Introduction

IMPORTANT:

The VT2420 is an Accessory Handset for use with the VT2431 GIGAPHONE system. You must have the VT2431 in order to use the VT2420 Accessory Handset.

This manual is designed to familiarize you with the VT2420 Accessory Handset setup, registration and basic functions. For detailed operational instructions, please refer to the VT2431 manual.

To order additional system Handsets (model# VT 2420), battery packs, or headsets, call VTech Communications Inc at 1-800-595-9511.

Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen sink,

or swimming pool).

5. Do not place this product on an unstable cart, stand, or table. The product

may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for

ventilation. To protect it from overheating, these openings must not be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation where proper ventilation is not provided.

7. This product should be operated only from the type of power source indicated

on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not locate this product

where the cord will be abused by persons walking on it.

9. Never push objects of any kind into this product through cabinet slots as they

may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.

10. To reduce the risk of electric shock, do not disassemble this product, but take

it to a VTech authorized service facility. Opening or removing cabinet parts other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassemb-ling can cause electric shock when the appliance is subsequently used.

11. Do not overload wall outlets and extension cords as this can result in the risk

of fire or electric shock.

12. Unplug this product from the wall outlet and refer servicing to a VTECH

authorized service facility under the following conditions:

A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions, because improper adjustment of other controls may result in damage and will often require extensive work by a VTech authorized

technician to restore the product to normal operation. E. If the product has been dropped and the cabinet has been damaged. F. If the product exhibits a distinct change in performance.

13. Avoid using a telephone (other than a cordless type) during an electrical storm.

There may be a remote risk of electric shock from lighting.

14. Do not use the telephone to report a gas leak in the vicinity of the leak.

VTECH COMMUNICATIONS INC

SERVICE DEPT. at 1-800-595-9511. In Canada, call VTech Electronics Ltd at 1-800267-7377.

SAVE THESE INSTRUCTIONS

Registration And Operation Of The VTECH VT2420 Accessory Handset

Your VTECH GIGAPHONE system can operate up to 4 Handsets. The VTECH accessory Handset consists of the following:

Getting Started

Setup

Handset

Belt Clip

Battery Pack

Charger Unit

Setup Of The VT2420

Accessory Handset

1. Plug the AC power adapter into an

electrical outlet.

2. Remove the Handset battery cover

by pressing on the indent and sliding downward.

3. Place the new battery pack in the

Handset, with the metal contacts aligned with the charge contacts in the battery compartment.

4. Replace the battery cover by sliding

it upward.

5. Place the Handset in the Charge

Cradle, and allow it to charge for 12 hours. After the initial charge,

a maintenance charge of 8 hours should be sufficient.

Installation of Battery Pack in Handset

Follow the steps below:

1. Remove the battery cover by

pressing on the indent and sliding

downward.

2. Place the new battery pack in the

handset with the metal contacts aligned with the charge contacts in the battery compartment.

3. Replace the battery cover by

sliding it upwards.

4. If the new battery pack is not

already charged, place the handset in the base unit, or a remote charging stand, and allow it to charge for 12 hours. After initial charge, a maintenance charge of 8 hours should be sufficient.

The original Handset that is shipped with your GIGAPHONE system will be automatically registered to the Base. This Handset is HANDSET 1.

As you register additional Handsets to the system, they will be assigned extension numbers in the following order: HANDSET 2, HANDSET 3, and finally HANDSET

Getting Started

Whenever a Handset battery pack is installed, the Handset will automatically begin

SEARCHING FOR BASE (if previously registered), or it will prompt you to ENTER BASE ID to register the new Handset.

Enter Base ID Code

1. After charging the Handset, remove

it from its Charge Cradle, the screen will display:

Getting Started

Registration

2. Press

3. Press

NEW

Base Unit ID code, located on the underside of the Base Unit.

PLEASE WAIT!!

, then enter the 15 digit

. The Handset will display:

4. Wait approximately 15 seconds.

The Handset will display:

FOUND BASE

If the Handset displays: BASE BUSY TRY LATER, this indicates

that the system is in use. Wait until the Base Unit is in the idle (on hook) mode, and repeat step 2 to

Congratulations! You can now enjoy the benefits of your VTECH multi-Handset system.
