SET YOUR MUSIC FREE™
TABLE OF CONTENTS
Intro to VSSL
Product Overview
Specifications
Getting Started
Playing Music
Voice Control
VSSL App
Device Status
Troubleshooting
Warranty Information
Safety Information
2
2
4
5
7
9
10
11
13
15
16
VSSL A.1x HOME 1
WELCOME TO VSSL
VSSL is the music system you’ve always wanted.
• Out of sight.
• No other apps.
• Just the music you love.
• Controlled by voice.
VSSL strives to deliver the best music listening experience based on your music ecosystem. By
incorporating Apple AirPlay 2, Google Chromecast, Amazon, and Spotify Connect, you can choose
your favorite music app, device, and ecosystem.
Note: Your favorite music apps are maintained outside of the VSSL system. These apps may be
subject to updates or changes and could aect the performance of your music system.
PRODUCT OVERVIEW
DEVICE STATUS
INDICATOR
FRONT PANEL
Power Indicator
Device Status Indicator
POWER INDICATOR
Indicates the power state of the device. There are two power
states, auto and always on.
Indicates the status of the zones. See the Device Status section
later for more details.
VSSL A.1x HOME 2
BACK
AMPLIFICATION
FACTORY
RESET
Speaker Output
Subwoofer Output
SPEAKER
OUTPUT
IR REMOTE
INPUT
SUB
OUT
ANALOG
INPUT
ANALOG
OUTPUT
DIGITAL
INPUTS
DIGITAL
OUTPUTS
POWER
INPUT
NETWORK
Use the phoenix connector supplied. Output is not bridgeable. The L+,
L- are positive and negative outputs for the left channel speaker while
the R+, R- are the positive and negative outputs for the right channel
speaker.
For connecting a subwoofer. Output can be full range or with a
crossover pass only the low frequencies (LFE). The crossover is
adjustable from 50-200Hz within the VSSL app.
Analog Output Analog RCA output, can be fixed volume or variable.
Digital Output (1) Digital coax, (1) Optical, output can be fixed volume or variable.
Network Ports (1) 10/100MB network input, (1) 10/100MB network output
Power Input 100-240VAC 50/60Hz
Use the power cord supplied with the unit. Adapters can be used for
international power connections.
Analog Inputs Analog RCA line-level input. Input can be fixed volume or variable
Digital Inputs (1) Digital coax, (1) Optical, inputs can be fixed volume or variable
IR Remote Input For remote control of the device. Use the included IR receiver cable.
IR commands can be learned for volume+, volume-, and mute.
Amplification Use this switch to disable the speaker output and amplifier on the
unit. Used when the unit is the streaming source for another amp.
Factory Reset Can use a pin to reset the device to its factory settings
ACCESSORIES
Phoenix Connector Can accept size 12-20 gauge speaker wire.
IR Receiver Cable Receives IR signals from remotes
Power Cord Standard 3-prong power adapter for the U.S.
VSSL A.1x HOME 3
SPECIFICATIONS
Zones
Channels
Amplifier Class D
WiFi 2.4/5 GHz, dual antenna MIMO
Inputs (1) Network, (1) RCA, (1) Digital coax, (1) optical, (1) IR
Wireless Inputs AirPlay 2, Chromecast built-in, Amazon, Spotify Connect, Bluetooth
Outputs (1) RCA, (1) Optical, (1) Digital coax, (1) Subwoofer
Sub Out Crossover Adjustable, 50-200Hz
EQ 7 band adjustable
S/N >98 dB A-weighted
Frequency Response 20-20kHz
Frequency Range 2412MHz~2483MHz or 5180MHz~5725MHz
1
2
35 watts/ch RMS @ 8Ω
50 watts/ch RMS @ 4Ω
Transmit Output Power 6 dBm
Bluetooth V4.2, EDR
Rack Space 1U
Dimensions No Feet 7 7/16” W x 8 11/16” D x 1 11/16” H
Dimensions With Feet 7 7/16” W x 8 11/16” D x 2” H
Shipping Weight 5 lbs.
VSSL A.1x HOME 4
GETTING STARTED
1. PREP YOUR NETWORK
New Installation Steps
Do not install your VSSL before checking your network.
•
Analyze your existing network topology.
•
Login to your network equipment.
•
Make adjustments according to network settings suggestions.
