PRINTING METRIC IMPERIAL
Minimum Trace Width 0.2mm 8mil
Minimum Passive Size 1005 0402
Minimum Pin-to-Pin Pitch 0.65mm 26mil
Resistivity 12mΩ/Sq @ 70um Height 12mΩ/Sq @ 3mil Height
Supplied Substrate Material FR4 FR4
Maximum Board Thickness 3mm 0.125"
SOLDERING
Minimum Passive Size 1005 0402
Minimum Pin-to-Pin Pitch 0.5mm 20mil
Solder Paste Alloy Sn42/Bi57.6/Ag0.4 Sn42/Bi57.6/Ag0.4
Solder Wire Alloy SnBiAg1 SnBiAg1
Soldering Iron Temperature 180-200°C 355-390°F
The Voltera V-One Spec
DRILLING
Spindle Speed (Max.) 13,000 RPM 13,000 RPM
Power 12V, 25W 12V, 25W
Runout (TIR) 0.076mm 0.003"
Shank Diameter 3.175mm 1/8"
Supplied Substrate Material FR1 FR1
Bit Diameter (Max.) 2mm 0.078"
Bit Length (Max.) 38.1mm 1.5"
SOLDER COMPATIBILITY Sn42/Bi57.6/Ag0.4 Solder Sn63/Pb37 Solder
Standard Ink
Flexible Ink
METRIC IMPERIAL
✓
✓
✗
✗
FOOTPRINT AND PRINT BED
Dimensions (L × W × H) 390mm × 257mm × 207mm 15.4" × 10.1" × 8.2"
Weight 7kg 15.4lbs
Print Area 128mm × 116mm 5" × 4.5"
Max. Heated Bed Temperature 240°C 464°F
Design your circuit and export a Gerber le
Load your design into the V-One software
Copper PCBs
HASL PCBs
✗
SOFTWARE REQUIREMENTS
Operating Systems Windows 7, 8, 10 (64bit), OSX 10.11+
Compatible File Format Gerber
Connection Type Wired USB 2.0
✓✓
✓
Drill, print, solder and reow your board
Test your prototype, iterate and repeat.
