Vortex Razor HD 4000 User Manual

RAZOR® HD 4000 SPECIFICATIONS

DEER RANGE TREE RANGE REFLECTIVE RANGE

1,60 0 yd.
(1,463 m)

2,000 yd.
(1,829 m)

2,200 yd.
(2,012 m)

NORMAL MODE

NORMAL MODE
(SCAN)

ELR MODE

*Expected ranges given favorable environmental conditions

Minimum Range: 5 yd. (4 m)
Accuracy: ± 0.5 yards at 5-199.9 yards

± 1 yards at 200 -1,000 yards
± 2 yards at over 1,000 yards

Maximum Angle Reading: ± 70 de gree s
Measuring Time: < .25 seconds (Normal Mode)
Battery Life: > 4,000 range cycles
Operating Temperature: -4° to 140° F (-20° to 60° C)
Storage Temperature: -13° to 140° F (-25° to 60° C)
Magnification: 7x
Objective Lens: 25 mm
Eye Relief: 16-19 mm
Diopter: ± 2
Brightness Settings: 5
Battery: CR2
Weight: 9.9 oz.
Length: 114mm
Width: 34mm

1,800 y d.
(1,646 m)

2,200 yd.
(2,012 m)

2,500 yd.
(2,28 6 m)

*Cold weather may reduce battery performance

2,400 yd.
(2,19 4 m)

2,400 yd.
(2,19 4 m)

4,000 yd.
(3,658 m)

RAZOR® HD 4000 LASER RANGEFINDER

The Razor® HD 4000 is the essential companion for the
extreme hunter, archer and shooter. The extremely effective
angle compensated laser rangefinder features four targeting
modes (Normal Mode, First Mode, Last Mode and Extended
Laser Range Mode) for any ranging environment. The
primary HCD (Horizontal Component Distance) range mode
provides key angle compensated range information required
by the vast majority of shooters in a simple, quick to read
display. The Razor HD 4000 also has a LOS (Line of Sight)
range mode and scan feature.

Images are fo r representation only. Product may var y slightly from what is shown.

3 2

Diopter Fo cus

Adjust able
Eyec up

Lanyard
Attachment
Sockets

Measure But ton

Battery Compartment

Menu Button

Utility Clip

BASIC OPERATION

Battery Replacement

To insert a new battery, open the
battery compartment and remove
the used battery. Insert new CR2
battery with positive side facing
outwards. Once installed, reinstall
battery compartment cover and
ensure it is tightly closed.

Power Up

Once the battery is installed,
the Razor® HD 4000 is in ready
condition – the normal power-off
condition when not ranging. To
power up the Razor HD 4000
from ready condition and prepare
for ranging, press and release the
Measure button. The HCD or LOS
ranging screen will display. The
Razor HD 4000 will power down
automatically after 20 seconds of
non-use.

5 4

Remove batte ry
compartment cover.

Install batter y with positive
side facing outwards.

Adjust the Eyecup

The eyecup on the Razor® HD 4000 twists up and down
so any viewer can see the full field and enjoy comfortable
viewing and ranging – with or without eyeglasses. When not
using eyeglasses or sunglasses, it is recommended to keep
the eyecup fully extended. For best viewing when wearing
eyeglasses, twist eyecups down.

Focus

Adjust the diopter until the image is sharp. Make note of this
diopter setting in case you need to set it again.

Low Battery Icon

The low battery icon displays once the
battery reaches 25% life and stays on
until there is no power.

Batter y Power Indicator

MODE SELECTION

The Razor® HD 4000 is factory set to the angle compensating
HCD range mode, normal target mode, brightness level 4 and
displayed in yards.

To change modes:

After the Razor HD
4000 is powered up,
activate the Mode/Display
Selection by pressing and
holding the Menu button
for at least four seconds.

Use the Menu button to activate the Mode Selection
displays. Use the Measure button to toggle through each
Mode Selection option. You may exit Mode Selection at any
time and save your settings by pressing and holding the
Menu button for at least four seconds.

7 6

Use the Menu button to
activate the Mode/Display
Selection displays.

Use the Measur e
button to tog gle
through each Mo de
Selection option.