•
Reboot your networking equipment.
•
Recommendations
Recommended – Download speeds of at least 1Mbps
•
Not recommended – Satellite internet, 3G/4G/LTE hotspot or cellular INTERNET
•
Not supported – Guest WiFi networks, shared networks
•
Network Topology Best Practices
In homes with access points, it is recommended that an AP controller be present and that
•
all access points be consolidated to a single switch. The VSSL should be installed within
that same switch.
In homes with a switch, ensure the switch is placed downstream from the router.
•
In homes with 2 routers (e.g. modem/router combo unit from ISP and 3rd party router)
•
ensure the ISP router is placed in “Bridge Mode” in order to avoid a Double NAT.
Do not connect your VSSL via ethernet cable to access points, mesh points, or network
•
extenders.
Ensure that the ethernet (patch) cable is fully functional. Note: ethernet cables commonly
•
degrade over time.
General Router Settings
To configure your router, it’s important to consult the manual that corresponds with your
exact router model.
Ensure the router has the most up-to-date firmware installed.
•
Avoid Double NAT when using 3rd party router/mesh system by placing the ISP router in
•
“Bridge Mode” (e.g., Google, eero).
Ensure that the ethernet (patch) cable is fully functional. Note: ethernet cables commonly
•
degrade over time.
Separate the 2.4GHz and 5GHz WiFi bands and ensure that they maintain dierent SSID’s.
•
Enable “UPnP” (Universal Plug and Play).
•
When using access points, disable “AP Isolation” or “Client Isolation”.
•
Enable “Multicasting” (multicast terminology diers between manufacturers).
•
Disable “IPv6” and only use “IPv4”.
•
Enable “IGMP” (Internet Group Management Protocol).
•
When using Apple devices, enable “Bonjour” or “ZeroConf Discovery”.
•
Ensure managed switches and access point controllers follow the same network
•
topography suggestions as detailed above.
See more router-specific suggestions at vssl.com/support.
•
VSSL A.1x HOME 5
2. PLAN YOUR AUDIO SYSTEM
Your A.1x has the versatility to connect to your high-speed network either via ethernet cable
or wirelessly. Choose which setup works best for your home.
Plan how each device within your audio system will be connected and where they will be
located within your home. Ensure that you follow all speaker, subwoofer and external device
manufacturers’ guidelines for wiring and powering. As your A.1x is stable down to 4 ohms,
ensure the speaker impedance load for each channel does not fall below 4 ohms.
AUDIO
INPUT
DEVICES
EXTERNAL
AUDIO
SYSTEMS
SPEAKERS
SUBWOOFER
WIFI ROUTER
LISTENING DEVICES
3. INSTALLATION OPTIONS
Tabletop - Ensure the location has adequate ventilation and at least 0.5” of headroom above
the device. If you are going to stack multiple A.1x devices on top of each other, you must use
the magnetic feet attached to the bottom.
Rack - Use a standard 1U rack shelf to install 2 A.1x units side by side. It is recommended to
have at least 0.5” of head room above the A.1x. Use the magnetic feet if you are going to
stack multiple A.1x devices on top of each other.
Wall Mount - The built-in mounting ports are designed to fit a standard #8 or #6 drywall
screw. Use the included template to locate where to position the screws.
4. DOWNLOAD THE VSSL APP
Once you’re ready to set up your A.1x, download the app from the app store on your mobile
device. Open the app and we’ll guide you through connecting and setting up your A.1x.
VSSL A.1x HOME 6
PLAYING MUSIC
Listening to music with VSSL is easy. Just play music in your favorite music streaming app,
choose your preferred streaming method, and select the zone(s) to play to.
AIRPLAY2®
Use AirPlay 2 to stream music, podcasts, radio and more directly from your favorite apps to
your A.1x. With AirPlay 2, you’re in control of your audio. If you have more than one VSSL
zone within your home, you can enjoy your favorite music or podcasts throughout your
house — in perfect sync. You can even play dierent songs in dierent rooms.
CHROMECAST BUILT-IN
Chromecast built-in is a platform that lets you cast your favorite music from your phone, tablet or
laptop right to your speakers. Easily control your speakers with apps you already know and love from
your iPhone®, iPad®, Android phone or tablet, Mac® or Windows® laptop, or Chromebook.
