INTRODUCTION
Thank you for purchasing VTech® Kidizoom Camera™!
Kidizoom Camera™ is a fun and durable digital camera for kids to take
photos, view photos, edit photos and play games! Kidizoom Camera™
has 64MB of built-in memory, and it includes a USB port and cable to
connect the Kidizoom Camera™ to your home computer for viewing
and printing photos.
FEATURES
PRODUCT LAYOUT AND BUTTONS
Introduction / Features
Shutter Button
Lens
Flash
ON/OFF Button
4-Directional
Cursor Buttons
Mode Button
USB Port for
Computer
Connection
Delete Button
Flash Button
OK Button
Zoom Out &
Zoom In Buttons
Reset Button
4
ON/OFF Button
Press this button to turn the camera ON or OFF.
USB Port
Plug the included USB cable into this USB port to connect the camera
to your computer.
Mode Button
Press this button to go to the main menu or to go back to the previous
submenu.
4-Directional Cursor Buttons
Press these buttons to move the cursor and make selections.
OK Button
Press this button to conrm a choice or action.
Note: The OK Button can also be used to take a photo.
Delete Button
Press this button to delete the selected le.
Shutter Button
Press this button to take a photo.
Reset Button
Press this button to reset the camera if it stops working properly.
Note: The photos stored in the camera’s memory will not be affected
by resetting the camera. However, you will need to select the camera’s
language setting again, and the volume setting will return to the default
level.
Flash Button
Press this button to switch between Auto-ash, Strong Flash On, Weak
Flash On, and Flash Off.
Zoom In Button
Press this button to zoom in.
Zoom Out Button
Press this button to zoom out.
INCLUDED IN THIS PACKAGE
• 1 VTech® Kidizoom Camera™
• 1 USB cable
• 1 wrist strap
• 1 user’s manual
WARNING: All packing materials such as tape, plastic sheets, wire
ties and tags are not part of this toy, and should be discarded for
your child’s safety.
Features
5
PRODUCT SPECIFICATIONS
Display: 1.5” CSTN color LCD
Photo Resolution: 640x480
Memory: 64MB built-in memory (approximately 45MB free memory for
photos)
Store up to 500 photos (photo size = 640x480 resolution in JPEG
format)
Supported File Formats: JPEG
Supported Hardware: USB cable (included) for computer connection
Zoom: 2X digital zoom
GETTING STARTED
BATTERY INSTALLATION
Note: Adult assembly is required for battery installation. Tools required
for battery installation: Phillips screwdriver (not included).
• Make sure the camera is turned OFF.
• Locate the battery cover on the bottom of the camera. Loosen the
screws using a screwdriver and remove the battery cover.
• Install 4 new “AA” batteries (2 on each side) as illustrated above.
(The use of new, alkaline batteries is recommended for maximum
performance.)
• Replace the battery cover and tighten the screws. Do not over-tighten
screws.
Note: If Kidizoom Camera™ is not
working properly after the batteries
have been replaced, press the Reset
Button and then restart the camera.
Note: The photos stored in the
camera’s memory will not be affected by resetting the camera. However,
you will need to select the camera’s language setting again, and the
volume setting will return to the default level.
Getting Started
6
BATTERY NOTICE
• The use of new alkaline batteries is recommended for maximum
performance.
• Install batteries correctly observing the polarity (+, -) signs to avoid
leakage.
• Do not mix old and new batteries.
• Do not mix batteries of different types: alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium).
• Remove the batteries from the equipment when the unit will not be
used for an extended period of time. Please note: To prevent data
loss, copy all photos from Kidizoom Camera™ to a computer before
removing batteries.
• Always remove exhausted batteries from the equipment.
• Do not dispose of batteries in re.
• Do not attempt to recharge ordinary batteries.
• The supply terminals are not to be short-circuited.
• Only batteries of the same and equivalent type as recommended are
to be used.
TO BEGIN USING
KIDIZOOM CAMERA™
• Press the ON/OFF Button to turn on the camera.
• If it is the rst time that you are turning on the
Kidizoom Camera™, the
Try-me demo movie will start playing. Press the OK Button during the
movie to exit the Try-me demo mode. The Try-me demo will be disabled
and will not play again on start-up. After the camera exits demo mode,
the language selection screen will appear. Press the Up Cursor Button
or Down Cursor Button to select a language, and then press the OK
Button to conrm. If you wish to change the language selection later,
please go to the Settings menu.
• After the Try-me demo mode has been disabled, when
Kidizoom
Camera™ is turned on, it will go directly into camera mode and you can
start taking photos.
• To switch to other activities, press the Mode Button
to go to the
Main Menu. From the Main Menu, you can select the following activities:
Camera , Photo Editor , Games and Settings .
• To connect to a computer, follow the instructions in the
Connecting to
a Computer section below.
• Press the ON/OFF Button
again to turn the unit off.
To Begin Using
Kidizoom Camera™
