User’s Manual
DeskPro
™
Printed in China
91-xxxxx-00x
© 2005 VTech
Dear Parent,
At
VTech
®
we know that in order to effectively reach kids, today’s learning tools
have to be plugged into the fast-paced world around them. That’s why we created
the Grade School Learning Series - an engaging set of stylized, interactive
computers specially designed to get grade-school kids up to speed with their fastpaced, tech-savvy world.
Every product in the Grade School Learning Series covers a wide range of school
basics - math, language, social studies, science, and even an intro to basic Spanish.
Activities are presented in a fast-paced, arcade-game style that kids will recognize
and enjoy. Each learning machine is loaded with hi-tech features such as word
processors, electronic address books, plug-in accessories, and PC uplinks - tools
that go hand-in-hand with the way kids learn, play and use information. And of
course, each laptop is designed to travel easily along with a busy grade-schooler.
With the Grade School Learning Series, kids can access a way to learn that
closely matches they way they already live and play. We thank you for trusting
VTech
®
with the important job of helping your child learn and succeed. We hope to
help your child discover that “It’s Cool to be Smart!”
Sincerely,
Your Friends at
VTech
®
To learn more about the Electronic Learning Series and other
VTech
®
toys, visit
www.vtechkids.com
1
1
INTRODUCTION
Thank you for purchasing the VTech® DeskPro™ learning computer.
The DeskPro™ learning computer puts learning fun right on your desk top! 100 fun,
arcade-style activities cover all the school skills you need, like English, math, social studies,
science, and even Spanish. Plus, the neat Artificial Intelligence feature keeps track of
your skill level, and adjusts the curriculum just for you!
Interactive
Light-up Mouse
Mouse Pad
Reset Button
Keyboard
On/Off
Button
Intelli-Challenge
Button
Volume/
Contrast
Button
Progress Report Button
LCD Screen
Utilities Button
Adventure Button
Main Menu Button
CD-ROM
Eject Button
CD-ROM Drive
Caps Lock Light
INTRODUCTION
2
INSTRUCTIONS & ACTIVITIES
INCLUDED IN THIS PACKAGE
- DeskPro™ learning product
- Interactive light-up mouse
- Mouse pad
- 3 bonus activity CD-ROMs
- 4 “AA” sized batteries
- Instruction manual
WARNING:
All packing materials such as tape, plastic sheets, wire ties and tabs are not part of this
toy and should be discarded for your child’s safety.
GETTING STARTED
Before playing for the first time, be sure you have 2 “AA” sized backup batteries, in addition
to the 4 “AA” sized batteries included with the unit. These backup batteries enable you to
save information onto the unit.
Before playing, please make sure the plastic strip has been removed from the bottom
of the unit.
USING THE MOUSE
Before use, take the mouse out of the storage compartment at the
back of the unit, and position it next to the unit, on the included mouse
pad.
1. Move the mouse in the direction you want the cursor to move.
2. Click the mouse button to make a selection.
CLEANING THE MOUSE
1. Following the arrows, use a screwdriver to open the cover on the
bottom of the mouse.
2. Take the ball out of the mouse and use a dry cloth to clean the
mouse and the ball.
3. Place the ball back into the mouse, replace the mouse cover and
screw the cover closed.
BATTERY INSTALLATION
The DeskPro™ operates on 4 “AA” size batteries (UM-3/
LR6) or a VTech
®
9V adaptor (sold separately).
1. Make sure the unit is turned OFF.
2. Locate the battery cover on the bottom of the unit and
open it.
3. Insert 4 new “AA” batteries (UM-3/LR6) as illustrated.
4. Close the battery cover.
INSTRUCTIONS & ACTIVITIES
3
3
NOTE: Replace with new, alkaline batteries.
RECHARGEABLE BATTERIES ARE NOT RECOMMENDED.
BATTERY NOTICE
• Do not try to recharge non-rechargeable batteries;
• Rechargeable batteries are to be removed from the toy before being charged;
• Rechargeable batteries are only to be charged under adult supervision;
• Do not mix different types of batteries; Do not mix new and used batteries;
• Only use batteries of the recommended or equivalent type;
• Always insert batteries properly matching the plus (+) and minus (-) signs;
• Batteries that have run out of energy must be removed from the toy;
• Do not short circuit the supply terminals;
• Do not use more batteries than recommended;
• Remove batteries from the toy if it will not be used for an extended period of time.
AC-DC ADAPTOR
Use a VTech
®
adaptor or any other standard adaptor that complies with EN61558 DC 9V
300mA center-positive adaptor.
