ViInt16 polarity[]

- This parameter specifies the polarity to be configured for the
specified channels.

Valid Range:
vtvm4016_INVERTED_POLARITY (0) or
vtvm4016_NORMAL_POLARITY (1)

ViInt16 voltage_range[]

- This parameter specifies the voltage range to be configured for
the specified channels.

Valid Range:
vtvm4016_10VOLTS_RANGE (0) or
vtvm4016_100VOLTS_RANGE (1)

44 VM4016 Programming

www.vxitech.com

ViPInt16 first_latched_reg

- This parameter returns the first input channel which crosses the
programmed threshold voltage.

ViPInt16 raw_data

- This returns the 16 bit value that represents the current
unconditioned [raw] state of the inputs.

ViPInt16 conditioned_data

- This returns the 16 bit value that represents the current
conditioned state of the inputs.

Return Values: Returns VI_SUCCESS if successful, else returns error

value.

Description This is an application function that shows how the

user can use core functions to enable/disable the
specified channels for interrupt generation and
configure the specified channels’ various parameters
such as offset, polarity and voltage-range. It
returns the value of the First Latched register which
records the first input channel to cross its threshold
and queries the current state of the inputs. Note
that this function resets the module to its default
state.

***************************************************************************/
ViStatus_VI_FUNC vtvm4016_setup_and_read_data(ViSession instr_hndl,

ViInt16 channel_list[],ViInt16 num_of_channels,ViReal32

offset[],ViInt16 polarity[],ViInt16 voltage_range[],
ViPInt16 first_latched_reg,ViPInt16 raw_data,
ViPInt16 conditioned_data)

{

/* Variable used to store return status of the function */
ViStatus status = VI_NULL;

/* Reset to the default state */

status = vtvm4016_reset(instr_hndl);

if (status < VI_SUCCESS)

return status;

/* Function to enable the selected channels to cause interrupt */
status = vtvm4016_enable_disable_channels (instr_hndl,

vtvm4016_ENABLE_CHANNEL, channel_list, num_of_channels);
if (status < VI_SUCCESS)
return vtvm4016_ERROR_MASK_OR_UNMASK_CHANNELS;

VM4016 Programming 45

VXI Technology, Inc.

/* Function to set the offset, polarity and voltage range to the channels */

status = vtvm4016_config_channels ( instr_hndl, channel_list,

num_of_channels, offset, polarity, voltage_range);

if (status < VI_SUCCESS)

return vtvm4016_ERROR_SETTING_CHANNELS;

/* Function to query the first latched register */
status = vtvm4016_query_latched_reg(instr_hndl, first_latched_reg);

if (status < VI_SUCCESS)

return vtvm4016_ERROR_QUERYING_LATCHED_REG;

/* Function to query the Raw data */
status = vtvm4016_read_data (instr_hndl,

vtvm4016_READ_RAW_DATA, raw_data);

if (status < VI_SUCCESS)

return vtvm4016_ERROR_READING_RAW_DATA;

/* Function to query the Conditioned data */

status = vtvm4016_read_data (instr_hndl,

vtvm4016_READ_CONDITIONED_DATA, conditioned_data);

if (status < VI_SUCCESS)

return vtvm4016_ERROR_READING_CONDITIONED_DATA;

return VI_SUCCESS;

46 VM4016 Programming

www.vxitech.com

SECTION 4

COMMAND DICTIONARY

INTRODUCTION

This section presents the instrument command set. It begins with an alphabetical list of all the
commands supported by the VM4016 divided into three sections: IEEE 488.2 commands, the
instrument specific SCPI commands and the required SCPI commands. With each command is a
brief description of its function, whether the command’s value is affected by the *RST command
and its *RST value.

The remainder of this section is devoted to describing each command, one per page, in detail.
Every command entry describes the exact command and query syntax, the use and range of
parameters and a complete description of the command’s purpose.

