Please keep both cover flaps open and cross reference
pictures with text where necessary.
Tools for your Elyps
A
Dust bags
B
Extension tubes (x2)
C
Telescopic tube (some models)
D
Swivel hose and handle with manual suction control
E
Combination carpet/hard floor nozzle
G
Narrow crevice nozzle
H
Upholstery nozzle
I
Dusting brush (some models)
J
Small tool holder
K
Large tool holder (some models)
Ensuring your safety
The Elyps is for domestic use only and has been designed
to ensure maximum safety and performance. Please follow
these simple precautions:
L
The Elyps is double-insulated so it must not
be earthed
M
The Elyps is only to be used by adults.
N
Always store in a dry place
O
Do not use to pick up liquids
P
Avoid sharp objects
Q
Do not pick up hot cinders or lighted cigarette ends
R
Do not use near flammable gases
S
Avoid tugging on the mains cable and check cable
regularly for damage
T
Note: Do not use your cleaner with a damaged
cable. If damaged the cable should be replaced
at an authorized Service Centre
U
The Plug must be removed from the socket-outlet
before cleaning or maintaining the appliance
W
All service and repairs must be carried out by
authorised service staff
Getting Started
•
Check the dust bag is in place.
•
Insert the hose until the catches click to engage.
(Press catches inwards to release).
•
Attach tubes or telescopic tube to the hose handle and
floor nozzle by pushing and twisting together.
(Pull apart to dismantle).
•
Extend the cable and connect to mains. The Elyps is
fitted with cable rewind, ensure cable is not twisted
before use. (Press foot pedal to rewind.
Note: Please
hold the plug to prevent it striking you or the
machine
).
•
Press the On/Off foot pedal to activate the cleaner.
•
To reduce suction, gradually open the aperture on the
hose handle. For some models slide the electronic
suction control between ‘MAX’ and ‘MIN’. press the ‘-/+’
foot pedal. The selected suction will be displayed by the
indicator lights on these two models.
Your Elyps features
AXMains cable
B
Y
Cable rewind pedal
C
c
Power outlet (for the use of power driven tools)
(some modells)
D
t
Electronic suction controll (some models)
E
d
Mechanical dust bag indicator
F
e
Hose connection
G
f
Dust bag security device – prevents lid closing
without a dust bag in place
H
g
Carrying handle
I
h
Cover release catch for dust bag compartment
J
i
On/off switch
K
j
Storage slot for floor nozzle and extension tubes
when in use
L
k
Storage slot for floor nozzle and extension tubes
when not in use
M
J
Tool holder (for attachment to hose handle or
extension tube) with slot for wall mounting
N
K
Tool holder (for attachment to hose handle)
(some models)
