Page 1
ASSEMBLY MANUAL
for Lift, Lift Pro & Thunder
Wheels
Page 2
2
MAINTENANCE | CARE INSTRUCTIONS
WARNING:
• Install with two people (lifting required).
• Remove Wheels before bouncing.
Improper use, or lack of care, can lead to your Lift / Lift Pro / Thunder Wheels deteriorating earlier than expected. Please follow all of these
care instructions to ensure that your Thunder Pro Wheels last for as long as possible.
WEATHER CARE
Remove your Lift / Lift Pro / Thunder Wheels when not in use or during extreme weather. This will preserve their integrity for longer.
STORAGE
When not in use, store Lift / Lift Pro / Thunder Wheels in a cool, dry place in the original packaging.
LIFT / LIFT PRO / THUNDER WHEELS | ASSEMBLY INSTRUCTIONS
Remove the R-pin that locks the bolt
into place, and then remove the bolt.
1
STEP
Go to a Frame leg, and have one person lift
the trampoline by the Lower Frame Tube.
2
STEP
Page 3
3
Sit the Frame leg onto the Wheels plate,
with the open side facing towards you.
3
STEP
Go around your trampoline, repeating Steps 1-4 for the remaining 3 Wheels in the pattern according to your model:
5
STEP
Go around your trampoline, repeating Steps 1-4 for the remaining 3 Wheels in the pattern according to your model:
5
STEP
Re-insert the bolt and lock it into place with the R-pin.
4
STEP
Wheels install points.
Small - 4x Wheels Small - 4x Wheels
Medium - 4x Wheels Medium - 4x Wheels
Large - 6x Wheels Large - 6x Wheels
Extra Large - 6x Wheels Extra Large - 6x Wheels
LIFT / LIFT PRO THUNDER