ALPHABETICAL COMMAND LISTING

The following tables provide an alphabetical listing of each command supported by the VM4016
along with a brief description. If an X is found in the column titled *RST, then the value or
setting controlled by this command is possibly changed by the execution of the *RST command.
If no X is found, then *RST has no effect. The default column gives the value of each
command’s setting when the unit is powered up or when a *RST command is executed.

VM4016 Command Dictionary 47

VXI Technology, Inc.

TABLE 4-1: IEEE 488.2 COMMON COMMANDS

Command Description *RST RST Value

*CLS Clears the Status Register X
*ESE Sets the Event Status Enable Register X
*ESR? Query the Standard Event Status

Register
*IDN? Query the module identification string N/A
*OPC Set the OPC bit in the Event Status

Register
*RST Resets the module to a known state N/A
*SRE Set the service request enable register
*STB? Query the Status Byte Register
*TRG Causes a trigger event to occur
*TST? Starts and reports a self-test procedure N/A
*WAI Halts execution and queries X

N/A

48 VM4016 Command Dictionary

www.vxitech.com

TABLE 4-2: INSTRUMENT SPECIFIC SCPI COMMANDS

Command Description RST RST Value

FETCh:CONDitioned? Reads back the 16-bit value that

represents the current conditioned
(masked and inverted) output state of
the comparators in the group.

FETCh:LATChed? Read back the 16-bit value that was

latched when the first input(s) in the
group caused an active edge.

FETCh:RAW? Reads back the 16-bit value that

represents the current unconditioned
(no masking or inversion) output state

of the comparators in the group.
INHOUSE:PSEUDO Sets the type of register interface used.
INHOUSE:REGINT Controls type of interrupt response X 0
INHOUSE:REG_ENABLE Interrupt masking X 0
INHOUSE:CLEAR_LATCH Controls clearing of first latched

information.
INPut:DEBounce This sets the debounce timing on a

group of the analog comparators.
INPut:MASK Sets the masking for a group of

channels
INPut:MASK:INTerrupt Enable or disable interrupt generation

when changing MASKs
INPut:OFFSet Sets the comparator threshold for a

group of channels.
INPut:POLarity Sets the polarity for a group of

channels.
INPut:RANGe Sets the range for a group of channels. X 100
OUTPut:POLarity:EXTernal:INTerrupt Sets the polarity for the interrupt

output on the front panel for one of the

three groups.
OUTPut:POLarity:EXTernal:LATChed Sets the polarity for latched interrupt

output on the front panel for one of the

three groups.

X 0

X

X 0

X 0

X 0.469 V

X NORMAL

X NORMAL

X NORMAL

19.2

µ

s

VM4016 Command Dictionary 49

VXI Technology, Inc.

TABLE 4-3: SCPI REQUIRED COMMANDS

Command Description *RST *RST Value

STATus:OPERation:CONDition? Queries the Operation Status

Condition Register.

STATus:OPERation:ENABle Sets the Operation Status Enable

Register.

STATus:OPERation[:EVENt]? Queries the Operation Status Event

Register.
STATus:PRESet Presets the Status Register. X
STATus:QUEStionable:CONDition? Queries the Questionable Status

Condition Register
STATus:QUEStionable:ENABle Sets the Questionable Status Enable

Register.
STATus:QUEStionable[:EVENt]? Queries the Questionable Status Event

Register
SYSTem:ERRor? Queries the Error Queue X Clears Queue
SYSTem:VERsion? Queries which version of the SCPI

standard the module complies with

X

X

X

X

X

X

N/A

50 VM4016 Command Dictionary

www.vxitech.com

COMMAND DICTIONARY

The remainder of this section is devoted to the actual command dictionary. Each command is
fully described on its own page. In defining how each command is used, the following items are
described:

Purpose

Type

Command Syntax

Command Parameters

Reset Value

Query Syntax

Query Parameters

Query Response

Description

Examples

Related Commands

Describes the purpose of the command.

Describes the type of command such as an event or setting.

Details the exact command format.

Describes the parameters sent with the command and their legal range.

Describes the values assumed when the *RST command is sent.

Details the exact query form of the command.