CONNECTION
1. Make sure the unit is OFF.
2. Locate the adaptor jack on the back of the unit.
3. Insert the adaptor plug into the unit’s adaptor jack.
4. Plug the adaptor into a wall outlet.
5. Turn the unit ON.
NOTE: If the unit stops working or the sound becomes weak, it may be the result of the
adaptor connection. Turn the unit OFF and unplug the adaptor for 15 seconds.
Next, plug the adaptor back in and turn the unit ON. If the problem persists, it
may be the result of the adaptor’s wiring.
ADAPTOR NOTICE
• The toy is not intended for use by children under 3 years old;
• Only use the recommended adaptor with the toy;
• The adaptor is not a toy;
• Never clean a plugged-in toy with liquid;
• Never use more than 1 adaptor;
• Do not leave the toy plugged-in for extended periods of time.
NOTICE TO PARENTS
Regularly examine the adaptor, checking for damage to the cord, plug, transformer or
other parts. Do not use the adaptor if there is any damage to it.
INSTRUCTIONS & ACTIVITIES
4
BACKUP BATTERY INSTALLATION
The DeskPro™ uses 2 additional “AA” sized batteries (not
included) to save information you input. To avoid damage from
leaky batteries, replace the batteries at least once a year.
To replace the backup batteries:
1. Make sure the unit is OFF.
2. Locate the backup battery cover on the bottom of the unit.
3. Using a screwdriver, loosen the screw on the battery cover.
4. Insert 2 “AA” sized batteries as illustrated.
5. Close the battery cover and tighten the screw to secure it.
Important: While replacing the backup batteries, the 4 “AA” batteries must be kept in
the unit or the unit must be plugged into the wall outlet with the adaptor.
Otherwise you will lose any information saved on the unit.
PRODUCT FEATURES
1. THE INTELLI-SYSTEM
The DeskPro™ learning computer has a unique feature called the Intelli-System, which
helps you learn as much as possible in a way that fits you best.
As you play, the Intelli-System keeps track of how you do in every subject. After a while,
the Intelli-System has enough information to guide your learning: it knows when you should
switch to another subject, which level of an activity is best for you, and which subjects you
could use more work on.
The Intelli-System works in two ways:
1. When you choose an activity from the Main Menu, the Intelli-System checks to see
how you’re doing in each curriculum of that subject. Then it automatically chooses a
curriculum that you need more practice in.
2. When you press the Intelli-Challenge button or choose Intelli-Challenge from the Main
Menu, the Intelli-System picks activities for you based on how you’ve done in the past.
In Fun Mode, the Intelli-System picks activities that you play often, or do very well in.
In Challenge Mode, the Intelli-System picks activities that are more challenging for
you.
2. PLAY MODES
In the DeskPro™, you can choose from 3 different modes of play:
• Menu Mode
• Adventure
• Intelli-Challenge
MENU MODE
Pick the games and subjects you want to explore. How about Word games? Math games?
Or would you like Social Studies or Science? Check out the Main Menu to get started.
INSTRUCTIONS & ACTIVITIES
5
5
ADVENTURE - EXPLORER QUEST
Help our daring explorer find the treasure in the Room of the Scarab! The treasure is
hidden deep underground in a cleverly designed tomb. Can you open the four locks and
get into the Room of the Scarab?
Enter the Explorer Quest by selecting it from the Main Menu, or by pressing the Adventure
button on the keyboard. After you get 4 keys and open the lock, you must help our explorer
make her way through the path by dodging a flood of creepy bugs! Will our hero find the
treasure? That depends on you!
INTELLI-CHALLENGE
In this mode, the Intelli-System takes over and challenges you with all kinds of different
subjects and questions. You can choose from Fun Mode and Challenge Mode.
Fun Mode
The unit will automatically pick games that you have done well in, or have played most
often.
Challenge Mode
The unit will automatically challenege you with activities you have not played often, or
could use more practice in.
3. GENERAL BUTTONS
ON/OFF BUTTON
Press the On/Off Button to turn the unit ON. Press it again to turn the unit OFF.
VOLUME/CONTRAST BUTTON
Press this button once to change the sound level of the speaker. Use the “+” or “-” buttons
on the keyboard, or click the left/right arrow on the screen by using the mouse.
Press this button twice to make the screen darker or lighter. Use the “+” or “-” buttons on
the keyboard, or click the left/right arrow on the screen by using the mouse.
Press this button a third time to turn the background music ON or OFF.
Press this button a fourth time to exit. You can also press the Esc key to exit.
MAIN MENU BUTTON
Press this button at any time to go to the Main Menu.
ADVENTURE
Press this button to enter the Adventure mode.
INSTRUCTIONS & ACTIVITIES