With Chromecast built into your VSSL A.1x, your phone becomes your remote. Simply tap the Cast
button from the app to stream music/tunes/podcasts/ playlists from your phone, tablet or laptop
to your VSSL A.1x.
Note: Go to the Chromecast built-in website for a full list of Chromecast enabled apps.
https://www.google.com/cast/apps
For configuring groups and volume control of Chromecast sessions, you must use the Google
Home app. The Google Home app is available on iOS and Android.
SPOTIFY CONNECT
Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to
learn more.
Note: The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses
ALEXA CAST
Alexa Cast allows you to play (cast) and control music on any of your VSSL zones from your Amazon
Music iOS or Android app. Your devices do not need to be on the same Wi-Fi network as your mobile
device and you can target any VSSL zone from anywhere. Your app becomes a remote control for
your A.1x.
VSSL A.1x HOME 7
BLUETOOTH
Your VSSL A.1x is equipped with Bluetooth. The Bluetooth on the A.1x can always be
discovered but streaming over Wi-Fi is recommended.
LOCAL MUSIC LIBRARY
For local music you can use any DLNA, Chromecast, Alexa, or AirPlay-based streaming app
to play content to your VSSL A.1x. You can also use these apps to access local music from a
NAS drive. See instructions for External Audio Source (Input).
EXTERNAL AUDIO SYSTEM (OUTPUT)
You can connect your A.1x to an external amplifier system (e.g., home theater receiver,
high-powered amplifier, outdoor audio system). The A.1x is capable of acting as the source
in these systems.
Connect the external amplifier to the analog, optical, or digital coax output.
1.
The output by default is variable, which allows you to control the volume of the
2.
external system from your phone or other streaming devices. A fixed output can be
configured in the VSSL app.
If the A.1x will only act as a source, enable line out only mode by setting the switch
3.
labeled AMPLIFICATION to the o position.
Note: In applications with multiple external systems, the A.1x will transmit the same line-level
signal to all line-level outputs simultaneously.
EXTERNAL AUDIO SYSTEM (INPUT)
You can connect your A.1x to the audio output of any device. Wire the output of any audio
source to any of the local inputs (e.g., satellite TV box, record player).
Connect the external audio source to the A.1x optical, analog, or coaxial input.
1.
If the external audio source has an IR remote, connect the provided IR sensor on the
2.
back panel and learn its controls through the VSSL app.
Set priority to “Local first” within the VSSL app’s zone settings.
3.
Note: In applications with multiple local sources, the A.1x has automatically set priorities that
cannot be adjusted: 1) optical input 2) coaxial input 3) analog input
By default, the A.1x sets priority to “Streaming first” in the case that 2 sources are attempting
to play to a zone.
CONNECTING A SUBWOOFER
A subwoofer is a great way to add more bass to your VSSL system. To connect a subwoofer,
use the sub out RCA connector and adjust the crossover settings within the VSSL app.
VSSL A.1x HOME 8
VOICE CONTROL
GOOGLE ASSISTANT
The VSSL A.1x works seamlessly with the Google Assistant.
Using Google Assistant on your Android, Google Home
speaker, or other certified Google Assistant device you can say
things like:
“Play some music in the master bedroom”
•
“Stop the music in the kitchen”
•
You can even set the default playback from your Google Home
speaker to shorten your phrases to:
“Play music”
•
“Turn up the volume”
•
“Stop”
•
AMAZON ALEXA
For the first time ever, VSSL now supports Amazon Alexa!
Control your VSSL zones with Alexa’s music skills and
automation.
Simply login to your Amazon account through the VSSL app interface. Your VSSL zone is
then instantly available within the Alexa app. In the Alexa app, change the name of the zone
and add it to a group under “Set Up Multi-Room Music.”
APPLE SIRI
As a certified AirPlay 2 product, you can use your A.1x with Siri on your iPhone, Mac, or Apple
TV. Using Siri, you can say things like:
•
•
•
•
•
•
•
•
To use Siri with your A.1x, you must first add the device to your home in the iOS Apple
HomeKit app. Please follow the recommended procedure from Apple. See the following
support article: https://support.apple.com/en-us/HT208724.
“Play ‘I Want It All’ by Queen on all speakers”
“Play something I like on all speakers”
“Play some rock on kitchen speaker”
“Play/pause music”
“Play the next song”
“Play the song before this one” etc.