Describes the parameters sent with the command and their legal range. The default
parameter values are assumed the same as in the command form unless described
otherwise.

Describes the format of the query response and the valid range of output.

Describes in detail what the command does and refers to additional sources.

Present the proper use of each command and its query (when available).

Lists commands that affect the use of this command or commands that are affected by
this command.

VM4016 Command Dictionary 51

COMMON SCPI COMMANDS

*CLS

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Clears all status and event registers

IEEE 488.2 Common Command

*CLS

N/A

N/A

N/A

N/A

N/A

This command clears the Status Event Register, Operation Status Register and the
Questionable Data/Signal Register. It also clears the OPC flag and clears all queues
(except the output queue).

Examples Command / Query Response / Descriptions

Related Commands

52 VM4016 Command Dictionary

*CLS

N/A

(Clears all status and event registers)

www.vxitech.com

*ESE

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Sets the bits of the Event Status Enable Register

IEEE 488.2 Common Command

*ESE <mask>

<mask> = numeric ASCII value

N/A, the parameter is required

*ESE?

N/A

Numeric ASCII value from 0 to 255

The Event Status Enable (ESE) command is used to set the bits of the Event Status
Enable Register. See ANSI/IEEE 488.2-1987 section 11.5.1 for a complete
description of the ESE register. A value of 1 in a bit position of the ESE register
enables generation of the Event Status Bit (ESB) in the Status Byte by the
corresponding bit in the Event Status Register (ESR). If the ESB is set in the Service
Request Enable (SRE) register, then an interrupt will be generated. See the *ESR?
command for details regarding the individual bits. The ESE register layout is:

Bit 0 - Operation Complete
Bit 1 - Request Control
Bit 2 - Query Error
Bit 3 - Device Dependent Error
Bit 4 - Execution Error
Bit 5 - Command Error
Bit 6 - User Request
Bit 7 - Power On

The Event Status Enable query reports the current contents of the Event Status Enable
Register.

*ESE 36
*ESE?

*ESR?

36 (Returns the value of the event status enable register)

VM4016 Command Dictionary 53

*ESR?

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Queries and clears the Standard Event Status Register

IEEE 488.2 Common Command

N/A

N/A

N/A

ESR?

N/A

Numeric ASCII value from 0 to 255

The Event Status Register (ESR) query queries and clears the contents of the
Standard Event Status Register. This register is used in conjunction with the ESE
register to generate the Event Status Bit (ESB) in the Status Byte. The layout of the
ESR is:

Bit 0 - Operation Complete
Bit 1 - Request Control
Bit 2 - Query Error
Bit 3 - Device Dependent Error
Bit 4 - Execution Error
Bit 5 - Command Error
Bit 6 - User Request
Bit 7 - Power On

The Operation Complete bit is set when it receives an *OPC command.

The Query Error bit is set when data is over-written in the output queue. This could
occur if one query is followed by another without reading the data from the first
query.

The Execution Error bit is set when an execution error is detected. Errors that range
from -200 to -299 are execution errors.

The Command Error bit is set when a command error is detected. Errors that range
from -100 to -199 are command errors.

The Power On bit is set when the module is first powered on or after it receives a
reset via the VXI Control Register. Once the bit is cleared (by executing the *ESR?
command) it will remain cleared.

*ESR? 4

*ESE

54 VM4016 Command Dictionary

www.vxitech.com

*IDN?

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Queries the module for its identification string

IEEE 488.2 Common Command

N/A

N/A

N/A

*IDN?

N/A

ASCII character string

The Identification (IDN) query returns the identification string of the module. The
response is divided into four fields separated by commas. The first field is the
manufacturer’s name, the second field is the model number, the third field is an
optional serial number and the fourth field is the firmware revision number. If a
serial number is not supplied, the third field is set to 0 (zero).

Examples Command / Query Response (Description)

Related Commands

*IDN

N/A

VXI Technology, Inc.,VM4016,0,1.0

(The revision listed here is for reference only; the
response will always be the current revision of the
instrument.)

