Voltage Valet VCSP User Manual

Converts Foreign Electriticity to North American Standard

Use the Voltage Valet™ 50/2000 Watt Voltage Converter to safely operate your 110-120 volt North American personal appliances while traveling in foreign countries
that use 220-240 volt electricity. Select the 50 watt transformer setting for small electronic and motorized appliances rated up

to a maxim
the 2000 watt solid state converter setting for NON-ELECTRONIC heating appliances rated up to a maximum of 2000 watts. The International Adaptor Plug Set
(adaptors A, B, C, D) included with model VCSP, modifies electrical outlets to allow use of the converter in most countries. See reverse side for country list.

u

m of 50 watts and

How to Use the Voltage Valet™
50/2000 Watt Voltage Converter

Use with NON-ELECTRONIC heating appliances** rated up to 2000 watts MAXIMUM such as:
Clothes Steamers

Coffee Makers
Electric Blankets
Electric Curlers

Food/Bottle Warmers
Hair Dryers
Heating Pads
Immersion Heaters

Irons
Incandescent Lamps

DUTY CYCLE AT 2000 WATTS: MAXIMUM ON 10 MINUTES, MINIMUM OFF 60 MINUTES
**IMPORTANT: Electronically controlled coffee makers, electric blankets, curling irons, hair

straighteners, irons, etc., that use digital timing/temperature circuits or have auto-start/auto-

Use with motorized and electronic appliances rated up to 50 watts MAXIMUM* such as:

Battery Chargers
Camcorders
CD/MP3/DVD Players
Cell Phones
Contact Lens Sterilizers

Digital Cameras

Shavers

Electric

ral Hygiene Devices

O
Radios
Sound Machines

*IMPORTANT: Electronic and motorized appliances rated OVER 50 watts may be damaged if used
with the converter.

shutoff features may be damaged if used on the 2000 watt setting.

CAUTION: The Voltage Valet™ 50/2000 Watt Voltage Converter should never be used with clocks, computers, television sets, high fidelity equipment, typewriters, hooded
hair dryers, projectors, kitchen appliances or any permanently installed electrical equipment. The converter IS NOT DESIGNED FOR CONTINUOUS USE.

Important - Please read...

• Before using your Voltage Valet™ converter, check

to see if the electrical outlet is 110-120 volts
or 220-240 volts. Your converter will not work
in a 110-120 volt outlet, and both it and your
appliance may be seriously damaged or ruined if
used incorrectly.

• All Voltage Valet™ converters are equipped with

an internal shut-off and reset system. When it
becomes overworked it will automatically shut
itself off. Should this occur, remove the converter
from the outlet and allow a short period for it
to cool down and reset itself.

• Some motorized appliances may operate a bit

slower when used in foreign countries. This is
normal and will not harm your appliances.

• At times there may be a low humming sound in

the converter – this is normal.

• Remove your Voltage Valet™ converter from the

wall outlet when not in use.

We guarantee each new converter to be free from defects
in material or workmanship and to perform under normal
use and service. This guarantee shall run for a period of
one year from the date of purchase, and obligations under
this guarantee are limited to remedying any defect or
replacing any defective part
if
after purchase. Damage due to abuse or misuse is not
covered by this guarantee. We shall not be responsible for
any other loss or damage that may arise through the use
by a purchaser or others of this device, and the purchaser
assumes such responsibility and will hold Hybrinetics, Inc.
harmless in respect to all such loss or damage.

Important: This is a factory direct
warranty, valid in North America only.
Do not return defectives to your retailer.
All defectives must be returned to the
factory accompanied by a sales receipt
with the original date of purchase. For
more information please call our toll free
number: [phone].

the defective unit is returned to us within 12 months

and shall be effective only

Support Bracket

To help support the converter when using with an
adaptor plug: Slide the support bracket out from
the converter body until it stops. Pinch the tips of
the support bracket together and pull out to the
desired length. To return the support bracket inside
the converter body, pinch the bracket tips together
and push in until the support bracket is flush with
the converter body.

Support bracket
slides out from body

Voltage Valet Division

Hybrinetics, Inc.

225 Sutton Place

Santa Rosa, CA 95407

E-mail: hybrinet

Web Site: www.voltagevalet.com

@voltagevalet.com

©2006 HYBRINETICS, INC.

Adaptor Plugs

Electrical wall outlets around the world differ in
shape, assortment, and arrangement of outlet holes.
The most common outlet requires two round pins
(Continental Europe type). These round pins have
been designed into all Voltage Valet™ converters.
Many countries, however, use other types of outlets
that require an adaptor plug. Voltage Valet™ offers
five different adaptor plugs for use with voltage
converters and dual voltage appliances.

A

No., So. & Central
America

B

Continental
Europe

C

Australia
New Zealand
& China

IMPORTANT NOTE: Adaptor plugs DO NOT
convert voltage. They only enable you
to plug your converter or dual voltage
appliance into a foreign wall outlet.

D

E

F

Great Britain/
Hong Kong

India &
South Africa

India &
Middle East

READ ALL INSTRUCTIONS.

1. Check the wattage rating on your appliances.

2. If using appliances rated up to 50 watts maximum (electronic, motorized or heating) set the
wattage selector to 50; if using NON-ELECTRONIC heating appliances rated from 50 watts up
to 2000 watts maximum set the wattage selector switch to 2000.

3. Insert your 110-120 volt appliance plug into the converter (be sure appliance is turned off).

4. Plug the converter into the 220-240 volt foreign wall outlet. If an adaptor plug is needed
(see section on adaptor plugs) select the appropriate adaptor, snap it onto the converter’s two

nd pins and then plug into the wall outlet.

rou

Country List

s a list of popularly traveled countries and the Voltage

Below i
V

alet™ adaptor plug(s) required for each. Check the list to
determine which adaptor plug(s), if any, you need to operate your
voltage converter or dual voltage appliance. It is recommended
that you carry all of the adaptor plugs listed for each country.

NOTE: Some countries in Continental Europe have recessed
electrical outlets. Use the ‘B’ adaptor plug with your
voltage converter to fit into these recessed outlets.

Afghanistan B,F
Algeria B,F
Argentina B,C
Australia C
Austria B
Bahamas A
Belgium B
Bolivia A,B
Brazil A,B
Burma B,D,F
Canada A
Chile B
China B,C,D
Colombia A
Congo, D. Rep B,F
Costa Rica A
Czech Rep. B
Denmark B
Ecuador A
Egypt B
England D,E
Ethiopia B,F
Fiji C
Finland B
France B

Germany B
Greece B
Guatemala A
Hong Kong D,E
Hungary B
India E,F
Indonesia B
Ireland D,E
Israel B
Italy B
Japan A
Jordan B,D,F
Kenya B,D,F
Korea A,B
Kuwait B,D,F
Lebanon B,F
Luxembourg B
Malaysia D
Mexico A
Morocco B,F
Nepal B,F
Netherlands B
New Zealand C
Nigeria D,F
Norway B

Pakistan B,F
Paraguay B
Peru A,B
Philippines A,B
Poland B
Portugal B
Romania B
Russia B
Saudi Arabia A,B,D
Scotland D,E
Singapore B,D,F
South Africa E
Spain B
Sri Lanka B,F
Sweden B
Switzerland B
Tahiti A,B
Taiwan A
Tanzania D,F
Thailand A,B
Turkey B
Ukraine B
U. Arab Emirates D,F
Uruguay B
Venezuela A
Vietnam A,B

Instructions

50/2000 Watt

Voltage Converter

Model VCSB & VCSP