“Repeat last song/album/playlist”
“Fast forward 30 seconds”, “Rewind 10 seconds”, etc.
VSSL A.1x HOME 9
VSSL APP
INITIAL SETUP
When your A.1x is plugged into power, the VSSL app will automatically recognize your
device and initiate setup. Simply follow the prompts to name your zones and choose how
you would like to stream to your amplifier.
PLAYBACK & VOLUME CONTROL
On the home screen, you may adjust the volume of each zone, control the playback on
existing streams, and assign external input sources.
PAGING
Your A.1x can turn any and all zones into an internal paging system.
Upon entering the app, simply tap the microphone icon at the top right of the screen,
•
press and hold the desired zone to page to, then record your message.
The page volume can be adjusted in the settings as long as you are logged into the app
•
with your email.
IR CONTROL
Your A.1x can learn IR codes to control your TV’s or control system’s volume with its original
remote.
Connect the included IR cable to the IR Remote port on the back panel.
•
In the VSSL app zone settings with the remote in hand, follow the prompts on the
•
screen to learn the IR codes for Volume+, Volume-, and Mute functions. The device
status indicator will blink purple when it receives a learned command.
MAX VOLUME
You can set volume limits on any of your zones by adjusting the left and right channel max
volume slider. For your convenience, the app acts as an SPL meter and calculates the
current sound pressure in decibels (dB).
PRIORITY
By default, the A.1x sets priority to “Streaming first” in the case that 2 dierent source
types are attempting to play to a zone. For scenarios where you desire to have the local
input take priority over a stream, toggle the zone’s priority setting to “Local first.” This is
especially helpful in cases where speakers are being used for both TV watching and
listening to distributed audio.
EQ SETTINGS
You can fine tune any of your zones to improve & tailor your listening experience.
Toggle on “Enable EQ” and adjust the basic treble, mid, and bass preset sliders.
•
Finer frequency range adjustments can be made under “Advanced EQ.”
•
VSSL A.1x HOME 10
DEVICE STATUS
DEVICE STATUS INDICATOR
DEVICE STATUS
INDICATOR
POWER INDICATOR
Blinking Red
Solid Green
The device is booting up.
The device has lost connection to the network, see the
troubleshooting section of this guide.
Solid Red The zone has a connection error, see troubleshooting section of this
guide.
Solid White The zone is active.
Blinking White The device is ready and waiting for setup.
Flashing Multicolor The device is updating its firmware.
POWER INDICATOR
Solid Bright
Solid Dim
The device is on and ready.
The device is in a low power sleep mode.
Pulsing The device is in a boot up sequence.
VSSL A.1x HOME 11
BOOT UP
During boot up, the power and device status indicators will cycle through a multicolored
flashing light sequence. Upon powering the A.1x for the first time, or after a factory reset, a
flashing white device status indicator light indicates it is ready to be set up.
POWER MODES
Auto mode - Enabled by default, this mode allows the device to enter into a network
standby mode after 10 minutes of no music output. To wake the A.1x, simply start a music
stream to the device.
Always On mode – This setting can be adjusted in the VSSL app.
Note: The A.1x is equipped with the HiNA functionality of a network switch and is therefore
classified as a networking device providing high network availability and network switching
when operational.
SOFTWARE UPDATES
Your VSSL system checks for updates automatically on a daily basis. This ensures delivery
of important updates and will keep your system running bug free. During system updates
the zone indicator will flash a multicolor pattern.
VSSL A.1x HOME 12
TROUBLESHOOTING
VSSL APP SPINS
When opening the app, the screen spins and cannot find a zone.
Make sure the device is connected to the same network as the VSSL. If the device is having
1.
trouble connecting to the internet, the zone status indicators will all be red.
If the zone status indicators are blinking white, your A.3x requires setup in the VSSL app.
2.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
3.
Visit vssl.com/knowledgebase/vssl-networking-support/ and make the following adjustments
4.
to your network with the help of your Internet Service Provider.
Reboot your network.
5.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds after
6.
network adjustments have been made.
MISSING DEVICE
You cannot see your zone within the music streaming app.
Ensure the device is powered on by checking the power indicator light.
1.
Check your internet connection.
2.
Make sure the device is connected to the same network as the VSSL. If no network is
3.
connected, the zone status indicators will be red.
