Vortex HRC-5007, HRC-5009 User manual

Vortex puts optimal low-light performance in your hands with the

rugged Hurricane Porro prism binocular.

Ocular Lens

Fold-Down
Eyecup

Left Eye
Focus

Tripod Adapter
Socket

Objective Lens

Right Eye
Focus

Customizing the hurri Cane

Adjust the eyecups

The soft, rubber eyecups on a Hurricane binocular provide comfort,

folding up and down for viewing with or without eyeglasses.

For the best viewing
through eyeglasses, fold
the eyecups down. When
not using eyeglasses or
sunglasses, keep the
eyecups fully extended.

Adjust the interpupillary distance

The interpupillary distance (IPD) is the distance between the centers of

the left and right eye pupils. Match the IPD of your eyes to that of the

binocular so that you see a single image that is free of shading.

IPD

IPD is the distance between the
centers of the ocular lenses.

Rotate the binocular barrels
inward or outward to line your
eyes up with the ocular lenses.