VM4016 Command Dictionary 55

*OPC

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Sets the OPC bit in the Event Status Register

IEEE 488.2 Common Command

*OPC

N/A

N/A

*OPC?

N/A

1

The Operation Complete (OPC) command sets the OPC bit in the Event Status
Register when all pending operations have completed. The OPC query will return a 1
to the output queue when all pending operations have completed.

Examples Command / Query Response (Description)

Related Commands

*OPC
*OPC?

*WAI

(Sets the OPC bit in the Event Status Register)
1 (Returns the value of the Event Status Register)

56 VM4016 Command Dictionary

www.vxitech.com

*RST

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Resets the module’s hardware and software to a known state

IEEE 488.2 Common Command

*RST

N/A

N/A

N/A

N/A

N/A

The Reset (RST) command resets the module’s hardware and software to a known
state. See the command index at the beginning of this chapter for the default
parameter values used with this command.

Examples Command / Query Response (Description)

Related Commands

*RST

N/A

(Resets the module)

VM4016 Command Dictionary 57

*SRE

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Sets the service request enable register

IEEE 488.2 Common Command

*SRE <mask>

<mask> = Numeric ASCII value from 0 to 255

None – Required Parameter

*SRE?

N/A

Numeric ASCII value from 0 to 255

The Service Request Enable (SRE) mask is used to control which bits in the status
byte generate back plane interrupts. If a bit is set in the mask that newly enables a
bit set in the status byte and interrupts are enabled, the module will generate a
REQUEST TRUE event via an interrupt. See the *STB? Command for the layout of
bits.

Note:

Bit 6 is always internally cleared to zero as required by IEEE 488.2 section 11.3.2.3.

The layout of the Service Request Enable Register is:

Bit 0 – Unused
Bit 1 – Unused
Bit 2 – Error Queue Has Data
Bit 3 – Questionable Status Summary (Not Used)
Bit 4 – Message Available
Bit 5 – Event Status Summary
Bit 6 – 0 (per IEEE 488.2 section 11.3.2.3)
Bit 7 – Operation Status Summary

*SRE 4
*SRE?

N/A

(Sets the service request enable register)
4 (Returns the value of the SRE register)

58 VM4016 Command Dictionary

www.vxitech.com

*STB?

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Queries the Status Byte Register

IEEE 488.2 Common Command

N/A

N/A

N/A

*STB?

N/A

Numeric ASCII value from 0 to 255

The Read Status Byte (STB) query fetches the current contents of the Status Byte
Register. See the IEEE 488.2 specification for additional information regarding the
Status byte Register and its use. The layout of the Status Register is:

Bit 0 – Unused
Bit 1 – Unused
Bit 2 – Error Queue Has Data
Bit 4 – Questionable Status Summary (not used)
Bit 5 – Message Available
Bit 6 – Master Summary Status
Bit 7 – Operation Status Summary

*STB?

N/A

16 (Queries the Status Byte Register)

VM4016 Command Dictionary 59

*TRG

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Causes a trigger event to occur

IEEE 488.2 Common Command

*TRG

N/A

N/A

N/A

N/A

N/A

The Trigger command causes a trigger event to occur.

Examples Command / Query Response (Description)

Related Commands

*TRG

N/A

(Triggers an event)

60 VM4016 Command Dictionary

www.vxitech.com

*TST?

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Causes a self-test procedure to occur and queries the results

IEEE 488.2 Common Command

N/A

N/A

N/A

*TST?

N/A

Numeric ASCII value from 0 to 143

The Self-Test query causes the VM4016 to run its self-test procedures and report on
the results.

Examples Command / Query Response (Description)

Related Commands

*TST

N/A

0 (Begins the self-test procedure returns the result)

VM4016 Command Dictionary 61

*WAI

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Halts execution of additional commands and queries until the No Operation Pending
message is true

IEEE 488.2 Common Command

*WAI

N/A

N/A

N/A

N/A

N/A

The Wait to Continue command halts the execution of commands and queries until
the No Operation Pending message is true. This command makes sure that all
previous commands have been executed before proceeding. It provides a way of
synchronizing the module with its commander.

