VOZ NV-W044 User Manual

第 - 1 - 页 共 12 页

USER MANUAL

TWS Wireless earphone

第 - 2 - 页 共 12 页

Product Parameters：

Product model

TWS Wireless earphone

version

CW6693D, V5.0+EDR

Talk time

about 3 hours

Music time

about 3 hours

Headphone tip language

English

Transmission distance

10m

Headphone charging time

about 1 hours

Charging time of charging box

about 4 hours

Single headphone weight

4.8g

Charging box weight

36.1g

Headphone battery capacity

50mAH

第 - 3 - 页 共 12 页

Charging box battery capacity

500mAH

Headphone battery model

581013+PCB board

Charging box battery model

902030+PCB board

Battery type

Polymer lithium battery
Guarantee

1 Year

Function description：

Charging contact

Switch/Power

button

microphone

LED indicator

第 - 4 - 页 共 12 页

Charging:

(1) Headphone charging. The charging box has a built-in battery.

When the charging box is fully charged, the earphone is placed in
the charging box, and the earphone can be charged. When the
earphone is in the charging state, the red light is always on, the blue

Horn

Micro USB charging

Charging box indicator