If the zone status indicators are blinking white, your A.3x requires setup in the VSSL app.
4.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
5.
CAN’T CONNECT TO A ZONE
You can see your zone within the music streaming app but cannot establish a connection.
Reboot your A.3x by flipping the power switch on the back of the unit o and on again.
1.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
2.
Visit vssl.com/knowledgebase/vssl-networking-support/ and make the following adjustments
3.
to your network with the help of your Internet Service Provider.
Reboot your network.
4.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds after
5.
network adjustments have been made.
NO MUSIC OUTPUT
You are able to connect/play to your zone, but no music can be heard from the speakers.
Check your speaker connections. Make sure all the cables are properly terminated in the
1.
phoenix connectors and there are no wires touching across to other ports.
Open the VSSL app to make sure the zone you're playing to is not muted and the volume is
2.
turned up high enough to hear.
Ensure each zone’s max impedance load does not exceed 4 ohms. Visit vssl.com/support for
3.
more information on impedance, amplifiers, and speakers.
Try dierent streaming protocols AirPlay 2, Chromecast, and Spotify Connect within dierent
4.
music apps like Apple Music, Spotify, or Pandora.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
5.
VSSL A.1x
13
TROUBLESHOOTING
MUSIC STOPS
Your music intermittently stops on its own and/or the zone disconnects from the device.
Close and restart the music app that was being used when the music stopped.
1.
Try reducing wireless interference by moving the source device and A.1x closer to the Wi-Fi
2.
router or access point.
Try dierent streaming protocols AirPlay 2, Chromecast, and Spotify Connect within dierent
3.
music apps in order to isolate the issue.
Check the music service’s online site to find reports of possible service outage.
4.
Visit vssl.com/knowledgebase/vssl-networking-support/ and make the following adjustments
5.
to your network with the help of your Internet Service Provider.
Reboot your network.
6.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds after
7.
network adjustments have been made.
ZONE INDICATOR LIGHT IS GREEN
Your A.1x is stuck with a green zone indicator light indicating no network connection.
Temporarily connect your A.1x to the internet via an ethernet cable.
1.
Check your internet connection and replace your ethernet cable.
2.
Reboot your A.1x from the app or by unplugging and plugging in the power cord.
3.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
4.
INDICATOR LIGHTS ARE DEAD
Even after booting up, neither power nor zone indicator lights turn on.
Ensure the power cord is fully inserted into the back of the A.1x.
1.
Open the VSSL app, enter the settings section, and disable DARK MODE.
2.
Perform a factory reset from the app or holding in the reset button for at least 5 seconds.
3.
GOOGLE HOME APP CANNOT FIND ZONE TO SET UP
While attempting to setup in Google Home, cannot find zone.
Ensure the device is powered on by checking the power indicator light.
1.
Temporarily connect your A.1x to the internet via ethernet cable.
2.
Check your internet connection.
3.
Make sure the device is connected to the same network as the VSSL. If no network is
4.
connected the device status indicator will be green.
Perform a factory reset from the app or hold in the reset button for at least 5 seconds.
5.
MY STREAMING APP IS FROZEN WITH MUSIC PLAYING
Hard close and restart the app on your device.
1.
Reboot your A.1x from the VSSL app or by unplugging and plugging in the power cord.
2.
Note: For more support and other questions please visit, vssl.com/support
VSSL A.1x HOME 14
WARRANTY INFORMATION
All VSSL branded products have a limited one (1) year warranty. The VSSL Product Warranty covers
defects in materials and workmanship in every VSSL product for one (1) year from the date of shipment from VSSL or the date of the original retail purchase from an authorized VSSL Dealer. The
VSSL Product Warranty will cover the cost of parts and repair labor on all products deemed to be
defective by Soundvision Technologies. The VSSL Product Warranty does not guarantee that VSSL
products will at all times operate without interruption or will be error-free, or that all errors may be
corrected. The warranty extends only to the original purchaser of the product and not to any subsequent owner.
Soundvision Technologies’ obligation under this warranty is limited to repairing or replacing any
component found defective in material or workmanship under normal conditions of use with an
equal and/or current product. Products to be repaired or returned under this warranty must be
returned to VSSL through an authorized VSSL dealer with all transportation and insurance charges
prepaid. The warranty period is not extended if we repair or replace your product.
