VTech Dect LS6204 User Manual

User’s manual

www.vtech.com

Table of contents

1. IMPORTANT SAFETY INSTRUCTIONS .......................1

2. SETTING UP THE TELEPHONE ...................................2

2.1 Package contents ..............................................................2

2.2 Location .............................................................................2

2.3 Setting up ..........................................................................3

2.3.1 Connecting the charger .....................................3

2.3.2 Installing and charging the battery pack............4

2.4 Set date and time ..............................................................4

2.4.1 Change the Date Format ...................................4

2.4.2 Change the Time Format...................................5

2.4.3 Set Date/Time....................................................5

3. GETTING TO KNOW YOUR PHONE ............................6

3.1 Overview of your handset ..................................................6

3.2 Handset LCD display .........................................................7

3.3 Charger..............................................................................8

3.4 Navigating the menus ........................................................8

3.5 Menu map..........................................................................9

4. USING ADDITIONAL HANDSETS ..............................10

4.1 Registration .....................................................................10

4.2 Intercom and Conference Call.........................................11

4.2.1 Intercom...........................................................11

4.2.2 Transfer an External Call .................................11

4.2.3 Make a 3-way Conference Call ....................... 12

4.2.4 Switch between internal call and

external call ....................................................13

1. IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury,
including the following:

1. Read and understand all the instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen sink, swimming pool).

5. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.

6. Unplug this product from the wall outlet and refer servicing to VTech under the following conditions:

• When the power adapter or plug is damaged or frayed.

• If the product does not operate normally by following the operating instructions.

• If the product has been dropped and the cabinet has been damaged.

• If the product exhibits a distinct change in performance.

7. Avoid using corded telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from
lightning.

8. Do not use the telephone to report a gas leak in the vicinity of the leak.

9. Use only the supplied NiMH (Nickel Metal Hydride) battery pack! The operation periods for the handsets are only applicable with the default
battery pack capacities.

10. The use of other battery pack types or non-rechargeable battery packs/primary cells can be dangerous. These may cause interference and/
or unit damages. The manufacturer will not be held liable for damage arising from such non-compliance.

11. Do not use third party charging bays. The battery pack may be damaged.

12. Please note the correct polarity while inserting the battery pack.

13. Do not immerse battery pack in water, do not place in fire.

If you have questions about this product, or having difficulty with setup or operation, call our VTech Electronics (HK) Ltd.
Customer Service Centre Tel: [phone]
Technical Inquiry Hotline Tel: [phone]

Setting up the telephone

2. SETTING UP THE TELEPHONE

2.1 Package contents

The package contains the following items:

･ 1 Handset ･ 1 Rechargeable battery pack
･ 1 Charger ･ 1 Chinese operation manual
･ 1 AC power adapter ･ 1 English operation manual

2.2 Location

For maximum coverage and reduce the interference, here are some guidelines you should consider when you place the base unit,

- place it at a convenient, high, and central location with no obstructions between the handset and base unit in an indoor environment.

- place it away from electronic appliances such as televisions, microwave ovens, radios, personal computers, wireless devices or other
cordless phones.

- avoid facing radio frequency transmitters, such as external antennas of mobile phone cell stations.

- avoid plugging it into the same circuit as other major household electrical appliances because of the potential for interference. Try moving
the appliance or the base unit to another power outlet.

If the reception for a base unit location is not satisfactory, move it to another location for better reception. Depending on the surrounding
conditions as well as spatial and structural factors, the range may be reduced. The range indoors is normally less than outdoors.

2.3 Setting up

2.3.1 Connecting the charger

1. Plug the power supply into the charger.

2. Plug the power supply cord into the wall outlet not controlled by a wall switch.

3. Always use the cables provided in the box.

Setting up the telephone

2.3.2 Installing and charging the battery pack

1. Slide out the battery compartment cover.

2. Place the supplied battery pack as indicated. Locate the battery pack lead and connector and plug it into the socket inside the battery
compartment (the red wire should be on the left). Tuck the battery pack leads in the space above the battery pack.

3. Slide the battery compartment cover back.

4. Put the handset on the charger or base and charge the battery pack for 16 hours first time.

Use only the supplied NiMH rechargeable battery pack.

2.4 Set date and time

Provided you have subscribed to your network's caller ID service, the date and time will be set automatically with every incoming call.

2.4.1 Change the Date Format

1. Press MENU and U/D to select SETTINGS.