Examples Command / Query Response (Description)

Related Commands

*WAI

*OPC

(Pauses the execution of additional commands until
the No Operation Pending message is true.)

62 VM4016 Command Dictionary

www.vxitech.com

INSTRUMENT SPECIFIC SCPI COMMANDS

FETCh:CONDitioned?

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Returns the state of the conditioned (masked and inverted) inputs

Query

N/A

N/A

N/A

FETCh:CONDitioned?

None

Numeric ASCII in the range of 0 to 65535

The FETCh:CONDitioned query reports the 16-bit value that represents the current
conditioned (masked and inverted) state of the inputs.

This information is also available at the VXIbus register level at offset 0x28.

Examples Command / Query Response (Description)

Related Commands

FETC:COND?

FETch:RAW?

0 (Returns the current conditioned state of the inputs)

VM4016 Command Dictionary 63

FETCh:LATChed?

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Reports the active signals in the First Latched register

Query

N/A

N/A

N/A

FETCh:LATChed?

N/A

Numeric ASCII in the range 0 to 65535

The FETCh:LATChed query reports the active signals in the First Latched register.
The First Latched register records the active signals when the first new input channel(s)
crosses its threshold.

This information is also available at the VXIbus register level at offset 0x30.

Examples Command / Query Response (Description)

Related Commands

FETC:LATC?

INHOUSE:CLEAR_LATCH

1 (Returns the active signal in the First Latched register.)

64 VM4016 Command Dictionary

www.vxitech.com

FETCh:RAW?

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Returns the state of the unconditioned (unmasked and non-inverted) inputs

Query

N/A

N/A

N/A

FETCh:RAW?

N/A

Numeric ASCII in the range 0 to 65535

The FETCh:RAW query reports the 16-bit value that represents the current
unconditioned (unmasked and non-inverted) state of the inputs.

This information is also available at the register level at offset 0x20.

Examples Command / Query Response (Description)

Related Commands

FETC:RAW?

FETch:CONDitioned?

1 (Returns the current unconditioned state of the inputs)

VM4016 Command Dictionary 65

INHOUSE:CLEAR_LATCH

VXI Technology, Inc.

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Controls whether the first latched information will be cleared when read by word serial
or pseudo register access of the first latched register

Setting

INHOUSE:CLEAR_LATCH <boolean>

<boolean> = 0 | 1 | OFF | ON

0

INHOUSE:CLEAR_LATCH?

N/A

ASCII numeric 0 or 1

CLEAR_LATCH determines whether the first latched information will be cleared
when the information is read. For some, this provides confidence that another interrupt
has not occurred. The information is cleared with the word serial FETCh:LATChed?
command. It is also cleared if PSEUDO is set and a register read of the first latched
information occurs. The information is not cleared if a hardware register read is used.
When the information is cleared, all following reads will return a value of 0 until a new
first latched event occurs.

Note: All letters of the command are required; there is no short form of the command.

INHOUSE:CLEAR_LATCH 1
INHOUSE:CLEAR_LATCH? 1

INHOUSE:PSEUDO
FETCh:LATChed?

66 VM4016 Command Dictionary

www.vxitech.com

INHOUSE:PSEUDO

Purpose

Type

Command Syntax

Command Parameters

*RST Value

Query Syntax

Query Parameters

Query Response

Description

Examples Command / Query Response (Description)

Related Commands

Controls the use of the register interface

Setting

INHOUSE:PSEUDO <boolean>

<boolean> = 0 | 1 | OFF | ON
Factory Default = 1

N/A

INHOUSE:PSEUDO?

N/A

ASCII numeric 0 or 1

If INHOUSE:PSEUDO is set true (1 or ON), the instrument uses the pseudo register
interface. If false (0 or OFF), the instrument uses the hardware register interface. The
value set is implemented upon the next power cycle. This command does not take
effect immediately.

The pseudo register interface allows use of the REG_ENABLE capability as well as the
