Vortex Razor HD Quick Manual

Ocular Lens

The eyecups on a Razor HD binocular twist up and down so any

viewer can see the full field and enjoy comfortable viewing—with

or without eyeglasses.

When not using eyeglasses or
sunglasses, keep the eyecups fully
extended. For the best viewing
when viewing through eyeglasses,
twist eyecups down.

Adjust the interpupillary distance

The interpupillary distance (IPD) is the distance between the centers

of the left and right eye pupils. Match the IPD of your eyes to that of

the binocular so that you see a single image that is free of shading.

BASIC OPERATION

Adjust the eyecups

Twist-up Eyecup

Strap
Attachment

Center Focus

Locking
Diopter