There are some exclusions to the VSSL Product Warranty, including but not limited to:
• Products which have been abused, modified, or disassembled;
• Problems that result from external causes such as accident, abuse or misuse;
• Use that is not in accordance with VSSL product instructions;
• Products with missing or altered serial numbers;
• Products which have had their housings opened or are otherwise tampered with; or
• Problems caused by using third party accessories, parts, or components.
COPYRIGHT
THE INFORMATION CONTAINED IN THIS DOCUMENT IS ACCURATE AT THE TIME OF PRINTING.
HOWEVER, THIS INFORMATION MAY BE CHANGED OR UPDATED AT ANY TIME WITHOUT
NOTICE.
This document is protected under the copyright laws of the United States and other countries, All
rights are reserved. No part of this publication may be reproduced, copied, or transmitted in any
form or by any means, electronic or mechanical, including but not limited to photocopying, recording, information retrieval systems, or computer networks without the express written permisssion of
VSSL, LLC.
VSSL™ is a registered trademark of VSSL, LLC, registered with the U.S. Patent and Trademark Oce.
Additionally VSSL has other product names and slogans that are protected under U.S. Trademark
laws, which may not be used without the express written permission of VSSL, LLC. Please take
notice that VSSL™ products may also be protected by one or more patents issued by the U.S. and
other countries.
Android, Google Play and Chomecast are trademarks of Google Inc.
iPhone®, iPod®, iPad®, AirPlay®, AirPlay2®, iTunes®, Mac®, OS X®, macOS™, Apple Music™, and Siri® are
trademarks of Apple Inc., registered in the U.S. and other countries.
Amazon, Alexa and all related logos and motion marks are trademarks of Amazon.com, Inc. or its
aiates.
Windows® is a trademark of Microsoft Corporation registered in the U.S. and other countries.
August 2020
© 2020 by VSSL, LLC. All rights reserved.
VSSL A.1x HOME 15
IMPORTANT SAFETY INFORMATION
Read these instructions.
1.
Keep these instructions.
2.
Heed all warnings.
3.
Follow all instructions
4.
Do not use this apparatus near water.
5.
Clean only with dry cloth.
6.
Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
7.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
8.
apparatus (including amplifiers) that produce heat.
Do not bypass the safety purpose of the polarized or grounding-type plug. A polarized plug
9.
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched, particularly at plugs, convenience
10.
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
11.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
12.
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods of time.
13.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
14.
been damaged in any way, such as; power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
•
moisture.
The apparatus shall not be exposed to dripping or splashing and that no objects filled
•
with liquids, such as vases, shall be placed on the apparatus.
An appliance coupler is used as the disconnect device, the disconnect device shall
•
remain readily operable.
Please always keep at least 20cm away from this device.
•
EU REGLATORY CONFORMANCE
According to Article 10 (10) of Directive 2014/53/EU, the packaging
shows that this radio equipment will be subject to some restrictions
when placed on the market in Belgium (BE), Bulgaria (BG), the
Czech Republic (CZ), Denmark (DK), Germany (DE), Estonia (EE),
Ireland (IE), Greece (EL), Spain (ES), France (FR), Italy (IT), Cyprus
(CY), Latvia (LV), Luxembourg (LU), Hungary (HU), Malta (MT),
Netherlands (NL), Austria (AT), Poland (PL), Portugal (PT), Romania
(RO), Slovenia (SI), Slovakia (SK), Finland (FI), Sweden (SE), the
United Kingdom (UK), Turkey(TR), Norway (NO), Switzerland (CH),
Iceland (IS), and Liechtenstein (LI). The WLAN function for this
device is restricted to indoor use only when operating in the 5150 to
5350 MHz frequency range.
BE BG CZ DK DE
EE IE EL ES FR
IT CY LV LU HU
MT NL AT PL PT
RO SI SK FI SE
UKLITR NO CH IS
VSSL A.1x HOME 16
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Cet appareil est conforme à la section 15 des réglementations de la FCC. Le fonctionnement de
l’appareil est sujetaux deux conditions suivantes :
(1) cet appareil ne doit pas provoquer d’interférences néfastes, et
(2) cet appareil doit tolérer les interférences reçues, y compris celles qui risquent de provoquer un
fonctionnement indésirable.
Note: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this product does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Please take attention that changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts
de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
VSSL A.1x HOME 17
Loading...
