Voptech VI2006 and Elastix Server

Setup Guide

PaloSanto Solutions

Voptech VI2006 and Elastix Server Setup Guide

2

1.0 Setup Diagram

Figure 1-1 is a setup diagram for a single IP Phone Voptech VI2006 configuration. The

phone is setup as a SIP telephony device.

Figure 1-1. Setup Diagram

2.0 Host PC Environment

Table 2-1. Host Server Environment Details

Description

Hardware Type

Elastix Appliance ELX-Series

Hardware Version

ELX-3000

Software Type

Elastix

Software Version

2.3

3.0 Test Setup Equipment

Table 3-1. Test Setup Equipment

Equipment

Model

Version

IP (SIP) Phone

N/A

N/A

Voptech IP Phone

VI2006

1.7.130.93

Switch

N/A

N/A

PaloSanto Solutions

Voptech VI2006 and Elastix Server Setup Guide

3

4.0 Setup Procedure

To set up the Elastix Server for the Voptech VI2006,

1. Go to the web address of the Elastix Server Login page. The web address is

determined by the customer, for this guide we have used the IP address

192.168.1.75

2. On the Login page, type the username and password for an administrative user into

the Username and Password fields, see Figure 4-1. The username and password are
determined by the customer.

Figure 4-1. Login

3. Press Enter or click on the Submit button to go to Elastix‟s Dashboard

4. Once inside, click on the PBX tab on the menu at the top of the screen

Figure 4-2. Dashboard
