80tc
Specification:
Size: 22*38*82mm
Output Mode: VV/VW/TC Mode
Output Wattage: 7-80W
Resistance Range during VV/VW mode: 0.2-3.0 OHM
Resistance Range during TC mode: 0.15-1.0 OHM
Temperature Range: 100-315°C, 200-600°F
Applicable Coil wire under TC mode: Stainless steel wire,
Ni-200 wire, Ti wire
HOW TO USE:
1. How to turn off the device
Slide down the magnetic back cover and place the 18650 battery in to the
mod. Be sure to follow the diagram inside the body for correct battery
orientation. The + side should be at the top when installing your 18650
battery. Once the battery is installed the screen will turn on and show
“OFF-CLICK 3X ON” press the fire button 3 times in succession to turn the
device on.The screen will show the EVOLVE logo and then to the main
device interface.
2. How to turn off the device
Press the fire button 3 times in succession to turn the device off. The screen
will show “GOODBYE” to let you know it has been turned off properly.
3. How to select TC/VW modes:
While the device is on, thread your tank system to the device. The screen will
light up and show “SELCOIL” as well as the coil resistance below it. Use the
+ or – buttons at the bottom of the device to move through the different
selections. There are 5 different settings to choose from:
· PREV – which can be used if you have already used that coil on the
device
· NI – If you are using an Ni200 coil
· TI – if you are using a Titanium coil
· SS – If you are using a Stainless Steel coil (316L recommended)
· W – If you are using a Kanthal coil (such as the supplied VTPC coil)
or SS coils
Once selected the screen will show the main interface displaying the
present output wattage, voltage and resistance or the present
temperature, wattage and resistance. In order to change the wattage
hold the + or – button until the wattage starts to blink and then move up
or down accordingly. In order to change the temperature hold the + or –
button until the temperature starts to blink and then move up or down
accordingly. To select between wattage and temperature while in TC
mode hold the + or – button until the temperature starts to blink then
press the fire button in order to switch between temperature and wattage
selections. In order to go back to the coil selection screen press and
hold both + and – simultaneously.
Malfunction Indication and Protection
Over 10 second protection:
When the power button is pressed for 10 seconds, the output will shut
off and the OLED screen will display “Over 10s protection”
Low Power Alert:
When the voltage of the battery is lower than 3.3v before using the
device, or under 2.8v during use of the device, the OLED screen will
display ”Battery Low” and cannot function. Please recharge the battery
to reactivate.
Temperature Alert:
If the temperature of the device is over 185 degrees, the output will shut
off automatically and the screen will display “Device Too Hot”.
Maintenance of the product:
To ensure best usage of the device:
• Regularly clean the 510 threading with a Q-Tip or an absorbent
paper to remove any dirt or liquids.
• Remove the drip tip regularly to clean any excess liquid build up.
• Always ensure the battery compartment is clean, dry and free of any
liquid build up.
Warranty Terms
The Voodoo Evolve 80TC kit is guaranteed from factory defects for 90
days from the date of purchase. We will not guarantee products that
have been damaged due to neglect or improper use. This product is only
intended for use with the provided usb charger and Voodoo Evolve
accessories.
***Due the hygienic nature of the products, the warranty does not cover
heating elements such as coils, cotton or coil housings.
All warranty claims must be accompanied by a copy of the original
receipt.
Warranty claims must be submitted online through voodoovape.com
CUSTOMER CARE
For more information on our products or to keep up to date on our latest
news, please visit us at VoodooVape.com
WARNING: This product has not yet been approved by the FDA. This
product is not intended to diagnose, treat, prevent, cure or mitigate any
disease or medical condition or offer any therapeutic benefit.
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
Voodoo reserves the right of final decision in all warranty cases.
Voodoo may interpret and revise the content of the warranty terms.
WARNING
1. Keep out of the reach of children
2. This product is not recommended for use by anyone under the
age of 21
3. This product is not suitable for use by children, pregnant or
breastfeeding woman and people who have allergies/sensitivity
to nicotine.
